Built-in Combi Refrigerator
AB320
Installation & User Instructions –
Please keep for future reference
– Please read these instructions fully before installing or using
Important
These instructions contain important information that will help you get the best from your
appliance, ensuring safe and correct installation, use and maintenance.
If you need help or have damaged or missing parts, call the Customer Helpline on 0845 600 4632
Issue 1 - 08/06/10
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Bush AB320
Summary of Contents for Bush AB320
- Page 1 Built-in Combi Refrigerator AB320 Installation & User Instructions – Please keep for future reference – Please read these instructions fully before installing or using Important These instructions contain important information that will help you get the best from your appliance, ensuring safe and correct installation, use and maintenance.
-
Page 2: Table Of Contents
Refrigerator compartment Freezer compartment Cleaning and Maintenance Cleaning Replacing the refrigerator light bulb Defrosting the freezer compartment Shipment and Repositioning Trouble Shooting Technical Specifi cations Disposal Information Tips for Energy Saving Guarantee Product code AB320 Customer Helpline 0845 600 4632... -
Page 3: Presentation And Description Of The Product
Presentation and Description of Product This presentation is only for A. Display panel I. Egg shelf information concerning the B. Refrigerator shelf J. Refrigerator lamp & cover parts of the appliance. Parts may vary according to the C. Crisper shelf K. -
Page 4: Safety Information
Safety Information IMPORTANT - Please read this booklet before WARNING - Do not eat ice that has just been installing and switching on this appliance. The removed from the freezer. manufacturer assumes no responsibility for incorrect WARNING - This appliance is not intended for use installation and usage as described in this booklet. -
Page 5: Before Using The Appliance
Before Using the Appliance Recommendations • Insert the plug into a socket with an effi cient ground connection. If the socket has no ground contact or the plug does not match, we suggest you to call an • Before installation, read the instructions authorised electrician for assistance. -
Page 6: Parts
Parts Please check you have all of the parts listed below Trim fl ap Trim gasket Guide D. Rail 17mm Screw 9.5mm Screw Tools required Philips screwdriver Customer Helpline 0845 600 4632... -
Page 7: Installation
Installation Dimensions for installation a: Check the installation dimensions according to (1). The position of the joint between the kitchen unit doors must be level with the position of the joint between the appliance doors.this booklet. • There can be an odour when you fi rst switch on the appliance. -
Page 8: Routing The Power Cord
Installation Installation Routing the power cord a: Pass the power cord through the ventilation shaft, as shown in (3), and position it so that the appliance can be easily plugged in once it has been installed. Installing the gasket a: Take out the trim gasket (B) located on the side of the appliance and stick it on the appliance on the opposite side to the door hinges. -
Page 9: Position The Appliance
Installation Installation Position the appliance Caution: Two people are required to handle the appliance. It is recommended that gloves are worn. a: Carefully move the appliance into position into the kitchen unit. b: Push the appliance back to the reverse side of the door hinges, and make sure that the trim gasket (B) covers the space between the appliance and the kitchen unit. -
Page 10: Installing The Doors
Installation Installation b: Secure the fi xing bracket (G) to the kitchen unit using screws (E), as shown in (7). Repeat for the opposite side Installing the doors a: Secure the guides (C) to the appliance doors using screws (E), as shown in (8). b: Open the appliance doors to right angles and position the unit door against the appliance door. -
Page 11: Reversing The Doors
Installation Reversing the doors a: Unscrew the upper door hinge (L) and move the upper door (K) to a safe location. b: Unscrew the door hinge pin (M) and fi rmly screw it into the opposite side. Keep in a safe location. c: Unscrew the middle door hinge (H) and move the lower door (Q) to a safe location. -
Page 12: User Instructions
User Instructions Combi models with single compressor Thermostat knob Super freeze Power Alarm Alarm Thermostat setting Display panel The freezer and refrigerator thermostats Super Freeze Light (SF Light): Lights orange when automatically regulate the inside temperature of the the SF button is turned on. compartments. -
Page 13: Super Freeze And Low Ambient Switch
User Instructions Accessories Super freeze and low ambient switch Ice tray (In some models) • Fill the ice tray with water and place in the freezer compartment. • After the water has completely turned into ice, twist the tray to get the ice cubes out. Bottle holder •... -
Page 14: Refrigerator Compartment
User Instructions Refrigerator compartment • The maximum amount of fresh foods that can be loaded in the freezer within 24 hours is indicated The refrigerator compartment is used for storing on the name plate (see Freezing Capacity). fresh food for a few days. •... -
Page 15: Cleaning And Maintenance
Cleaning and Maintenance Cleaning Butter shelf cover WARNING: Disconnect the appliance from the power supply before cleaning. • Do not pour water over the appliance. • Clean the accessories separately with soap and water. Do not put them in the dishwasher. •... -
Page 16: Defrosting The Freezer Compartment
Cleaning and Maintenance Defrosting the freezer compartment WARNING: Plastic scraper is provided for scraping ice in defrost process. Do not use sharp metal objects for this operation. They could puncture the refrigerator circuit and cause irreparable damage to the unit. Ice scraper To maintain the effi... -
Page 17: Shipment And Repositioning
Shipment and Repositioning • Original packaging and foam may be kept for re-transportation (optional). • You should fasten your fridge with thick packaging, bands or strong cords and follow the re-transportation instructions on the packaging. • To protect the appliance during repositioning and/or transportation, remove movable parts (shelves, accessories, vegetable bins, etc.) or fi... -
Page 18: Trouble Shooting
Trouble Shooting If your refrigerator is not working properly there may • If you will not be using your refrigerator for a be a minor problem, therefore check the following. long period (holiday etc.), disconnect the plug from the socket. Clean your refrigerator as per If the appliance does not operate, check if;... -
Page 19: Technical Specifi Cations
Technical specifi cations Model/Item AB320 Supplier’s name or trademark BUSH Supplier’s model AB320 Type of appliance BGSN3200S The energy effi ciency class Voltage 220-240V/50HZ Power 0,8A Energy consumption 0,86kwh/24h Net storage volume of fresh food 189 lt. Net storage volume of frozen food 75 lt. -
Page 20: Tips For Energy Saving
Tips for Saving Energy 1. Install the appliance in a cool, well-ventilated room, but not in direct sunlight and not near a heat source (radiator, cooker etc.). Otherwise, use an insulating plate. 2. Allow food and drink to cool down outside of the appliance. -
Page 21: Guarantee
Guarantee Product guarantee This product is guaranteed against manufacturing defects for a period of Year This product is guaranteed for twelve months from the date of original purchase. During this period, any defect that arises due to faulty materials or workmanship will be replaced, refunded or repaired free of charge where applicable by the dealer from whom the unit was purchased.
