Page 12: Introduction
1 Introduction The TANDBERG 1000 MXP provides essential video features for face to face meetings for small groups and offices with the quality and reliability found in all TANDBERG equipment. Users can dial in from a video system outside the enterprise without being registered to a...
Page 13 60 fields per second true interlaced picture. SXGA input DVI-I (analog or digital). H.264 video compression up to 768kbps. High Definition (HD) Support on TANDBERG MXP systems with a DVI input and output Network The system supports videoconferencing via both IP and ISDN networks. The bandwidth...
Page 14 Interoperability The TANDBERG 1000 MXP is worldwide compatible with other ITU standards-based videoconferencing systems from many other vendors worldwide. * - optional feature. To check which options are installed, select Control Panel - Diagnostics - System Information in the menu.
Page 15: At A Glance
1.1 At a Glance Microphone The microphone is integrated and located at the edge on the left hand side of the unit. Headset / push-button For privacy, a headset may be connected to the connector (audio in and out) located at the edge on the left hand side of the unit.
Page 16: Menu Structure
Introduction 1.2 Menu Structure The Menu is available for all users and contains all the functionality of the system. The Control Panel contains all the settings of the system. Making changes to the settings will change the behavior of the system. The menu structure is shown below.
Page 17 TANDBERG 1000 MXP Note that the system features and menu settings may vary depending on network selection and software package.
Page 18: Installation
2 Installation Precautions: Never install communication wiring during a lightning storm. Never install jacks for communication cables in wet locations unless the jack is specifically designed for wet locations. Never touch uninstalled communication wires or terminals unless the telephone line has been disconnected at the network interface.
Page 19: Unpacking
2.1 Unpacking The TANDBERG 1000 MXP consists of the following items: Videoconferencing system with built-in camera Remote Control Batteries User Manual on CD Power supply Cables...
Page 20: Connecting Cables
2.2 Connecting Cables North America: The system does not have a built-in network terminator. If the wall socket provides an ISDN U-interface, an NT1 between the system and the ISDN line is needed, see Appendix 10 details. 1. Power cable Connect the power supply to the DC in input on the system.
Page 21 3. Plug for headset (optional) The TANDBERG 1000 has a 2.5mm 3-pole mini-jack connector at its left side marked with a headset symbol. This allows the user to connect a standard telecommunications headset to the system. Pressing the push button in front of the unit toggles...
Page 22: Monitor Configuration
Installation 2.3 Monitor Configuration Power on Switch the system on by connecting the power cable to an electrical distribution socket. After the system has performed a self-test routine, the Menu will be displayed on the monitor.
Page 23: System Configuration
2.4 System Configuration The system must be configured for each installation. Configuration settings can be made via the system menu. Navigate through the menu system using the arrow keys and OK. Remember to press the Save button on the bottom of each menu to save the changes. Press Cancel (x) to return to the previous Menu.
Page 24 “New Option Key”. Any bandwidth option key should be entered under “New Bandwidth Key”. For more information on these options, please contact your TANDBERG representative. 7. Date and Time Settings Select your preferred Date and Time Settings.
Page 25 Remember to save any changes made in the menu by selecting the Save button on the Menu line and pressing OK. * The International Name field is only visible if the system name contains Asian and non-Latin character text input.
Page 26: General Use
3 General Use Wake up the system When the system is not in use, it is in standby mode and the screen is black. Wake up the system by picking up the remote control. An incoming call or pressing any key on the remote control will also wake up the system.
Page 27: The Welcome Screen
3.1 The Welcome Screen When the system is switched on, the welcome screen will be displayed. The welcome screen presents the menu and displays your main camera image in the background (display main camera is the default setting). The ISDN/IP numbers and the system name are displayed in the upper right corner.
Page 28: Using The Remote Control
3.2 Using the Remote Control The system is controlled with a remote control. Think of the remote control as a mobile phone with number keys and call keys. Use the arrow keys and press OK to navigate through the menus. The system’s most commonly used functions are also accessible directly from the remote control.
Page 29 *This does not apply to systems with small integrated cameras. in and out.* 12. Selfview displays your outgoing video. Press Selfview again to turn selfview off, see Selfview. 13. Use the Phone Book to store and recall video contacts for easy placement of calls, see Phone Book.
Page 30 The remote control (TRC 4)**: 1. Change video source. If possible, you will start open a Dual Stream. Press the video source button again to stop the dual stream. 2. Mic Off turns your microphone on and off, see off. 3.
Page 31 *This does not apply to systems with small integrated cameras. ** Ordered separately presentation source. If the Presentation key is held down for 1 second then the Presentation video sources menu will appear, see Presentation Key. 12. Press OK/Menu to show the menu and to select menu items, see Navigation.
Page 32: Navigation
Administrator Settings 3.2.1 Navigation Arrow keys and OK Navigate in the menu with the arrow keys on the remote control. The orange selector on screen shows the selected item. Press OK to select. Cancel key In the Menu, pressing Cancel (X) will hide the menu. If the menu is hidden, bring it back with OK.
Page 33: Selfview
3.2.2 Selfview The term “Selfview” means the outgoing image. In a normal call using the main camera, this is the image of you. The Selfview button toggles the images between Far End, Selfview and Dual Video (if any). How to use Selfview: 1.
Page 34 Administrator Settings Example: You are using the system as a PC and get an incoming call. When the setting “Use Screen as Local PC monitor” is On, you will keep your PC image displayed locally and the incoming call pops up in a PIP or as smaller images in a 1+3 layout, depending on your system.
Page 35: Picture Layout
TANDBERG 1000 MXP 3.2.3 Picture Layout The layout of the screen can either be shown as Picture in Picture (PIP) or Picture outside Picture (POP) when displaying more than one video image. The behavior of the Layout button is dependent on the Picture Layout setting in Control Panel –...
Page 36: Mic Off
Administrator Settings 3.2.4 Mic Off To mute the microphone during a call, press the Mic off button. An on-screen indicator appears in the upper right corner when the microphone is off. In a call, if audio is detected, the on-screen symbol will start to flash.
Page 37: Volume + And
TANDBERG 1000 MXP 3.2.5 Volume + and - Press the Volume key to adjust the volume level. An on-screen indicator will show the current level.
Page 38: Number And Letter Keys
Administrator Settings 3.2.6 Number and Letter keys Pressing a number key when outside a call will bring up the call menu. When in a call, the number keys are used for Camera Presets. Press a number and go to the corresponding Camera Preset (see Camera Presets).
Page 39: Touch Tones
TANDBERG 1000 MXP 3.2.7 Touch Tones To activate dialing touch tones during a call, press the Touch tones button. Otherwise the number keys will work as configured in the Number Key Mode, see Control Panel – Menu Settings – Number Key Mode. An indicator will let you know that Touch tones are enabled. Press OK to exit...
Page 40: Presets And Extension Numbers
3.2.8 Presets and Extension Numbers When pressing a number key on the remote control, while in a call, the user can decide what shall happen. The system can be configured to act automatic or manual. While in a call, the user presses a number key to: •...
Page 41: On-Screen Indicators
3.3 On-screen Indicators The system has a number of icons signaling different settings: Microphone Off This indicator is shown when the microphone is turned off. Press the Mic off button again to turn the microphone back on, see Volume Off This indicator is shown when the volume is turned off.
Page 42 Headset active Activate the headset by pressing the button in front of the TANDBERG 1000. Deactivate the headset by pressing the button once more. A headset indicator is...
Page 43: Using The Menu
3.4 Using the Menu Press the Menu button on the remote control to display the menu. The menu contains all functions needed in order to control the system. The menu contains the following items: Make a Call Standby/End Call Camera Control* Presentation Conference Services Control Panel...
Page 44: Make A Call
1. Select Make a Call from the menu, or 2. Press the green Call button on the remote control The TANDBERG system can make both Call Settings specifies the quality of the call. It is possible to alter the default call settings for the current call if required.
Page 45: Place A Call
3.5.1 Place a Call The TANDBERG system can make both button is placed to the right of the number entry field. The button shows if it is a video call (default) or a telephone call. Press the button to show a drop down list to select the type of call.
Page 46 Place the call by either: 1. Use the arrow button on the remote control to select the Place Call icon and press OK, or 2. Press the green call button on the remote control. TIP: When dialing a telephone number and pressing the green Call button on the remote control, the system will in most cases automatically interpret the number as a video number and not a telephone number.
Page 47: Call Settings
3.5.2 Call Settings The Call Settings specifies the quality of the call. Each call will be set up with the Default Call Settings if the settings are not altered. In this case the field is labeled Default Call Settings. If the settings for some reason are altered for the current participant in the current call, the name of the field will be changed to reflect this.
