Teac HD2U-100 Datasheet

Portable 2.5 " Hard Disk Drive
High-Speed USB 2.0
40GB, 60GB, 80GB and 100GB Preformatted
•
High-Speed USB 2.0 backward
compatible with USB 1.1
•
Compatible with both Windows & Mac
•
Ideal solution for digital photos,
MP3 and data files
•
Bus-powered for true portability
•
Add unlimited storage with multiple
TEAC external hard drives
TEAC 2.5" USB 2.0 External Hard Disk Drives are preformatted
and ready to go (Mac users need to refomat). You can add reliable,
high performance storage instantly to your PC or Mac. Multiple
drives can be added to deliver unlimited capacity.
Featuring USB 2.0/1.1 compatibility and a fast access time, these
drives deliver the fastest performance for data storage, backup
or transporting large files between systems. Simply plug into the
two USB ports on your PC or USB PCI adapter card and within
seconds, your valuable data is securely transferred.
The sleek and ruggedized metal case design maximizes heat
dissipation and keeps the hard disk drive running much cooler for
optimum performance and years of dependable use.
Available in 40GB, 60GB, 80GB and 100GB capacity, these drives
are ready to use right out of the box. The retail kit includes the
drive, dual USB 2.0/1.1 interface cable and installation guide.
© 2005 TEAC America, Inc. All rights reserved. All trademarks and registered trademarks mentioned herein are the property of their respective companies.
TEAC America, Inc., 7733 Telegraph Road, Montebello, CA 90640 • Phone 323.726.0303, Fax 323.727.7652
"

2.5 Hard Disk Drive

Portable High-Speed USB 2.0

Drive Specifications

Models:
Interface:
Formatted Capacity:
Average Access Time:
Data Transfer Rate:
Spindle Speed:
Dimensions:
Weight:
Power:
Warranty:
Regulatory:
MTBF:
System Requirements:
Package Includes:
www.teac.com/DSPD
• HD2U-40: 40GB
• HD2U-60: 60GB
• HD2U-80: 80GB
• HD2U-100: 100GB
USB 2.0 / USB 1.1
40GB, 60GB, 80GB and 100GB, Preformatted
9.5ms
Up to 480MB/sec.
5400RPM
.562"(H) x 3"(W) x 5.25"(D)
.5 lbs.
Bus-powered (AC adaptor not required)
One-year limited
UL, CUL, FCC
100,000 POH
Windows Systems:
IBM PC compatible Pentium II
300MHz or higher; 64MB RAM or
higher; (2) USB 1.1 or USB 2.0 ports;
Windows 98SE, Me, XP, or
Windows 2000
Mac Systems:
32MB RAM or higher; True G3
processor or higher; (2) USB 1.1 or
USB 2.0 ports; Mac OS X or higher;
CD-ROM drive
TEAC external hard disk drive;
Dual USB 2.0 / 1.1 interface cable;
Installation guide
Note: USB 2.0 adapter card
not included
DSPD-86464/11-04/5M-DG
