Wireless keypad and optical mouse combo

Advertisement

Wireless
Keypad and
Optical Mouse
Combo
USER GUIDE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AKM10US and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Targus AKM10US

  • Page 1 Wireless Keypad and Optical Mouse Combo USER GUIDE...
  • Page 2 TARGUS WIRELESS OPTICAL MOUSE Introduction Congratulations on your purchase of the Targus wireless keypad and opitcal mouse combo. This combo set offers the latest technology for interference free operation with 2.4 GHz wireless connection. Both keypad and mouse feature on/off switch and power saving management for effective power conservation.
  • Page 3: Installing The Batteries

    Targus wireless keypad and opitcal mouse combo Operating System • Windows 2000/XP ® • Windows Vista™ Installing the Batteries Optical Mouse Removing the battery cover 1 Insert the supplied batteries , making sure that the positive (+) and negative (-) ends of each battery match the polarity indicators inside the battery housing.
  • Page 4: Connecting The Receiver

    Targus wireless keypad and opitcal mouse combo Wireless Keypad 1 Remove the battery cover located on the bottom of the keypad. 2 Insert the supplied batteries , making sure that the positive (+) and negative (-) ends of each battery match the polarity indicators inside the battery housing.
  • Page 5: Optical Mouse

    Targus wireless keypad and opitcal mouse combo Setting the Identification Code After your computer detects the USB receiver you must set the ID code between the receiver and the mouse as well as between the receiver and the keypad BEFORE you can use them.
  • Page 6 Targus wireless keypad and opitcal mouse combo Wireless Keypad The LED on the receiver will flash for 60 seconds to indicate ID search mode. During this time, press and release the connection button on the back of the keypad. 2 When the light emitter diode (LED) on the receiver is lit, the keypad is set up with an ID and the receiver is locked.
  • Page 7 Targus wireless keypad and opitcal mouse combo Using the Keypad Definition of the Keypad Keys: NumLock on - inserts a decimal point NumLock off - deletes a number NumLock on - enters “0” on the display NumLock off - emulates the Insert key NumLock on - enters “00”...
  • Page 8 Targus wireless keypad and opitcal mouse combo NumLock on - enters “7” on the display Home NumLock off - emulates the Home key NumLock on - enters “8” on the display NumLock off - moves the cursor up one line ...
  • Page 9: Media Keys

    Targus wireless keypad and opitcal mouse combo Using the multimedia/internet controls To switch between the two modes, press the Mode key. Media keys Internet keys Function Previous Track Next Track Play / Pause Mute Volume Up Volume Down Stop Default E-mail Program...
  • Page 10: Power Management

    Targus wireless keypad and opitcal mouse combo Power Management To power the keypad and mouse on and off, slide the on/off switch to the desired position. When power is on, the mouse goes into “power saving mode” after 4 minutes of inactivity. To activate the mouse, move the mouse or press any button.
  • Page 11: Troubleshooting

    Targus wireless keypad and opitcal mouse combo • If your computer has a metal case that contains aluminum or magnesium, use the optical mouse to the side. The display panel may interfere with the radio frequency signal if you use the mouse directly in front of the computer.
  • Page 12 Targus wireless keypad and opitcal mouse combo When I use the mouse, other wireless devices work more slowly or fail temporarily – what should I do? • The mouse may cause interference with any cordless, radio- based device that operates at 2.4 GHz, such as a telephone, baby monitor, or toy.
  • Page 13: Specifications

    Targus wireless keypad and opitcal mouse combo Specifications Operation Frequency Operating Distance Operating Voltage Operating Current Suspend Mode Dimensions Weight 2.4 GHz Up to 10m Keypad: Receiver: Mouse: Keypad: Receiver: Mouse: Keypad: Mouse: Keypad: Receiver: Mouse: Keypad: Receiver: Mouse: 2.4V...
  • Page 14: Technical Support

    You will need to provide your full name, email address, country of residence and product information. Warranty Targus warrants this product to be free from defects in materials and workmanship for one year. If your Targus accessory is found to be defective within that time, we will promptly repair or replace it.
  • Page 15: Declaration Of Conformity

    Microsoft Corporation in the United States and/or other countries. All trademarks and registered trademarks are the property of their respective owners. All rights reserved. Features and specifications are subject to change without notice. © 2008. Targus Group International, Inc. and Targus, Inc., Anaheim, CA 92806 USA...
  • Page 16 Visit our website at www.targus.com Features and specifications are subject to change without notice. © 2008 Targus Group International, Inc. and Targus, Inc. AKM10US/ 410-1449-001A...