Page 48: Sip Services
3.5.3 SIP Services SIP enables you to use the features Add Call and Transfer even if your system doesn’t have multipoint capabilities. To get the SIP Services available, you have to make a call using SIP as your Net. (See Call Settings) 3.5.3.1 Add Call You can add another call to your existing SIP call.
Page 49: Streaming
(if MultiSite), selfview, far end and DuoVideo streams are accessible via http. See descriptions of the possible snapshot files. Note that on the TANDBERG 1000 MXP Streaming is only supported outside a call. How to use Streaming: 1. Choose Streaming from the Call Menu to open the Streaming menu.
Page 50 more than 2 router hops. Auto: Enables streaming of both local and far end video. Streaming Selection of which site to be streamed is done using voice Source* switching (the site that speaks is streamed). Local: Only the local video will be streamed. Remote: Only the far end video will be streamed.
Page 51: Dialing In From Outside The Enterprise
Dialing In From Outside the Enterprise Dialing in Without Being Registered to a TANDBERG Gatekeeper The feature enhancement enables dialing through a TANDBERG Gatekeeper without being registered to it. This makes it easy to call in from a video system outside the enterprise.
Page 52: Answer An Incoming Call
3.6 Answer an incoming call How to answer an incoming call: To accept an incoming call, press the OK button or the green Call button on the remote control. Answering a call with the push-button The push-button on the front panel of the unit works as a connect button during an incoming call. When in a call, the push-button toggles between the headset and the internal microphone / loudspeaker.
Page 53: End Call
3.7 End Call How to end a call: Press the red End Call button on the remote control, or Press the Menu button on the remote control to display the menu and select End Call. When the End Call dialog box is displayed either: Press the red End Call button on the remote control again, or Press the OK button to confirm that the call is to be ended.
Page 54: Standby
3.8 Standby The system will automatically go to Standby mode when it is not in use. In standby mode, the screen(s) are black. It is however still possible to receive incoming calls. How to enter standby mode manually: Select Standby from the menu and select Standby Now, or Press the End Call button on the remote control twice.
Page 55: Delay Standby For 1 Hour
TANDBERG 1000 MXP 3.8.1 Delay Standby for 1 hour Delay Standby for 1 hour postpones the system from entering standby mode for 1 hour. This function is useful when using the monitors for a local presentation to prevent the system from automatically blanking the monitors.
Page 56: Delay Standby For 3 Hours
Administrator Settings 3.8.2 Delay Standby for 3 hours Delay Standby for 3 hours postpones the automatic standby mode for 3 hours. This function is useful when using the monitors for a local presentation to prevent the system from automatically blanking the monitors. It is also possible to postpone the system from entering standby mode for 1 hour, see Delay Standby for 1...
Page 57: Do Not Disturb
TANDBERG 1000 MXP 3.8.3 Do Not Disturb To prevent the system from accepting any incoming calls, activate the Do Not Disturb function. The caller will hear a busy tone when calling the system. The monitor will be black when Do Not Disturb is active, see figure below.
Page 58: Phone Book
3.9 Phone Book The Phone Book is available via the Phone Book button on the remote control or from the Make a Call menu. Using the Phone Book is time saving and prevents the user from inadvertently calling the wrong number.
Page 59 The following information is available from the Phone Book: Placed Calls Missed Calls Received Calls My Contacts Global Contacts...
Page 60: Call Log
3.9.1 Call Log The Call Log lists Placed Calls, Missed Calls and Received Calls. That allows the user to see which calls that are made in the past. The lists contain a maximum of 30 numbers and the numbers are stored in these lists until the system is restarted. If the contacts listed are available in the phone book, the names will be displayed instead of the numbers.
Page 61: My Contacts
3.9.2 My Contacts My Contacts are the locally stored contacts on the system. This means that it is possible to add new contacts and edit or delete existing contacts. My Contacts can store up to 200 contacts. How to make a call using My Contacts: 1.
Page 62 Administrator Settings The following functions are available from My Contacts: Call Now New Contact Edit Contact Delete Contact Close...
Page 63 3.9.2.1 Add New Contact The New Contact function is available from Add a new contact to My Contacts by: 1. Select the New Contacts button to open the New Contacts dialog box. 2. Enter Name by using the letter keys on the remote control. Input will automatically be interpreted as letters.
Page 64 3.9.2.2 Edit Contact The Edit Contact function is available from How to edit a contact in the Local Phone Book: 1. Select the contact that is to be edited. 2. Press the left arrow on the remote control, followed by the down arrow until the Edit Contact icon is selected.
Page 65 3.9.2.3 Delete Contact The Delete Contact function is available from How to delete a contact: 1. Select the contact that is to be deleted. 2. Press the left arrow on the remote control, followed by the down arrow until the Delete Contact icon is selected.
Page 66: Global Contacts
Corporate Directory, otherwise the Global Contacts will be displayed. ** The Corporate Directory is available if the system is connected to an external management system like the TANDBERG Management Suite (TMS) and if it is enabled in Phone Book Settings.
Page 67 TANDBERG 1000 MXP 3.9.3.1 Up one Level Global Contacts can be arranged in a tree structure with several sub folders. Use the Up one Level button to navigate up in the tree structure. When a search in the Global Phone Book is made by using the Search function, only contacts matching the search text are displayed.
Page 68 3.9.3.2 Search The phone book can contain an unlimited amount of global contacts. Using search makes it easier to find the wanted contact. How to search in the Global Phone Book: 1. Select the Search icon. 2. Enter search text in the dialogue box that appears and press the OK button on the remote control.
Page 69 3.9.3.3 Copy Contact to My Contacts The Copy Contact to My Contacts function is available from the Placed Calls, Missed Calls, Received Calls and Global Contacts folders, see It may be wise to copy contacts that are often used to My Contacts. Note that the local copy will not be updated if the Global Contacts are updated from the management system.
Page 70: Camera Control
Administrator Settings 3.10 Camera Control Manual Focus The focus on the TANDBERG 1000 MXP can be adjusted manually by rotating the focus ring on the camera lens.
Page 71: Far End Control
3.10.1 Far End Control Far End Control allows you to control your conference partner’s camera. An example of when this feature could be especially helpful is if it is not possible to see what a participant at the far end is writing on their white board.
Page 72: Picture Control
3.10.2 Picture Control Adjust Brightness from 1-98 Brightness Select Monitor Settings and adjust Monitor Brightness from 0-16 Monitor Brightness...
Page 73: Presentation
TANDBERG 1000 MXP 3.11 Presentation The Presentation Functionality in the system enables you to show other available video sources in addition to your Main Camera. This is perfect for meetings where you would like to show a PowerPoint presentation, for example. You can even use arrow keys up and down on the remote control to activate Page Up/Down on the PC (this only applies when using VNC).
Page 74: Presentation Key
3.11.1 Presentation Key The quickest way to show a presentation is to use the presentation key on the remote control. The presentation key is used to start and stop a presentation. The presentation key will display PC (default*). When holding the presentation key for 1 second, the presentation menu will be displayed. This menu allows you to choose other video sources.
Page 75: Presentation Menu
3.11.2 Presentation Menu The Presentation menu offers you all available video sources; Main Camera, PC, Document Camera, VCR, AUX and VNC. All these sources can be used as Main Video Stream or Dual Video Stream (Duo Video / H.239). Not all systems has all video sources available, see for details.
Page 76: Pc Presenter (Dvi/Vga Input)
3.11.3 PC Presenter (DVI/VGA Input) (Optional feature - not available on all systems) Users often have their presentations on a laptop that is brought into the meeting room. Remember to connect your PC to the codec before you press the Presentation button. Note that the image will appear smoother on the system if your presentation is already displaying in full screen on your PC prior to connecting your PC to the video system.
Page 77: Pc Soft Presenter And Vnc
3.11.4 PC Soft Presenter and VNC (Optional feature) PC SoftPresenter is used to display PC images on your system without using a VGA cable (PC Presenter). The system and your PC must be connected to the same LAN. In addition, VNC (Virtual Network Computing) server software must be installed on the PC.
Page 78: Dual Stream
Administrator Settings 3.11.5 Dual Stream (DuoVideo /H.239) (Optional feature - not available on all systems) With Dual Stream you have the opportunity to show two different live video streams simultaneously, main video and one additional source. This is handy when showing a presentation.
Page 79: Take New Snapshot
3.11.6 Take New Snapshot The system can take a snapshot of your live video. Snapshot is handy when you are in a call with a system that does not support Dual Stream. Use Snapshot to show a snapshot of your presentation and continue the meeting with main camera.
Page 80: Display Snapshot
3.11.7 Display Snapshot The system stores the last sent or received Snapshot. The snapshot is deleted automatically after the call. How to display snapshots: 1. To view a stored snapshot, first choose the Snapshot header. 2. Select Display Snapshot in the Presentation menu. 3.
Page 81: Services
