HIGH-DEFINITION TELEVISION
TO RECEIVE DIGITAL/ANALOG SIGNAL,
YOU MUST CONNECT ANTENNA.
IF YOU NEED ADDITIONAL ASSISTANCE WITH SETUP OR OPERATING AFTER
READING OWNER'S MANUAL, PLEASE CALL TOLL FREE 1-800-968-3429, OR
VISIT OUR WEB SITE AT http://www.SylvaniaConsumerElectronics.com
15" Digital / Analog
Owner's Manual
LC155SL8P
© 2007 Funai Electric Co., Ltd.
LCD TV
Advertisement
Table of Contents
Related Manuals for Sylvania LC155SL8P
Summary of Contents for Sylvania LC155SL8P
- Page 1 IF YOU NEED ADDITIONAL ASSISTANCE WITH SETUP OR OPERATING AFTER READING OWNER’S MANUAL, PLEASE CALL TOLL FREE 1-800-968-3429, OR VISIT OUR WEB SITE AT http://www.SylvaniaConsumerElectronics.com 15” Digital / Analog LCD TV Owner’s Manual LC155SL8P © 2007 Funai Electric Co., Ltd.
-
Page 2: Introduction
NTRODUCTION WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. -
Page 3: Precautions
OBJECT AND LIQUID ENTRY - Never push objects of any kind into this TV through openings as they may touch dangerous voltage points or short out parts that could result in a fi re or electric shock. Never spill liquid of any kind on the TV. SERVICING - Do not attempt to service this TV yourself as opening or removing covers may expose you to dangerous voltage or other hazards. -
Page 4: Supplied Accessories
NTRODUCTION LOCATION For safe operation and satisfactory performance of the unit, keep the following in mind when selecting a place for its installation: • Shield it from direct sunlight and keep it away from sources of intense heat. • Avoid dusty or humid places. •... -
Page 5: Table Of Contents
Features • DTV/TV/CATV - You can use your remote control to select channels which are broadcast in digital, conventional analog, standard definition, and high definition formats. Also, cable subscribers can access their cable TV channels. • Program Information Display (DTV only) - You can display the title, contents and other information of the current DTV program on the TV screen. -
Page 6: Remote Control Function
NTRODUCTION Remote Control Function Installing the Batteries Install the batteries (AA x 2) matching the polarity indicated inside battery compartment of the remote control. Battery Precautions: • Be sure to follow the correct polarity as indicated in the battery compartment. Reversed batteries may cause damage to the device. •... -
Page 7: Control Panel
Control Panel SETUP VOLUME CHANNEL INPUT top of the unit Rear Panel rear of this unit VIDEO 2 COMPONENT AUDIO VIDEO 1 AUDIO S-VIDEO VIDEO COAXIAL side of the unit SETUP button (p13) Press to display the main menu. VOLUME X / Y buttons (p15) Press to adjust the volume or move right( X )/left( Y ) through the main menu items. -
Page 8: Attaching A Wall Mount Bracket (Sold Separately)
NTRODUCTION Attaching a Wall Mount Bracket (sold separately) The following is a description of the method for attaching a wall mount to this unit. When performing this operation, refer to the instruction manual included with the wall mount kit. CAUTION •... -
Page 9: Connection
ONNECTION Cables not included. Please purchase the necessary cables at your local store. Basic Connection This section describes how to connect the unit to an antenna, cable/satellite box, etc. Note: • Be sure your antenna or other device is connected properly before plugging in the power cord. [Antenna Cable Connection] When connecting the unit to an antenna or cable TV company (without cable/satellite box) Connect the RF coaxial cable on your home outlet to the antenna input jack of this unit. -
Page 10: External Device Connection
ONNECTION Cables not included. Please purchase the necessary cables at your local store. External Device Connection [Component Video Cable Connection] Component video connection offers better picture quality for video devices connected to the unit. Use a component video cable to connect the unit to external video devices equipped with component video output jacks. - Page 11 Cables not included. Please purchase the necessary cables at your local store. [Video Connection] Video connection offers standard picture quality for video devices connected to the unit. If you connect to the unit’s video input jack, connect RCA audio cables to the audio L/R jacks of VIDEO1. When the audio jack of the video device is monaural, connect the RCA audio cable to the audio L input jack.
