SVAT CV0104DVR Instruction Manual

Web ready 4 channel dvr w/ 80gb hard drive
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
SVAT ELECTRONICS
Now You Can See
Web Ready 4 Channel DVR
W/ 80GB Hard Drive
EXPANDABLE SYSTEM
Instruction Manual
Model #
CV0104DVR
www.svat.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CV0104DVR and is the answer not in the manual?

Questions and answers

Related Manuals for SVAT CV0104DVR

Summary of Contents for SVAT CV0104DVR

  • Page 1 SVAT ELECTRONICS Now You Can See Web Ready 4 Channel DVR W/ 80GB Hard Drive EXPANDABLE SYSTEM Instruction Manual Model # CV0104DVR www.svat.com...
  • Page 2 SVAT ELECTRONICS Now You Can See CV0104DVR www.svat.com...

  • Page 3: Product Warranty & Registra Tion

    We take quality very seriously. This is why all of our products come with a one year warranty from the original purchase date against defects in workmanship and materials. If you have warranty or support issues please contact us using any of the following methods: SVAT Electronics USA 2315 Whirlpool St., Unit 333 NIagara Falls, New York...

  • Page 4: Table Of Contents

    5x BNC Connectors Software RCA to RCA Installation CD wire (male) T IS COMP T IS COMP The CV0104DVR is compatible with TVs, VCRs, computers and other SVAT systems including: CV65 CVP400C CV0104DVR 1x DVR Power Adapter RJ-45 Ethernet Cable...

  • Page 5: Safety Precautions

    SVAT ELECTRONICS Now You Can See SAFETY PRECAUTIONS SAFETY PRECAUTIONS Disposal of Old Electrical & Electronic Equipment (Applicable in the European Union and other European countries with separate collection systems). This symbol on the product or on its packaging indicates that this product shall not be treated as household waste.

  • Page 6: Introduction / Features

    1. INTRODUCTION 1. INTRODUCTION The CV0104DVR is a feature packed digital video recorder that can record four different camera views simultaenously and play it back at a smooth 30 frames per second. Customize the recording and set a 24 hour recording schedule based on your preferences.

  • Page 7: Installation

    RCA wire, there is no need to plug in the red or white inputs. On your television switch to the video/audio input channel Your system is now installed and ready for use. CV0104DVR SVAT ELECTRONICS Now You Can See...

  • Page 8: Name & Function Of Each Part

    Video Input [VIDEO IN]: Connect to cameras. DC 12V/ 4.2A [Power Input terminal]: power socket. S-Video Output [S-VIDEO OUT]: Connect to the monitor. Video Output [VIDEO OUT]: Connect to the monitor. Cooling Fan. RJ45: Internet connection terminal. CV0104DVR SVAT ELECTRONICS Now You Can See...

  • Page 9: Operating Procedure

    SVAT ELECTRONICS Now You Can See 4. OPERA TING PROCEDURE 4. OPERA TING PROCEDURE 4.1 POWERING ON This DVR is built to be on at all times, and therefore should be connected to a surge protected power bar (UPC power backup). Use the power bar's switch to turn the unit off and on.

  • Page 10: Playback Mode

    EACH mode. When the recording is done, press STOP to return to live mode. During playback, press FF to change the playback speed (FF1, FF2, FF3), or press the REW button to reverse playback. CV0104DVR SVAT ELECTRONICS Now You Can See...

  • Page 11: System Setup

    (second layer to first layer or third layer to second layer) and will auto update the modified data. Under main menu (first menu layer), the system will enter live mode. Press ENTER to increase or decrease the highlighted setting values. Menu Layer Operation Guide CV0104DVR SVAT ELECTRONICS Now You Can See...
  • Page 12 “System Setup” is situated on the second menu layer. Under this menu layer user may setup the system time, password, return system to default value, and language preference, etc (VERSION displayed represents the FIRMWARE version). CV0104DVR SVAT ELECTRONICS Now You Can See...

  • Page 13: Time Setup

    SVAT ELECTRONICS Now You Can See 5.2.1 TIME SETUP Time Set - Sets the time and date on your DVR. Use the up and down arrows to select a value to change, and press ENTER to change the value. When you are finished, press MENU to return to the previous menu screen.

  • Page 14: Password Setup

    The password must be entered to stop recording. Select STOP REC again to turn this feature off. When an incorrect password has been entered, “PASSWORD INCORRECT” will be shown on the display. To disable the message, press button: QUAD, CH1, CH2, CH3, or CH4. CV0104DVR SVAT ELECTRONICS Now You Can See...

