Sylvania SMPK2242 Pocket Manual

Digital mp4 player
Hide thumbs

Advertisement

SMPK2242
Digital MP4 Player
Your Pocket Guide
Install Software
Get Connected
Transfer Media
Plug Your Ears & Enjoy

Advertisement

Table of Contents
loading

  Related Manuals for Sylvania SMPK2242

  Summary of Contents for Sylvania SMPK2242

  • Page 1 SMPK2242 Digital MP4 Player Your Pocket Guide Install Software Get Connected Transfer Media Plug Your Ears & Enjoy...
  • Page 2 SMPK2242...
  • Page 3: Table Of Contents

    What’s in the box? System Requirement Software Installation Connect & Charge Synchronize songs to the player Transfer Software Operation Settings Know Your Player Well Music Playback Edit Lyrics Repeat Mode EQ Mode Video Playback Photo Browse Ebook / File Deletion Recorder Technical Data Trouble Shooting...
  • Page 4: What's In The Box

    What’s in the box? What’s in the box? Portable Media Player Earphone USB Cable Portable Media Player Your Pocket Guide Plug Your Ears & Enjoy Battery Charger Your Pocket Guide CD-ROM containing: Media player driver for Windows® 98 Software for converting video files Install Software Get Connected...
  • Page 5: System Requirement

    System Requirement You’ll need a computer with: Windows® 98 2000 XP Pentium Class or faster Processor CD-ROM Drive 64MB RAM 30MB free hard disk space USB Port...
  • Page 6: Software Installation

    Software Installation Software Utilities Installation Insert the CD into the CD ROM drive of your PC. Click Setup.exe to start driver installation. Follow the on-screen-menu to complete the installation. For Windows® 98 users, please install the driver in the CD-ROM before downloading any files to your player . Click Close once you reach the...
  • Page 7: Connect & Charge

    Connect & Charge Connect Your player will be charged while being connected to PC through the USB cable. You will see the charging animation on the display. The player is fully charged when the charging animation stops.
  • Page 8: Synchronize Songs To The Player

    Synchronize songs to the player You can use Windows Media Player 10 on Windows® XP SP2 to synchronize music which are downloaded from Internet legally and validly with license to the player. If the song is downloaded illegally without license, it cannot be synchronized. Jan 1st 2006 20:48 USB Disk...
  • Page 9 Step 3: Windows Media Player will find device automatically. And after a while, a dialog box of Device Setup choose Manual and click Finish Synchronize songs to the player Step 4: Windows Media Player will be operating. will appear, Drag and drop your downloaded songs into its Sync List, and press Start Sync synchronized to the player.
  • Page 10: Synchronize Songs To The Player

    Synchronize songs to the player Step 5: The synchronized music can be found in the player. Click into My Computer on the desktop, and you can see an Audio Device named as media player , click into it to view your synchronized songs.
  • Page 11: Transfer

    Get Your Player Connected Step 1: Plug the USB cable to the USB ports of your PC and player. Once the connection is successfully made, the removable disk of the player will be found. Step 2: The above screen (1) would appear. (Apply only to Windows®...
  • Page 12: Transfer

    Step 3: Double click the Removable Disk icon. Note: Do not disconnect the USB cable once you click into the removable disk window. Such action may cause data loss or problems to the player. Drag and drop your media files into the removable disk.
  • Page 13: Software Operation

    Software Operation You can convert your favorite video file in any other format into the .AVI format with the help of the AVI Converter Start\Programs\MP3 Player Utilities 5.02 \AVI Converter Software Operation After selecting the source video file and your preferred target file path.
  • Page 14 Software Operation Software Operation Your can enjoy songs from both PC and your player thru the Media Manager Programs\MP3 Player Utilities 5.02\Media Manager If the updated firmware version is available, please use MP3 Player Firmware Upgrade Tool to upgrade it.
  • Page 15: Settings

    Language Selection Jan 1st 2006 20:50 English Information Display Simplified Chinese Traditional Chinese Rename Playlist JAPANESE Date and Time KOREAN Player Configure French Language Select German Encrypted Disk Setting Italian Spanish Reset Portuguese Press to select Setting on the main menu, and press to enter its sub-menu.
  • Page 16: Know Your Player Well

