- Page 1 Operating Instructions Electrical quadrocopter “Foldable Drone G-Sense” RtF Item No. 1697439...
-
Page 2: Table Of Contents
Table of contents Page Introduction ................................4 Explanation of symbols ............................4 Intended use ................................5 Delivery content ..............................5 Product description ..............................6 Safety instructions ...............................7 a) General information ............................7 b) Before first use ..............................8 c) During operation ............................8 Information on non-rechargeable and rechargeable batteries ................9 Transmitter controls ............................10 Using the transmitter ............................ - Page 3 Page 19. Recording photos and videos ..........................31 20. Using the smartphone as a remote control ......................32 a) Enabling smartphone control ........................32 b) App control functions ...........................33 c) Quadrocopter take-off via smartphone ......................34 d) Landing the quadrocopter via smartphone ....................34 e) Other control options ...........................35 21.
-
Page 4: Introduction
1. Introduction Dear customer, Thank you for purchasing this product. This product complies with statutory, national and European regulations. To ensure that the product remains in this state and to guarantee safe operation, always follow these operating instructions! These operating instructions are part of this product. They contain important information on setting up and using the product. -
Page 5: Intended Use
3. Intended use The “Foldable Drone G-Sense RtF” electric quadrocopter is an electrically driven helicopter-like model that is wire- lessly controlled using the included wireless remote control or a suitable smartphone (not included). The quadrocopter is designed solely for private use within the domain of model construction with the associated operating times. -
Page 6: Product Description
5. Product description The ready-to-fly “Foldable Drone G-Sense RtF” quadrocopter features 4 separately controlled motors, each of which drives its own propeller. Using the simultaneous acceleration of all propellers, the quadrocopter can lift off the ground and hover steadily in the air at appropriate propeller speeds. For stabilisation in flight, the quadrocopter has sophisticated electronics with position and acceleration sensors allow- ing the model to detect uncontrolled movements and compensate them immediately. The quadrocopter is equipped with a barometric air pressure sensor allowing the quadrocopter to stabilise its flight altitude itself. -
Page 7: Safety Instructions
6. Safety instructions Damage caused by failure to observe these operating instructions will void the warranty. We shall not be liable for any consequential damage. We shall not be liable for damage to property or personal injury caused by improper handling or failure to observe the safety instructions! Such cases will void the warranty/guarantee. -
Page 8: B) Before First Use
b) Before first use • Select a suitable location to operate your model. • When switching on the quadrocopter, follow the procedure described below in a separate chapter. This ensures that the transmitter and receiver connect properly and that your model responds reliably to remote control commands of your transmitter. -
Page 9: Information On Non-Rechargeable And Rechargeable Batteries
7. Information on non-rechargeable and rechargeable batteries Although handling non-rechargeable and rechargeable batteries in daily life is a matter of course today, there are numerous hazards and problems. Therefore, always observe the following general information and safety instructions when handling non-rechargeable and rechargeable batteries. -
Page 10: Transmitter Controls
8. Transmitter controls Figure 1 1 Joystick for the pitch and yaw function 2 Push button for the take-off and landing function 3 Push button for the return function 4 LED indicator 5 Push button for the on/off function 6 Push button for the headless function 7 Push button for sensor calibration 8 Push button for photo and video recording * 9 Push button for the beginner, sport and expert mode... -
Page 11: Using The Transmitter
