- Page 1 CM2-MGN200-2001 MagneW PLUS+ Electromagnetic Flowmeter Open Channel Flowmeter Detector User’s Manual Model: NNK140/941,NNK150/951...
- Page 2 In no event shall Azbil Corporation be liable to anyone for any indirect, special or consequential damages. This information and specifications in this document are subject to change without notice.
-
Page 3: Table Of Contents
Table of Contents 1 :Introduction ....................1 2 :External view ....................3 3 :Outline and standard specifications ............. 5 3-1 :Standard specifications ..............5 3-2 :External dimensions ................ 6 3-3 :How to use model with an Elbow Flange ........14 3-4 :How to use the Dummy detector ............. - Page 5 List of Figure Figure 1 Open channel type Electromagnetic flowmeter detector ............... 2 Figure 2 State during flow rate measurement ....................2 Figure 3 Dimensional drawings of Bell mouth type detector ................ 6 Figure 4 Dimensional drawings of a detector with Elbow flange ..............8 Figure 5 Dimensional drawings of a Dummy ....................
- Page 6 List of Table Table 1: Tightening torque of detector ......................14...
-
Page 7: Introduction
Introduction This manual describes how to install and operate the MagneW 3000 FLEX/ PLUS NNK open channel electromagnetic flowmeter detector. If you are using a MagneW 3000 FLEX/PLUS NNK in combination with a converter, refer to the operation manual of the converter. Before installing a detector, make sure that its size is adequate by referring to the “Diameter Selection Graph”... - Page 8 Azbil Corporation MagneW PLUS+ Electromagnetic Flowmeter Open channel Flowmeter Detector...
-
Page 9: External View
Azbil Corporation External view Figure 1 Open channel type Electromagnetic flowmeter detector Figure 2 State during flow rate measurement MagneW PLUS+ Electromagnetic Flowmeter Open channel Flowmeter Detector... - Page 10 Azbil Corporation MagneW PLUS+ Electromagnetic Flowmeter Open channel Flowmeter Detector...
-
Page 11: Outline And Standard Specifications
Azbil Corporation Outline and standard specifications This open channel type electromagnetic flowmeter is used for measuring flow rates in open channels or closed conduits such as drainage canals. It is used for a large variety of flow rate measurements, such as drainage under total pollutant load regulations, water and sewer service, and irrigation water. -
Page 12: External Dimensions
Azbil Corporation Mass: 50 mm (detector;10 kg. dummy; 1.4 kg) 400 mm (detector;130 kg, dummy; 33.4 kg) 100 mm (detector;23 kg. dummy; 3.4 kg) 600 mm (detector;220 kg, dummy; 59.4 kg) 200 mm (detector;45 kg. dummy; 10.4 kg) 3-2 : External dimensions... - Page 13 Azbil Corporation Signal/Excitation cable Hole Dia. of Gate bolt Weir/Gate hole Installation interval or more Size 200mm Signal/Excitation cable bolt Weir/Gate Hole Dia. of Gate hole Installation interval Name plate Material or more Flow direction Size 400mm MagneW PLUS+ Electromagnetic Flowmeter Open channel Flowmeter Detector...
-
Page 14: Figure 3 Dimensional Drawings Of Bell Mouth Type Detector
Azbil Corporation bolt Weir/Gate Hole Dia. of Gate hole Installation interval Name plate Material or more Flow direction Size 600mm Figure 3 Dimensional drawings of Bell mouth type detector MagneW PLUS+ Electromagnetic Flowmeter Open channel Flowmeter Detector... - Page 15 Azbil Corporation Detector with Elbow flange Signal/Excitation cable Weir/Gate bolt Hole Dia. of Gate Flow direction hole Installation interval or more Size 50mm Signal/Excitation cable bolt Weir/Gate Hole Dia. of Gate Flow direction hole Installation interval or more Size 100mm...
-
Page 16: Figure 4 Dimensional Drawings Of A Detector With Elbow Flange
Azbil Corporation Signal/Excitation cable bolt Hole Dia. of Gate Weir/Gate hole Installation interval or more Size 200mm Figure 4 Dimensional drawings of a detector with Elbow flange MagneW PLUS+ Electromagnetic Flowmeter Open channel Flowmeter Detector... - Page 17 Azbil Corporation Dummy Hole Dia. of Gate Weir/Gate Bolt Flow direction hole Installation interval or more Size 50mm Weir/Gate Hole Dia. of Gate bolt Flow direction hole Installation interval or more Size 100mm Hole Dia. of Gate Weir/Gate bolt Flow direction...
-
Page 18: Figure 5 Dimensional Drawings Of A Dummy
Azbil Corporation Weir/Gate Flow direction Hole Dia. of Gate bolt hole Installation interval or more Size 400mm Weir/Gate Hole Dia. of Gate Flow direction bolt hole Installation interval or more Size 600mm Figure 5 Dimensional drawings of a Dummy MagneW PLUS+ Electromagnetic Flowmeter Open channel Flowmeter Detector... -
Page 19: Figure 6 Drawing Of A Dummy With Elbow Flange
Azbil Corporation Dummy with an Elbow flange Movable section Flow direction Size 50mm, 100mm, 200mm Figure 6 Drawing of a Dummy with Elbow flange Size 50mm 100mm 200mm 367 to 388 569 to 590 876 to 897 73 to 94... -
Page 20: How To Use Model With An Elbow Flange
Azbil Corporation 3-3 : How to use model with an Elbow Flange When no weir plate can be installed on the downstream side of a detector, use a model with an Elbow flange. (a) The water level (+ 7mm) can be adjusted since the elbow flange length can be changed. -
Page 21: How To Use The Dummy Detector
Azbil Corporation 3-4 : How to use the Dummy detector The measurable flow rate can be doubled, tripled, or quadrupled by installing 1,2,3 dummy detectors, respectively. A detector must be combined with dummy detectors of the similar shape. If the flow rate is to be increased in future, the measurable range can be expanded easily by installing a model with an elbow flange. - Page 22 Azbil Corporation MagneW PLUS+ Electromagnetic Flowmeter Open channel Flowmeter Detector...