3.12 Services A Multipoint Control Unit (MCU) enables several sites to participate in the same conference. During an MCU conference, the status line will provide information about the conference. Services contain the following features: • Request Floor and Release Floor •...
Page 82 Using the system’s internal MCU, MultiSite Most TANDBERG MXP systems have an optional built-in MCU, which is called MultiSite*. It supports up to 6 video calls and 5 telephone calls including yourself for high-end systems, and 4 video calls and 3 telephone calls including yourself for the mid- and lower end systems. The MultiSite supports both Split Screen and Voice Switched mode.
Page 83 Using an external MCU with limited Chair Control Support you may have the following services With an external MCU that does not support H.243, you have the following services: Request/Release Floor Terminal Names * The MultiSIte option is not available on the TANDBERG 550 MXP, TANDBERG 770 MXP and TANDBERG 1000 MXP...
Page 84: Request Floor And Release Floor
3.12.1 Request Floor and Release Floor When requesting floor, your video will be broadcasted in full screen to all other participants in the conference. Request Floor is useful when you want to speak or display something in front of all participants.
Page 85: Conference Layout
Switch between these picture modes using the Conference Layout menu. Continuous Presence layout 4 split Voice Switched mode * The MultiSite option is not available on the TANDBERG 550 MXP, TANDBERG 770 MXP and TANDBERG 1000 MXP...
Page 86: Terminal Names
Administrator Settings 3.12.3 Terminal Names Choose Terminal Names to see a list of the participants of the MultiSite conference. Press Cancel to go back.
Page 87: Chair Control
3.12.4 Chair Control (Not supported by TANDBERG MCU or MultiSite) As chairman, you have access to more MultiSite Services. Select Chair Control to assume the role of chairman of the conference. Select Release Chair to end the role as chairman. A Chair...
Page 88: Assign Floor And Release Floor From Participant
Administrator Settings 3.12.5 Assign Floor and Release Floor from Participant Assign Floor allows the chairman to select which of the conference participants are to be broadcasted to all other participants.
Page 89: View Site And End View
3.12.6 View Site and End View (Not supported by TANDBERG MCU or MultiSite) View Site allows you to view any participant in the conference regardless of who has the floor and chair. Choose End View to go back to normal.
Page 90: Disconnect Participant
Administrator Settings 3.12.7 Disconnect Participant Disconnect Participant allows the chairman to disconnect any participant in the conference. In a multipoint call, this is equivalent to disconnecting a participant from the end call menu.
Page 91: Terminate Meeting
TANDBERG 1000 MXP 3.12.8 Terminate Meeting Terminate Meeting allows the chairman to terminate the conference altogether. In a MultiSite call, this is equivalent to pressing End All Calls from the end call menu.
Page 92: More About Multisite (Embedded Mcu)
Video or H.239 will only receive Main Video or only the dual stream dependent on software options installed. Mix ISDN/IP A conference can consist of any combination of ISDN/IP sites. * The MultiSite option is not available on the TANDBERG 550 MXP, TANDBERG 770 MXP and TANDBERG 1000 MXP...
Page 93: Text Chat
3.12.10 Text Chat While in an ISDN or IP call to another system supporting Text Chat (T.140), select Text Chat the Services Menu. Enter text in the displayed window. How to use Text Chat: 1. Choose Text Chat from the Services Menu to open the Text Chat window. 2.
Page 94: Control Panel
4 Control Panel The Control Panel contains the following features: User Guide Diagnostics Audio Demo Restart Settings* Settings: General Call Quality Security Menu Settings Audio Network Presentation Settings Video Restore Default Settings NOTE: If Administrator Password is On, a Settings button will appear on the menu line together with User Guide, Diagnostics, Audio Demo and Restart.
Page 95: User Guide
TANDBERG 1000 MXP 4.1 User Guide The on screen user guide takes you through a quick step-by-step introduction to the video system. It gives the user basic skills in how to use the system.
Page 96: Diagnostics
4.2 Diagnostics Diagnostics allows testing of individual system components and displays the current system settings. Diagnostics contain: System Information Channel Status Call Status System Selftest View Settings IP Address Conflict Check Warnings...
Page 97: System Information
4.2.1 System Information Select System Information to view system numbers, line status, software version, hardware serial number and other useful information. Press arrow key up and down to scroll in the System Information list. System Information contains: System Name Software Version My ISDN Number Internal Test My IP Number...
Page 98: Channel Status
Normal, unspecified No circuit/channel available Temporary failure Bearer capability not presently available Bearer service not implemented Requested facility not implemented Invalid call reference value Incompatible destination Invalid information element contents Recovery on timer expiry Internetworking, unspecified TANDBERG specific. undefined cause code...
Page 99: Call Status
TANDBERG 1000 MXP 4.2.3 Call Status Comprehensive information about the call is available through the Call Status window. The menu has two columns, one for transmitted and one for received audio/video/data information. If Dual Stream or MultiSite is available on your system and in use, pressing the UP/DOWN keys will show one page per connected site.
Page 100: System Selftest
Administrator Settings 4.2.4 System Selftest The system performs a check to determine internal hardware integrity. System Selftest is useful when you want to check if your network connection is active.
Page 101: View Settings
4.2.5 View Settings This window displays all the system settings. Use the arrow key on the remote control to scroll through the list. View Settings may contain*: General Settings Screen Settings Software Options Menu Settings Presentation Settings VNC Settings Video Quality System Name Language Dual Monitor...
Page 102 Default Call Settings Audio Settings Inputs Level Settings Outputs Level Settings Echo Control Audio Leveling (AGC) Alert Tones & Volume Video Settings Picture Control Document Camera Split Screen Call Type Network Bandwidth Restrict (56k) Auto H320 Bandwidth Auto H323 Bandwidth Mic1 Mic2 Mic3...
Page 103 Video Name Network Type Advanced ISDN Settings ISDN-PRI Settings Channel Hunting Advanced ISDN PRI Settings Leased E1/T1 Settings External network configuration IP Settings Brightness Main Cam Doc Cam ISDN-BRI\PRI\Leased E1\T1\External H331 ISDN Switch Type ETSI (Euro ISDN) Line1 Setup On Number1 Number2 SPID1...
Page 104 H.323 Settings Advanced H.323 Settings IP Precedence Diffserv IEEE802.1x Settings SNMP Settings IP Services Streaming Settings Network Profiles Security Gateway Ethernet Speed DNS Settings E.164 Alias Use Gatekeeper Gatekeeper IP H.323 Prefix RSVP NAT Address Audio Video Data Signaling IP Type of Service (TOS) Audio Video Data...
Page 105 Data Port 1 Data Port 2 * The Settings available will vary within the MXP system range depending on system and what software options installed. Baud rate Parity Data bits Stop bits Mode Baud rate Parity Data bits Stop bits Mode...
Page 106: Ip Address Conflict Check
Administrator Settings 4.2.6 IP Address Conflict Check The system will give a warning if there is an IP conflict. The user may initiate this check by selecting IP Address Conflict Check.
Page 107: Warnings
4.2.7 Warnings Any warnings registered by the system will be displayed in the Warnings menu. Open a warning in the list to get more information about the warning. The following warnings may be displayed if detected by the system, depending on system type and configuration: ISDN BRI warnings ISDN is enabled on BRI line x, but the line is not connected.
Page 108 Administrator Settings There is something wrong with the Leased E1/T1 line (Blue alarm). Please check your network connection. (192) There is something wrong with the Leased E1/T1 line (Yellow alarm). Please check your network connection. (193) H323 gatekeeper warnings Could not register to the gatekeeper. The gatekeeper rejected to register the system.
Page 109: Audio Demo
TANDBERG 1000 MXP 4.3 Audio Demo TANDBERG systems are designed to improve audio quality during a video conference – as if the person is in the same room! Demonstrate the high quality Audio of your system by pressing the Audio Demo button at the...
Page 110: Restart
Administrator Settings 4.4 Restart Restart the system by pressing the Restart button. You are prompted with a dialog box saying: Do you want to restart the system? Press OK to restart, press Cancel (X) to abort.
Page 111: System Settings
5 System Settings The Control Panel contains all the settings of the system. Making changes to the settings will change the behavior of the system. It is recommended to password protect the access to the settings to prevent occasional users from making crucial changes to the system, see Control Panel –...
Page 112: General Settings
5.1 General Settings When installing the system, go through the General Settings menu to ensure that you have the right settings for your system, see System Configuration. General Settings contain: Language System Name / International Auto Answer Phone Book Settings External Service Settings Permissions Screen Settings...
Page 113: Language
TANDBERG 1000 MXP 5.1.1 Language The system supports 16 different languages for its on-screen menus; English, German, French, Norwegian, Swedish, Italian, Spanish, Portuguese, Russian, Finnish, Chinese Simplified, Chinese Traditional, Japanese, Korean, Thai and Arabic. Select the preferred language and press OK to save.
Page 114: System Name
5.1.2 System Name System Name identifies the system: On the welcome page. During an MCU conference call. When using the Web-interface. When the codec is acting as an SNMP Agent. Towards a DHCP server. H323 ID. Other systems can call in using this name instead of IP-number/IP-address. System Name is blank by default.
Page 115: International Name
TANDBERG 1000 MXP 5.1.3 International Name If the System Name contains Asian and non-Latin character text input, the International Name using Latin characters only, must be specified as well. This is in order to make other systems understand the system name.
