Owner's Manual
Please read before using this unit.
DVD/CD Player
DVL150G
Supplied Accessories
Remote control
Audio/Video cables
(NB080UD) with
(WPZ0102TM015/
two AA batteries
WPZ0102LTE01)
Connecting to RF Modulator
If your TV has AUDIO/VIDEO input jacks, see the section
"Connections" on page 6. If not, it is still possible to
connect this unit to your TV by using a STEREO AUDIO/
VIDEO RF modulator (commercially available). In this
case, follow the instructions below.
1) Connect the AUDIO/VIDEO output jacks of this unit to the
AUDIO/VIDEO input jacks of your RF modulator by
Audio / Video cables.
2) The antenna input jack of your TV may have been already
occupied. If so, disconnect the RF cable from your TV and
then connect the RF cable to your RF modulator (usually
marked "ANT IN").
3) Connect your RF modulator to your TV by another RF
cable.
4) Set your RF modulator's channel 3/4 switch to either 3 or
4, whichever the TV channel is least used in your area. If
your RF modulator has a modulator/antenna switch, set it
according to your RF modulator's manual.
5) Turn on your TV and choose the same channel as you set
the RF modulator's channel 3/4 switch to.
For more details, follow the instructions supplied with the
RF modulator.
If your TV does not have AUDIO / VIDEO input jack.
Antenna
Cable
Signal
STEREO AUDIO / VIDEO RF Modulator
(commercially available)
AC 120V
ANT IN
CHANNEL
TO TV
3
4
2
Hint
• The quality of picture may become poor if the unit is connected to
an RF modulator.
If you need additional operating assistance
after reading this owner's manual, please call
TOLL FREE : 1-800-968-3429
or visit our web site at
http://www.SylvaniaConsumerElectronics.com
DVL150G_E6C21UD.indd 1
DVL150G_E6C21UD.indd 1
Owner's Manual
(1VMN22597A)
Owner's Manual
(Back of this unit)
L
Y
C
R
/P
R
COMPONENT VIDEO OUT
COAXIAL
R
DIGITAL
AUDIO
VIDEO
C
B
/P
B
OUT
OUT
AUDIO OUT
(Back of TV)
1
VIDEO
AUDIO
R
L
Audio/Video
Cables
(Supplied)
RF Cable (Not supplied)
3
Antenna in jack
INSTRUCCIONES EN ESPAÑOL INCLUIDAS.

Table of Contents

Precautions
Laser Safety ....................................................................2
■ Important Safeguards ...................................................3
Location and Handling .....................................................4
Warning of Dew Formation ..............................................4
About Copyright ...............................................................4
Notice for Progressive Scan Outputs ..............................4
Symbols Used in This Manual .........................................4
Maintenance ....................................................................4
■ About the Media.............................................................5
Playable Media ................................................................5
Unplayable Media ............................................................5
■ Connections ...................................................................6
Connection to a TV ..........................................................6
Connection to an Audio System ......................................7
■ About the Remote Control ............................................8
Remote Control ...............................................................8
■ Playback .........................................................................9
■ MP3/WMA Playback ......................................................10
■ Search Functions .........................................................10
Using Track Search ........................................................10
Using Title / Chapter Search ..........................................10
Using Time Search .........................................................10
■ On-Screen Display ........................................................11
■ Marker Setup .................................................................11
Repeat Playback ............................................................12
Repeat A-B Playback .....................................................12
Random Playback ..........................................................12
Programmed Playback ...................................................12
■ Special Settings ............................................................13
Subtitle Language ...........................................................13
Audio Language .............................................................13
Camera Angles ...............................................................13
Black Level Setting .........................................................13
S-VIDEO
OUT
Stereo Sound Mode........................................................13
Virtual Surround ..............................................................13
■ DVD Setup .....................................................................14
LANGUAGE Setting .......................................................14
DISPLAY Setting ............................................................15
AUDIO Setting ................................................................15
PARENTAL Setting ........................................................16
OTHERS Setting ............................................................16
(Except for PARENTAL Setting) .....................................17
■ Troubleshooting Guide ................................................17
■ Specifications ...............................................................18
■ Language Code List .....................................................18
■ Limited Warranty ..........................................................18
■ Español ..........................................................................19
■ Quick Use Guide ............................................ Back Cover
2006/05/10 9:36:50
2006/05/10 9:36:50

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DVL150G and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sylvania DVL150G

Summary of Contents for Sylvania DVL150G

  • Page 1: Table Of Contents

    Owner’s Manual Please read before using this unit. DVD/CD Player DVL150G Supplied Accessories Remote control Audio/Video cables (NB080UD) with (WPZ0102TM015/ two AA batteries WPZ0102LTE01) Connecting to RF Modulator If your TV has AUDIO/VIDEO input jacks, see the section “Connections” on page 6. If not, it is still possible to connect this unit to your TV by using a STEREO AUDIO/ VIDEO RF modulator (commercially available).

  • Page 2: Laser Safety

    WARNING : TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION : TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE.

  • Page 3: Important Safeguards

    IMPORTANT SAFEGUARDS 1) Read Instructions - All the safety and operating instructions should be read before the product is operated. 2) Retain Instructions - The safety and operating instructions should be retained for future reference. 3) Heed Warnings - All warnings on the product and in the operating instructions should be adhered to.

  • Page 4: Location And Handling

    Location and Handling • Do not stand this unit up vertically. Install this unit in a horizontal and stable position. Do not place anything directly on top of this unit. Do not place this unit directly on top of the TV. •...

