EMC Filters for AC Power Line
For Single-phase, Small-size Box Cased ZCB-11, ZCB-M Series
FEATURES
• The ZCB-11 and ZCB-M series EMC filters exhibit outstanding
attenuation characteristics with respect to both differential mode
and common mode noise components in the MF and HF bands.
• Leakage current is maintained at less than 0.41mA for the ZCB-
M series and less than 0.75mA for the ZCB-11 series.
• Efficient manufacturing makes these filters highly cost-effective.
• Connection terminals employing Faston
mentation and maintenance.
• It is a product conforming to RoHS directive.
APPLICATIONS
Digital applied devices (ECR, calculators, electronic scales, etc.),
control devices, measurement devices, and other electronic equip-
ment.
SHAPES AND DIMENSIONS
Screw hole H
1
4
2
3
B
F
G
Part No.
ZCB2203-11 2206-11
ZCB2201-M 2203-M
®
• Case: plastic, terminal: Faston
• Conformity to RoHS Directive: This means that, in conformity with EU Directive 2002/95/EC, lead, cadmium, mercury, hexavalent chromium, and specific
bromine-based flame retardants, PBB and PBDE, have not been used, except for exempted applications.
• All specifications are subject to change without notice.
®
#110 facilitate imple-
A
B
C
32
50
25
26
35
17.5
#110 (t=0.5mm)
SAFETY STANDARDS
Standard and standard No.
U.S.A.
Part No.
UL1283
ZCB2203-11
E62388
ZCB2206-11
E62388
ZCB2201-M
E62388
ZCB2203-M
E62388
Ground
terminal
D
E
F
50
40
68
44
35
53
®
• Faston
is a registered trademark of Tyco Electronics AMP Corp. Incorporated.
Conformity to RoHS Directive
Canada
CSA
UL
CSA C22.2 No.8
LR76849C
LR76849C
LR76849C
LR76849C
Dimensions in mm
G
H
I
8
3.6
20
8
3.6
18
003-01 / 20080820 / e9143_zcb_11.fm
(1/3)
Europe
NEMKO
EN60939
P08209033/A1
P08209033/A1
P08209033/A1
P08209033/A1
J
14
9.3