Page 116: Auto Answer
5.1.4 Auto Answer The auto answer setting decides whether an incoming call is put through automatically or manually. The system will automatically answer all incoming calls. The system will automatically answer all incoming calls and switch the On+Mic microphone off when the call is connected. Press Mic Off to switch the microphone on.
Page 117: Phone Book Settings
5.1.5 Phone Book Settings Corporate Directory The Corporate Directory is available in the menu. The Corporate Directory is hidden from the menu and is unavailable for users. IP address Enter the IP address of the management system that provides the Phone Book. Path The Path indicates the function of the management system.
Page 118: External Services Settings
5.1.6 External Services Settings External Services When set to On External Services are available. When set to Off External Services are unavailable. IP address Enter the IP address of the service provider for External Services. Path Enter the Path to the External Services provider. The services available are defined by the service provider.
Page 119: Permissions
5.1.7 Permissions Permissions contains settings for incoming telephone Calls, Far End Control, Remote Software Upgrade and Fallback to Telephony. Access Code An access code will help you control the use of the system. All users must enter a code to identify themselves and the call will be charged on their account.
Page 120 Fallback to Telephony When dialing a number and the system fails to place a video call to the number dialed, the system will attempt to place a telephone call if Fallback to Telephony is enabled. Enables fallback from video calls to telephone calls. Disables fallback.
Page 121: Screen Settings
5.1.8 Screen Settings Auto Layout If Auto Layout is On the system will change layouts automatically depending on the number of participants in a call and if you have a dual video stream or not. Please refer to Layout for more information. If Auto Layout is Off there will be no automatic layout changes during a call.
Page 122 Pressing the Layout button on the remote will result in an extra picture in Picture in smaller view (Picture in Picture). Press the Layout button to move it around Picture (PIP) in the corners of the screen and finally hide it. Pressing and holding Layout for 1 second will hide the small picture directly from any position.
Page 123 Example of 1+2 Picture outside Picture (wide screen). Example of 1+3 Picture outside Picture (wide screen). Note that the following menu settings do not apply for all TANDBERG MXP systems. Please refer to the actual menu page on your system.
Page 124 Wide screen VGA or TV monitor in Normal (stretched) mode. Wide screen VGA or TV monitor In Wide (native) mode. VGA Out Quality* The supported range of VGA formats will be optimized for the VGA display monitor based on the source image.
Page 125 VGA output will have 4:3 aspect ratio on wide screen monitor. Normal VGA output will utilize the wide screen monitor at full. Wide PC presentation shown in Normal (correct ratio) mode. PC Presentation shown in Wide (stretched) mode. * Not available in TANDBERG 1000 MXP...
Page 126: Software Options
5.1.9 Software Options The system requires a valid option key to activate MultiSite and/or Presenter functionality. In order to activate additional bandwidth, you need to enter a bandwidth key. A restart of the system is required after entering a new option and/or bandwidth keys. If the key is invalid, the original key will be used.
Page 127: Date And Time Settings
5.1.10 Date and Time Settings NTP IP This is the NTP time server address from which the system can get updated time information. IP Services for more details. The NTP IP will be provided by the DHCP server. Auto The NTP IP address is set manually. Manual IP Address The IP Address for obtaining the date and time information.
Page 128: Menu Settings
5.2 Menu Settings Menu Settings contain the settings: Input Editor Language Menu Timeout In Call Balloon Help Number Key Mode Administrator Password Kiosk Mode Settings Startup Icons...
Page 129: Input Editor Language
TANDBERG 1000 MXP 5.2.1 Input Editor Language When the Input Editor Language is set to Chinese, Korean or Japanese the user will be able to enter Chinese / Korean / Japanese characters into an input field like the System Name or Phone...
Page 130: Menu Timeout In Call
5.2.2 Menu Timeout In Call The Menu appears on the bottom line of the screen. Set Menu Timeout In Call to On if you want the menu to time out automatically when you are in a call. The menus will time out automatically after 15 seconds if there is no activity on the remote control.
Page 131: Balloon Help
5.2.3 Balloon Help It is possible to enable / disable the balloon help window. Choose On if you want help text windows to appear. There will be no help text window.
Page 132: Number Key Mode
5.2.4 Number Key Mode When pressing a number key on the remote control, while in a call, the user can decide what shall happen. The system can be configured to act automatic or manual. While in a call, the user presses a number key to: •...
Page 133 Settings for Remote Control Number Keys while in a call: Add Call While in a call, the Call Menu will automatically appear when a number key is pressed on the remote control. This will enable the user to add another call. Touch While in a call, the Touch Tones Mode will automatically become active tones...
Page 134 If you have no stored presets on your system, you are likely not to use presets. Therefore the presets option is not present in the dialog box. Press arrow key to navigate in the list. Press OK on the remote control to select the desired entry. Press a number key while in a call, when having no MultiSite and having stored presets: A dialog box appears offering the options: •...
Page 135: Administrator Password
TANDBERG 1000 MXP 5.2.5 Administrator Password It is recommended to put an Administrator Password on the system. The Administrator Password can be maximum 5 digits long. The Administrator Password dialog box will pop up when you choose Settings from the Control Panel.
Page 136: Kiosk Mode Settings
5.2.6 Kiosk Mode Settings Kiosk Mode In Kiosk Mode the system is set to a simplified state where it can be controlled with just the four arrow keys and OK. You will get a simplified on-screen menu with only basic functionality available: make calls (using predefined contacts in the phone book) receive calls...
Page 137 If Language Menu is enabled you will first see the language selection menu. Select language and the Welcome Menu will be displayed with your desired language. In a call, the system will display Far End video in full screen. If Max Call Length is set to a value and the system is in a call, the system will display a warning when it is 5 minutes, 1 minute and 10 seconds left of the call.
Page 138 Kiosk Mode - Auto Dial* The system will automatically dial to the first contact in the Phone Book when he handset is lifted. If this contact is busy, the system will call the second number in the Phone Book and so on. If the user places the handset in the cradle, the system will switch to Speaker Mode.
Page 139: Startup
Choose On if you want the company logo to appear in the background of the welcome menu. The logo is not displayed. Note: The TANDBERG Logo will be displayed if no other company logo is loaded and logo is enabled. Display Welcome Text The welcome text displays your system name and dial in numbers by default.
Page 140 Administrator Settings Welcome text is not displayed on the welcome menu. Welcome Text You can change the welcome text to any text you like, instead of the default text. Remember that Display Welcome Text must be On to be able to edit the welcome text.
Page 141: Icons
5.2.8 Icons The following indicator icons may be set to on or off: Mic Off Volume Off On Air Encryption Bad Network Telephone DuoVideo/H.239 On-screen Indicators for details.
Page 142: Presentation Settings
5.3 Presentation Settings Presentation Settings contain: H.239 Startup Video Source Presentation Source Snapshot Source Auto-Display Snapshot PIP Placing Presentation Rate VNC Settings...
Page 143: Presentation Start
5.3.1 Presentation Start If your system has Dual Stream capabilities, you can show two video streams at the same time (see also Dual Stream). Presentation Start is Auto by default. This means that you will start Dual Stream (a second video stream) automatically when starting a presentation. Dual Stream requires the Presenter Option and H.263 video.
Page 144: H.239
5.3.2 H.239 H.239 supports transmission of two video streams. It combines elements of Duo Video and People+Content. If H.239 is disabled you will still be able to start TANDBERG Dual Video Stream* Enables H.239 Enabled Disables H.239 Disabled * The TANDBERG 550 MXP can only receive Dual Video Stream.
Page 145: Startup Video Source
TANDBERG 1000 MXP 5.3.3 Startup Video Source The Startup Video Source is the video source on display when the system wakes up from standby mode. If you use Main Camera as start up source, the system will start with Main Camera every time the system wakes up from standby, regardless of what the previous user was using.
Page 146: Presentation Source
Administrator Settings 5.3.4 Presentation Source The Presentation Source is connected to the Presentation button on the remote. Pressing the Presentation button will put the Presentation Source on display. Presentation Source is PC by default*. You can change the Presentation Source to any video source and none. Choosing none results in opening the Presentation menu when pressing the Presentation key.
Page 147: Snapshot Source
TANDBERG 1000 MXP 5.3.5 Snapshot Source When you take a Snapshot, you get a snapshot of the Snapshot Source. Current is the default Snapshot Source. This means that you take a snapshot of the video source that is currently active.
Page 148: Auto-Display Snapshot
5.3.6 Auto-Display Snapshot Select Auto to automatically display a received snapshot. Turn Auto-Display Snapshot Manual if you wish not to have them displayed on the screen when they are sent or received. The snapshots will be sent and received, but not displayed. With Auto-Display Snapshot set for Manual, you must enter the Presentation menu to display a snapshot.
