- Page 1 Model #: CVDVR200 User Manual now you can see www.svat.com...
-
Page 2: Important Safety Information
INTRODUCTION Thank you for purchasing the SVAT DVR200 DVR system. To ensure that you are getting the most out of this system please read this entire manual before you install the system. Also, be sure to keep this manual for future reference in case any problems or questions should arise. -
Page 3: Control Panel And Function
CONTROL PANEL AND FUNCTION FRONT PANEL 1. Mobile Rack 2. Key Socket 3. Hard Disk in-use Indicator 4. Power Indicator Playback Control Buttons Rewind Playback button Stop Button Pause Button Fast Forward and Skip Button Play Button Function Control Buttons 10. -
Page 4: Installation
INSTALLATION 1. Hard Disk installation The system supports Dual Hard Disk recording feature. Please carefully follow the steps as below to install Hard Disk Driver. Install the Hard Disk into mobile rack 1. Take out the mobile rack. 4. Connect the cable and power cord. -
Page 5: Operation
SENSOR & ALARM INSTALLATION 2. Alarm Connect the wire of alarm one pin to alarm terminal, the other pin of the wire connect to the DC power wire pin as the following picture showed. The other pin of adapter (power) wire connect to the alarm terminal. V ID E O INP UT * If the sensor or alarm you purchased is different from above instruction, please refer to the manual with the sensor/alarm. - Page 6 OPERATION CONTINUED The default setting on the SUB-MENU > PASSWORD CHANGE TIME SET FULL SCREEN BY SENSOR SEQUENT VIEW TIME The default setting on the HARD DRIVE SETUP > OVERWRITE ENABLED MASTER HDD SIZE MASTER HDD USED MASTER HDD FORMAT SLAVE HDD SIZE SLAVE HDD USED SLAVE HDD FORMAT...
- Page 7 OPERATION CONTINUED Watch & View Control This View button controls FULL SCREEN display from camera 1. This View button controls FULL SCREEN display from camera 2. This View button controls FULL SCREEN display from camera 3. This View button controls FULL SCREEN display from camera 4. This View button controls QUAD SCREEN, displays all cameras.
-
Page 8: Main Menu Setting
OPERATION CONTINUED REMARK The event logging maximum can record 95 events for each hard disk, but the screen can only show 7 events. If the events are more than 7 and the select mark stays on the 7th event, press [ ] key once will roll up the next event till the last event is shown. -
Page 9: Menu Settings
MENU SETTINGS Main Menu Setting > CAMERA SELECT RECORD SELECT RECORD MODE RECORD FRAMERATE VIDEO QUALITY RECORD SCHEDULE SUB MENU HARD DRIVE SETUP SENSOR SETUP NETWORK SETUP Camera Select 1. When CAMERA SELECT option is selected, 4 different images from all cameras are initially displayed. - Page 10 MENU SETTINGS Record Frame Rate 1. When RECORD FRAME RATE is selected, you may choose the following recording frame rate - 30, 15, 10, 7, 5, 4, 3, 2 or 1 fps for recording. 2. The higher the record frame rate is, the more natural the look will be displayed on the screen when you playback.
- Page 11 MENU SETTINGS 4. When the new password is accepted, the system will flash the following screen message: Password Change !!! 5. The message will flash 5 times. 6. Then, it will be back to the SUB MENU If the password is not accepted, you will receive a message to inform you: Password Incorrect , then return to the SUB MENU .
- Page 12 MENU SETTINGS 1. Overwrite Enabled If you choose [YES], the recording will continue and overwrite previous recording when all hard disk driver capacity is full. If you choose [NO], the recording session stops when all hard disk driver capacity is full. 2.
-
Page 13: Network Setup
MENU SETTINGS Alarm Out Time When you select ALARM OUT TIME , the number indicates how long (in seconds) the alarm lasts after the sensor detected the motion signal. If you set CONT, the alarm will keep continuous when sensor detected the motion signal. -
Page 14: Troubleshooting
TROUBLE SHOOTING The power indicator is OFF on the DVR. 1. Check and see if the AC power cord is connected properly. 2. Check and see if the power outlet on the wall is working. 3. Is the power outlet on the wall controlled by a wall switch? If it is, make sure the switch is on. -
Page 15: Specifications
TROUBLE SHOOTING When Record does not work. Check the system and see whether it is in Play Mode, press button to stop Play Mode. Then, you can enter the RECORD function. When you forgot the password Please contact your distributor or engineer to solve this problem. To avoid this, have your password stored in a secure place away from the unit. - Page 16 For Further Assistance call: 1.866.946.7828 now you can see www.svat.com...
