SVA CZC-1302W Specifications

PTZ Camera
Features
● Auto tracking of moving objects (auto PTZ) based on our motion
tracking technology
● 18x optical zoom
● 360° horizontal rotation at maximum speed of 240° / sec
● Vertical rotation from -5° to 92° with maximum speed of 160° / sec
● Auto panning function with 256 preset positions
● Built in OSD menu to change dome parameter, save or call preset,
achieve auto scan, pattern, etc.
● Features password protection to prevent unauthorized changes to
the dome setting
● Windows blanking and tracking boundary for privacy purpose
● EasyClip installation features
● Define specific activity when the dome parks
● Integrated design with high reliability
● RS-485 data communication
● Auto-flip to follow object and surveillance of any subject that is
constant and continuous
● Speed can be adjusted automatically according to zooming times
● Auto focus lens and auto white balance, BLC function
● Multi protocol compatible (Pelco-P, Pelco-D, KALATEL, etc)
● Alarm input/output/action
Connections
CZC-1302W
Specifications
MODEL CZC-1302W
TV System NTSC/PAL
Image Sensor 1/4" SONY Super HAD CCD
NO. of Effective Pixels NTSC:768(H)X494(V)
Horizontal Resolution 480 TV Lines
Minimum Illumination 0.05Lux/F1.6
S/N Ratio 50dB
Pan/Tilt Speed Pan: 0.05° ~ 240°; Tilt: 0.03° ~ 160°/sec
256
Preset positions
Lens F1.4-F3.0 f=4.1-73.8mm
Back Light Compensation Auto/Manual
Auto Gain Control Auto/Manual
Protocol Pelco-P, Pelco-D, KALATEL, etc
Video Output 1.0±0.2Vp-p
Power Supply DC24V
Control RS-485
Body Aluminum
Weight 4 lbs
