VC-04
Product Overview
The TDK VC-04 Color Video Camera is a high
performance CCD specifically designed for re-
mote monitoring of equipment under EMC testing.
The camera is also ideal for wide angle anechoic
chamber monitoring, shielded access control, and
test action archiving.
Designed for EMC Testing
signed to operate in the harsh environments re-
quired by EMC testing. The camera is housed in
an EMI hardened protective case, and the control
and video signals use fiber optics to prevent inter-
ference caused by high electromagnetic fields
present during EMC testing.
Full-Featured
motely focused, positioned, and zoomed using the
TDK SI-300CC controller. The camera is available
in both NTSC and PAL versions.
Camera Features
1/4" CCD; high resolution; NTSC and PAL

versions
EMI shielded to >200 V/m (DC to 18 GHz);

Shielded 12 V DC or universal AC adapter
operated
Pan/tilt mechanism

Remote control for pan/tilt, focus, zoom, iris

control
Computer control with IEEE-488 option

Audio option provides both audio and visual

monitoring
1101 Cypress Creek Road  Cedar Park, Texas 78613, USA  1-512-258-9478  FAX 1-512-258-0740
Color Video Camera
The VC-04 is de-
The high-resolution VC-04 is re-
The TDK VC-04 Color Video Camera is de-
signed specifically for remote monitoring of
equipment during EMC testing in a shielded
room or anechoic chamber.
VC-04 Video Camera System Components
One VC-04 Color Video Camera

SI-300CC Camera Controller capable of

controlling up to four VC-04 cameras

A 20" LCD monitor

One set of 25m fiber optic cables

Either AC power or DC battery pack

Permanent sturdy fixture

Options
Built-in audio

VCMS-150R Video Camera Monopod Stand

VCWM Video Camera Wall Mount

AC power or DC battery pack