Page 149: Pip Placing
5.3.7 PIP Placing PIP Placing lets you decide where the PIP shall appear. You can of course move the PIP with the Layout button on the remote anytime. PIP is placed in the Top Right corner. Top Right PIP is placed in the Bottom Right corner. Bottom Right PIP is placed in the Bottom Left corner.
Page 150: Presentation Rate
Administrator Settings 5.3.8 Presentation Rate When setting up a call with H.323 the bandwidth can be controlled by the user. The Presentation Rate is expressed in percent of the Call Rate and shall reflect the H.323 Presentation Rate settings of the sender. The settings are 25%, 50% and 75% of the total available video stream.
Page 151: Vnc Settings
5.3.9 VNC Settings VNC Settings is necessary when using a VNC presentation. See chapter for more information on how to use VNC. The IP-address of the PC with the VNC software installed. To find the IP- Address address of the PC, place the mouse pointer on the VNC program icon in the lower right corner of the Windows taskbar.
Page 152: Call Quality
5.4 Call Quality Call Quality contains the settings: Video Algorithm Audio Algorithm Max Upstream Rate Video Quality Default Call Settings...
Page 153: Video Algorithm
5.4.1 Video Algorithm The system will automatically select the best video algorithm based on the video source and the capabilities of the remote system. Use this menu to disable video algorithms in case you have interoperability issues calling other systems. Bandwidth efficient video compression and decompression.
Page 154: Audio Algorithm
* G.722 at 64kbps is used in H.323 (IP) calls only. ** G.711 at 64kbps is used in SIP and H.323 (IP) calls only. *** Dependent on a call rate above the AAC-LD 128 threshold. Note that this is not available on all TANDBERG systems.
Page 155: Max Upstream Rate (Kbps)
TANDBERG 1000 MXP 5.4.3 Max Upstream Rate (kbps) The Max Upstream Rate (kbps) defines the desired maximum transmitted call rate. This is to be able to limit the outgoing bandwidth whilst keeping the maximum incoming bandwidth, especially useful for home offices with different upstream and downstream rates, typically ADSL.
Page 156: Video Quality
5.4.4 Video Quality The different video sources need different Video Quality Settings. Main Camera, VCR, AUX and Split Screen have Motion as default. PC, Document Camera and VNC have Sharpness as default. Optimized for smooth motion video (CIF/SIF or w288p for low bandwidths, Motion* 448p/400p, Interlaced CIF (iCIF) / Interlaced SIF (iSIF) or w448p for high bandwidths).
Page 157: Native Resolutions
Sharpness*: Improved quality of detailed images and graphics, lower frame rate, ideal for enhancing quality at lower bandwidths. 4CIF will be used from a PAL video input, Digital Clarity 4SIF from NTSC, Digital Clarity w720p will be used from a wide format (HD720p) input VGA/SVGA/XGA from PC, Digital Clarity IVM Resolution The following table shows relationship between Transmission modes selected by the system...
Page 158 (768 x 448 pixels) w576p (1024 x 576 pixels) w720p (1280 x 720 pixels) * Note that the TANDBERG 550 MXP and the TANDBERG 1000 MXP do not transmit the following video formats: 448p, 400p, iCIF, iSIF, w288p, w448p, w576p, and w720p.
Page 159: Call Settings
5.4.5 Call Settings Default Call Settings are connected with unchanged when making a call, the system will use the default Call Settings in the call. In addition to the Call Settings Call Type, Net, Bandwidth and Restrict (56k), you also find settings for H.320 Auto bandwidth and H.323 Auto bandwidth in Call Settings.
Page 160 Bandwidth decides the quality of the video picture. Bandwidth When set to Auto the system will establish a connection using a proper bandwidth for the call, typically 384kbps for ISDN calls and 768kbps for IP calls. When set to Max the system will set up the call with maximum bandwidth depending on the selected network.
Page 161 TANDBERG 1000 MXP Sub-address is used to address different systems on the same ISDN line and is primarily used in European Countries. LAN equivalent extension address or TCS-4 is used to address different systems on a LAN, when dialing via a gateway.
Page 162: Audio
5.5 Audio Audio contains the settings: Headset Level Settings Alert Tones and Volume...
Page 163: Headset Level Settings
It is possible to adjust the audio output level to the headset loudspeakers. Note that the TANDBERG 1000 MXP has separate volume settings for loudspeaker and headset output. The volume keys on the remote control also adjust the level of the headset output when the headset is activated by pressing the push-button, without changing the volume setting you have for the loudspeaker.
Page 164: Alert Tones And Volume
5.5.2 Alert Tones and Volume Video Call Alert Tone and Telephone Alert Tone To help distinguish between incoming video calls and ordinary telephone calls, it is recommended to use different ringing tones for video calls and telephone calls. Alert Volume You may change the volume level for the selected ringing tone.
Page 165: Video
5.6 Video Video contains the settings: MCU Status Line Web Snapshots Video Name...
Page 166: Mcu Status Line
5.6.1 MCU Status Line The MCU / DuoVideo indicator will be displayed and provide information about the conference. The MCU / DuoVideo indicator will not be displayed. The MCU / DuoVideo indicator will be displayed for a few seconds and then timed Auto out.
Page 167: Web Snapshots
5.6.2 Web Snapshots The system is able to generate JPEG snapshots and provide them when requested (as ‘http get’ or via ftp). See Appendix 6 for descriptions of the possible snapshot files. Snapshots generation is enabled. Snapshots generation is disabled. Note that web snapshots are not generated if the conference is encrypted.
Page 168: Video Name
Administrator Settings 5.6.3 Video Name As a default, the video inputs are given the names Main Cam, PC, Doc Cam, VCR, AUX or VNC, dependent on what video sources are available on your system. The video names cannot exceed eight characters. The names correspond to the video names in the Presentation Menu (Choose Presentation from the Menu and open the Main Video or Presentation Video pop up menu).
Page 169: Security
5.7 Security Security contains the settings: Encryption Encryption Mode Passwords...
Page 170: Encryption
5.7.1 Encryption (Country specific) The system will try to set up calls using encryption. Auto Point to point calls: If the far end system supports encryption (AES or DES), the call will be encrypted. If not, the call will proceed without encryption. MultiSite calls*: In order to have encrypted MultiSite calls, all sites must support encryption.
Page 171: Encryption Mode
5.7.2 Encryption Mode The system will try to use the most secure encryption - AES, dependent on the Auto capabilities of the other sites. For sites that do not support AES encryption, DES encryption will be tried. The system will try to use AES with 128 bits encryption when setting up calls. If AES is not supported by the other site(s), no other type of encryption will be initiated.
Page 172: Passwords
Administrator Settings 5.7.3 Passwords Administrator Password, IP Access Password, Streaming Password, VNC Password, Access Code and Remote Software Upgrade password are duplicated from their respective menus. Using the Security menu gives you a quick way to change all passwords of the system.
Page 173: Network
5.8 Network The network menu contain: ISDN-BRI Settings LAN Settings Network Profiles...
Page 174: Isdn-Bri Settings
5.8.1 ISDN-BRI Settings To make sure your system will work properly using ISDN-BRI, make the following settings: 1. Set ISDN switch type 2. Enter ISDN line numbers (and SPIDs, if required) 3. Disable unused lines Some software versions do not support 6 ISDN lines, therefore some of the Line Setup entries may be grayed out.
Page 175 Advanced ISDN Settings Sub address Using a sub address enables you to connect up to eight ISDN terminals to the same ISDN telephone number and line. The terminals are addressed by using different sub addresses. To call a terminal with a sub address, separate the ISDN telephone number and the sub address with a ‘*’.
Page 176: Lan Settings
5.8.2 LAN Settings LAN Settings contain: IP Settings H.323 Settings SIP Settings Wireless LAN Settings SNMP Settings IP Services Quality of Service 802.1X Settings...
Page 177: Ip Settings
5.8.2.1 IP Settings Remember to restart the system after making changes to IP Settings. This can be done by selecting the “Save and Restart” at the bottom of the IP setting menu. Changes in IP Settings menu will not have any effect until the system is restarted. IP Protocol IP version 4 supported.
Page 178 100 Mbps speed/Half Duplex. 100/Half 100 Mbps speed/Full Duplex. 100/Full IP Access Password By setting an IP Access Password on the system, all access to the system using IP (Telnet, FTP and WEB) requires a password. The default IP Access Password is “TANDBERG”.
Page 179 TANDBERG 1000 MXP DNS Settings DNS Server 1-5 DNS Server defines the network addresses for DNS servers. Up to 5 addresses may be specified. If the network addresses are unknown, please contact your administrator or Internet Service Provider. DNS Domain Name DNS Domain Name is the default domain name suffix which is added to unqualified names.
Page 180 5.8.2.2 H.323 Settings E.164 alias This is the E.164 address of the system. The E.164 address is equivalent to a telephone number, sometimes combined with access codes. Valid characters are 0-9,* and #. When using a gatekeeper, the system will send a message to the gatekeeper containing both the E.164 address and the H.323 ID of the system.
Page 181 This is the gatekeeper IP-address that is used if you specify H.323 Call Setup: Gatekeeper and Gatekeeper Discovery: Manual. Note that if your system is part of a TANDBERG Expressway™ firewall traversal solution and is placed outside the firewall, you should register the IP address of your Border Controller as the Gatekeeper IP address and set H.323 Call Setup to Gatekeeper.
Page 182 Administrator Settings Multiple H.323 Aliases is set to Off. If set to Off, the system will register a single H.323-IDs on the Gatekeeper based on the following priority: • H.323 ID • International Name • System Name The default setting for Multiple H.323 Aliases is Off.
