Tech 21 SansAmp Acoustic DI Owner's Manual

Tech 21 SansAmp Acoustic DI Owner's Manual

Tech 21 acoustic guitar amplifier owner's manual

Advertisement

Quick Links

POWER REQUIREMENTS
*
Operable with phantom power supply, minimum 24V DC, however, 48V DC,
is recommended.
*
Utilizes standard 9V alkaline battery (not included). NOTE:The Input jack
activates battery.To conserve energy, unplug when not in use.
Power Consumption: approx. 7mA.
*USE DC POWER SUPPLY ONLY!
unit and void warranty. DC Power Supply Specifications:
-9V DC regulated or unregulated, 100mA minimum;
-2.1mm female plug, center negative (-).
Optional factory power supply is available:Tech 21 Model
WARNINGS:
* Attempting to repair unit is not recommended and may void warranty.
* Missing or altered serial numbers automatically void warranty. For your own
protection: be sure serial number labels on the unit's back plate and exterior
box are intact, and return your warranty registration card.
ONE YEAR LIMITED WARRANTY. PROOF OF PURCHASE
REQUIRED. Manufacturer warrants unit to be free from defects in materials
and workmanship for one (1) year from date of purchase.This warranty does
not include damage resulting from accident, misuse, abuse, alteration, or incor-
rect current or voltage. If unit becomes defective within warranty period,Tech
21 will elect to repair or replace it free of charge. After warranty expires,Tech
21 will repair defective unit for a fee.
ALL REPAIRS for residents of U.S. and Canada: Call Tech 21 for Return
Authorization Number. Manufacturer will not accept packages without
prior authorization, pre-paid freight (UPS preferred) and proper insurance.
FOR PERSONAL ASSISTANCE & SERVICE:
Contact Tech 21, Inc., any weekday from 10:00 AM to 6:00 PM, EST.
MADE IN THE U.S.A.
T E C H 2 1 . N Y C
333 West 52nd Street, NY, New York 10019
212-315-1116 / Fax: 212-315-0825 / www.tech21nyc.com
Failure to do so may damage the
#
DC2.

Advertisement

loading
Need help?

Need help?

Do you have a question about the SansAmp Acoustic DI and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Tech 21 SansAmp Acoustic DI

  • Page 1 21 will elect to repair or replace it free of charge. After warranty expires,Tech 21 will repair defective unit for a fee. ALL REPAIRS for residents of U.S. and Canada: Call Tech 21 for Return Authorization Number. Manufacturer will not accept packages without prior authorization, pre-paid freight (UPS preferred) and proper insurance.
  • Page 2: Product Overview

    If a power amp input is not available, use the cleanest channel with the amp’s EQ flat and maximum headroom. For best results, keep the Level control of SansAmp Acoustic DI close to unity gain so as not to overload the amp’s input (which could yield undesirable distortion).
  • Page 3 OUTPUT ACTIVE SWITCH: To avoid unwanted and their settings. Inactive, LED will be off and SansAmp Acoustic DI is in bypass mode. It then functions as a transparent direct box and will not sonically alter the instrument signal. -20dB PAD: -20dB.
  • Page 4 LEVEL Adjusts the output level. TUBE/MIC EMULATION Tube/Microphone Emulation is an integral part of the SansAmp Acoustic DI’s circuitry.The tube emulation yields a warm, gentle saturation to limit dynamic peaks, while the microphone emulation removes the unnatural harmonics associated with piezo pickups. It is specifically engineered to yield a smooth, even response as would be achieved by a properly miked acoustic guitar.
  • Page 5: Sample Settings

    SAMPLE SETTINGS (for acoustic guitars) FOLK COUNTRY FINGER PICKING JAZZ NOTE: Sample settings are provided as a starting point. As acoustic guitar designs vary greatly, controls may have to be adjusted accordingly. SAMPLE SETTINGS (other) BASS GUITAR BASS GUITAR (hard driven) ELECTRIC GUITAR (semi dirty) SPEAKER/MIC...
  • Page 6: Custom Settings

    CUSTOM SETTINGS CUSTOM SETTINGS...
