Targus Click N Type
for Compaq iPAQ 3800/3900
Making Your Mobile Life Easier.
USER'S GUIDE
Visit our Web site at: www.targus.com
Making Your Mobile Life Easier.
Features and specifications are subject to change without notice. © 2002 Targus Corp.
400-0090-001A
B
H
B
T
M
A
S
L
P
N
Y
L
A
T
H
K
S
RUSSELS
ANNOVER
ARCELONA
OKYO
ILANO
MSTERDAM
INGAPORE
ONDON
ARIS
EW
ORK
OS
NGELES
ORONTO
ONG
ONG
YDNEY
Advertisement
Table of Contents
Related Manuals for Targus iPAQ 3800
Summary of Contents for Targus iPAQ 3800
- Page 1 Compaq iPAQ 3800/3900 Making Your Mobile Life Easier. USER’S GUIDE Visit our Web site at: www.targus.com Making Your Mobile Life Easier. Features and specifications are subject to change without notice. © 2002 Targus Corp. 400-0090-001A RUSSELS ANNOVER ARCELONA OKYO...
-
Page 3: Installing The Driver
• Take a keyboard and mouse with you whenever you travel with your PDA. In addition to this user’s guide, this package contains the Targus Click N Type and the driver software CD-ROM. Installing the Driver To install the driver software for the Click N Type, you need: •... - Page 4 3 Insert the driver software CD-ROM into your computer’s CD-ROM drive. 4 Click Start, Run, then enter D:\Setup.exe (where D: is the path of your CD-ROM drive) and then click OK. The Click N Type Installation screen appears. PDA Mouse Click N Type Installation screen 5 Click Install.
- Page 5 Connecting the Click N Type to Your PDA Once you have installed the driver, you can connect the Click N Type to your PDA. To do this: 1 Turn off your PDA (if it’s turned on). 2 Hold your PDA in one hand and the Click N Type in your other hand.
- Page 6 3 Align your PDA with the keyboard connector, located at the top of the Click N Type. Aligning your PDA with the keyboard connector 4 Gently slide your PDA into the keyboard connector until you hear a “click.” When you connect the Click N Type, your PDA automatically turns on and you can begin typing.
- Page 7 Disconnecting the Click N Type To disconnect the Click N Type from your PDA: 1 Turn off your PDA (if it’s turned on). 2 Press the release button, located on the back of the keyboard, and gently pull your PDA away from the Click N Type, sliding it out of the keyboard connector.
- Page 8 To enable the Click N Type: 1 Tap Start, then Click N Type. The main application screen appears. Sample main application screen 2 Tap on the box next to Enabled so that a check mark appears. You are now ready to customize and use the Click N Type. Customizing the Click N Type Options Once you enable the Click N Type, you can view and customize its options through the File menu on the main application screen.
- Page 9 To customize the Click N Type option: 1 Tap Start, Click N Type, then File. The File menu appears. 2 Select the option you want to view or customize. The available options are: • About • Help • Function Keys •...
- Page 10 About The About screen in the Click N Type application allows you to view the software version and copyright information. Help The Help screen in the Click N Type application displays the online help topics. Find the topic you want to learn more about and select the link to view more information.
- Page 11 To define the function keys: 1 Choose a modifier (Shift or Fn) that you want to assign as a part of the key sequence, or select None, from the drop-down menu. 2 Tap the function key that you want to assign. 3 Select a mode from the drop-down menu.
- Page 12 Keyboard Speed The Keyboard Speed screen in the Click N Type application allows you to regulate the keystroke repeat function. Sample Keyboard Speed screen • Delay until repeat: allows you to set the length of time before a letter, number or other character begins to repeat when you press and hold a key.
- Page 13 Mouse Speed The Mouse Speed screen in the Click N Type application allows you to regulate the rate at which the mouse (8-way navigation button) moves the cursor across the screen. Sample Keyboard Speed screen • Mouse Speed Slow: allows you to set the speed at which the cursor normally moves.
-
Page 14: Typing Keyboard Shortcuts
Using the Keyboard Mouse With the Click N Type’s 8-way navigation button, you can control the cursor’s movement and tap items on your PDA’s screen — all “stylus-free.” Click N Type 8-way navigation button Press the arrows on the navigation button to move the cursor across the PDA’s screen. -
Page 15: Keyboard Combinations
Keyboard Combinations Key Sequence Shift + any key Caps Fn + any key Shift + ↑ Shift + ↓ Shift + → Shift + ← Fn + Mouse Mouse Ctrl + X Ctrl + C Ctrl + V Ctrl + A Ctrl + Z Fn + Backspace Ctrl + Q... -
Page 16: Troubleshooting
5 Install the driver software, following the instructions in “Installing the Driver” on page 3. Does the Targus Click N Type require batteries? No — the keyboard uses only a small amount of power, which it draws directly from your PDA. Alternately, you can charge your PDA while using the Click N Type by connecting an AC adapter to the AC adapter port, located at the bottom of the keyboard. -
Page 17: Technical Support
Technical Support In the unlikely event that you encounter a problem with your Targus accessory, please contact our technical support team at: Email: techsupport@targus.com Internet: http://www.targus.com/support.asp Our knowledgeable staff is also available to answer your questions through one of the following telephone numbers. -
Page 18: Product Registration
Warranty Targus warrants this product to be free from defects in materials and workmanship for one year. If your Targus Targus Click N Type is found to be defective within that time, we will promptly repair or replace it. This warranty does not cover accidental damage, wear and tear, or consequential or incidental loss. - Page 19 If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: •...
