Superior SSBV-3530CNE Homeowner's Care And Operation Instructions Manual

Ssbv-35/40 series b-vent gas fireplaces, millivolt and electronic models
Hide thumbs Also See for SSBV-3530CNE:
Table of Contents

Advertisement

Quick Links

See also: Instruction and Installation Manual
Retain These Instructions For Future Reference
A French manual is available upon request. Order P/N 725,034CF.
Ce manuel d'installation est disponible en francais, simplement
en faire la demande. Numéro de la pièce 725,034CF.
•
Hot! Do not touch! The glass and surfaces of this appliance will be hot during operation and will
retain heat for a while after shutting off the appliance. Severe burns may result.
Reference Running Changes
E:\ENGINEERING\Document Numbers\LOGBOOKS\Revision Log - Manuals & Instr Sheets
•
Carefully supervise children in the same room as appliance.
•
If small children are present in the home, it is recommended that this appliance be fitted with a
screen door or screen panel kit. See Page 15 for ordering information.
WARNING: If the information in this manual is not
followed exactly, a fire or explosion may result
causing property damage, personal injury or loss
of life.
FOR YOUR SAFETY
Do not store or use gasoline or other flammable
vapors or liquids in the vicinity of this or any other
appliance.
WHAT TO DO IF YOU SMELL GAS:
• DO NOT light any appliance.
• DO NOT touch any electrical switches.
• Do not use any phone in your building.
• Immediately call your gas supplier from a
neighbor's phone. Follow your gas supplier's
instructions.
• If your gas supplier cannot be reached, call
the fire department.
Installation and service must be performed by a quali-
fied installer, service agency or the gas supplier
HOMEOWNER'S CARE AND OPERATION INSTRUCTIONS
B-Vent Gas
Fireplaces
Millivolt Models ........Electronic Models
SSBV-3530CNM ..........SSBV-3530CNE
SSBV-4035CNM ..........SSBV-4035CNE
P/N 725,034M Rev. E, 01/2007
WARNINGS
AVERTISSEMENT: Assurez-vous de bien suivre les
instructions donné dans cette notice pour réduire au
minimum le risque d'incendie ou pour éviter tout dom-
mage matériel, toute blessure ou la mort.
POUR VOTRE SÉCURITÉ: Ne pas entreposer ni utiliser
d'essence ni d'autre vapeurs ou liquides inflammables dans
le voisinage de cet appareil ou de tout autre appareil.
POUR VOTRE SÉCURITÉ: Que faire si vous sentez une odeur
de gaz:
• Ne pas tenter d'allumer d'appareil.
• Ne touchez à aucun interrupteur. Ne pas vous servir
des téléphones se trouvant dans le batiment où vous
vous trouvez.
• Evacuez la piéce, le bâtiment ou la zone.
• Appelez immédiatement votre fournisseur de gaz depuis
un voisin. Suivez les instructions du fournisseur.
• Si vous ne pouvez rejoindre le fournisseur de gaz,
appelez le service dos incendies.
L'installation et service doit être exécuté par un qualifié instal-
.
leur, agence de service ou le fournisseur de gaz.
SSBV-35/40 Series
US
OTL Report No. 116-F-30-5

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SSBV-3530CNE and is the answer not in the manual?

Questions and answers

Related Manuals for Superior SSBV-3530CNE

Summary of Contents for Superior SSBV-3530CNE

  • Page 1 B-Vent Gas Fireplaces Millivolt Models ...Electronic Models SSBV-3530CNM ...SSBV-3530CNE SSBV-4035CNM ...SSBV-4035CNE Retain These Instructions For Future Reference P/N 725,034M Rev. E, 01/2007 A French manual is available upon request. Order P/N 725,034CF. Ce manuel d’installation est disponible en francais, simplement en faire la demande.

  • Page 2: Safety And Warning Information

    SAFETY & WARNIING INFORMATION IMPORTANT: PLEASE READ THIS MANUAL IN ITS ENTIRETY AND UNDERSTAND THESE RULES TO FOLLOW FOR SAFETY. WARNING If the information in this manual is not followed exactly, a fire or explo- sion may result caus- ing property damage, personal injury or loss of life.

