Owner's Manual
Please read before using this unit.
DVD/CD Player
DVL150F
Supplied Accessory
• Remote control
• Audio/Video cables
(NB064UD) with
(WPZ0102TM015/
two AA batteries
WPZ0102LTE01/
WPZ0102CAB01)
Connecting to RF Modulator
If your TV has AUDIO/VIDEO input jacks, see the section
"Connections" on page 6. If not, it is still possible to connect
this unit to your TV by using a STEREO AUDIO/VIDEO RF
Modulator (commercially available). In this case, follow the
instructions below.
1) Connect the AUDIO/VIDEO output jacks of this unit to the
AUDIO/VIDEO input jacks of your RF Modulator by audio and
video cables.
2) The antenna input jack of your TV may have been already occu-
pied. If so, disconnect the RF cable from your TV, then connect
the RF cable to your RF Modulator (usually marked "ANT IN").
3) Connect your RF modulator to your TV by another RF cable.
4) Set your RF modulator's channel 3/4 switch to either 3 or 4,
whichever the TV channel is least used in your area. If your RF
modulator has a Modulator/Antenna switch, set it according to
your RF modulator's manual.
5) Turn on your TV and choose the same channel as you set the
RF modulator's channel 3/4 switch to.
For more details, follow the instructions supplied with the RF
Modulator.
Antenna
Cable
Signal
Stereo Audio/Video RF Modulator
(commercially available)
AC 120V
ANT IN
CHANNEL
TO TV
VIDEO
3
4
2
Hint
Hint
The quality of picture may become poor if the unit is connected
•
to an RF Modulator.
If you need additional operating assistance after
reading this owner's manual, please call
TOLL FREE : 1-800-968-3429
or visit our web site at
http://www.SylvaniaConsumerElectronics.com
• Owner's Manual
(1VMN20433)
Owner's Manual
(Back of DVD player)
AUDIO OUT
L
Y
C
R
/P
R
COMPONENT
VIDEO OUT
DIGITAL AUDIO OUT
S-VIDEO
COAXIAL
R
VIDEO
C
/P
B
B
OUT
OUT
1
AUDIO
R
L
Audio/Video
Cables
(Supplied)
Antenna in jack
RF Cable (Not supplied)
3
INSTRUCCIONES EN ESPAÑOL INCLUIDAS.

Table of Contents

Precautions
Laser Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
s Important Safeguards . . . . . . . . . . . . . . . . . . . . . . . . . 3
Installation Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Moisture Condensation Warning . . . . . . . . . . . . . . . . . . 4
About Copyright. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Notice for Progressive Scan Outputs . . . . . . . . . . . . . . . 4
Symbols Used in This Manual . . . . . . . . . . . . . . . . . . . . 4
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
s About the Discs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Playable Discs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Unplayable Discs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
s Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Connection to a TV . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Connection to an Audio System . . . . . . . . . . . . . . . . . . . 7
Rear Terminals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
s About the Remote Control . . . . . . . . . . . . . . . . . . . . . 8
Remote Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
s Playback. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
s MP3 Playback. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
s On-Screen Display. . . . . . . . . . . . . . . . . . . . . . . . . . . 10
s Search Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Track Search . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Title / Chapter Search . . . . . . . . . . . . . . . . . . . . . . . . . 11
Time Search . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
s Marker Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Repeat Playback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Repeat A-B Playback. . . . . . . . . . . . . . . . . . . . . . . . . . 12
Random Playback . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Programmed Playback. . . . . . . . . . . . . . . . . . . . . . . . . 12
s Special Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Subtitle Language . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
(Back of TV)
Audio Language . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Camera Angles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Black Level Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Stereo Sound Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Virtual Surround . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
s DVD Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
LANGUAGE Setting. . . . . . . . . . . . . . . . . . . . . . . . . . . 14
DISPLAY Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
AUDIO Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
PARENTAL Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
OTHERS Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
(Except for PARENTAL Setting) . . . . . . . . . . . . . . . . . . 17
s Troubleshooting Guide . . . . . . . . . . . . . . . . . . . . . . . 17
s Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
s Language List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
s Limited Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Español . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Quick Use Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DVL150F and is the answer not in the manual?

Questions and answers

Related Manuals for Sylvania DVL150F

Summary of Contents for Sylvania DVL150F

  • Page 1: Table Of Contents

    Owner’s Manual Please read before using this unit. DVD/CD Player DVL150F Supplied Accessory • Remote control • Audio/Video cables (NB064UD) with (WPZ0102TM015/ two AA batteries WPZ0102LTE01/ WPZ0102CAB01) Connecting to RF Modulator If your TV has AUDIO/VIDEO input jacks, see the section “Connections”...

  • Page 2: Laser Safety

    WARNING : TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION : TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK).

  • Page 3: Important Safeguards

    IMPORTANT SAFEGUARDS 1) Read Instructions - All the safety and operating instruc- tions should be read before the product is operated. 2) Retain Instructions - The safety and operating instruc- tions should be retained for future reference. 3) Heed Warnings - All warnings on the product and in the operating instructions should be adhered to.

  • Page 4: Installation Location

    Installation Location For safety and optimum performance of this unit: • Do not stand the unit up vertically. Install the unit in a horizontal and stable position. Do not place any- thing directly on top of the unit. Do not place the unit directly on top of the TV.

  • Page 5: About The Discs

    About the Discs Playable Discs Playable Mark (logo) discs DVD-Video * 1, 2, 4, 6 DVD-RW DVD-R * 1, 3, 4, 5, 6, 7, 9, 10 DVD+RW DVD+R * 1, 3, 4, 5, 6, 8 Audio CD * 4, 6 CD-RW CD-R * 4, 5, 6,...

