Targus Ultra-Mini Wireless
Optical Mouse Presenter
®
Making Your Mobile Life Easier.
USER'S GUIDE
Visit our Web site at: www.targus.com
®
Making Your Mobile Life Easier.
Features and specifications are subject to change without notice.
© 2003 Targus Group International and Targus, Inc..
400-0140-001A
B
H
B
T
M
A
S
L
P
N
Y
L
A
T
H
K
S
RUSSELS
ANNOVER
ARCELONA
OKYO
ILANO
MSTERDAM
INGAPORE
ONDON
ARIS
EW
ORK
OS
NGELES
ORONTO
ONG
ONG
YDNEY
Advertisement
Table of Contents
Related Manuals for Targus 400-0140-001A
Summary of Contents for Targus 400-0140-001A
- Page 1 Making Your Mobile Life Easier. USER’S GUIDE Visit our Web site at: www.targus.com ® Making Your Mobile Life Easier. Features and specifications are subject to change without notice. © 2003 Targus Group International and Targus, Inc.. 400-0140-001A RUSSELS ANNOVER ARCELONA OKYO...
- Page 3 TARGUS ULTRA-MINI WIRELESS OPTICAL MOUSE PRESENTER Introduction Congratulations on your purchase of a Targus Ultra-Mini Wirelss Optical Mouse Presenter. This 2.4GHz Mouse Presenter is an ideal solution when giving a presentation or when travelling. It provides multi-functions as wireless optical mouse, presenter and laser pointer up to 50 feet (15 m).
-
Page 4: System Requirements
Targus Ultra-Mini Wireless Optical Mouse Presenter System Requirements To use the Mouse Presenter, your computer must meet the following hardware requirements and run one of the operating systems listed below. Hardware › PC with a Pentium › USB v1.1 or higher interface Operating System ®... - Page 5 Targus Ultra-Mini Wireless Optical Mouse Presenter Connecting the Charger Base/ Receiver and Installing the Default Driver To connect the charger base/receiver: 1 Turn off your computer. 2 Plug the USB connector into an available USB port on your computer. 3 Turn on your computer.
-
Page 6: Installing The Batteries
Targus Ultra-Mini Wireless Optical Mouse Presenter Installing the Batteries 1 Remove the battery cover from the top of the mouse presenter by pressing the battery cover hinge located on the bottom of the mouse presenter and sliding it off. 2 Insert the supplied batteries, making sure that the positive (+) and negative (-) ends of each battery match the polarity indicators inside the battery housing. - Page 7 Targus Ultra-Mini Wireless Optical Mouse Presenter Synchronizing After your computer detects the USB charger base/receiver and the driver software is installed, you must synchronize the mouse presenter with the charger base/receiver BEFORE you can use the mouse presenter. To do this: 1 Press and release the connect button on the bottom of the mouse presenter.
- Page 8 Targus Ultra-Mini Wireless Optical Mouse Presenter Using the Mouse Presenter Functionality The Mouse Presenter provides 3 working modes: • Presenter Mode In Presenter Mode the device will work as a Wireless Presenter and provide the functionalities as follows: Left button:...
- Page 9 Targus Ultra-Mini Wireless Optical Mouse Presenter • Mouse Mode In Mouse Mode the device will work as a Wireless Optical Mouse and provide functionalities as follows: Left button: Right button: Middle button/Scrolling wheel: Function key 1: Function key 2: Function key 3: •...
-
Page 10: Power Management
Targus Ultra-Mini Wireless Optical Mouse Presenter Power Management To power the mouse presenter on and off, slide the on/off switch at the bottom of the mouse presenter to the desired position. To save battery power, turn off the mouse presenter while traveling or when you’re not using it. -
Page 11: Comfortable Usage
Targus Ultra-Mini Wireless Optical Mouse Presenter mouse presenter’s LED light to glow brighter, which causes the battery to discharge more rapidly. Comfortable Usage Research suggests that physical discomfort and injury to nerves, tendons, and muscles may be related to repetitive motion, an improperly set up work area, incorrect body posture, and poor work habits. -
Page 12: Things To Remember
Targus Ultra-Mini Wireless Optical Mouse Presenter › Never view the Mouse Presenter’s laser beam using telescopic devices, such as a microscope or binocu- lars. › Any attempt to disassemble, adjust or repair the Mouse Presenter may result in exposure to laser light or other safety hazards. -
Page 13: Specifications
Targus Ultra-Mini Wireless Optical Mouse Presenter Specifications Button Count Function Keys Operating Frequency 2.4 GHz Number of IDs Resolution Dimensions Weight Receiver Interface Operating Voltage Batteries Operating Current Mouse Presenter Sleep Mode RF Output 3 with scrolling wheel 83 Channels, 65000 IDs... -
Page 14: Troubleshooting
Targus Ultra-Mini Wireless Optical Mouse Presenter Troubleshooting What do I do if the Mouse Presenter does not work? › Make sure that the polarity of the batteries is correct. The positive (+) and negative (-) ends of each battery must match the positive (+) and negative (-) connec- tions in the battery housing. -
Page 15: Technical Support
I can’t use the Mouse Presenter while another RF mouse presenter is in use – what should I do? Reset the identification code. See “Synchronizing” on page 7 Technical Support For technical questions, please visit: www.targus.com/ support.asp Australia Internet: www.targus.com.au Email: infoaust@targus.com Monday through Friday, 8:30 a.m. -
Page 16: Product Registration
(if applicable). Warranty Targus warrants this product to be free from defects in materials and workmanship for one year. If your Targus accessory is found to be defective within that time, we will promptly repair or replace it. This warranty does not cover accidental damage, wear and tear, or consequential or incidental loss. -
Page 17: Regulatory Compliance
Features and specifications subject to change without notice. All trademarks and registered trademarks are the property of their respective owners. © 2003, All Rights Reserved, Targus Group International and Targus, Inc., Anaheim, CA 92806 USA.
