Swann TV Cables Easy Setup Manual

A
DVR Unit
Packaging
4 x Maxi Day/Night Extension Cables x 4
Cameras
Camera Power
Software CD Camera Power
Supply
Power Cable for DVR Power
Ethernet
DVR Power Supply Supply
B
Connecting the Monitor to DVR
Right side of Monitor
2. Connect BNC end to
Monitor on DVR
1. Connect Mini Jack to
Connect Yellow RCA
3.
right side of montior
cables together
Tune Monitor to
4.
AV1 using controls
Swann Communications • Toll Free Technical Support: USA - 1-800-627-2799, 1-877-274-3695, Australia - 1300 13 8324 • Email: tech@swann.com.au
C

Package Contents

8" Monitor and
Remote
Manual Security
Stickers
Monitor Power
Splitter Supply
BNC to
Cable
RCA Cable
Back of DVR
Audio
DVR4 - PRO-NET, 4 Camera & LCD
Camera 1 Camera 2
3.
Connect Power end of
Extension Cable to
Camera Power Splitter
SPARE
Camera Power Splitter
Easy Setup Guide
DVR & Camera Connections
Camera 3
1.
Connect Camera cables
to Extension Cables x 4
2.
Connect extension cables
to camera inputs on back
of DVR
4.
Plug in DVR Power
& Camera Power
www.swannsecurity.com
Camera 4
DVR
Power Supply
Camera
Power Supply