  • Page 15: Change Password

    “PASSWORD CHANGED”. Default Value: 111111 If password entered is incorrect, you will receive a message “NO PASSWORD CHANGED” to inform you (message flashes three times) and the system returns to “Password setup” selection. CV0104DVR SVAT ELECTRONICS Now You Can See...

  • Page 16: Load Default

    SVAT ELECTRONICS Now You Can See 5.2.3 LOAD DEFAULT Press enter on this option to return the DVR to its factory default settings. Press enter again to confirm, or menu to cancel. When the message “DVR RESET COMPLETED TURN OFF AND ON THE VCR” is displayed, restart the DVR.

  • Page 17: Language Setup

    SVAT ELECTRONICS Now You Can See 5.2.4 LANGUAGE SETUP To setup “LANGUAGE SET” function, press ENTER, to select the desired language (languages supported are Chinese and English). CV0104DVR...

  • Page 18: Camera Setup

    “V” indicates the position of the cursor. Press the up and down buttons to move the cursor, and press ENTER to change the title (maximum 8 characters). All channel titles are setup in the same way. CV0104DVR SVAT ELECTRONICS Now You Can See...
  • Page 19 Motion Sensitivity - Press ENTER to set up the motion sensitivity level (1-5, 1 being the most sensitive). Hue - Press ENTER to adjust the color of the camera. Contrast - Press ENTER to adjust the camera contrast. Brightness - Press ENTER to adjust the camera brightness CV0104DVR SVAT ELECTRONICS Now You Can See...

  • Page 20: Record Setup

    “M” (motion) or “A” (alarm) modes are set up under schedule record. Recording frame rates available: NTSC: 30, 15, 10, 7, 5, 4, 3, 2, 1 PAL: 25, 12, 8, 6, 4, 3, 2, 1 CV0104DVR SVAT ELECTRONICS Now You Can See...
  • Page 21 (1) When motion has been detected, it will be recorded by “Motion Record Frame Rate”. (2) Otherwise, it is recorded by “Time Record Rate”. _ : OFF. The DVR will not record during the specified time. CV0104DVR SVAT ELECTRONICS Now You Can See...

  • Page 22: Buzzer Setup

    (this setup is only active when the system is under record status). BUZZER TIME: Press ENTER to setup the buzzer time to continuous (CONT), and press any button to release this setup. CV0104DVR SVAT ELECTRONICS Now You Can See...

  • Page 23: Event List

    Press ENTER to proceed. Press MENU to exit “EVENT LIST” selection. “EVENT LIST” is situated on the second menu layer. Under this menu layer user may setup “TIME SERACH” or “EVENT SEARCH”. CV0104DVR SVAT ELECTRONICS Now You Can See...

  • Page 24: Time Search

    TIME SEARCH: Displays system recording time (begin and end). Press button to select the desired time and date. Press ENTER to setup playback starting time and date. Press MENU to exit “TIME SEARCH” selection. Press PLAY button to play. CV0104DVR SVAT ELECTRONICS Now You Can See...

  • Page 25: Event Search

    EVENT SEARCH: Displays all recording events, every page consists of 7 events, and maximum 63 stored events. Press PLAY button to play the selected event. BEGIN: 05/01/15 15:00:01 Displays the beginning and end time of each event. CV0104DVR END: 05/01/15 15:00:06 SVAT ELECTRONICS Now You Can See...

  • Page 26: Hard Drive Setup

    MASTER HDD USED: displays the capacity of the MASTER HDD already used. SLAVE HDD: displays the capacity of the SLAVE HDD. SLAVE HDD USED: displays the capacity of the SLAVE HDD already used. N/A indicates HDD not installed or unable to be detected. CV0104DVR SVAT ELECTRONICS Now You Can See...
  • Page 27 INCORRECT” (flashes 3 times), and return to “HARD DRIVE” selection. Once the user formats the hard disk drive (MASTER), the camera title returns to its default setting (CAMERA1/ CAMERA2/ CAMERA3/ CAMERA4), because this setup is stored in the hard disk drive (MASTER). CV0104DVR SVAT ELECTRONICS Now You Can See...

  • Page 28: Network Remote Control (Optional)

    Use IPEDIT.exe to find the installed Network DVR. Select this Network DVR in the Camera List Window. The default configuration will be shown on the right window. Update the IP status. CV0104DVR Online with DHCP Server SVAT ELECTRONICS Now You Can See...

