Summary of Contents for Sylvania SSD800
- Page 1 OWNER’S MANUAL DVD PLAYER with VIDEO CASSETTE RECORDER SSD800 INSTRUCCIONES EN ESPAÑOL INCLUIDAS. If you need additional assistance for set-up or operating after reading owner’s manual, please call TOLL FREE : 1 - 800 - 968-3429 Please read before using this equipment.
-
Page 2: Laser Safety
WARNING : TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION : TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER SER- VICEABLE PARTS INSIDE. -
Page 3: Important Safeguards
IMPORTANT SAFEGUARDS 1. Read Instructions - All the safety and operating instruc- tions should be read before the appliance is operated. 2. Retain Instructions- The safety and operating instructions should be retained for future reference. 3. Heed Warnings - All warnings on the appliance and in the operating instructions should be adhered to. -
Page 4: About Copyright
A NOTE ABOUT RECYCLING This product’s packaging materials are recyclable and can be reused. Please dispose of all materials in accordance with your local recycling regulations. Batteries should never be thrown away or incinerated but disposed of in accordance with your local regulations concerning chemical wastes. -
Page 5: Table Of Contents
I LASER SAFETY ........2 I IMPORTANT SAFEGUARDS ......3 ABOUT COPYRIGHT . -
Page 6: I Features
Mode ¡ Dolby Digital sound This player can handle Dolby Digital surround sound with 5.1 channels when connected to a Dolby Digital decoder. ¡ Still/fast/slow/step playback Various playback modes are available including still pic- tures, fast forward/reverse, slow motion and step frames. ¡... -
Page 7: Installation Location
Mode Hardware specifications ¡ Auto Head Cleaner ¡ 4 Head HiFi Stereo ¡ Bilingual on-screen menu display selectable in English, French, or Spanish ¡ 181 channel capability PLL frequency synthesiz- er tuner with direct station call (A cable converter box may be necessary to view scram- bled cable channels.) Automatic functions ¡... -
Page 8: About The Discs
PLAYABLE DISCS The following discs can be played back on this DVD/VCR COMBINATION UNITS. Disc Type Logo Contents Disc Size 12 cm Sound Video Pictures 8 cm 12 cm Audio Sound 8 cm (singles) This player conforms to the NTSC color system. You can- not play discs recorded in other color systems such as PAL or SECAM. -
Page 9: Remote Control
OPERATING CONTROLS AND FUNCTIONS FRONT PANEL REMOTE CONTROL SPEED AUDIO POWER SKIP/CH. VCR/TV +100 DISPLAY PAUSE PLAY STOP RECORD MENU ENTER SETUP TITLE RETURN SEARCH MODE ZOOM MODE SUBTITLE ANGLE REPEAT 1. Disc loading tray 2. DVD OUTPUT Light (Green) [page 13] This light appears when the DVD output mode is selected. - Page 10 19. STOP/EJECT Button (VCR) [page 21] GEJECT Button Press to remove the tape from the VCR. STOP Button Press to stop the tape motion. Press to enter digits when setting program (For example:setting clock or timer program). Press to select the setting modes from the on screen menu.
