- Page 1 Workingman’s Series BASS SPEAKER ENCLOSURES OWNER’S MANUAL WORKINGMAN’S 1X10T WORKINGMAN’S 2X15T WORKINGMAN’S 2X10T WORKINGMAN’S 4X10T WORKINGMAN’S TOWER SWR • CORONA, CA • USA...
-
Page 2: Introduction
SWR WORKINGMAN’S SERIES BASS SPEAKER ENCLOSURE USER GUIDE INTRODUCTION Congratulations on your purchase of an SWR WorkingMan’s Series bass speaker enclo- sure. By placing an SWR cabinet in your bass amplification system you have made a sound desicion that could very well be the best of your life! Just a little humor there, but true nonetheless. -
Page 3: Table Of Contents
Input Panel Diagrams ......4 WorkingMan’s 1X10T ......5 WorkingMan’s 1X15T . -
Page 4: General Information
GENERAL INFORMATION Connection Only one amplifier at a time can be connected to your WorkingMan’s speaker enclosure. DO NOT plug two amplifiers into one speaker enclosure, as it will not work and may damage your system. Always complete your amplifier-to-speaker and speaker-to-speaker connections before powering up your sys- tem. -
Page 5: Input Panel Diagrams
INPUT PANEL DIAGRAM All Models (except WorkingMan’s Tower) Tweeter Attenuator Switch 1/4" Input 1/4" Output INPUT PANEL DIAGRAM WorkingMan’s Tower Tweeter Attenuator Control Workingman’s Series Bass Speaker Enclosures • 4 1/4" Input 1/4" Output Speakon Input Speakon Output... -
Page 6: Workingman's 1X10T
8 ohm load. To connect your amplifier to the WorkingMan’s 1X10T, run a high quality speaker cable (18 gauge or heavier) from your amplifier’s speaker output to the designated 1/4" speaker input on the cabinet's input panel. -
Page 7: Workingman's 1X15T
WORKINGMAN’S 1X15T Specifications Description: 1x15 and Tweeter Speaker Enclosure Power Handling: 200 watts RMS Impedance: 8 ohms Frequency Response & SPL: 100 dB SPL @ 1W1M (–6dB @ 40 Hz and 18KHz) Speaker Complement: (1) Custom Designed, Stamped Steel Frame 15" SWR Driver (1) Custom Designed Tweeter Porting: Front Slot Port... -
Page 8: Workingman's 2X10T
WORKINGMAN’S 2X10T Specifications Description: 2x10 and Tweeter Speaker Enclosure Power Handling: 200 watts RMS Impedance: 8 ohms Frequency Response & SPL: 98 dB SPL @ 1W1M (–3db @ 63 Hz and 18.5 KHz) Speaker Complement: (2) Custom Designed 10" SWR Drivers (1) Custom Designed Tweeter Porting: Front Slot Port Dimensions: 23"W x 17"H x 16.25"D... -
Page 9: Workingman's 4X10T
WORKINGMAN’S 4X10T Specifications Description: 4x10 and Tweeter Speaker Enclosure Power Handling: 400 watts RMS Impedance: 8 ohms Frequency Response & SPL: 100 dB SPL @ 1W1M (–3dB @ 50 Hz and 18KHz) Speaker Complement: (2) Custom Designed 10" SWR Drivers (1) LCustom Designed Tweeter Porting: Front Slot Port Dimensions: 23"W x 25.25"H x 18.375"D... -
Page 10: Workingman's Tower
WORKINGMAN’S TOWER Specifications Description: 8x10 and Tweeter Speaker Enclosure Power Handling: 800 watts RMS Impedance: 4 ohms Frequency Response & SPL: 93 dB @ 1W1M (–3dB 60 Hz & 13.5 kHz) Speaker Complement: (8) Custom Designed, Stamped Steel Frame, 10" SWR Drivers (1) Custom Designed Tweeter Porting: Front Slot Port... - Page 11 WORKINGMAN’S TOWER Tweeter Attenuator Control The large dial found on the input panel of the cabinet is the Tweeter Attenuator Control (see dia- gram, page 4). This control is used to adjust the level of high frequency signal present at the tweeter.
-
Page 12: Impedance: A General Overview
IMPEDANCE: A GENERAL OVERVIEW The following terms will be helpful in understanding the information in this section: Impedance: The resistance of a device to the flow of alternating current. Often used to rate the resistance of a speaker's voice coil. Ohm: A unit of electrical resistance equal to that of a conductor in which a current of one ampere is produced by a potential of one volt across its terminals. -
Page 13: Troubleshooting Guide
IMPEDANCE (continued) one 8 ohm enclosure, you know you can add one more 8 ohm speaker safely (8 divided by 2 = 4). Although much less common, you could also add one, or even two, 16 ohm cabinets: two 16 ohm cabinets in parallel have the same total impedance as one 8 ohm speaker. - Page 14 than one cabinet, check all cable connections in the chain. If you then suspect that the problem may be a bad cable, you can use a 9 volt battery as a cable-tester. To do so, plug one end of the questionable cable into your speaker cabinet, and then touch the phone plug on the other end to the two terminals (+ and –) of the battery, contacting the tip and sleeve.
-
Page 15: Warranty Information
SWR LIMITED WARRANTY YEAR from the date of purchase (with the exception of the WorkingMan’s Tower which is war- rantied for TWO YEARS) against defects in materials and workmanship, provided that it is pur- chased from an Authorized SWR dealer. This warranty applies only to products purchased in the USA or Canada. -
Page 16: Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS CAUTION: TO REDUCE RISK OF ELECTRIC SHOCK, DO NOT REMOVE THE COVER OR BACK. NO USER-SERVICEABLE PARTS INSIDE. PLEASE REFER TO A QUALIFIED SERVICE TECHNICIAN. A. Read Instructions: All safety and operation instructions should be read before the product is operated. B.