Page 183 TANDBERG 1000 MXP CallManager Settings CallManager IP This is the CallManager IP-address that is used if you specify H.323 Call Setup: CallManager.
Page 184 Port 1720 Port 5555- 5560 Port 2326- 2365 Please contact your TANDBERG representative for further information. RSVP Resource Reservation Protocol enables the systems to request the optimal amount Auto of bandwidth for the duration of an IP videoconference. Resource Reservation Protocol is switched off.
Page 185 H.323 Ports When selecting static H.323 ports for TCP connections the ports 5555 to 5574 Static will be used for Q.931 and H.245 respectively. The system will allocate which ports to use when opening a TCP connection. Dynamic The reason for doing this is to avoid using the same ports for subsequent calls as some firewall consider this as a sign of attack.
Page 186: Sip Settings
5.8.2.3 SIP Settings Mode Setting the SIP mode to on will enable the system for incoming and outgoing SIP calls. Setting the SIP mode to off will disable incoming and outgoing SIP calls from the system. Display Name The Display name part of the SIP Address (URI) is usually a full name or system name. Examples: “Alice Wonderland”...
Page 187 Server Address The Server Address is the manually configured address for the outbound proxy and registrar. It is possible to use a fully qualified domain name, or an IP address. The default port is 5060 for TCP and UDP, but another one can be provided. Server Address: <text field>...
Page 188 Draft-ietf-avt-rfc2032-bis-06.txt - Draft for advanced video signaling including resolution and mpi. RFC 2190 RTP Payload Format for H.263 Video Streams RFC 2429 RTP Payload Format for the 1998 Version of ITU-T Rec. H.263 Video (H.263+) Draft-ietf-avt-rfc2429-bis-05.txt - Draft for advanced video signaling including resolution, mpi, annexes and custom formats.
Page 189: Wireless Lan Settings
5.8.2.4 Wireless LAN Settings SSID (Service Set Identification) Example “WLANNETWORK”. Defines a local network id for this wireless region. It must be the same for all end points and the access point. An endpoint will find the access point if the SSID is correct, however if the encryption key is faulty it will not transmit any data.
Page 190 Select which of the keys shown below you want to use. Use Key The 64-bit keys can consist of a leading star (*) and 5 characters. Key 1-4 The 128-bit key can consist of a leading star (*) and 13 characters. Start with a * and then the text.
Page 191: Snmp Settings
TANDBERG 1000 MXP 5.8.2.5 SNMP Settings SNMP Settings SNMP Trap Host identifies the IP-address of the SNMP manager. SNMP (Simple Network Management Protocol, SNMP Ver 1) is used for monitoring and configuring of different entities in a network. The system's SNMP Agent responds to requests from SNMP Managers (a PC program etc.).
Page 192 Administrator Settings 5.8.2.6 IP Services NTP IP This is the NTP time server address from which the system can get updated time information. This is a requirement for proper operation if H.235 authentication is implemented. The Network Time Protocol (NTP) is used to synchronize the time of the system to a reference time server.
Page 193 5.8.2.7 Quality of Service QoS Type No QoS is used. Diffserv QoS method is used. Please see below for details. Diffserv IP Precedence QoS method is used. Please see below for details. Precedence IP Precedence Video Used to define which priority audio, video, data and signaling should have in the network. The higher the number, the higher the priority.
Page 194 Administrator Settings Auto will provide the following priority: Audio Diffserv Video Used to define which priority Audio, Video, Data and Signaling packets should have in an IP network. The priority ranges from 0 to 63 for each type of packets. Diffserv Telephony Used to define which priority Audio packets should have in an IP network for telephone calls.
Page 195 5.8.2.8 IEEE 802.1x 802.1X The system may be connected to an IEEE 802.1x LAN network. Supported 802.1x protocols are EAP-MD5, EAP-PEAP and EAP-TTLS. The 802.1x authentication are enabled by setting 802.1x Mode to On. 802.1x authentication enabled 802.1x authentication disabled Anonymous Identity The 802.1x Anonymous ID string is to be used as unencrypted identity with EAP types that support different tunneled identity, EAP-PEAP and EAP-TTLS.
Page 196: Network Profiles
Administrator Settings 5.8.3 Network Profiles This menu consists of 7 network profiles; a prefix and a suffix can be added for each profile. If you add a prefix/suffix to a profile, this prefix/suffix will automatically be added in front/back of the number being dialed.
Page 197: Restore Default Settings
5.8.4 Restore Default Settings Restore Default Settings will restore all system settings. Note that this will not affect your Call Directory information, Network Type, Line Setup numbers or your SPID numbers. Note that when holding the headset / speaker button while turning on the power, and while the notification lamp is flashing, it is possible to press: The number button 1 to restore default values.
Page 198: Peripheral Equipment
Codec. Peripheral Equipment contains: Interfaces Document Camera VCR / DVD Additional Cameras Additional Microphones TANDBERG DNAM and Speakers Stereo Speaker Kit Telephone Add-On Dual Monitor XGA Monitors and Projectors VESA Display Power Management Digital Monitor Power Management...
Page 199: Interfaces
DVI stands for Digital Video Interface, and is a form of video interface technology made to maximize the quality of flat panel LCD monitors and high-end video graphics cards. DVI Specifications TANDBERG DVI-I follows the VESA Monitor Timing Standard v1.08, also knows as Display Monitor Timing (DMT).
Page 200 Supported DVI cables: TANDBERG supports DVI-D Single-Link, DVI-A and DVI-I Single-Link format cables. DVI-D cables transmit digital T.M.D.S. signals, DVI-A cables transmit analog VGA signals and DVI-I cables can transmit either digital or analog signals. It is possible to extend existing DVI cables by the use of extension cables. The maximum cable length however, is 5 meters.
Page 201 The TANDBERG 6000 MXP Profile and 3000 MXP Profile* systems are shipped with a PC cable with integrated audio: DVI-A Plug + 2*RCA Plug to VGA Plug + 3.5mm Stereo Plug, length 6m. PC cable, VGA - DVI with integrated audio Signal name CON.
Page 202 RGB Return Outer Shield Shell Ground Audio Left Audio Right Audio GND PC cable, VGA - DVI with integrated audio * Applies to T3000 MXP Profile with new hardware. 6, 7, 8 Shell Centre Ring Centre Sleeve RGB Coax Shield Outer Shield Audio Black Audio Red...
Page 203 HDD 15P Dust Cover PE Mold [A2T0225] Dust Cover DVI Dust Cover PE Mold [A2E1544] * The TANDBERG 550MXP and TANDBERG 770 MXP do not support VGA in, but the endpoint can be setup to support VGA out for a monitor...
Page 204: Audio
Headsets with the microphone positioned in front of the user’s mouth, connected to the earphone through a rod, tend to give more echo than earbud headsets with the microphone attached to the cord. TANDBERG recommends the Plantronics MX100 headset (www.plantronics.com, products → mobile).
Page 205: Network
Network Ethernet: 1 x Ethernet (RJ-45 Jack) LAN interface (10/100 Mb) up to 768kbps To connect the system to a LAN, use the Ethernet cable provided by TANDBERG (or a standard Ethernet cable). The cable specification is: 1 ------------ 1...
Page 206: Document Camera
6.2 Document Camera A document camera can be used for showing text, diagrams and a variety of graphical material as well as small three-dimensional objects. How to use a document camera with your system: 1. Connect the document camera to the Doc Cam input, if available, on the system. 2.
Page 207: Dvd / Vcr
TANDBERG 1000 MXP 6.3 DVD / VCR DVD/VCR Playback Mono For playback, connect a cable between Video Out on the VCR and Video In (VCR) on the system. Connect a cable between Audio Out on the VCR and the Audio In (VCR) on the system.
Page 208: Additional Cameras
Peripheral Equipment 6.4 Additional Cameras Extra fixed Cameras You can connect extra fixed cameras to your system, for example, a whiteboard camera. Connect the video output of the additional camera to one of the available Video inputs on the system. Note that additional controllable cameras are only available for some roll-about systems.
Page 209: Additional Microphones
TANDBERG 1000 MXP 6.5 Additional Microphones If your environment is such that you require more than one microphone for your room, e.g. you have a whiteboard at a distance from your table microphone, it is possible to connect additional microphones to your system. See Appendix 4 for more information.
Page 210: The Tandberg Dnam And Speakers
6.6 The TANDBERG DNAM and Speakers TANDBERG 6000 MXP Profile, TANDBERG 6000 MXP, TANDBERG 7000 MXP, TANDBERG 8000 MXP and TANDBERG Maestro The TANDBERG Digital Natural Audio Module, DNAM*: The DNAM audiosystem is built on two specially designed and separate modules; the DNAM audio amplifier and the DNAM loudspeaker cabinet.
Page 211 The DNAM Amplifier*: 3 x 50W continuous average Center Output Power (load specified by DNAM Center Speakers). 2 x 50W continuous average Stereo Output Power (load specified by TANDBERG Loudspeaker Stereo Kit). Full dynamic range for audio (high fidelity range) Digital Signal Processing and Filtering on all channels for best audio detail clarity Digital Crossover Filtering on center channels.
Page 212 DNAM amplifier and the Mini-DNAM loudspeaker cabinet. The Mini-DNAM loudspeaker cabinet is stereo-configured and based on two versions made for fitting both the TANDBERG 3000 Profile 43’’ and 32’’ systems. The compact sized amplifier is mounted in the rear of the speaker cabinet.
Page 213 *Note that there are different solutions on integrated audio modules and speakers included in the larger high-end TANDBERG systems. Please contact your TANDBERG representative for more information. ** These are available with the TANDBERG 3000 MXP Profile and TANDBERG 6000 MXP Profile only.
Page 214: Stereo Speaker Kit
Stereo Speaker Kit. Note that if stereo speakers are enabled in the menu without having any stereo speakers connected to the Digital NAM, or having other speakers than the TANDBERG stereo speakers, it may cause the acoustic echo-canceller to malfunction.
Page 215 TANDBERG 1000 MXP...
Page 216: Telephone Add-On