-
Page 11: Rear View
48. ENTER Button Press to accept a setting. 49. g (FWD) Button DVD mode Press to fast forward the Disc. Press the PAUSE button, then press this button to begin slow motion playback. Press this button repeatedly to change the forward speed of slow motion. VCR mode Press to rapidly advance the tape, or view the pic- ture rapidly in forward during playback (Forward... -
Page 12: Display
DVD/VCR AUDIO OUT Jacks Connect the supplied audio cables here and to the Audio In jacks of a television or other audio equipment. COMPONENT VIDEO OUT Jacks Connect optional component video cables here and to the component Video In jacks of a televi- sion. -
Page 13: Vcr/Dvd Switching
Since this product comprises VCR and DVD players, it is necessary to select the correct output mode. SWITCHING TO VCR MODE Press the VCR button on the remote control. (Verify that the VCR OUTPUT Light is lit.) Notes ¡ Pressing only the OUTPUT button on the front panel does not switch the mode of the remote control. You always need to select the correct mode on the remote control too. -
Page 14: I Hookups
DVD/VCR TO TV CONNECTION 1. Disconnect the AC power cord of the TV from the AC outlet. 2. Disconnect the antenna or cable from the TV. 3. Connect the antenna or cable to the ANT-IN jack of the DVD/VCR COMBINATION UNITS. 4. -
Page 15: Deck
FOR TVs WITH COMPONENT VIDEO IN JACKS Use a component video cable (commercially available) in place of the yellow video cable to enjoy higher qual- ity pictures. The component video connection only supplies video (picture) in the DVD mode of the DVD/VCR COMBINA- TION UNITS. -
Page 16: Connecting To A Dolby Digital Decoder Or Dts Decoder
CONNECTING TO A DOLBY DIGITAL DECODER OR DTS DECODER If using this DVD/VCR COMBINATION UNITS to play a DVD disc in 5.1 channel Dolby Digital surround, or DTS surround formats, the DVD/VCR COMBINATION UNITS outputs a Dolby Digital, or DTS data stream from its COAXIAL DIGITAL AUDIO OUT jack. -
Page 17: I Setup
AUTOMATIC CHANNEL SET UP The VCR can automatically program the tuner to scan only the channels which are available in your area. ¡ Channel memory programming is NOT needed when the VCR is connected to a cable box or a satel- lite box as in "DVD/VCR TO TV CONNECTION"... -
Page 18: To Add/Delete Channels
TO ADD/DELETE CHANNELS When scanning, some channels may be skipped due to a weak signal. In such cases, you can add the channels to the VCR memory manually. Press the MENU button until the main menu appears. (If you have already set the clock, you only have to press it once. -
Page 19: Playback Function
NORMAL PLAYBACK Insert a prerecorded tape. The VCR will turn on, and the VCR/TV Light and the CST IN Light comes on. ¡ If the safety tab has been removed, the VCR will start playback automatically. Turn on the TV and set the TV to channel 3 or 4. ¡... -
Page 20: Recording Function
It may be UNLAWFUL to record copyrighted materi- al without the consent of the copyright owner. Accidental Erasure Prevention To prevent accidental recording on a recorded cassette, remove its record safety tab. To record on it later, cover the hole with cellophane tape. Before recording, make sure: ¡... -
Page 21: Hints For Timer Recording
4) Set the start time First, press the PLAY button or the STOP button for the hour. Then, press the F.FWD button. Next, press the PLAY button or the STOP button for the minute. Then, press the F.FWD button. And then, press the PLAY button or the STOP button for AM or PM. -
Page 22: Special Features
COPYING A VIDEO TAPE You can make copies of video tapes made by friends or relatives for your enjoyment. Warning: Unauthorized recordings of copyrighted video tapes may be an infringement of copyright laws. Connect the recording VCR (this unit), the playing VCR (another source) and your TV using the follow- ing diagram. -
Page 23: Auto Rewind
AUTO REWIND When a tape reaches the end during recording, play- back, or fast-forward, the tape will automatically rewind to the beginning. After rewinding finishes, the VCR will eject the tape. ¡ The VCR will not rewind the tape automatically dur- ing timer recording or One Touch Recording. -