  • Page 3: Table Of Contents

    Input of electronic models is shown in the following table: Electronic Models with Fixed Rate Gas Valve Natural and Propane Gas Model Series Input Rate (BTU / HR) SSBV-3530CNE ,000 SSBV-4035CNE 9,000 Table 3 Inlet Gas Supply Pressure (all models) Fuel #...

  • Page 4: Burn-In Period

    Manifold Gas Supply Pressure (electronic models) Fuel # Fixed Natural Gas .5" WC (.87 kPa) Propane 10.0" WC (.49 kPa) Table 6 Test gauge connections are provided on the front of the millivolt gas control valve, identi- fied IN for the inlet and OUT for the manifold side. A 1/8" NPT Test gauge connection is provided at the inlet and outlet side of the electronic gas control valve.

  • Page 5: Variable Flame Adjustment

    Electronic Appliances -To light electronic appli- ances refer to the detailed lighting instructions found on Pages 18 & 19 of these instructions. Electronic appliance lighting instructions may also be found on the pull out lighting instruction labels attached to the gas control valve. Honeywell Electronic Gas Valve Manifold Pressure ON / OFF Switch Port Inlet Pressure Port Electronic Gas Figure 3 Control Valve If your electronic appliance is equipped with an optional remote wall switch or remote control kit the appliance main burner may be turned on and off with the wall switch or remote control. If your electronic appliance is not equipped with a wall switch or remote control, the main burner must be turned off and on with the gas control switch. Toggle the switch from ON to OFF to operate the main burner .

  • Page 6: Venting Action And (Spill Switch)

    Small Area Paint Touch-up The finish of the appliance is a high qual- ity powdercoat. Only use factory supplied powdercoat paint kit for touch-ups. Paint is Superior available at your local authorized Hearth Products dealer, cat. no. 90L74. Never attempt to paint a hot fireplace. Do not attempt to repaint the appliance until the finish is completely cured (see Burn-In Period on Page 4 ). If the surface later becomes stained...

  • Page 7: Outside Combustion Air Control

    Lintel Securing Screw Firebox Hole in Cabinet Top Scoop Scoop Securing Screws Figure 7 Lintel Securing Screw Firebox Hole in Cabinet Top Spill Switch (limit disc) Bracket Securing Screws Spill Switch (limit disc) View Without Scoop Figure 8 Outside Combustion Air Controls WARNING Do not operate the shutoff lever unless a complete outside COM-...

  • Page 8: Install Volcanic Stone, Glowing Embers And Logs

    Removing Glass Enclosure Panel (see Figure 11) 1. Remove top louver assembly by pulling it up and out. 2. Remove the control compartment access door (see removal instructions on Page 4 - Removing Control Compartment Door). 3. Locate the two (2) latches at the top of the control compartment. To disengage the two latches from the bottom vee-flange of the glass enclosure panel, reach for the handles located towards the back of the latches and pull the handles down toward the front of the appliance. 4. Swing the bottom of the door out and raise it slightly to lift the top flange of the door frame away from the appliance. Installing Glass Enclosure Panel (see Figure 11 ) 1. Visually inspect the gasket on the backside of the glass panel. The gasket surface must be clean, free of irregularities and seated firmly.

  • Page 9: Log Placement Instructions

    MODEL SSBV-50 Log Placement Instructions LOG SET Catalog Number H67 * Item Description Log, Rear Log, Top Left Log, Center Log, Top Right * Item "letters" above correspond to photos Install the Embers, Volcanic Stone and Logs in the order shown here (1 through 6) and per the instructions on Page 8. Place Embers &...
  • Page 10 MODEL SSBV-405 Log Placement Instructions LOG SET Catalog Number H68 * Item Description Log, Rear Log, Top Left Log, Center Log, Top Right * Item "letters" above correspond to photos Install the Embers, Volcanic Stone and Logs in the order shown here (1 through 6) and per the instructions on Page 8. Place Embers and Volcanic Stone as Shown Volcanic Stone Sub-Floor...

