Camera kit

Advertisement

Quick Links

A
Package Contents
Packaging
2 or 3 NightHawk
Cameras
Receiver
Hardware
AV Cable
Remote Control
C
Connecting the receiver to your TV
Back of Receiver
1.
Connect the AV cable to the back of the Receiver
2.
Connect the AV cable to an available Video INPUT on TV
3.
Tune TV to the correct INPUT* using TV remote
Nighthawk 2/3 Camera Kit Easy Setup Guide
B
Quick Start Manual
Receiver Power
Supply
Connect the A/V cable
from the receiver to
the VCR
Camera Power
Supplies
Back of TV
INPUTS
1
3
D
Power on the Receiver,
1.
VCR and TV
*Some VCR's and TV's will list this as INPUT, A/V, SOURCE, L1, Channel 0 - Consult your manufacturer's manual for more information
1 877 274 3695
1300 13 8324
RECEIVER
Plug the power supply
D.
into the receiver
VCR
AUDIO
VIDEO
LINE IN
LINE OUT
Connect an A/V cable
B.
from the Line OUTPUT
on the back of the VCR
2.
Using your TV's remote
control tune your TV to
the correct INPUT*. In our
example above the TV
should be set to INPUT 1
tech@swann.com.au
Connecting the receiver to record on a VCR
TV
Component
INPUTS
1
Video
INPUTS
1
3
Connect the A/V cable
C.
to the INPUT on the
back of the TV
Viewing the cameras and recording to VCR
3.
Using your VCR's remote
4.
You should now see
control tune your VCR to
your cameras on the
the LINE 1 INPUT*
TV screen. Follow
your manufacturer's
instructions to
record to your VCR
www.swannsecurity.com
2
Video
OUTPUT