6.8 Telephone Add-On The system has a built in audio bridge* that can bring in Voice over IP (VoIP) telephony or normal telephone sites using ISDN. Note that this requires a system with mixed audio output (audio from local and far end) and one audio input without integrated echo cancelling.
Page 217: Dual Monitor
TANDBERG 1000 MXP 6.9 Dual Monitor Note that this requires a system with dual monitor video output.
Page 218: Xga Monitors And Projectors
6.10 XGA Monitors and Projectors (Optional) Some TANDBERG systems can be delivered with optional single or dual TV/XGA monitors. It can also be connected to any DVI/VGA/PAL or NTSC display. Note that this requires a system with minimum one DVI-I output.
Page 219: Vesa Display Power Management
In Off mode some power may still be drawn in order to power indicator lights etc. EDID contains the information on which mode a specific monitor supports. TANDBERG supports all four modes. However, in F1 and above, all monitors not listed below are automatically set to Off.
Page 220: Digital Monitor Power Management
DMPM in software F2 and above. Six monitor power states are defined. Monitor On Power state Transmitter (TANDBERG codec) and receiver (Monitor) are powered and active. This power state is equivalent with the DPMS normal mode. Intermediate Power state...
Page 221: Extended Display Identification Data (Edid)
This standard contains information on product ID, basic display parameters, timing identifications and detailed timing descriptions. In F1 and above, TANDBERG will use the EDID information to decide which resolution to use, 800x600 @ 75Hz or 1024x768 @ 60Hz. Example (1024x768@60Hz)
Page 222 Peripheral Equipment Tested and verified monitors, EDID & Timing Listed below are some of the monitors TANDBERG have tested and verified against: ADI A715 Dell W1700 Dell W1900 EIZO L367 EIZO F730 ErgoScan 400S Hitachi CM640ET Hitachi CM769ET IBM 9494-HBO...
Page 223: Appendices
Appendix 8: Connecting the system to PRI/T1 Appendix 9: Connecting the system to the Switched 56 network Appendix 10: Connecting the system to ISDN using NT1 network adapters Appendix 11: TANDBERG Cameras Appendix 12: Remote control Appendix 13: Cisco CallManager registration...
Page 224: Appendix 1: Technical Specification
Auto or manual brightness BANDWIDTH H.320 up to 384 kbps H.323 up to 768 kbps SIP up to 768 kbps FIREWALL TRAVERSAL TANDBERG Expressway TechnologyTM Auto NAT H.460.18, H.460.19 Firewall Traversal VIDEO STANDARDS H.261, H.263, H.263+, H.264 VIDEO FEATURES Intelligent Video Management...
Page 225 Dual Monitor Emulation (Side by Side) Streaming compatible with Cisco IP/TV, Apple QuickTime®, RealPlayer® v8 etc. SYSTEM MANAGEMENT Support for the TANDBERG Management Suite Total management via embedded web server, SNMP, Telnet, SSH, FTP and SOAP Remote software upload: via web server, ftp server or...
Page 226 System features vary depending on network selection and software package. All specifications are subject to change without notice. TANDBERG is a registered trademark or trademark of TANDBERG in the U.S. and other countries. RealPlayer is a trademark or a registered trademark of RealNetworks, Inc. QuickTime is a registered trademark of Apple Computer, Inc., registered in the U.S.
Page 227: Appendix 2: Bandwidth Information For Tandberg Endpoints
Appendix 2: Bandwidth Information for TANDBERG Endpoints Bandwidth information for TANDBERG endpoints Model Bandwidth Point to point ISDN / IP MultiSite Rate Matching Dual Stream (DuoVideo / H.239) Secure Conference H.264 Picture Mode MultiSite Model Bandwidth Point to point ISDN / IP...
Page 228 H.264 Picture Mode MultiSite Model Bandwidth Point to point ISDN / IP MultiSite Rate Matching Dual Stream (DuoVideo / H.239) Secure Conference H.264 Picture Mode MultiSite Model Bandwidth Point to point ISDN / IP MultiSite Rate Matching Dual Stream (DuoVideo / H.239) Secure Conference H.264...
Page 229: Appendix 3: Environmental Considerations
Appendix 3: Environmental Considerations Environmental considerations This section explains how to carry out basic adjustments and simple tests to ensure that you send and receive the best possible image and audio quality when using your system. Iris control and lighting By default the system camera will use an automatic iris to compensate for changes in lighting.
Page 230: Appendix 4: Guidelines For Setting Up Rooms For Video Meetings
Appendix 4: Guidelines for Setting up Rooms for Video Meetings Guidelines for setting up rooms for video meetings The following are a set of guidelines to consider when either building a video meeting room, or using an existing room for video meeting. Lighting: Low Contrast desired for light intensity.
Page 231 TANDBERG 1000 MXP How to prepare a typical room for video meetings: The illustration below shows the principles of a typical room designed to obtain the best results when using a video meeting system. If the system has a separate microphone, it should be placed at the front of the table to ensure that all speech will be detected.
Page 232: Appendix 5: Security
Appendix 5: Security Security The system has several features both to protect from unauthorized use and system access: Access Code: When Access Code is enabled, the user will be asked to enter an access code before he/she is able to make a call. The system will verify if the entered access code is valid by checking the code with the allowed codes listed in the access.txt file on the ftp-server in the system.
Page 233 All TANDBERG systems support both AES and DES encryption. By default this feature is enabled such that when connecting with any other video system or MCU, a TANDBERG system will attempt to establish a secure conference using AES or DES encryption. The TANDBERG system will attempt this for both IP and ISDN connections.
Page 234 Diffie Hellman key distribution via H.320, H.323 and Leased Line connections. The TANDBERG AES implementation is validated as conforming to the Advanced Encryption Standard (AES) Algorithm, as specified in Federal Information Processing Standard Publication 197, Advanced Encryption Standard, by The National Institute of Standards and Technology (NIST).
Page 235: Appendix 6: Using The File System
Appendix 6: Using the File System Using the file system It is possible to access a file system within the TANDBERG system by using ftp: DOS- ftp <IP-address of system>, or window: Web- ftp:// <IP-address of system> browser: Description of the different files: all.prm...
Page 236: Appendix 7: Web Interface
3. Start your Web-browser. In the address field type the IP-address of the system. Enter the password and the Web-page of the system will be shown. The default password is TANDBERG. 4. Restart the system. Choose Restart from the Control Panel.
Page 237: Appendix 8: Connecting The System To Pri/T1
Appendix 8: Connecting the System to PRI/T1 (Not available on all TANDBERG systems) Connecting the system to PRI/T1 Using CSU adapter Connecting the system to the ISDN network via the E1/T1-interface using an Adtran T1 ESF CSU ACE or equivalent CSU, will allow up to 1.54 Mbps connection. The E1/T1-interface must be connected to a CSU approved according to IEC 60950, UL 1950 or equivalent standard.
Page 238: Appendix 9: Connecting The System To The Switched 56 Network
Appendix 9: Connecting the System to the Switched 56 Network Connecting the system to the Switched 56 network Using Telesync TS-256 SW56/ISDN adapter Connecting the system to the SW56 network using a Telesync Adapter is described below. There are different Telesync Adapters for different configurations of SW56 networks. The network types tested with the system are SW56 2Wire and 4Wire.
Page 239: Appendix 10: Connecting The System To Isdn Using Nt1 Network Adapters
TANDBERG 1000 MXP Appendix 10: Connecting the System to ISDN using NT1 Network Adapters Connecting the system to ISDN using NT1 network adapters Connecting Connect the first ISDN cable from ISDN 1 on the system to the S-interface on your first NT1 network adapter.
Page 240 Appendices...
Page 241: Appendix 11: Tandberg Cameras
TANDBERG 1000 MXP Appendix 11: TANDBERG Cameras TANDBERG Precision HD Camera (Available to TANDBERG 8000 MXP, 6000 MXP Profile, 3000 MXP Profile*, Maestro MXP and Edge 75/85/95 MXP) Pin-outs and Connectors 1. Extra Camera In...
Page 242 4. Codec – HD Video Out 5. Kensington Lock NOTE! The enclosed TANDBERG Camera Cables must be used! Do not use other camera cables as this might cause problems with the transfer of video signals from the Precision HD Camera.
Page 243 The maximum length of the camera cable for multiple cameras supported by TANDBERG is 20 m (65 ft). * Applies to T3000 MXP Profile with new hardware. ** Disabled when connected to a TANDBERG system using the TANDBERG Camera Cable. This output does not support HDCP (High Bandwidth Digital Content Protection). Precision HD Camera Dimensions:...
Page 244 Appendices Top view:...
Page 245: Wave Ii Camera
(Not available with TANDBERG 1000 MXP and set top systems) WAVE II Camera Pinouts and Connectors 8-PIN RJ (shielded modular jack): This connector is used for the power and control signals to the main camera. Pin-8 +12V (presence when connected in...
Page 246 Pin-5 Pin-4 RXD (in) Pin-3 TXD (out) Pin-2 Presence (+12V in daisy chain) Pin-1...
Page 247 TANDBERG 1000 MXP Dimensions Front view: Rear view: Side view: Underside view:...
Page 248: Appendix 12: Remote Control (Trc3 / Trc4)
Appendix 12: Remote Control (TRC3 / TRC4) Remote Control (TRC3 / TRC4) The TANDBERG remote control transmits IR-signals using the following parameters: Protocol Siemens SDA2208 Reference frequency 485kHz Address 4 & 7 IR wavelength 940nm IR carrier frequency 30kHz...
Page 249 NUMBER 2 NUMBER 3 NUMBER 4 NUMBER 5 NUMBER 6 NUMBER 7 NUMBER 8 NUMBER 9 NUMBER 0 PRESENTER ZOOM OUT ZOOM IN VOLUME DOWN DOWN VOLUME UP MIC OFF DOWN DOWN LEFT LEFT RIGHT RIGHT TANDBERG TRACKER Address Button name...
Page 250 CALL END CALL PHONE BOOK MENU CANCEL LAYOUT WAKE UP LOW BATT PROG VER CALL END CALL PHONE BOOK MENU CANCEL LAYOUT MAIN CAM DOC CAM HELP FAR END PRESETS SERVICES WAKE UP LOW BATT PROG VER...
Page 251: Appendix 13: Cisco Callmanager Registration
2. The Phone configuration page is located on: device (top menu) -> Add a New device -> Phone -> H.323 Client. 3. In the phone configuration page type the IP address of the TANDBERG system in the Device name field, select device pool and push the insert button.