  • Page 11: Burner Adjustments

    BURNER ADjUSTMENTS (QUALIFIED TECHNICIANS ONLY) Flame Appearance and Sooting Proper flame appearance is a flame which is blue at the base and becomes yellowish-orange in the body of the flame. When the appliance is first lit, the entire flame may be blue and will gradually turn yellowish-orange during the first 15 minutes of operation. If after a short period the flame stays lowered blue, or if the flame is orange with evidence of sooting (black tip), the air shutter opening may need to be adjusted.

  • Page 12: Electronic Appliance Checkout

    Gas Va lve PILOT ASSEMBLY OPTIONAL BLOWER Electronic Wiring Diagram (Honeywell) Showing Blower Wiring Figure 21 for Optional FBK-100 & FBK-200 Kits Superior CAUTION Field Wired Factory Wired Wiring Diagram Showing the Blower Wiring for the Optional FBK-100 Kit 1. If any of the original wire as supplied must be replaced, it must be replaced with Type AWM 105°C –...

  • Page 13: Warranty

    F or t he n umber o f y our n earest S uperior dealer, please call 1-800-9-LENNOX. Cat. Model Ship. Ship.Vol. Wt.(lbs) (inches) H3337 SSBV-3530CNM 115 lbs 37W x 17D x 36H (13.1 cu.ft). H3338 SSBV-3530CNE 115 lbs 37W x 17D x 36H (13.1 cu.ft). H3339 SSBV-4035CNM 125 lbs 42W x 17D x 41H (16.9 cu.ft). H3340 SSBV-4035CNE 125 lbs 42W x 17D x 41H (16.9 cu.ft).
  • Page 14 * Assembled 8-Piece Louver Kits Polished Brass Brushed Stainless Where Used Cat. # Model Cat. # Model H154 LK-500B H155 LK-500BS SSBV-50 H156 LK-600B H157 LK-600BS SSBV-405 (ref. Form # 750,166M) * Superior Nameplate Logo, 56L93, is not included. Polished Brass & Brushed Stainless Louvers Kits These kits include a top 4-louver assembly and a bottom 4-louver assembly. They provide a touch of elegance. These kits can be retrofitted to previously installed appliances. NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE. Models Models Models...
  • Page 15 ACCESSORY COMPONENTS (CONTINUED) Arch Door Kit - Polished Brass Cat. No. Model Fireplace Model 6M4 ADK5CMPB SSBV-50 81L5 ADK40CPB SSBV-405 Arch Door Kit - Brushed Stainless Steel Cat. No. Model Fireplace Model 6M44 ADK5CMBS SSBV-50 98L69 ADK40CBS SSBV-405 Arch Door Kits The arch door kits are easy to install and do not require hardware to attach them to the standard door frame.

  • Page 16: Lighting Instructions - Millivolt

    LIGHTING INSTRUCTIONS – HONEYWELL AND SIT MILLIVOLT GAS VALVE WARNING: IF YOU DO NOT FOLLOW THESE INSTRUCTIONS EXACTLY, A FIRE OR EXPLOSION MAY RESULT CAUSING PROPERTY DAMAGE, PERSONAL INjURY OR LOSS OF LIFE. A. This appliance has a pilot which must be lighted with a piezo igniter. When lighting the pilot, follow these instructions exactly. B. BEFORE OPERATING smell all around the appliance area for gas. Be sure to smell next to the floor because some gas is heavier than air and will settle on the floor.

  • Page 17: Instructions D'allumage

    INSTRUCTIONS D’ALLUMAGE – VANNE GAZ MILLIVOLT HONEYWELL ET SIT POUR VOTRE SÉCURITÉ, LISEZ CES INSTRUCTIONS AVANT L’ALLUMAGE AVERTISSEMENT : SI VOUS NE SUIVEZ PAS CES INSTRUCTIONS À LA LETTRE, IL POURRAIT S’EN SUIVRE UN INCENDIE OU UNE EXPLOSION CAUSANT DES DOMMAGES MATÉRIELS, DES BLESSURES CORPORELLES OU MÊME DES PERTES DE VIE. A.

