- Page 1 UTILISATION ET INSTALLATION GEBRUIK EN INSTALLATIE OBSLUHA A INSTALACE Speicher- und Hydraulikmodul | Cylinder and hydraulic module | Module ballon et hydraulique | Boiler- en hydraulische module | Modul zásobníku a hydraulický modul » HSBB 3 » HSBB 3 S...
-
Page 2: Table Of Contents
Checks before commissioning the heat pump manager 39 13.2 Commissioning the heat pump manager ������������������ 39 13.3 Appliance handover �������������������������������������������� 39 Shutdown ��������������������������������������������������� 39 Maintenance ������������������������������������������������ 40 15.1 DHW cylinder ���������������������������������������������������� 40 15.2 Replacing the signal anode ����������������������������������� 40 | HSBB 3 www.stiebel-eltron.com... -
Page 3: Special Information
Failure to observe this information may result in serious injury or death. - Install the safety valve drain pipe with a constant CAUTION Failure to observe this information may result in non-seri- ous or minor injury. fall to the drain. www.stiebel-eltron.com HSBB 3 |... -
Page 4: Other Symbols In This Documentation
| water heat pumps: - WPL 13 E - WPL 10 I - WPL 10 AC (S) - WPL 15-25 AC (S) - WPL 08-22 (S) Trend | HSBB 3 www.stiebel-eltron.com... -
Page 5: Appliance Description
You can extend the heat pump manager with the following com- ponents: - Room temperature controllers FE 7 and FEK for controlling the direct heating circuit and the heating circuit with mixer. - Mixer module MSM, if connecting a second heating circuit with mixer www.stiebel-eltron.com HSBB 3 |... -
Page 6: Installation
- The room must not be subject to a risk of explosions arising ble-free operation of the appliance and to allow enough from dust, gases or vapours. space for maintenance work. - Load-bearing floor (for the weight of the appliance, see chapter "Specification / Data table") | HSBB 3 www.stiebel-eltron.com... -
Page 7: Installation
Debris (e.g. welding pearls, rust, sand, sealant, etc.) can im- pair the operational reliability of the heat pump. Thoroughly flush the pipework before connecting the heat pump. f Ensure the heating flow and return are connected correctly (see chapter "Specification / Dimensions and connections"). www.stiebel-eltron.com HSBB 3 |... -
Page 8: Connection To The Heat Pump
If you treat the fill water with inhibitors or additives, the same limits as for desalination apply. Note Suitable appliances for water softening, as well as for filling and flushing heating systems, can be obtained from trade suppliers. 1 Pipes carrying heating water 2 Pressure hoses | HSBB 3 www.stiebel-eltron.com... -
Page 9: Venting The Appliance
Fill the DHW cylinder via the drain valve. f Open all downstream draw-off valves/taps until the appli- ance is full and the pipework is free of air. f Carry out a tightness check. f Check the safety valve. www.stiebel-eltron.com HSBB 3 |... -
Page 10: Dhw Connection
1 Drain (DHW cylinder) f Fill the DHW cylinder via the drain. f Open all downstream draw-off valves/taps until the appli- ance is full and the pipework is free of air. f Carry out a tightness check. | HSBB 3 www.stiebel-eltron.com... -
Page 11: Power Supply
B 16 A Control cable 1.5 mm² Electrical data is provided in chapter "Specification / Data table". Material losses Provide separate fuses/MCBs for the two power circuits, i.e. for the compressor and the electric emergency/boost- er heater circuits. www.stiebel-eltron.com HSBB 3 |... - Page 12 If you are using energy efficient circulation pumps that Power connection single phase only HSBB 3 S have not been approved by us, use a relay with a break- ing capacity of at least 10 A/250 V AC or our WPM-RBS relay set.