Page 24: Using The Title Menu
USING THE TITLE MENU With a DVD containing a title menu, you can select the desired titles from the menu. Press the TITLE button. ¡ The title menu will appear. ¡ With some discs, a title menu may appear automati- cally. -
Page 25: Fast Forward/Reverse
FAST FORWARD/REVERSE Press the (FWD) or the ton during playback. ¡ For DVDs, pressing the g (FWD) or h (REV) button cycles the playback speed in four steps. In the case of DVDs, the sound will mute. For audio CDs, the playback speed is fixed at ×16. ¡... -
Page 26: Starting From A Desired Time Count
By using only the Number buttons. TITLE SEARCH: Directly enter the desired title number with the Number buttons with playback stopped. CHAPTER SEARCH: Directly enter the desired chapter number with the Number buttons when the disc is being played or paused. ¡... -
Page 27: Repeat
REPEAT Press the REPEAT button during playback. For DVDs ¡ A single title or chapter can be played back repeat- edly. ¡ Pressing the REPEAT button cycles the display on the screen as follows. REPEAT [OFF] REPEAT [CHAPTER] REPEAT [TITLE] For audio CDs ¡... -
Page 28: Program (Audio Cd)
PROGRAM (Audio CD) Press the MODE button in stop mode. ¡ The program screen will appear. Press the Number buttons to enter the desired track numbers. ¡ 50 programs can be displayed at once on the screen. Press “ ” to go to the next page. Press the PLAY button. -
Page 29: Playing An Mp3 Disc
PLAYING AN MP3 DISC Insert an MP3 file recorded on disc. ¡ The MP3 menu screen is displayed. ¡ Folders are referred to as “Albums” and files are referred to as “Tracks”. ¡ “+” appears at the beginning of the album name. ¡... -
Page 30: Playing A Desired Track From An Mp3 Disc
PLAYING A DESIRED TRACK FROM AN MP3 DISC Press the SEARCH MODE button during play- back. ¡ The SEARCH menu is displayed. ¡ The track currently being played or in RESUME ON will be highlighted. In the case of RESUME OFF, the first track of the disc will be highlighted. -
Page 31: I Settings
CHANGING THE AUDIO LANGUAGE OR SOUND MODE The DVD has a function which allows you to select the desired audio language and sound mode. For DVDs Press the AUDIO button during playback. ¡ The current audio status will appear at the top. Press the AUDIO button repeatedly until you see the language of your choice. -
Page 32: Changing The Subtitle Language
CHANGING THE SUBTITLE LANGUAGE The DVD has a function which allows you to select the desired language for subtitles. Press the SUBTITLE button during playback, and then press the SUBTITLE button to select the desired subtitle language. ¡ The subtitle language can be changed if the subtitles are recorded in multiple languages on the DVD being played. -
Page 33: Changing The On-Screen Display
CHANGING THE ON-SCREEN DISPLAY You can check the information regarding the disc by pressing the DISPLAY button on the remote control. For DVDs Press the DISPLAY button during playback. CH 7/49 0:01:46 -0:03:27 CH (Chapter): Current chapter number / the total number of chapters. -
Page 34: Changing The Setup Items
CHANGING THE SETUP ITEMS LANGUAGE SETTINGS Press the SETUP button in STOP mode. ¡ The setup screen is displayed. SET-UP 1.LANGUAGE 2.DISPLAY 3.AUDIO 4.PARENTAL SELECT: EXIT: SETUP Press the Arrow buttons ( Language, and then press the ENTER but- ton. SET-UP 1.LANGUAGE 2.DISPLAY... -
Page 35: Display Settings
DISPLAY SETTINGS Press the SETUP button in STOP mode. ¡ The setup screen will appear. SET-UP 1.LANGUAGE 2.DISPLAY 3.AUDIO 4.PARENTAL SELECT: SET: EXIT: SETUP CANCEL: Press the Arrow buttons ( select DISPLAY and then press the ENTER button. SET-UP 1.LANGUAGE 2.DISPLAY 3.AUDIO 4.PARENTAL... -
Page 36: Audio Settings
AUDIO SETTINGS Press the SETUP button in STOP mode. ¡ The setup screen will appear. Press the Arrow buttons ( Audio and then press the ENTER button. Press the Arrow buttons ( item, and then press the ENTER button. DRC (Default: OFF) On: DRC (Dynamic Range Control) ¡... -
