Novik Neo EVO-8P Instruction Manual

EVO-8P / EVO-10P / EVO-12P / EVO-15P

INSTRUCTIONS MANUAL

• Be sure to place the box in a safe and stable.
• Do not overload the box, avoid damage to the structure and internal.
• Do not use this device near water presence.
• Use a clean and dry cloth to clean it. Do not use chemical products.
• Indoor use is recommended; if used outdoors, make sure that no moisture in the box.
• Do not place a flame (eg candles) near or on the box. - Fire Hazard.
• Do not place liquids on the case and protect it from moisture; can significantly shorten the life of the equip-
ment
• Do not install near any heat sources such as radiators, heaters, stoves or other devices (including amplifiers)
that produce heat and avoid putting it under direct sunlight.
• Keep out of the reach of children.
• Use appropriate means of transport in case you want to move the box. Watch your back.
• To hang or fly the Loudspeaker, only do so safely with the correct hardware and accessories suggested by the
brand.
• Pull the cable so that no one falls on it or put anything on it.
• Never attempt to repair the unit yourself. Contains exclusive parts inside.
• Never attempt to suspend the loudspeaker by their handles. Consult a certified structural engineer
• CAUTION: This loudspeaker is capable of producing sound levels that may cause severe and permanent
hearing damage.
System
LF Transducer
HF Transducer
Power RMS
Program Power
Peak Power
Sensitivity
Max SPL
Impedance
Frequency Response
Dispersion
Input Conector
*Specifications are subject to change without notice.
8P 10P
Passive Full Range Passive Full Range
8"(1,5" KVC) 10"(1,5" KVC)
1" 1,44"
100W 150W
200W 300W
400W 600W
92dB(1W/1m) 92dB(1W/1m)
125dB 120dB
8Ω 8Ω
65Hz-18 Khz 55Hz-18 Khz
90°x60° 90°x60°
Speakon Speakon
12P 15P
Passive Full Range Passive Full Range
12"(2" KVC) 15"(2,5" KVC)
1,44" 1,75"
250W 350W
500W 700W
1000W 1400W
94dB(1W/1m) 96dB(1W/1m)
122dB 125dB
8Ω 8Ω
45Hz-18 Khz 40Hz-18 Khz
90°x60° 90°x60°
Speakon Speakon