Page 252: Appendix 14: Diagnostic Tools For Ip
Appendix 14: Diagnostic Tools for IP Diagnostic Tools for IP To use these tools, will require using a PC and setting up a telnet session towards the system. Q.931 To show Q.931 trace during a call you need to issue the command ‘syslog on’. One can get traces for RAS, Q.931 and H.245 with this command.
Page 253 Function Gatekeeper Discovery (RAS) Q.931 Call Setup H.245 Video Audio Data/FECC Point-to-point + Duo Video Function Gatekeeper Discovery (RAS) Q.931 Call Setup H.245* Video Audio Data/FECC MultiSite + Duo Video (*) Note: While using MultiSite, if a site is disconnected and reconnected without terminating the entire conference, the next site to be connected will have a H.245 port outside of the specified range.
Page 254: Appendix 15: System Upgrade
Using ISDN A) To upgrade using the the web interface, please do the following steps: 1. Type the IP address of the TANDBERG MXP system that shall be upgraded (for instance 10.0.8.77) in a standard browser, such as Internet Explorer 6.0.
Page 255 TANDBERG 1000 MXP The following page will now be displayed: Figure 1 3. Enter the Release key in the ‘Release Key’ field and press the ‘Install Software’ button.
Page 256 1. Copy the new software file to a folder on your harddisk, for instance c:\software. 2. Open a DOS window, and go to the folder where the new software is stored. 3. Type ftp <ip address of the TANDBERG MXP system>. 4. Type in the supplied ‘Release Key’ as user.
Page 257 2. Copy the new software file to a folder on your computer, for instance c:\software. 3. Type the IP address of the TANDBERG MXP system that the software upgrade is going to be done from (for instance 10.0.8.77) in a standard browser, such as Internet Explorer 6.0. The web interface of the codec will then be displayed.
Page 258 Settings/General/Permissions menu. 7. Enter the password set at the far end for remote upgrade (default password is “TANDBERG”) 8. Press ‘Install Software' .The system will now use about 90% of the call capacity to transfer the software file across.
Page 259: Appendix 16: Declaration Of Conformity
EN 61000-3-3 : 1995, A1 TBR 3 Layer 1, 2 and 3 TECHNICAL CONSTRUCTION FILE NO.: X13677 YEAR WHICH THE CE-MARK WAS AFFIXED: 2005 For an official, signed version of this document, or details regarding documentation from the technical construction file, please contact TANDBERG.
Page 260: Appendix 18: Protocols Supported
(Max. number of simultaneous connection = 8, in addition to the RS232 connection). TELNET Challenge TMS (Tandberg Management Suite) uses MD5-Challenge Response algorithm (RFC-1321) Telnet access for encryption of password over the IP network. SNMP - Simple Network Management Protocol A standard network protocol for management and surveillance of TCP/IP networks (RFC 1157 SNMP v1, RFC 1213 MIB-II).
Page 261 TANDBERG 1000 MXP WAN – Wide Area Network A communications network connecting geographically separated computers, printers, and other devices. SSL - Secure Sockets Layer SSL is a proposed open standard for establishing a secure communications channel to prevent the interception of critical information.
Page 262: Appendix 19: Cable Specifications
Appendix 19: Cable Specifications TANDBERG MXP and Classic Endpoints that support External Network External Network Pinout With respect to signals on the NET port: • For balanced signals a “0”=low voltage is defined as terminal A positive with respect to terminal B.
Page 263 Cable Specification V.35 Cable TANDBERG MXP and Classic Endpoints that support External Network • Connector on cable at Codec end: Female 26 pin high-density DSUB with thumbscrews. • Connectors on cable at V.35-adapter end: Male 34 pin Winchester (AMP part number 201357-1 or equivalent).
Page 264 Cable Specification V.35/RS-366 Cable TANDBERG MXP and Classic Endpoints that support External Network • Connector on cable at Codec end: Female 26 pin high-density DSUB with thumbscrews. • Connectors on cable at V.35-adapter end: Male 34 pin Winchester (AMP part number 201357-1 or equivalent) and Male 25 pin DSUB with thumbscrews.
Page 265 Cable Specification RS-449 Cable TANDBERG MXP and Classic Endpoints that support External Network • Connector on Tandberg End: Female 26pin High Density DSUB Newark P/N 50F2055 or Equivalent • Connector on RS-449: DSUB 37 pin Male Signal Name Female 26pin...
Page 266 Cable Specification RS-449/RS-366 Cable TANDBERG MXP and Classic Endpoints that support External Network • Connector on Tandberg End: Female 26pin High Density DSUB Newark P/N 50F2055 or Equivalent • Connector on RS-449: DSUB 37 pin Male • Connector on RS-366:...
Page 267 Cable Specification RS-530 Cable TANDBERG MXP and Classic Endpoints that support External Network • Connector on Tandberg End: Female 26pin High Density DSUB Newark P/N 50F2055 or Equivalent • Connector on RS-530: DSUB 25 pin Male • Cable length: 1 meter...
Page 268 Cable Specification RS-530/RS-366 TANDBERG MXP and Classic Endpoints that support External Network • Connector on Tandberg End: Female 26pin High Density DSUB Newark P/N 50F2055 or Equivalent • Connector on RS-530: DSUB 25 pin Male • Connector on RS-366: DSUB 25 pin Male •...
Page 269 Cable Specification RS-449 Cable to KIV-7 TANDBERG MXP and Classic Endpoints that support External Network • Connector on Tandberg End: Female 26pin High Density DSUB Newark P/N 50F2055 or Equivalent • Connector on RS-449: DSUB 37 pin Male Signal Name...
Page 270: Glossary
Audio input 6: Intended for connection to a VCR or DVD player or other external playback devices. Audio out 1: Intended for connection to TANDBERG Natural Audio, televisions or audio amplifiers. Audio out 2: Intended for connection to audio recording equipment (or to a telephone add-on hybrid).
Page 271 Bandwidth: Decides the quality of the video call. High bandwidth gives high quality. Call Control Data Triggered: Uses TxData, RxData and clock signals only. Use Data Triggered when no handshake signal is available. Call control Leased Line: Is a non-dialing protocol and should be used when two systems are connected in a point-to-point connection.
Page 272 Diagnostics: Allows testing of individual system components and displays the current system settings. Digital ClarityTF: Participants enjoy presentations of exceptionally high quality resolution video. Disconnect site: As a Chairman, you get the option Disconnect site. Disconnect site allows you to disconnect any participant in the conference. Do Not Disturb: When Do Not Disturb is active the system will not accept any incoming calls.
Page 273 H.264: Video algorithm for bandwidth-efficient video compression and decompression Hardware serial number: A unique number (listed in the System Information menu) to identify your system towards your TANDBERG representatives. HD Camera: High Definition camera – delivers high resolution with excellent quality video Humfilter: A highpass filter which reduces very low frequency noise.
Page 274 A call with more than two participants including yourself MultiSite: The TANDBERG systems internal MCU. Built-in system which makes it possible to establish meetings with up to 6 video calls and 5 telephone calls. The MultiSite option is not available on all systems.
Page 275 Network profiles: It is possible to define up to 6 network profiles, each consisting of name and call prefix, and 3 of them also include network selection. Non Standard Facility: The network provider may require service selection in your ISDN configuration.
Page 276 Selfview: Outgoing video. In most cases, the image of your self. Serial number: A unique number (the hardware serial number, listed in the System Information menu) to identify your system towards your TANDBERG representatives. Side-by-Side: Side-by-side view means that two pictures are displayed side by side each other on the screen.
Page 277 Terminate meeting: The chairman can terminate the conference, i.e. all participants are disconnected. TMS: TANDBERG Management Suite Touch Tones: To dial extension numbers etc. during a call, use touch tones in order to get tones instead of preset on the number keys.
Page 278 Glossary VNC: Virtual Network Computing. Voice Switched: The active site will be displayed in full screen during a MultiSite conference. WAVE II Camera: Wide Angle View Camera - delivers the widest angle of view in the industry. Welcome menu: The welcome menu displays the Menu when you are outside a call. XGA: extended Graphics Array (1024 x 768)
Page 279: Index
9 Index Access Code...86, 108 Additional microphone ...198 Administrator Password...124 Alert Speaker ...153 Alert Tones and Volume ...153 Allowance ...108 Answer an incoming Call ...41 Assign Floor to Participant...77 Audio Algorithm ...143 Audio Demo ...98 AudioScience microphone...198 Auto answer...105 Auto-Display Snapshot ...137 Battery handling...v Call history ...49 Call Status ...88...
Page 280 Snapshot Source ...136 Software Options ...115 Start up Video Source ...134 System configuration ...12 System Information...86 System Name ...103 Take Chair ...76 Take new snapshot ...68, 69 Telephone Add-On ...205 Terminate Meeting...80 Test Subsystem ...89 Text Chat ...98 Timeout...119 Touch Tones...28 User Guide...100 Video Algorithm ...142 Video Call...

TANDBERG 1000 MXP User Manual

1 Introduction

2 Installation

3 General Use

4 Control Panel

5 System Settings

6 Peripheral Equipment

7 Appendices

Appendix 1: Technical Specification

Appendix 2: Bandwidth Information for TANDBERG Endpoints

Appendix 3: Environmental Considerations

Appendix 4: Guidelines for Setting up Rooms for Video Meetings

Appendix 5: Security

Appendix 6: Using the File System

Appendix 7: Web Interface

Appendix 8: Connecting the System to PRI/T1

Appendix 9: Connecting the System to the Switched 56 Network

Appendix 10: Connecting the System to ISDN Using NT1 Network Adapters

Appendix 11: TANDBERG Cameras

Appendix 12: Remote Control (TRC3 / TRC4)

Appendix 13: Cisco Callmanager Registration

Appendix 14: Diagnostic Tools for IP

Appendix 15: System Upgrade

Appendix 16: Declaration of Conformity

Appendix 18: Protocols Supported

Appendix 19: Cable Specifications

8 Glossary

9 Index

Quick Links

User Manual

Related Manuals for TANDBERG 1000 MXP

Summary of Contents for TANDBERG 1000 MXP