  • Page 6: Setup

    Connections If your TV has AUDIO/VIDEO input jacks, see the following instructions. If not, see the section “Connecting to RF Modulator” on the front page. Connection to a TV Basic Audio AUDIO IN Audio cable (supplied) This unit AUDIO OUT DIGITAL AUDIO OUT AUDIO OUT COMPONENT...

  • Page 7: Connection To An Audio System

    Connection to an Audio System Method 1 Stereo system Analog audio input jacks AUDIO Audio cable (supplied) (Analog) AUDIO OUT This unit AUDIO OUT DIGITAL AUDIO OUT COAXIAL SETUP > AUDIO menu > Setting Connection Connecting to Stereo System. * To complete these settings, refer to pages 14-15. Hint Hint •...

  • Page 8: About The Remote Control

    About the Remote Control Remote Control POWER OPEN/CLOSE SEARCH DISPLAY MODE AUDIO SUBTITLE ANGLE REPEAT CLEAR PAUSE SKIP SLOW PLAY STOP SETUP TOP MENU MENU MODE ENTER ZOOM RETURN Installing the Batteries for the Remote Control Install two AA batteries (supplied) matching the polarity indicated inside battery compartment of the remote control.

  • Page 9: Functions

    Operations described after this section are mainly based on the remote control use. Some operations can be carried out on main unit. Playback Before: Turn on the TV, amplifier and any other equipments which are connected to this unit. Make sure the TV and audio receiver (commercially available) are set to the correct channel.

  • Page 10: Mp3 Playback

    MP3 Playback MP3 is a method of compressing files. You can copy MP3 files on CD-R/RWs from the computer and play the files on this unit. [MENU] Insert an MP3-format disc, then hit to call up the file list on the TV screen. MENU FILE LIST DISC NAME...

  • Page 11: Search Function

    Search Function Track Search Using [SEARCH MODE] Using [SEARCH MODE] SEARCH MODE Within 30 seconds. For the disc with less than 10 tracks, hit • the track number directly. For discs with more than 10 but less • than 99 tracks, to play single-digit track, hit [0] first, then the track number (e.g.

  • Page 12: Repeat / Random / Programmed Playback

    Repeat / Random / Programmed Playback Repeat Playback DVD-V DVD-V Repeat function is available only during playback. PLAY REPEAT Each time you hit [REPEAT], repeat function changes as example below. DVD-V DVD-V (current chapter repeat) CHAPTER (current title repeat) TITLE (repeat off) (current track repeat) TRACK...

  • Page 13: Special Settings

    Special Settings Subtitle Language DVD-V DVD-V This unit allows you to select a subtitle language (if available) during DVD play- back. PLAY 1.ENG/6 SUB TITLE Each time you hit [SUBTITLE], subtitle language changes as example below. (English subtitles) (French subtitles) (no subtitles) To set subtitle ON/OFF PLAY...

  • Page 14: Dvd Setup

    DVD Setup UICK SETUP Men UICK SETUP Men You can select the “PLAYER MENU”, “TV ASPECT” or “DOLBY DIGITAL” from the “QUICK SETUP” menu quickly. SETUP STOP <SETUP MENU> Confirm that “QUICK” is selected. SETUP QUICK CUSTOM INITIALIZE CUST OM Men CUST OM Men You can change the settings of the unit.

  • Page 15: Display Setting

    DISPLAY Setting You can change the display functions. Follow steps 1) to 3) in the “CUSTOM Menu” section on page 14. Select the desired item. TV ASPECT: (Default: 4:3 LETTER BOX) See Hint to the right. DISPLAY menu SETUP DISPLAY TV ASPECT 4:3 LETTER BOX STILL MODE:...

  • Page 16: Parental Setting

    PARENTAL Setting Parental Control limits the disc viewing that exceed your settings. (An incorrect password will not play.) This feature prevents your children from viewing inappropriate materials. arental vels arental vels Parental Level allows you to set the rating levels of your DVD discs. Playback will stop if the ratings exceed the levels you set. Follow steps 1) to 3) in the “CUSTOM Menu”...

  • Page 17: Reset To The Default Setting (Except For Parental Setting)

    Reset to the Default Setting (Except for PARENTAL Setting) SETUP STOP <SETUP MENU> SETUP QUICK CUSTOM INITIALIZE Troubleshooting Guide If the unit does not perform properly when operated as instructed in this Owner’s Manual, check the unit consulting the following checklist. Problem No power No sound or picture...

  • Page 18: Specifications

    13. If you choose any other languages, ‘---’ will be displayed instead. (3 letter language code is written in bracket.) LIMITED WARRANTY FUNAI CORP. will repair this SYLVANIA product, free of charge in the USA in the event of defect in materials or workmanship as follows:...

  • Page 19: Español

    Conexiones Si su televisor tiene entradas de AUDIO/VIDEO vea la sec- ción “Connection to a TV” en la página 6 en el Manual de Manejo. En caso contrario, vea la sección “Connecting to RF Modulator” en la página del frente en el Manual de Manejo. Instalación de las pilas en el control remoto Para cambiar el idioma...

  • Page 20: Quick Use Guide

    Connections If your TV has AUDIO/VIDEO input jacks, see the section “Connection to a TV” on page 6 of the Owner’s Manual. If not, see the section “Connecting to RF Modulator” on the front page of the Owner’s Manual. Installing the Batteries for the Remote Control To Change the On- Screen Language...