    Vol- button Vol+ button On/Off switch Back View Previous button Play/Pause button MODE button Next button Microphone Right View Earphone jack USB port...
  • Page 17 Press Power On/Off Switch the On/Off switch Turn On/Off Hold Scroll through lists General Select Option Return to previous menu Play/Pause songs Jump to next song Fast Forward Hold Move back to previous song Music Fast Backward Hold Display lyrics Stop lyrics display Volume up Volume down...
  • Page 18: Music Playback

    Music Playback Music Playback Now Playing 16:30 my+heart+will+go+on.mp3 unknown unknown 00:00:41 00:05:10 While enjoying music, you can press or continue the music; Press to move back to the previous song or jump to the next song; Hold long to move your song forward or rewind it.
  • Page 19: Edit Lyrics

    Edit Lyrics You can copy the synchronous lyrics from internet, and create a new Text Document on your PC, paste them, and then select to save this document in the extension of .LRC shown as below. Edit Lyrics Then put both .LRC and .MP3 (or .WMA) files of the same song into the same folder in the removable disk.
  • Page 20: Repeat Mode

    Repeat Mode Repeat Mode Now Playing 16:30 Repeat Replay Times: 00 times my+heart+will+go+on.mp3 Replay Gap: 5 seconds Replay Mode Tempo Rate: Remove Add To MyList Information 00:00:41 Add Tag Procedure: Hold while playing music to enter the sub-menu screen (1). Select Repeat and press...
  • Page 21: Eq Mode

    Listen to your music at its best Now Playing 16:30 Repeat Replay Times: 00 times my+heart+will+go+on.mp3 Replay Gap: 5 seconds Replay Mode Tempo Rate: Remove Add To MyList Information 00:00:41 Add Tag Now Playing 16:30 Normal Rock my+heart+will+go+on.mp3 Classic Soft unknown Jazz unknown...
  • Page 22: Video Playback

    Video Playback Press to select My Video and press to enter it. Select Choose Local Memory , and press Press to select different movies, and press Video Playback on the main menu, Dir List by pressing to enter the video files list. to play.
  • Page 23: Photo Browse

    Photo Browse Jan 2nd 2006 16:39 Picture List Scan Mode Play Mode Slide Gap Press to select My Picture on the main menu, and press to confirm. Select Picture List by pressing Press Dir List , and press to enter it. Choose Local Memory .
  • Page 24 Photo Browse SlideShow Jan 2nd 2006 16:39 Picture List Scan Mode Play Mode Slide Gap If you want to create a slideshow for all photos, select Play Mode on the sub-menu of My Picture, and press its options list. Press to choose Slide Play could be played one by one automatically according to the Slide Gap you preset.
  • Page 25: Ebook / File Deletion

    Ebook / File Deletion Ebook Jan 2nd 2006 16:40 Now Reading Dir List Tag List Auto Play Gap: 5Sec Press to select My Ebook on the main menu, and press to enter it. Press Dir List , and press to enter it. Choose Local Memory .
  • Page 26: Recorder

    Voice Recording Jan 2nd 2006 16:45 Now Recording Rec Type VOR: Off 00:00:12 Press to select Recorder on the main menu, and press to enter it. Select Now Recording , and press You can press to save the recorded voice. To preset the format of the recorded voice file, you could select to go into Rec Type...
  • Page 27: Technical Data

    Technical Data General Information 128MB/256MB/512MB/1GB/2GB/4GB Capacity internal flash memory Display 2.4 inch Colour TFT display Power Supply 3.7V Lithium battery Operating System Windows® 98/2000/XP Interface USB 2.0 High Speed Dimensions 50mm x 84mm x 10mm Weight 39.5g Voice Recording Supported File Types .ACT and .MP3 files Video Playback Supported File Type...
  • Page 28: Trouble Shooting

    What should I do if… Q: I cannot enter the MUSIC mode after using the player for a period of time. A: You should format the memory of the player under connection to PC. (Be sure you remember to backup the data in your player before performing the above action.) Q: I cannot convert my video file into the .AVI format.
  • Page 29: Disposal Of Your Old Product

    More Disposal of your old product Electrical and electronic equipment (EEE) contains materials, parts and substances which can be dangerous to the environment and harmful to human health if wastes of electrical and electronic equipment (WEEE) are not disposed correctly. Equipments which are marked with the WEEE logo (as shown on the right), should not be thrown away with your household waste.
  • Page 30 M03AC2135DR Version1.0 2008©GENX MIDDLE EAST FZE. All Right Reserved...
