- Page 1 Model Numbers: TBC-2211, TBC-2251,TBC-230/B TBC-2211, TBC-2251,TBC-230/B TBC-2211, TBC-2251,TBC-230/B TBC-2211, TBC-2251,TBC-230/B TBC-2211, TBC-2251,TBC-230/B TRIMMERS/BR TRIMMERS/BR USHCUTTERS USHCUTTERS TRIMMERS/BR TRIMMERS/BRUSHCUTTERS TRIMMERS/BR USHCUTTERS USHCUTTERS ISM, Inc. • 1028 4 www.tanakapowerequipment.com Owner’ Owner’ Owner’ s Man Owner’ Owner’ TBC-2211 Supplier To The Outdoor Power Equipment Industry Street SW •...
- Page 2 15m (50 ft) away from unit. If anyone approaches you, stop the engine and cutting attachment immediately. www.tanaka-usa.com TBC-2211,TBC-2251,TBC-230/B WARNING It is important that you read, fully understand and observe the following safety precautions and warnings. Careless or improper use of the unit may cause serious or fatal injury.
- Page 3 TBC-2211,TBC-2251,TBC-230/B Do not use metal/rigid Be careful of thrown blades when this sign is objects. shown on the unit. Use anti-slip and sturdy footwear. Indicates blade guard location for trimmer head or Brain Head. WARNING! • Read the Operator's Manual and follow all warnings and safety instructions. Failure to do so can result in serious injury to the operator and /or bystanders.
-
Page 4: What Is What
TBC-2211,TBC-2251,TBC-230/B 1. What is What? Since this manual covers several models, there may be some difference between pictures and your unit. Use the instructions that apply to your unit. www.tanaka-usa.com Owner’s Manual 10. Harness 11. Throttle lock 12. Safety trigger 13. -
Page 5: Warnings And Safety Instructions
TBC-2211,TBC-2251,TBC-230/B 2. Warnings and safety instructions. Operator Safety • Always wear a safety face shield or goggles. • Always wear heavy, long pants, boots and gloves. Do not wear loose clothing, jewelry, short pants, sandals or go barefoot. Secure hair so it is above shoulder length. -
Page 6: Assembly Procedures
TBC-2211,TBC-2251,TBC-230/B 3. Assembly procedures Drive shaft to engine (Fig. 1 -1) Loosen tube locking bolt (1) about ten turns so that the bolt tip will not obstruct drive shaft tube to be inserted. When inserting drive shaft tube, hold the tube locking bolt outward preventing inside fitting from obstructing as well. - Page 7 TBC-2211,TBC-2251,TBC-230/B www.tanaka-usa.com Throttle wire/stop cord Remove the air cleaner cover. (Fig. 1-4) Connect stop cords. (Fig. 1 -5) Set outer receiver (1) (if so provided) into wire guide and put throttle wire through the outer receiver. (Fig. 1 -4) Connect throttle wire end to carburetor. (Fig. 1 -6) Cover throttle wire and stop cords together with protective tube provided up to air cleaner cover.
- Page 8 For TANAKA heads, use only flexible, non-metallic line recommended by the manufacturer. Never use wire or wire-ropes. They can break off and become a dangerous projectile. NOTE! When using TANAKA alloy head (CH-100), initial cutting line length should be about 13cm (5”) each. (Fig. 1 -11) www.tanaka-usa.com Owner’s Manual...
- Page 9 Fuel • Always use branded 89 octane unleaded gasoline. • Use Tanaka two-cycle oil or a quality two-cycle oil at mixing ratio of 25-50:1 (Gasoline (A) : Oil (B)), only for the state of California at 50:1. • Never use multi-grade oil (10W/30) or waste oil.
