Main Features
5.1ch Discrete Amplifier
Dolby Digital, Dolby Pro-Logic II
DTS Digital Surround
AM/FM Stereo Tuner
30 Preset Station Memory
DSP Surround
Tone Control
Fluorescent Display with Dimmer
Sleep Timer, Night Mode
Dual Voltage
Full Function Remote Control
GND
FM 75
AM
ANTENNA
HDMI 1
MONITOR
IN
OUT
HDMI
Design and specifications are subject to change without notice.
Rev. 0 JAN15-09
(Movie, Music)
(Hall, Jazz, Rock, 5-stereo)
(Bass, Treble)
(120V 60Hz, 230V 50Hz)
L
R
TAPE
TAPE
VCR
VCR
VIDEO1
VIDEO2
MONITOR
OPTICAL
HDMI 2
IN
OUT
IN
OUT
IN
IN
OUT
IN
IN
AUDIO
VIDEO
MONITOR
DIGITAL AUDIO
SURROUND CENTER
FRONT
SR
SL
C
R
L
PREOUT
SUBWOOFER
SPEAKERS (6
MIN)
General Specifications
Output Power: 120W x 5
Signal-to-Noise Ratio: 90dB
Frequency Response: 20Hz-60kHz
Audio Input: x 4
Audio Output: x 2
Subwoofer Preout: x 1
Digital Audio Input: x 2
HDMI In: x 2
HDMI Out: x 1
Component Video Input: x 2
Component Video Output: x 1
Composite Video Input: x 3
Composite Video Output: x 2
Headphone Jack: x 1
Speaker Terminals: x 5 pairs
Operation: 120/230V AC, 50/60Hz Switchable
Dimension
Weight: 20.8 lbs, 9.4kg
AC IN
Y
Pb/
Cb
Pr/
Cr
COAX
VIDEO1
VIDEO2
MONITOR
IN
IN
IN
OUT
COMPONENT VIDEO
CAUTION
VOLTAGE SELECTOR
230V
120V
AG-D2000
5.1ch SURROUND RECEIVER
(1ch driven, 6 ohms, 1kHz, 10% THD)
65Wx 2
(2ch driven, 6 ohms, 1kHz, 0.9% THD)
(Line, IHF-A)
(Line, +1/-3dB)
x 1
(RCA),
(Front, Stereo Mini)
(RCA)
(RCA)
(Optical x 1, Coaxial x 1)
(RCA)
(RCA)
(RCA)
(RCA)
(Stereo)
(Clip-type)
: 16-
1
/
" x 5-
3
/
" x 11-
(W x H x D)
2
8
420 x 135 x 295mm
TEAC CORPORATION, JAN. 2009
(US/Export)
5
/
"
