- Page 1 User's manual ... Page 2 Guide de l'utilisateur ... page 18 Manual de usuario ... Pagina 34...
- Page 2 1. General Thank you for buying the TEAC Mini CD/MP3 Player, the new standard in portable compressed audio players! Please read the operating instructions care- fully before starting to use your player. Please note that the TEAC MP3 Player plays Mini CDs only (Mini CDs have a diameter of 8cm, in comparison with the regular CDs which have a diameter of 12cm).
- Page 3 2. Operating Instructions Power The player can be powered either by 2 AA-size alkaline batteries or by the AC adapter. Inserting Batteries Remove the battery cover on the back of the player by sliding it in the direction indicated by the arrow on the battery-cover.
- Page 4 Front Panel 1 Stop/Off ( ) 2 Previous ( ) 3 Play/On/Pause ( 4 Next ( ) figure 2 5 Equalizer 6 Repeat 7 Intro 8 Program...
- Page 5 Side Panel 9 Power supply in 10 Headphone in + Line out figure 3 figure 4 11 Open player cover 14 Volume control 12 Hold 13 Bass boost...
- Page 6 Connecting the AC adapter Insert the 120VAC AC adapter into the appropriate socket (9 figure 3). Insert the power plug into the main outlet. Getting Started Open the cover by sliding the "Open" switch (11 figure 3). Insert a MiniCD into the player, with the disc label facing up.
- Page 7 Play/Pause/Resume (3) Press Play " " (3 figure 2) to start playing music. If this button is pressed during playing, the player will go into "Pause" mode. To resume play, press " " (3 figure 2) once again. play mode pause mode Please note that when playing a MP3 CD, the songs will be played in the file names’...
- Page 8 Program (8) The TEAC MP3 Player has a memory for program ming up to 20 songs. To start the "program" function, press the Program button (8 figure 2). The memory-ID starts from "01". The song ID starts from title 1 and track 00 if the memory is empty.
- Page 9 If the player is in Program mode, the Repeat function will only repeat the memorized songs. Equalizer (5) The TEAC MP3 Player has 4 equalizer modes: Normal/Jazz/Rock/Classic. Press the EQ button (5 figure 2) to change the EQ mode; default setting by power on is "normal".
- Page 10 Opening the cover will stop any action, but the power will remain on. The LCD-display shows "OPEN". Volume (14) The TEAC MP3 Player has a rotary volume controller; turning the volume-wheel clockwise will increase the volume; turning the wheel anti-clockwise will de- crease the volume.
- Page 11 WARNING! When using headphones Avoid damaging your hearing: do not play your headset at a high volume. Hearing experts ad- vise against continuous extended play. If you experience a ringing in your ears, reduce the volume or discontinue use. Do not use while operating a motorized vehi- cle.
- Page 12 When your player does not operate properly, please check the following points. If you are unable to solve the problem, please contact TEAC Tech Support. Power can not be turned on • Check if the batteries are inserted correctly, see page 3.
- Page 13 Playback does not start from the first track • Check if the program or the resume function is activated, if so clear program or switch off resume. No sound or sound quality is poor • Check if headphones are connected properly, see figure 3 on page 5.
- Page 14 185MB = 3 to 4 hours of MP3 music on 1 MiniCD, 21min Audio (CD-DA) on 1 MiniCD TEAC recommends the use of TEAC Mini CD-R media. Most CD-R/RW drives support reading and writing this media. 8cm CD-media can not be used in a "slot-in" drive and in a car-hifi set, unless a CD-adapter is used.
- Page 15 Power supply: TEAC recommends Duracell UltraM3 AA alkaline batteries for optimal performance. Operation Time: Anti-shock: Supported bitrate: Supported sampling rate: Temperature and humidity Storage: Operating: 1.5V AA alkaline battery x 2 4.5V/1A Linear Power Adapter up to 7 hours on 2 AA-size...
- Page 16 Headphone specifications Type: Frequency response: 18 – 20000Hz Impedance: Max. SPL: Cable length: Output: Frequency Response: 100Hz-20KHz Signal to noise ratio: >80dB Distortion (thd): Channel separation: >65dB MTBF: Sennheiser MX 300 32 Ω 116dB (at 1kHz, 0.5Vrms) approx. 1 m. 0.75Vrms (load=32 Ω) 1% max at 1KHz minimum 20000 POH...
- Page 17 5. Technical Support For technical support, please contact the TEAC Ser- vice and Support Center: North America TEAC America, Inc. (USA) Technical Support Telephone: (323)727-4860 • Fax: (323)869-8751 Monday -Friday 8:00 a.m.-5:00 pm PST http://www.teac.com/dspd E-mail: dspdtsg@teac.com...