Page 37: Parental Lock
PARENTAL LOCK Press the SETUP button in STOP mode. ¡ The setup screen will appear. SET-UP 1.LANGUAGE 2.DISPLAY 3.AUDIO 4.PARENTAL SELECT: EXIT: Press the Arrow buttons ( PARENTAL, and then press the ENTER but- ton. SET-UP 1.LANGUAGE 2.DISPLAY 3.AUDIO 4.PARENTAL SELECT: EXIT: SETUP... -
Page 38: Language Code List
Language Afar Abkhazian Afrikaans Amharic Arabic Assamese Aymara Azerbaijani Bashkir Byelorussian Bulgarian Bihari Bislama Bengali; Bangla Tibetan Breton Catalan Corsican Czech Welsh Danish [DAN] German [GER] Bhutani Greek [GRE] English [ENG] Esperanto Spanish [SPA] Estonian Basque Persian Finnish [FIN] Fiji Faroese French [FRE] Frisian... -
Page 39: Troubleshooting Guide
TROUBLESHOOTING GUIDE If the DVD/VCR COMBINATION UNITS does not perform properly when operated as instructed in this Owner's Manual, check the player consulting the following checklist. PROBLEM No power. The player does not respond to. • Check if the power plug is connected to an AC outlet. the remote control. -
Page 40: Cabinet Cleaning
HANDLING PRECAUTIONS SERVICING Should your DVD/VCR COMBINATION UNITS become inoperative, do not try to correct the problem by yourself. There are no user-serviceable parts inside. Turn off, unplug the power cord, and please call our help line at 1-800-968-3429 to locate an Authorized Service Center. -
Page 41: Specifications
Product type: Discs: Converter output: Power source: Power consumption: Operating temperature: Dimensions: Weight: ¡ Designs and specifications are subject to change without notice. ¡ If there is a discrepancy between languages, the default language will be English. SPECIFICATIONS DVD player with Video Cassette Recorder DVD video Audio CD Video Cassette tape... -
Page 42: Controles Del Funcionamiento Y Sus Funciones
CONTROLES DEL FUNCIONAMIENTO Y SUS FUNCIONES PANEL DELANTERO PANEL REMOTO POWER SPEED AUDIO SKIP/CH. VCR/TV +100 SLOW DISPLAY PAUSE PLAY STOP RECORD MENU ENTER SETUP TITLE RETURN SEARCH CLEAR/ MODE ZOOM MODE C.RESET SUBTITLE ANGLE REPEAT 1. Bandeja de carga del disco 2. - Page 43 Botón Stop Presione detener el movimiento de la cinta. Presione para entrar dígitos cuando ajuste progra- ma. (Por ejemplo: ajuste reloj o programa con tem- porizador). Presione para seleccionar los modos de ajuste del menú en pantalla. 20. Botón OUTPUT Presione para seleccionar el modo DVD o el modo VCR.
- Page 44 ma. (Por ejemplo: ajuste reloj o programa con tem- porizador), presione para determinar su selección y proceder al siguiente paso que usted desea entrar. Presione para determinar los modos de ajuste del menú en pantalla. Presione para añadir o cancelar números de canal durante preajuste de canal.
-
Page 45: I Cambio De Vcr/Dvd
Como este producto se utiliza del reproductor VCR y DVD, es necesario cambiar uno del otro. CAMBIO AL MODO VCR Presione el Botón VCR en el control remote. (Verifique que la Luz VCR OUTPUT está encendida.) Notas ¡ Presionando sólo el Botón OUTPUT en el panel delantero no cambia el modo del control remoto. Usted siem- pre necesita seleccionar el modo correcto en el control remoto, también. -
Page 46: I Conexiones
DVD/VCR A CONEXIÓN DE TV 1. Desconecte el cordón de alimentación AC del toma de corriente AC. 2. Desconecte la antena o cable del TV. 3. Conecte la antena o cable a la toma ANT.IN del UNIDADES COMBINADAS DE DVD/VCR. 4. -
Page 47: Preparación De Reloj
PREPARACIÓN DE RELOJ Ajuste el reloj con precisión para grabación con tempo- rizador automática adecuada. Le sugerimos que usted utilice un TV o estación de radio como su fuente de tiempos. Presione [MENU] dos veces para llamar el menú principal. (Si usted ha ajustado ya el reloj, usted sólo tiene que presionarlo una vez). -
Page 48: Limited Warranty
FUNAI CORP. will repair this SYLVANIA product, free of charge in the USA in the event of defect in materials or workmanship as follows: DURATION: PARTS: FUNAI CORP. will provide parts to replace defective parts without charge for one (1) year from the date of original retail purchase.
