Tascam 112RmkII Technical Documentation

PRODUCT OVERVIEW
The 112RmkII is the perfect deck for people needing a
extended recording and playback from a reversible
cassette deck, yet they still need professional reliability
and performance characteristics. The 112RmkII offers
true three head performance during the recording
process, allowing the user to monitor from tape. The
parallel I/O controls offer the facilities for controlling
the deck from other control surfaces, getting tally
responses back from the deck, or connecting the
optional RC-112R. When you need the best reversible
cassette deck around, get TASCAM's 112RmkII.
• Professional Reversible 3 Head Cassette Mechanism
• Hysteresis Tension Servo Control System
• Dolby B and C with HX Pro Headroom Extension
• ±12% Pitch Control with Clear On/Off Switch
• Two Locate Points and Return To Zero Functions
• Headphone Output with Level Control
• RCA Analog I/O
• Front Panel Line Inputs
APPLICATIONS
The 112RmkII is the most advanced bidirectional cassette deck on the
market. The 112RmkII was built with the same attention to detail and
focus on quality as the venerable 122mkIII, a commitment that is always
appreciated not only when the unit is first installed, but even after
logging years of steady use.
Broadcast Facilities - Live Theaters
The 112RmkII has all the interfacing necessary to make live production a
breeze. Whether it's calling in a sound cue, recording longer program
material, or just bringing in background music or music beds, the
112RmkII is the machine of choice. Since this cassette deck also employs
separate record and reproduce heads, the 112RmkII is also an excellent
mastering recorder, allowing the user to monitor from tape.
Home Studios - Project Studios
Reference mixes are often dropped onto cassette since the media is far
easier to work with than CD-R, and more ubiquitous than DAT or MiniDisc.
The 112RmkII's separate record and reproduce heads mean you instantly
know what your mixdown sounds like on tape. No more waiting for the
playback afterwards to know if you've overloaded the tape or not.
The simple pleasures of an RTZ function and two locate buttons with
looping make auditioning songs or selected parts of songs a breeze. Add
the optional remote or balancing kit when needed, and you've got the
best reversible cassette deck available on the market.
Contracting Installations
Whether you need to create a tape loop for background tracks, or an
inexpensive logging system, the 112RmkII is an excellent choice. The
112RmkII offers a cascade play/record control through the parallel
control for linking multiple 112RmkIIs in hands free sequential operation.
7733 Telegraph Road
All features and specifications are subject to change without notice. Contact your local TASCAM representative for the latest information.
• Montebello, CA 90640 • (323) 726-0303
112RmkII
Technical Documentation
• Precision VU Meters with Peak LEDs
• Auto-Input Monitor Selector
• Repeat Function
• Parallel Control Port
• Fader Start Function
• MPX Filter
• Optional RC-112R Remote Control
• Optional LA-112 Balancing Kit
SPECIFICATIONS
Performance Specifications:
Track System: 4 track, 2 channel stereo
Heads: (2) Erase, rotary mechanism with
(1) Record, (1) Reproduce
Type of Tape: Cassette C-60, C-90
Tape Speed: 1 7/8 ips, 4.76 cm/sec
Pitch Control: Approx ±12%
Motors: 1 DC servo capstan motor
1 DC reel motor
1 DC ancillary motor
Frequency Response: 25Hz-19kHz ±3dB Metal
25Hz-18kHz ±3dB CrO2
25Hz-17kHz ±3dB Normal
Total Harmonic Distortion: <1% (1kHz, 160nWb/m)
Signal to Noise Ratio: >80dB Dolby C, 1kHz, 3% THD wtd
>70dB Dolby B, 5kHz, 3% THD wtd
>60dB Dolby off
Wow and Flutter: <0.04% (W RMS)
±0.07 peak (DIN/IEC/ANSI wtd)
Bias/Erase Frequency: 100kHz
Input RCA & 1/4": -10dBu, 20kOhm
Line Output RCA: -10dBu, 100 Ohm
Headphone Output: 100mW + 100mW, 8 Ohm
General Specifications:
Power Requirements: 120V AC, 60Hz (US/Canada Model)
230V AC, 50Hz (Europe Model)
240V AC, 50Hz (Australia Model)
Power Consumption: 23W
Dimensions: 482 x 132 x 356 mm
19" x 5 1/4" x 14"
Weight: 8.7Kg, 19-3/16 lbs.
Optional Accessories: Wired Remote (RC-112R)
Balancing Kit (LA-112)