-
Page 12: Initial Setting
NITIAL SETTING These operations are accessible by remote control. Some may also be accessible by controls on the main unit. Initial Setup This section will guide you through the unit’s initial setting which includes selecting a language for your on-screen menu and “AUTO PRESET CH”, which automatically scans and memorizes viewable channels. -
Page 13: Main Menu
Main Menu This section describes the overview of the main menu displayed when you press [SETUP]. For more details, see the reference page for each item. The main menu consists of the function setting items below. Press [SETUP]. e.g.) digital TV mode - TV SETUP - PICTURE CHANNEL SETUP... -
Page 14: Language Selection
NITIAL SETTING Note: • If you connect the cable system directly, contact the CATV installer. • If you press [POWER] or [SETUP] during auto channel scan, the setting will be canceled. • When no channel can be received by auto channel scan, “NO TV SIGNALS”... -
Page 15: Watching Tv
ATCHING TV Channel Selection Select channels by pressing [CH. K /L] or [the Number buttons]. • To select the memorized channels, use [CH. K /L] or [the Number buttons]. • To select the non-memorized channels use [the Number buttons]. To Use [the Number buttons] - When selecting analog channel 12 - When selecting digital channel 12-1 Be sure to press [–/ENT.] before entering the minor... -
Page 16: Switching Each Mode
ATCHING TV Switching Each Mode You can easily switch with the remote control to the DTV (ATSC) and TV (NTSC) or to access an external device when they are connected to the unit. Press [INPUT] repeatedly to cycle through analog TV, digital TV, VIDEO1 and VIDEO2. -
Page 17: Screen Information
Screen Information You can display the currently selected channel or other information such as the audio mode on the TV screen. In the analog mode, the current channel number is displayed. Press [DISPLAY]. • The current channel number is displayed at the top- right corner of the TV screen. -
Page 18: Tv Screen Display Mode
ATCHING TV TV Screen Display Mode 2 types of display modes can be selected in the digital mode when the broadcasting station is sending 16:9 video signal. Press [SCREEN MODE] repeatedly to switch the TV aspect ratio. LETTERBOX [LETTERBOX] Display the digital-supported program in full-screen. Black borders will spread in the upper and lower screen. -
Page 19: Optional Setting
PTIONAL SETTING Channel Add/Delete The channel add/delete function lets you add the channel that was not added by the auto channel scan due to the reception status at the initial setting. You can also delete the unnecessary channels. Press [SETUP] to display the main menu. Use [Cursor K/L] to select “CHANNEL SETUP”, then press [ENTER]. -
Page 20: Picture Adjustment
PTIONAL SETTING Picture Adjustment You can adjust brightness, contrast, color, tint and sharpness. Press [SETUP] to display the main menu. Use [Cursor K /L] to select “PICTURE”, then press [ENTER]. e.g.) digital TV mode - TV SETUP - PICTURE CHANNEL SETUP V-CHIP SETUP LANGUAGE CAPTION... -
Page 21: Dtv Closed Caption
Press [SETUP] to exit. Note: • To show the closed caption on your TV screen, broadcast signal must contain the closed caption data. • Not all TV programs and commercials have the closed caption or all types of the closed caption. •... -
Page 22: Dtvcc Style
PTIONAL SETTING DTVCC Style You can change the style of DTV CC such as font, color or size, etc. Press [SETUP] to display the main menu. Use [Cursor K /L] to select “DTVCC“, then press [ENTER]. e.g.) digital TV mode - TV SETUP - PICTURE CHANNEL SETUP... -
Page 23: Back Light Setting
Back Light Setting You can set the desired brightness mode. Press [SETUP] to display the main menu. Use [Cursor K /L] to select “BACK LIGHT”, then press [ENTER] repeatedly to change the setting. e.g.) digital TV mode - TV SETUP - PICTURE CHANNEL SETUP V-CHIP SETUP... -
Page 24: V-Chip
PTIONAL SETTING V-chip V-chip reads the ratings for programs, then denies access to the programs which exceed the rating level you set. With this function, you can block certain programming inappropriate for children. Press [SETUP] to display the main menu. Use [Cursor K /L] to select “V-CHIP SETUP“, then press [ENTER]. - Page 25 A. TV Rating A. TV Rating Use [Cursor K /L] to select “TV RATING”, then press [ENTER]. e.g.) digital TV mode - V - CHIP SETUP - TV RATING MPAA RATING DOWNLOADABLE RATING CHANGE PASSWORD Use [Cursor K /L ] to select the desired rating, then press [ENTER] repeatedly to switch between “VIEW”...
- Page 26 PTIONAL SETTING B. MPAA Rating B. MPAA Rating MPAA Rating is the rating system created by MPAA (Motion Picture Association of America). Use [Cursor K /L] to select “MPAA RATING”, then press [ENTER]. e.g.) digital TV mode - V - CHIP SETUP - TV RATING MPAA RATING DOWNLOADABLE RATING...
-
Page 27: Troubleshooting
ROUBLESHOOTING Troubleshooting Guide If the unit does not perform properly when operated as instructed in this owner’s manual, check the following chart once before calling for service. Symptom Remedy No power • Be sure the power cord is plugged in. •... -
Page 28: Maintenance
ROUBLESHOOTING Symptom The entered channel number changes automatically Remote control does not work Misspelled captions are displayed. Captions are not entirely displayed, or captions are delayed behind the dialogue. Captions are displayed as a white box. No caption is displayed in the closed caption-supported program. -
Page 29: Glossary
NFORMATION Glossary ATSC Acronym that stands for Advanced Television Systems Committee and the name of the digital broadcasting standards. Aspect Ratio The width of a TV screen relative to its height. Conventional TVs are 4:3 (in other words, the TV screen is almost square); widescreen models are 16:9 (the TV screen is almost twice as wide as its height). -
Page 30: Limited Warranty
FUNAI CORP. will repair this product, free of charge in the USA in the event of defect in materials or workmanship as follows: DURATION: PARTS: FUNAI CORP. will provide parts to replace defective parts without charge for one (1) year from the date of original retail purchase.