  • Page 29: Connecting Network Dvr

    After the “Submit” button is clicked, the IP information of this Network DVR will be updated. 6.2 CONNECTING NETWORK DVR 3 methods for connecting Network DVR: Online using Intranet or Static IP Online using ADSL (PPPoE) Router Online using DDNS Server CV0104DVR Online without DHCP Server SVAT ELECTRONICS Now You Can See...
  • Page 30 SVAT ELECTRONICS Now You Can See 6.2.1 ONLINE USING Setup similar to “6.1 Network DVR Setup”. 6.2.2 ONLINE USING ADSL (PPPOE) ROUTER Setup similar to “6.4.3.3 Connect to ADSL by PPPoE mode”. 6.2.3 ONLINE USING DDNS SERVER (RECOMMENDED) The DDNS service provides the dynamic IP to users to gain access to resources connected to the Internet via a cable or DSL connection.
  • Page 31 SVAT ELECTRONICS Now You Can See 6.2.4.1 ONLINE CONNECTION Before entering remote connection, install ActiveX (If you are running Windows XP you most likely have it) and check your browser setup by following the procedures below: A. Open Internet Explorer under “Tools” and select “Internet Options”.
  • Page 32 SVAT ELECTRONICS Now You Can See Change ActiveX settings to the ones seen above CV0104DVR...
  • Page 33 SVAT ELECTRONICS Now You Can See The graphic below will be shown the first time you install the ActiveX Control. Please select "Yes" to accept installation. Download ActiveX Control Live view will be displayed when installation is successful. Live display under ActiveX mode...

  • Page 34: Main Display

    Save Current Picture/ Save the current image. • Welcome! Administrator/ Display current user name. • About/ Version description. Move the cursor inside the image range, right mouse click to display 9 function selections: CV0104DVR Remote control DVR - Main Menu SVAT ELECTRONICS Now You Can See...

  • Page 35: Image Recording

    Time: Image storage according to “time”. Maximum Number of Frame in Each File: Image storage according to “maximum frame”. Save Path: Image storage according to “Save Path”. Pre Name: Image storage according to “Prefix Name”. CV0104DVR SVAT ELECTRONICS Now You Can See...

  • Page 36: Save Current Picture

    Controls, on page 5). 6.3.7 QUALITY SETTING Network DVR provides 5 image quality settings. The user can select the quality setting from the “Quality” list box. • Highest • High • Medium • • Lowest CV0104DVR SVAT ELECTRONICS Now You Can See...
  • Page 37 Only the administrator can select the “Configuration”; the ordinary user account does not have this privilege to access this function. 6.4.1 SYSTEM SETTING The number on Port 1 and Port 2 may be changed, press “OK” button to save the setting. CV0104DVR System Setting Display SVAT ELECTRONICS Now You Can See...

  • Page 38: User Authorization Setting

    Select item “Needed” to enable user authorization function, then each time before login to Network DVR the Login window will request for “Username” and “Password”. To disable user authorization function, select item “No Need”. CV0104DVR User Setting Display SVAT ELECTRONICS...

  • Page 39: New User / Change Password

    List”. 6.4.3 NETWORK SETTING 6.4.3.1 FIXED IP To setup follow the steps below: Select item “Manually”. Enter “IP Address”, “Subnet mask”, and “DNS”. Click “OK” button to save the setting. CV0104DVR User Setting Display SVAT ELECTRONICS Now You Can See...

  • Page 40: Connect To Adsl By Pppoe Mode

    Once connected, mail the IP address information to the preset e-mail address. After 10 times of connection failure, it aborts the operation and the user can reconnect it by LAN to find the cause. CV0104DVR ADSL Setting Display SVAT ELECTRONICS...
  • Page 41 To setup follow the steps below: Register at DDNS Server: http://www.dyndns.org. Apply domain name. Click the "Enable" button. Enter "Username" and "Password" and the domain name you registered with dyndns.org. CV0104DVR Connection Message Send to User DDNS Setting SVAT ELECTRONICS Now You Can See...

  • Page 42: Firmware Update

    In the configuration menu of your network DVR, click on Firmware Update. Select browse and select the .bin firmware file. Press Open. Press Upload and follow the onscreen instructions. CV0104DVR Select the Firmware to be Updated Uploading the Selected Firmware SVAT ELECTRONICS...
  • Page 43 SVAT ELECTRONICS Now You Can See Firmware Update. Press "here" button (1) to update Firmware. Press "here" button (2) to delete the file. The message below displays the writing progress of the firmware update. When Firmware update is completed, it will show 100%, and a message "Click here to reboot DVR browser"...

