Tascam CD RECORDER/CASSETTE DECK CC-222MKII Specifications

Tascam CC-222MKII
CC-222MKII
CD Recorder/Cassette Deck
The CC-222MKII is the world's first CD recorder and cassette recorder combo deck, bringing the two most popular consumer media formats
in one very affordable package. The two decks can be used independently, perhaps for playback of material on one deck while the other
deck is recording. Or, you can use both decks for continuous play between the two decks.
The cassette deck provides Dolby B Noise Reduction for better sounding recordings. A ±12% pitch control allows for varied speeds during
recording or playback. This is ideal for performers, allowing them to adjust pitch and tempo to suit their needs.
Each deck offers analogue inputs and outputs on unbalanced RCAs, allowing truly independent operation. Digital I/O for the CD recorder is
provided on SPDIF coax and optical ports. As a bonus, the CC-222MKII is equipped with an RIAA phono input which allows direct connection
of a turntable for creating CD or cassette masters of your favorite LPs. For ease of operation a wireless remote control is included.
Main Features
Cassette to CD-R/RW dubbing and vice versa
Continuous playback between decks
Individual RCA unbalanced analogue inputs/outputs on both decks
RIAA phono input
Headphones output with level control
Wireless remote controller RC-222 supplied as standard
3U rack-mountable
CD-RW Recorder:
CD-R, CD-RW, CD-R-DA, CD-RW-DA discs applicable
24-bit A/D and D/A converters
Digital input level control
Digital direct recording (bypassing the SRC and digital level)
Sampling rate converter (32kHz – 48kHz)
Fade in and out (1 to 24 seconds, 1 second steps)
Auto Track Increment (via SPDIF or audio level)
Specifications
Cassette Deck
Heads
Motor
Pitch control
Inputs (analogue, unbalanced)
http://www.tascam.de/en/cc-222mkii.html
Links and Downloads
Manuals
Sync record
Adjustable sound level for auto track and sync recording
Record Mute
Erase CD-RW discs
Un-finalize CD-RW discs
Continuous play, random play, and program play (maximum 25
songs)
Repeat function (single, all, A–B)
Intro check
Timer play
Coaxial and optical digital input/output
Cassette deck:
Auto reverse
Dolby B noise reduction
Approx. ±12% pitch control
RTZ (Return to Zero)
Record Mute
CPS search function
Record/playback (rotary reverse) x 1, Erase x 1
DC servo capstan motor
approx. ±12%
RCA x 2
Page 1 of 2
Rear panel drawing (31 KB)
Quick Start Guide (203 KB)
Owners Manual (1.2 MB)
3/18/2005