9. Using the transmitter The numbers used in these operating instructions refer to the figure alongside the text or the figures within the respective section. Cross references to other figures are indicated with the corresponding figure num- ber. The figures of the remote control and the model in these operating instructions are for illustrative purposes only. The label, design and colour scheme of the products supplied in series may differ completely from the figures in these operating instructions. a) Inserting the non-rechargeable batteries The transmitter is supplied by 2 Micro/AAA non-rechargeable batteries. Important! Use only non-rechargeable batteries (1.5 V/cell) and do not use rechargeable batteries (1.2 V/cell) as the power supply for the transmitter. -
Page 12: B) Switching On The Transmitter
b) Switching on the transmitter Press and hold down the push button for the on/off func- tion (see also Figure 1, no. 5). The transmitter will emit two short beeps and the LED indi- cator (see also Figure 1, no. 4) will start to flash. Then push the joystick for the pitch and yaw function (see also Figure 1, no. -
Page 13: Operating The Quadrocopter
10. Operating the quadrocopter a) Charging the flight battery The flight battery can be charged using the included USB charging cable. The charging cable in Figure 4 is wound up for photo-technical reasons. Before first use, remove the cable tie and fully unwind the charging cable. Charging: Connect the USB plug of the charging cable (1) to a USB port of a computer/laptop or a USB charger plug. The LED charging indicator on the USB plug (2) will go on to indicate that the USB charging cable is supplied with the correct voltage. -
Page 14: B) Folding The Rotor Arms In And Out
b) Folding the rotor arms in and out The propeller arms with the propellers and guards can be folded in for space-saving transport (see Figure 5A). The front and rear propeller arms on each side are mechanically interconnected and folded in and out together (see Figure 5B). -
Page 15: D) Inserting The Flight Battery
d) Inserting the flight battery Mount the flight battery (1) on the quadrocopter from above. It is important that the connection contacts (2) of the quad- rocopter engage securely in the connection socket (3) of the flight battery. The flight battery lock is taken over by two locking latches (4) on the sides of the flight battery. To remove the rechargeable battery, slightly press the two grooved surfaces (5) on the right and left of the flight bat- tery inwards and lift off the rechargeable battery. -
Page 16: E) Switching On The Quadrocopter
e) Switching on the quadrocopter So that the receiver in the quadrocopter can respond to the transmitter signals, the receiver and the transmitter must have the same digital coding (pairing). For this reason, it is important that you switch on the quadrocopter as described below. -
Page 17: F) Basic Information On Steering Quadrocopters
f) Basic information on steering quadrocopters Before starting your model for the first time, you should first familiarise yourself with the control features available to you to be able to control the model in a safe manner. The quadrocopter is controlled using the joystick on the remote control transmitter and the movement of the transmit- ter. The following functions are available: Pitch function With the pitch function, you can control the flight altitude of the quadrocopter (see Figure 9). Use the joystick for steer- ing (see also Figure 1, no. - Page 18 Yaw function The torques that act on the model are balanced by the two right-rotating and the two left-rotating propellers, and the quadrocopter hovers steadily in the air. When the joystick is moved to the left (see also Figure 1, no. 1), the model electronics speed up the propeller rotating to the right (clockwise) as viewed from above and simultaneously slow down the propeller rotating to the left (counter- clockwise).
- Page 19 Pitch function The pitch function allows you to move your quadrocopter forward and backward (see Figure 12). Move the remote control transmitter for steering. When the front of the transmitter is tilted downwards, the quadrocopter electronics change the propeller speeds so that the model tilts slightly forward and thus also flies forward (see arrows in Figure 12).