  • Page 44: Troubleshooting

    DVR not recording No playback During playback, I can't switch to different camera views. CV0104DVR Solution Make sure all RCA and power cables are plugged in securely and in their proper places. Make sure your television is on the correct channel (input mode).
  • Page 45 Problem Unexpected Alarms (beeps) go off. No picture from camera(s) CV0104DVR Solution Video Loss - One of your cameras are disconnected. There are a few options: connect a camera, disable that camera's channel if you don't want a camera installed in that channel, or disable the VIDEO LOSS alert alarm by going to MENU>Buzzer Setup>Video...

  • Page 46: Glossary

    SVAT ELECTRONICS Now You Can See 8. GLOSSAR 8. GLOSSAR DDNS - Dynamic Domain Name Service. Use dyndns.org to track your IP on the Internet and assign it an easy to remember domain name instead of an IP number. Dynamic IP (DHCP) - A DHCP server assigns an IP address automatically when a device connects to the network.

  • Page 47: Port Forwarding

    SVAT ELECTRONICS Now You Can See 9. PORT FOR ARDING YOUR ROUTER FOR USE 9. PORT FOR ARDING YOUR ROUTER FOR USE WITH NETWORK DVR WITH NETWORK DVR 1. Belkin Router 2. DLINK Wireless Router 3. LINKSYS Wireless Router 4. LINKSYS Wired Router 5.
  • Page 48 The set up instruction outlined below is an example of port forwarding using Linksys Model WRK54GV2. Step 1: Open your web browser. Enter the router IP address in the address bar as shown below (192.168.1.1), followed by pressing Enter. CV0104DVR SVAT ELECTRONICS Now You Can See...
  • Page 49 SVAT ELECTRONICS Now You Can See Step 2: Enter the user name and password as shown below (admin by default) and press the OK button. Step 3: Select the Applications and Gaming tab. Step 4: Select the Port Range Forwarding tab.
  • Page 50 The set up instruction outlined below is an example of port forwarding a Netgear Router using Netgear Model DG 824M. Step 1: Open your web browser. Enter the router IP address (192.168.0.1)in the address bar as shown below, followed by pressing Enter. CV0104DVR SVAT ELECTRONICS Now You Can See...
  • Page 51 SVAT ELECTRONICS Now You Can See Step 2: Enter ‘admin’ in the User Name and ‘password’ in the Password dialog box to enter the Westell configuration page. Step 3: Select the Services button in the Security menu Step 4: In the Services menu, select the Add Custom Service button...
  • Page 52 SVAT ELECTRONICS Now You Can See Step 6: In the Port Range screen, proceed as follows: In the Service Name field, type DVR In the Global Port Range field, enter in the first box, the first number of the port you need to port forward (e.g.
  • Page 53 SVAT ELECTRONICS Now You Can See 9. WIRE ROUTER 9. WIRE ROUTER The port forwarding process may vary depending on the brand and model number of the router being used. Port forwarding of a router is required to allow user access to your network device.

  • Page 54: Dvr Specifications

    LAN IP ...Static, Dynamic Network Connection...10/100 BaseT Ethernet (RJ-45) Operating System ...Written using Linux Processor ...Propietary Disk Full Warning ...Yes Automatic Overwrite Option ...Yes LED Indicators...Power, Record, Play, Live Housing Material ...Aluminum CV0104DVR TIONS TIONS SVAT ELECTRONICS Now You Can See...
  • Page 55 Power Input ...DC 12V 2A Power Adapter Input ...AC 100-250V 50/60Hz Cooling ...Fan Based Operating Environment Temperature ...41°F ~ 104°F Humidity ...30 ~ 80% Dimensions ...12.6" x 1.8" x 10.6" Weight ...6.6lbs (without HDD) CV0104DVR SVAT ELECTRONICS Now You Can See...
  • Page 56 SVAT ELECTRONICS Now You Can See T SUPPORTS CRIME ST OPPERS T SUPPORTS CRIME ST OPPERS Crime Stoppers programs are operated as non-profit charities and are managed by a volunteer board of directors who raise funds and pay rewards to individuals who anonymously call with information that helps solve crime.
  • Page 57 SVAT ELECTRONICS Now You Can See T SUPPORTS CRIME ST OPPERS T SUPPORTS CRIME ST OPPERS To receive more information about Crime Stoppers or to make a charitable donation please fill in the fields below, cut on the dotted line and mail in.
  • Page 58 SVAT ELECTRONICS Now You Can See NOTES CV0104DVR...
  • Page 59 SVAT ELECTRONICS Now You Can See CV0104DVR www.svat.com...
  • Page 60 SVAT ELECTRONICS Now You Can See w w w. s v a t . c o m D i s c l a i m e r S VAT d o e s n o t e n d o r s e a n y o f S VAT p r o d u c ts f o r a n y i l l e g a l a c t i v i t i e s .