-
Page 23: Installation
Azbil Corporation Installation 4-1 : Considerations on installation Before the installation of a open channel type electromagnetic flowmeter, observe the following considerations. • If you are asking a subcontractor to install a flowmeter, you are advised to check the procedure of installation work in writing in advance. -
Page 24: Transportation Of Flowmeter To The Installation Site
Azbil Corporation Table 1: Tightening torque of detector Nominal size Tightening torque Nominal size Tightening torque 50mm 400mm 10 to 20 25 to 35 100mm 600mm 11 to 21 25 to 35 200mm 25 to 35 4-2 : Transportation of flowmeter to the installation site •... -
Page 25: Example Of Installation Work
Azbil Corporation 4-3 : Example of installation work Chief field supervisor Meeting about installation Installation supervisor Detailed supervision from the beginning to completion of installation Flowmeter mounting Flowmeter mounting Flowmeter mounting worker worker worker Assigned to unloading Support on upstream... -
Page 26: Examples Of Installation
Azbil Corporation 4-4 : Examples of installation Schematic drawings 1) It is recommended that a gate with a lifting device be Mounting used. If there is a possibility that Gate the upstream water level will become lower than the inlet port... - Page 27 Azbil Corporation Pictures of flowmeter installation Measurement with one 200mm detector High accuracy measurement with two 200mm and one 200mm dummy detectors Installed on a water tank outlet (600mm) Installed in a discharge pipe of the plant (400mm) MagneW PLUS+ Electromagnetic Flowmeter Open channel Flowmeter Detector...
-
Page 28: Wiring
Azbil Corporation Wiring 5-1 : Considerations on wiring Since the root of the 4-core cabtyre cable (including cores for signal and excitation) is a watertight structure, do not pull them. The standard length of each cable of the detector is 10m. If the cable length between a detector and a converter is over 10m, use a cable connection box (Model No. -
Page 29: Figure 12 Connection Of Converter And Detector
Azbil Corporation A detector is used in combination with a Open channel type detector (Type NNK) and a converter (Type MGG10C/14C). Its output signals are instantaneous flow rate signals (4 to 20mA DC), totalized output (pulse) and contact output (open collector). -
Page 30: Inspection
Azbil Corporation Inspection Inspect the following parts. 6-1 : Flowmeter in general (a) Check to see if the detector and the converter are mounted as specified. …. See “Considerations on installation” on page 17. “Examples of installation” on page 20 and “Considerations on wiring” on page 22. -
Page 31: Appendix
Appendix Water level calculation (Bell mouth type) Example: Mounting Size and number of detector : 200mm, 1unit Gate Size and number of dummy detector : 200mm, 1unit Width of weir plate (W) : 2m Maximum flow rate (Qt.) : 500m Average flow velocity per detector (V) : 2.21m/s Weir... -
Page 32: Figure A-1 Detector Size Selection Graph
Appendix Azbil Corporation Figure A-1 Detector size selection graph ~Note The expression “200mm(3)” refers to the structure consisting of one 200mm detector and two 200mm dummies. (“200mm” referts to the detector’s size or aperture and “(3)“means that the total number of detectors including dummy detectors.) -
Page 33: Water Level Calculation (Elbow Flange Type)
Azbil Corporation Appendix Water level calculation (Elbow flange type) Gate Example Size and number of detector: 200mm, 1 unit Size and number of dummy detector: 200mm, 1 unit Maximum flow rate (Qt.): 500m Average flow velocity per detector (V): 2.21m/s... -
Page 34: Average Flow Velocity Of Detector (M/S)
Appendix Azbil Corporation Average flow velocity of detector (m/s) Flow velocity conversion table Where : Flow velocity (m/s), : Flow rate (m : Flow velocity conversion coefficient (Example) Detector size: 200(mm) Flow rate per detector: 250(m Nominal size Flow velocity conversion... - Page 36 Warranty period and warranty scope 1.1 Warranty period Azbil Corporation’s products shall be warranted for one (1) year from the date of your purchase of the said products or the delivery of the said products to a place designated by you.
- Page 37 Although acceleration of the above situation varies depending on the conditions or environment of use of the products, you are required not to use any Azbil Corporation’s products for a period exceeding ten (10) years unless otherwise stated in specifications or instruction manuals.
- Page 39 Document Number: CM2-MGN200-2001 Document Name: MagneW PLUS+ Electromagnetic Flowmeter Open Channel Flowmeter Detector User’s Manual Model NNK140/941, NNK150/951 Date: 1st edition: Nov. 2008 3rd edition: Nov. 2019 Issued/Edited by: Azbil Corporation...