-
Page 20: G) Practical Flight Tips For The First Start
g) Practical flight tips for the first start Calibrate the position sensors before each start. The exact procedure is described in the following chapter. Although the model can be flown in a very confined space, we recommend using an unobstructed space of approx. 3 x 3 m for the first flight attempts. When flying the quadrocopter outdoors for the first time, there should be absolutely no wind. Place yourself directly behind your quadrocopter. For as long as you see your model from behind, it will respond from your perspective to the right, left, forward and backward control commands just as you steer the transmitter. -
Page 21: Calibrating The Position Sensors
11. Calibrating the position sensors Before starting the quadrocopter, you should calibrate the position sensors. This ensures that the quadrocopter hovers smoothly at one spot and does not fly in one direction spontaneously and without a control command. Proceed as follows: First switch on the quadrocopter with the function button (2) and then place it on a flat, level horizontal surface. Then turn on the transmitter and push the joystick (1) com- pletely forward and then pull it back again. -
Page 22: Lifting Off The Quadrocopter
12. Lifting off the quadrocopter With the quadrocopter and transmitter switched on and the sensors successfully calibrated, the quadrocopter can be lifted off. Push the joystick completely forward and then pull it back again. The propellers will start to rotate at low speed. To stop the rotating propellers, move the joystick to the lowest position and hold it until the propellers stop. -
Page 23: Landing The Quadrocopter
13. Landing the quadrocopter There are two methods for landing the quadrocopter: Method 1: When the quadrocopter is hovering, carefully reduce the flight altitude with the joystick (see Figure 14, no. 1) until the quadrocopter stands safely on the ground. Once the quadrocopter has landed, move the joystick to the lowest position and hold it in this position until the propel- lers stop. -
Page 24: Beginner/Sport/Expert Mode Switching
14. Beginner/sport/expert mode switching With beginner/sport/expert mode switching, the remote control allows you to individually adjust the control sensitivity of the quadrocopter (dual rate function). The following modes are available: • Beginner mode Beginner mode is automatically enabled when the remote control transmitter is switched on. In this flight mode, the quadrocopter responses less sensitively to the control commands from the transmitter and can therefore be controlled very delicately. This mode is ideal for beginners flying the quadrocopter for the first time. -
Page 25: Flip Function
15. Flip function The quadrocopter can perform sideways flips, if necessary. You should perform the first flips outdoors when there is absolutely no wind. For this purpose, allow the quadrocopter to ascend to a safe altitude of approx. 2 – 3 m and then hover at one spot. To switch the transmitter to flip mode, press the joystick from above (see also Figure 1, no. -
Page 26: Flying In Headless Mode
16. Flying in headless mode The quadrocopter's direction of movement always depends on the direction in which the model is oriented with respect to the pilot or the side from which the pilot is looking at the quadrocopter. Therefore, you can be confused quickly when you see the model from the side or the front, not from behind. -
Page 27: Return Function
17. Return function The quadrocopter has a return function which causes it to fly backwards automatically. Thus exactly in the opposite di- rection, which has been set as the forward direction when switching on (see white arrow in Figure 19A). As with head- less mode, it does not matter in which direction the front of the quadrocopter is currently oriented (see Figure 19B). Important! The return function should only be enabled if the quadrocopter has flown too far from the pilot in the previously defined forward direction and the pilot is in line with the quadrocopter facing forwards. If the... -
Page 28: Installing The Smartphone App
In order for the app to establish a working connection with the quadrocopter, it is important to select the image of the “Foldable Drone G-Sense RtF” quadrocopter on the home page (see Figure 20, no. 6). To change the quadrocopter images, use the swipe function or the side direction arrows. -
Page 29: B) Making Settings
b) Making settings If the gearwheel symbol (see Figure 20, no. 1) is enabled, a new screen will appear, in which you can set the follow- ing functions: 1 Music volume adjustment 2 Sound effects volume adjustment 3 Menu language selection 4 Back to app's home page Figure 21 c) Help function... -
Page 30: D) Operation
d) Operation If you select the “FLY” button (see Figure 20, no. 4), the following user interface will open: The background image shown in Figure 23 only appears if the app has been activated with the quadrocopter switched off. When the quadrocopter is connected to Wi- Fi, the camera image is shown in the background. -
