Description
The TASCAM TM-ST1 is configured
with an M/S stereo pattern for excellent
imaging and natural ambience.
The microphone pattern can be switched
to 90 for narrower coverage, such as a
solo instrument or voice, or 120
orchestra, choir or stage performance.
The TM-ST1 is suitable for digital
recordings of concerts, meetings
events.
Features
! M/S stereo space, for natural and clear stereo sound
image.
! Coverage can be switched between 90
! 3.5mm stereo plug.
! Light weight body with professional clip, convenient
for carrying and set-up.
Specifications
Type:
Polar pattern:
Frequency response:
Sensitivity:
Nominal Impedance:
Min load impedance:
Max. SPL:
Dynamic range:
Power Source:
Power consumption:
Battery lifetime:
Output connector:
Weight:
for
and
and 120
Single point stereo (Mid-Side
arrangement), electret
condenser microphones
Cardioid for Mid, and figure of 8
for Side. Coverage at 90 or 120
100~15,000Hz
-45dBV/Pa @120 setting.
Channel difference within 3dB
1k ohm
20% at 1kHz
2k ohm
110dB
85dB
1.5V Battery (AA)
4mA
approx. 200 hours
3.5mm stereo plug
110g(including battery)
Inserting Battery Steps
1. Unscrew the microphone rear cover.
2. Remove the body shell to expose the battery holder.
3. Insert the battery according to the polarity markings.
Power Switch
When powering on the microphone, the Power LED
flashes once then goes off to extend battery life. When the
light no longer turns on, you need to change the battery.
The AA battery generally provides approximately 200
hours of use under normal circumstances. This can vary
from user to user.
Precautions
1. Insert the battery correctly
2. Do not charge the battery
3. Remove the battery if the microphone will not be used
for a long period of time.
4. If the battery leaks, clean the battery holder before
inserting a new battery.
Connection
Switch off the microphone and insert the 3.5mm stereo
plug into the microphone input of your recording device.
Accessories
The TM-ST1 includes a microphone clip and tabletop
stand. To use the clip with a microphone stand, the mic
clip comes with 3/8" and 5/8" adapter screws. A
windscreen is also provided to reduce breath or wind
noise.