  • Page 5: About The Media

    About the Media Playable Media Playable Mark (logo) discs DVD-Video *1, 2, 4, 6 DVD-R DVD-RW *1, 3, 4, 5, 6, 7, 9, 10 DVD+R DVD+RW *1, 3, 4, 5, 6, 8, 9, 10 Audio CD *4, 6 CD-R CD-RW *4, 5, 6, 9, 10 is a trademark of DVD Format/Logo Licensing Corporation.

  • Page 6: Setup

    Connections If your TV has AUDIO/VIDEO input jacks, see the following instructions. If not, see the section “Connecting to RF Modulator” on the front page. Connection to a TV Basic Audio AUDIO IN Audio cable (supplied) This unit AUDIO VIDEO AUDIO AUDIO OUT (Analog)

  • Page 7: Connection To An Audio System

    Connection to an Audio System Playing 2 channel audio Stereo system AUDIO Audio cable (supplied) This unit AUDIO OUT (Analog) Hint • Playing a DVD using incorrect settings may generate noise distortion and may also damage the speakers. Front Panel Indicator and Rear Terminals Front Panel POWER 1 POWER indicator...

  • Page 8: About The Remote Control

    About the Remote Control Remote Control POWER OPEN/CLOSE SEARCH DISPLAY MODE AUDIO SUBTITLE ANGLE REPEAT CLEAR SKIP PAUSE SLOW PLAY STOP SETUP TOP MENU MENU MODE ENTER ZOOM RETURN Installing the Batteries for the Remote Control Install two AA batteries (supplied) matching the polarity indicated inside battery compartment of the remote control.

  • Page 9: Functions

    Operations described in this section are mainly based on the remote control use. Some operations can be carried out on main unit. Playback Before: Turn on the TV, amplifier and any other equipments which are connected to this unit. Make sure the TV and audio receiver (commercially available) are set to the correct channel.

  • Page 10: Mp3/Wma Playback

    MP3/WMA Playback MP3/WMA is a method of compressing files. You can copy MP3/WMA files on CD-R/RWs from the computer and play the files on this unit. Insert an MP3/WMA-format disc, then the file list will automatically appear on the TV screen.

  • Page 11: On-Screen Display

    On-Screen Display You can check the information about the current disc by pressing [DISPLAY] on the remote control. Angle icon appears only when avail- able on the DVD. Current playback status 11/16 0:00:00 - 0:03:30 Remaining time of the current chapter Elapsed time of the current chapter CH(Chapter): Current chapter number / Total chapters...

  • Page 12: Repeat / Random / Programmed Playback

    Repeat / Random / Programmed Playback Repeat Playback Repeat function is available only during playback. PLAY REPEAT <Example : DVD> Each time you press [REPEAT], repeat function changes as example below. (repeat off) CHAPTER (current chapter repeat) TITLE (current title repeat) (repeat off) TRACK (current track repeat)

  • Page 13: Special Settings

    Special Settings Subtitle Language This unit allows you to select a subtitle language (if available) during DVD playback. PLAY 1.ENG/6 SUBTITLE Each time you press [SUBTITLE], subtitle language changes as example below. (no subtitles) (English subtitles) (French subtitles) To set subtitle ON/OFF PLAY 1.ENG/6 SUBTITLE...

  • Page 14: Dvd Setup

    DVD Setup QUICK SETUP Menu You can select the “PLAYER MENU”, “TV ASPECT”, “PROGRESSIVE” or “DOLBY DIGITAL” from the QUICK SETUP menu quickly. SETUP STOP <SETUP MENU> Confirm that “QUICK” is selected. QUICK SETUP PLAYER MENU ENGLISH TV ASPECT 4:3 LETTER BOX PROGRESSIVE DOLBY DIGITAL BITSTREAM...

  • Page 15: Display Setting

    DISPLAY Setting You can change the display functions. Follow steps 1 to 3 in the “CUSTOM Menu” section on page 14. Select the desired item. ENTER DISPLAY menu DISPLAY TV ASPECT 4:3 LETTER BOX STILL MODE AUTO PROGRESSIVE ENTER Hint TV ASPECT: •...

  • Page 16: Parental Setting

    PARENTAL Setting Parental Control limits the disc viewing that exceed your settings. (An incorrect password will not be acceptable.) This feature prevents your children from viewing inappropriate materials. Parental Levels Parental Level allows you to set the rating levels of your DVD discs. Playback will stop if the ratings exceed the levels you set.

  • Page 17: Reset To The Default Setting (Except For Parental Setting)

    Reset to the Default Setting (Except for PARENTAL Setting) SETUP STOP <SETUP MENU> QUICK SETUP PLAYER MENU ENGLISH TV ASPECT 4:3 LETTER BOX PROGRESSIVE DOLBY DIGITAL BITSTREAM Troubleshooting Guide If the unit does not perform properly when operated as instructed in this Owner’s Manual, check the unit consulting the following checklist. Problem No power No sound or picture...

  • Page 18: Specifications

    Specifications Output signal format: NTSC color Power source: 120 V AC +/- 10%, 60 Hz +/- 0.5% Power consumption: 10 W (standby: 0.8 W) Language Code List Language Code Language French [FRE] Abkhazian 4748 Frisian Afar 4747 Galician Afrikaans 4752 Georgian Albanian 6563...

  • Page 19: Español

    Español Conexiones Si su televisor tiene entradas de AUDIO/VIDEO vea la sección “Connection to a TV” en la página 6 en el Manual de Manejo. En caso contrario, vea la sección “Connecting to RF Modulator” en la página del frente en el Manual de Manejo.

  • Page 20: The Remote Control

    Quick Use Guide Connections If your TV has AUDIO/VIDEO input jacks, see the section “Connection to a TV” on page 6 of the Owner’s Manual. If not, see the section “Connecting to RF Modulator” on the front page of the Owner’s Manual.