Page 31: Recording Photos And Videos
19. Recording photos and videos The quadrocopter has a built-in HD camera that is oriented diagonally downwards in flight direction. You can use this camera to record videos or photos on a smartphone (not included) during the flight. Start up the quadrocopter and then the transmitter. The LEDs on the quadrocopter and the transmitter must glow steadily. Then call up the settings menu for Wi-Fi connections in the settings area on your smartphone. The Wi-Fi connection of the quadrocopter will appear on the smartphone display shortly thereafter (for example, XT-XXXXXX). -
Page 32: Using The Smartphone As A Remote Control
Leave the settings area on your smartphone and start the “XT-GO” quadrocopter app. Select the image of the “Foldable Drone G-Sense RtF” quadrocopter on the home screen. As soon as you enable the “Play” button, the smartphone will show the current camera image. -
Page 33: B) App Control Functions
b) App control functions When the quadrocopter stands on a flat start surface, calibrate the position sensors. For this purpose, press the respective button (see Figure 25, no. 9) on the display. The button will get brighter and the green LED at the rear of the quadrocopter (see Figure 8, no. 3) will start to flash. As soon as the calibration process is completed, the button will get darker and the LED on the quadrocopter will glow steadily. -
Page 34: C) Quadrocopter Take-Off Via Smartphone
c) Quadrocopter take-off via smartphone If the propellers are rotating at low speed, carefully move the left virtual joystick (13) forward. The quadrocopter will significantly increase the propeller speeds and take off. Al- ternatively, you can also use the button for the automatic take-off (16). Then use both virtual joysticks for steering. Figure 27 d) Landing the quadrocopter via smartphone To land the quadrocopter, carefully reduce the flight altitude with the left joystick (see Figure 27, no. 13) until the... -
Page 35: E) Other Control Options
e) Other control options In addition to the control using both virtual joysticks, there are other quadrocopter control options. Voice control If the button for the voice control (5) has been enabled, the quadrocopter can be controlled by voice commands. The possible voice commands such as “take-off”, “landing”, “forward”, “backward”, “right side”, and “left side” are briefly displayed when voice control is enabled. -
Page 36: Augmented Reality Game
To start the game, the quadrocopter must be connected to Wi-Fi. Only then the “PVE” button (see Figure 20, no. 5) can be selected. Select the image of the “Foldable Drone G-Sense RtF” quadrocopter on the home screen. As soon as you enable the “PVE” button, the smartphone will show the current camera image with the displayed virtual aeroplanes. -
Page 37: Maintenance And Cleaning
22. Maintenance and cleaning Clean the exterior of the model and the remote control with a soft, dry cloth or brush. Never use aggressive cleaning agents or chemical solutions, as these may damage the surface of the housing. The propellers must move smoothly and motor shafts should not be bent or have any play in the bearing. Propellers that are cracked or bent or from which small pieces have broken off must always be replaced. -
Page 38: Disposal
23. Disposal a) Product Electronic devices are recyclable waste and must not be placed in household waste. At the end of its service life, dispose of the product according to the applicable statutory regulations. Remove any inserted non-rechargeable/rechargeable batteries and dispose of them separately from the product. -
Page 39: Troubleshooting
25. Troubleshooting This model and the remote control were built using the latest technology. However, faults and malfunctions may still occur. We would, therefore, like to show you how to rectify potential faults. Problem Solution The transmitter does not respond, the LED • Check the non-rechargeable batteries in the transmitter. -
Page 40: Technical Data
26. Technical data a) Transmitter Frequency range ..........2.450 – 2.478 GHz Transmission power..........9 dBm Control channels ..........4 Transmitter range ..........approx. 30 – 50 m Operating voltage ..........3.0 V/DC via 2 Micro/AAA non-rechargeable batteries Dimensions (L x W x H) ........112 x 37 x 55 mm Weight without batteries ........47 g b) Quadrocopter FPV frequency range ........2.402 –... - Page 44 This is a publication by Conrad Electronic SE, Klaus-Conrad-Str. 1, D-92240 Hirschau (www.conrad.com). All rights including translation reserved. Reproduction by any method, e.g. photocopy, microfilming, or the capture in electronic data processing systems require the prior written approval by the editor. Reprinting, also in part, is prohibited. This publication represent the technical status at the time of printing.