-
Page 10: Starting
TBC-2211,TBC-2251,TBC-230/B Starting (Fig. 2-2, 2B) CAUTION! Before starting, make sure the cutting attachment is not touching anything. 1. Set ignition switch (1) to the ON position. (Fig. 2-2) *Push priming bulb (4) several times so that fuel flows through return pipe (5) (if so equipped)(Fig. 2-2C) 2. - Page 11 TBC-2211,TBC-2251,TBC-230/B Cutting (Fig. 2-4, 4B, 4C, 4D) • When cutting, operate engine at over 6500 rpm. Extended use at a slow speeds may wear the clutch prematurely. • Cut grass from right to left. • Blade thrust may occur when the spinning blade contacts a solid object in the critical area. A dangerous reaction may occur causing the entire unit and operator to be thrust violently.
- Page 12 TBC-2211,TBC-2251,TBC-230/B 5. Maintenance MAINTENANCE, REPLACEMENT, OR REPAIR OF THE EMISSION CONTROL DEVICES AND SYSTEMS MAY BE PERFORMED BY ANY NONROAD ENGINE REPAIR ESTABLISHMENT OR INDIVIDUAL. Carburetor adjustment (Fig. 3-1) WARNING! The cutting attachement my be spinning during carburetor adjustments. WARNING! Never start the engine without the complete clutch cover and tube assembled! Otherwise the clutch can come loose and cause personal injuries.
- Page 13 TBC-2211,TBC-2251,TBC-230/B Spark plug (Fig. 3-3) The spark plug condition is influenced by: • An incorrect carburetor setting. • Wrong fuel mixture (too much oil in the gasoline) • A dirty air filter. • Hard running conditions (such as cold weather).
- Page 14 • When replacing blade, purchase one recommended by TANAKA, with a 25.4mm (one inch) mounting hole. • When installing a saw blade (2), always face the stamped side up. In the case of a 4 tooth blade (1), it can be used on either side.
-
Page 15: Maintenance Schedule
TBC-2211,TBC-2251,TBC-230/B Maintenance schedule Below you will find some general maintenance instructions. For further information please contact your Tanaka service dealer. Daily maintenance • Clean the exterior of the unit. • Check that the harness is undamaged. • Check the blade guard for damage or cracks. Change the guard in case of impacts or cracks. - Page 16 TBC-2211,TBC-2251,TBC-230/B Owner’s Manual 6. Optional Installation of free disk set (optional) (Fig. 4-1, 1 B) 1) Disassemble free disk (7) from the free disk set by loosening three bolts (8). 2) Place blade (3) as shown in drawing. Disk fixing bolt (4) is left-hand threaded ' Use special care to fix blade firmly. Use alien wrench (1) to hold cutter holder (2) so that you may easily tighten up disk fixing bolt (4) with wrench (6).
- Page 17 TBC-2211,TBC-2251,TBC-230/B Owner’s Manual 7. Specifications NOTE: Sound levels are calculated as the time-weighted energy total under various working conditions with the following time distribution: ½ idling, ½ racing. All data subject to change without notice. www.tanaka-usa.com custsvc@tanaka-ism.com...
- Page 18 Tanaka Kogyo Co., Ltd., 3-4-29 Tsudanuma, Narashino, Chiba, Japan Nous,soussignds, Noi, Der unterzelchnete, Nosotros, Declare under our sole responsibility that the product, grass trimmer model D6clarons sous notre scule responsabilit6 que le-produit en question, tondeuse de gazon mod~le Dichiariamo sotto la nostra unica responsabilita che il prodotto, il bordatore modello...
- Page 19 Blade adapter kit, part # 748501, will convert these models to a blade-capable configuration, and can be purchased at your local Tanaka dealer. The kit contains a safety barrier bar, shoulder strap as well as the necessary blade mounting hardware.
- Page 20 1) Fixed line commercial cutting heads offer excellent durability and light weight. Great for commercial use. 2) Tanaka Brain fully automatic heads. The Brain senses when more line is needed and utilizes centrifugal force to always feed the perfect length of line.
