Tascam QUICK REFERENCE DM-3200 Quick Reference

Making EQ settings
The channel modules from 1 through 32 have full 4-band
parametric EQ.
You can see the numerical values of the set-
tings, as well as a frequency response curve,
when you press the
MODULE
the POD 2 key under the display.
Use a channelʼs key to select the channel
SEL
you want to edit.
Press the encoder mode key (this is the
EQ
fourth key down in the
group.
ENCODER
The encoders above the
channel modules act as
EQ controls, allowing
the control of gain, fre-
quency, Q (width) and
the type of filter for each of the four EQ
bands.
As you adjust these controls, the indica-
tors around the encoders light to give an
indication of the current setting, and the
display also shows the current EQ re-
sponse curve.
Use the
EQ/DYN
key to the left of
the card slot to turn EQ for the module
on ( indicator is lit) and off (
EQ
dicator is unlit).
Use the cursor keys to highlight the individual band switches,
and the key to turn individual EQ bands on and off.
ENTER
✒ See section 3, "Modules" of the Ownerʼs Manual.
TASCAM DM-3200 Quick Reference – Page 5
Setting up and using monitoring
key, followed by
to make the
MONITOR
does not, press the POD 2 switch).
Use the cursor keys and the wheel to select
the sources for the three assignable monitor
selection keys (from individual or paired
aux sends or busses, the digital inputs, the
analog 2-track input or the oscillator).
in-
EQ
The studio outputs can be set to mirror the control room (
) or use pairs of busses, or aux sends, digital in-
CONTROL ROOM
puts or the analog 2-track inputs. Adjust the levels with the
controls (the talkback microphone is also there).
CONTROL ROOM
The ,
MONO, DIM
keys are "smart" keys (push and release to latch, push and
hold as non-latching) and control talkback routing, etc.
TEAC CORPORATION 3-7-3 Nakacho Musashino-shi Tokyo 180-8550 JAPAN
+81-422-52-5082
TEAC AMERICA, INC 7733 Telegraph Road Montebello CA 90640 USA
+1-323-726-0303
The control room outputs are +4 dBu
balanced XLR outputs, and the stu-
dio outputs are –10 dBV unbalanced
RCA jacks. The studio feed can
be separately to that of the control
room.
There are four keys allowing selec-
tion of the control room feed. The
first is hard-wired to the
STEREO
buss, but the others may be selected
using the screen.
MONITOR
Press the
MONI-
key (with the
TOR
indicator lit)
ALT
screen appear (if it
and keys below the selection
TO SLATE TO STUDIO
www.tascam.com
www.tascam.com
Printed in China
»
DM-3200 Quick Reference
Introduction
Use this guide as a quick reference to a few of the more com-
monly used functions of the DM-3200.
For full details of the functions described here and the full
description of all functions, consult the Ownerʼs Manual.
Routing inputs
To route the inputs, digital inputs, effect returns, etc.
MIC/LINE
to channel modules, press the
key:
When youʼve done this, use the POD 3
encoder (under the screen) to choose the
destination channels (or dynamic trig-
gers).
Use the POD 4 encoder to choose the
source: mic/line inputs, TDIF and ADAT
digital inputs, assignable returns, and ef-
fect returns, etc. as well as any installed
option cards.
Use the cursor keys to navigate around the input slots (high-
lighted in the screen below), to the left of the destination.
Note that channels 1 through 32 have two switchable inputs:
From
input and return, similar to traditional analog recording mix-
ing consoles.
These can be "fl ipped" using the on-screen
ton at the bottom right of the display.
✒ See section 4, "Routing and Assignment" of the Ownerʼs
Manual.
TASCAM DM-3200 Quick Reference – Page 1
ROUTING
but-
SOURCE INVERT