-
Page 13: Sensor Installation
1 m to the side of windows and doors. The Heat pump outside temperature sensor should be freely exposed to the elements but not placed in direct sunlight. f Never mount the outside temperature sensor above win- dows, doors or air ducts. www.stiebel-eltron.com HSBB 3 |... -
Page 14: Fe7 Remote Control
1 or heating circuit 2 by ± 5 °C in automatic mode only. You can also change the operating mode. Connect the remote control to terminals Rem.con.1 and Rem.con.3 at terminal strip X2 and to the LV earth terminal strip X26 of the appliance. | HSBB 3 www.stiebel-eltron.com... -
Page 15: Commissioning
Reset the high limit safety cut-out by pressing the reset button. f If you take the system out of use, set the heat pump manager to standby. That way the safety functions that protect the system remain en- abled, e.g. frost protection. www.stiebel-eltron.com HSBB 3 |... -
Page 16: Maintenance
1 Inspection port (fitted signal anode) f Remove the signal anode from the appliance. f Clean the DHW cylinder with a hose that you guide through the inspection port. f Draw the loosened limescale deposits out through the in- spection port. | HSBB 3 www.stiebel-eltron.com... -
Page 17: Dimensions And Connections
Specification 16. Specification 16.1 Dimensions and connections HSBB 3 Entry electrical cables Cold water inlet Diameter DHW outlet Diameter Safety assembly drain Heat pump flow Diameter Heat pump return Diameter Heating flow Diameter Heating return Diameter www.stiebel-eltron.com HSBB 3 |... - Page 18 INSTALLATION Specification 16.2 Wiring diagrams HSBB 3 HSBB 3-phasig mit WPM3 und MFG Steuerung DHC (MFG) L1 L2 L3 N (WPM 1 2 3 4 5 6 (Netzt T > 1 (L) 2 (N) > p (MFG) 4 3 2 1...
- Page 19 X71 Rast 2.5 connector (heat source pump, PWM or 1-10 V X60 Rast 2.5 connector (HP flow temperature) switching) X61 Rast 2.5 connector (HP return temperature) X72 Rast 2.5 connector (CAN BUS) X62 Not assigned (HS return temperature) X80 Connector (CAN BUS) www.stiebel-eltron.com HSBB 3 |...
- Page 20 INSTALLATION Specification HSBB 3 S HSBB 1-phasig mit WPM3 und MFG Steuerung DHC (MFG) 1 2 3 4 5 6 (Net T > 1 (L) 2 (N) > p (MFG) 4 3 2 1 3 2 1 3 2 1...
- Page 21 X71 Rast 2.5 connector (heat source pump, PWM or 1-10 V X60 Rast 2.5 connector (HP flow temperature) switching) X61 Rast 2.5 connector (HP return temperature) X72 Rast 2.5 connector (CAN BUS) X62 Not assigned (HS return temperature) X80 Connector (CAN BUS) www.stiebel-eltron.com HSBB 3 |...
- Page 22 INSTALLATION Specification 16.3 Details on energy consumption Product data complies with EU regulations relating to the Directive on the eco-design of energy related products (ErP). HSBB 3 HSBB 3 S 234264 234265 Manufacturer STIEBEL ELTRON STIEBEL ELTRON Energy efficiency class...
- Page 23 INSTALLATION | GUARANTEE | ENVIRONMENT AND RECYCLING HSBB 3 HSBB 3 S Values Nominal heating flow rate at A2/W35, B0/W35 and 7 K m³/h Total available external pressure differential Heat loss kW/24 h 1.78 1.78 Min heating flow rate m³/h Max. operating pressure...
- Page 24 Deutschland Verkauf Tel. 05531 702-110 | Fax 05531 702-95108 | info-center@stiebel-eltron.de STIEBEL ELTRON GmbH & Co. KG Kundendienst Tel. 05531 702-111 | Fax 05531 702-95890 | kundendienst@stiebel-eltron.de Dr.-Stiebel-Straße 33 | 37603 Holzminden Ersatzteilverkauf Tel. 05531 702-120 | Fax 05531 702-95335 | ersatzteile@stiebel-eltron.de Tel.