  • Page 18: Lighting Instructions - Electronic

    WARNING: IF YOU DO NOT FOLLOW THESE INSTRUCTIONS EXACTLY, A FIRE OR EXPLOSION MAY RESULT CAUSING PROPERTY DAMAGE, PERSONAL INjURY OR LOSS OF LIFE. A. When lighting the appliance, follow these instructions exactly. B. BEFORE OPERATING smell all around the appliance area for gas. Be sure to smell next to the floor because some gas is heavier than air and will settle on the floor. WHAT TO DO IF YOU SMELL GAS • Extinguish any open flame. • Open windows. • Do not light any appliance.
  • Page 19 INSTRUCTIONS D’ALLUMAGE — ELECTRONIC POUR VOTRE SÉCURITÉ, LISEZ CES INSTRUCTIONS AVANT L’ALLUMAGE AVERTISSEMENT: SI VOUS NE SUIVEZ PAS CES INSTRUCTIONS À LA LETTRE, IL POURRAIT S’EN SUIVRE UN INCENDIE OU UNE EXPLOSION CAUSANT DES DOMMAGES MATÉRIELS, DES BLESSURES CORPORELLES OU MÊME DES PERTES DE VIE. A.

  • Page 20: Maintenance Schedule

    MAINTENANCE SCHEDULE - Annually (Before the onset of the Burning Season) MAINTENANCE TASK Inspecting/Cleaning Burner, Logs and Controls Check Flame Patterns and Flame Height Inspecting/Cleaning Pilot and Burner Checking Vent System Appliance Checkout Replacing Rockwool Ember Materials MAINTENANCE SCHEDULE - Periodically (After the Burning Season) MAINTENANCE TASK Cleaning Firebox Interior Check Flame Patterns and Flame Height Checking Vent System Cleaning Front Glass Enclosure Panel ACCOMPLISHING PERSON Qualified Service Technician Inspect valve and ensure it is properly operating. Check piping for leaks. Vacuum the control compartment, fireplace logs and burner area. Qualified Service Technician Refer to Figure 15 on Page 11 and verify the flame pattern and height displayed by the appliance conforms to the picture.

  • Page 21: Troubleshooting Guide - Millivolt

    TROUBLESHOOTING Note: Before troubleshooting the gas control system, Ensure external gas shut off valve, located at gas supply inlet, (and wall switch, iff applicable), is in the “ON” position. Important: Valve system troubleshooting should only be accomplished by a qualified service technician. TROUBLESHOOTING GUIDE - MILLIVOLT GAS CONTROL SYSTEM SYMPTOM 1. Spark igniter will not light pilot after repeated triggering of igniter button. WARNING: if the pilot will not light after 1 minute of attempting, wait for at least 5 minutes for gas to clear before attempting again. . Pilot will not stay lit after carefully following the lighting instructions. . Pilot burning, no gas to burner, Valve knob “ON,” and the (standard) burner OFF/ON switch is “ON." Read impor- tant note below. IMPORTANT NOTE: If an optional *remote switch is used for burner operation, the standard burner OFF/ON switch on appliance must be in the "OFF" position. *Optional remote switch kits - wall switch or remote control. 4. Frequent pilot/burner outage prob- lem. TROUBLESHOOTING GUIDE - ELECTRONIC IGNITION SYSTEM SYMPTOM 1. Burner will not light. . Burners come “ON,” then turns “OFF.” POSSIBLE CAUSES A. Defective igniter (no spark at electrode).
  • Page 22 TROUBLESHOOTING PROCEDURE - ELECTRONIC IGNITION SYSTEM START • Turn Off Gas Supply. • Ensure Valve Switch Is In ON Position. • Disconnect Control Harness. • Turn On Optional Remote Switch (if applicable) Insert A End View of Control Harness Connector 4 Volt 4 Volt Hot Common...

  • Page 23: Replacement Parts List

    Bag of Glowing Embers (Rockwool) Bag of Decorative Volcanic Stone Gas Line Flexible Connector, FFGC Spill Switch (high limit disc) * Superior Nameplate Logo, 56L9, is not included. Gas Controls - SIT Millivolt Natural Gas Part No. Gas Valve, SIT...

  • Page 24: Replacement Parts Diagrams

    REPLACEMENT PARTS DIAGRAMS LHP reserves the right to make changes at any time, without notice, in design, materials, specifications, prices and also to discontinue colors, styles and products. Consult your local distribu- tor for fireplace code information. Printed in U.S.A. © 2005 by LHP P/N 75,04M REV. E 01/007 1110 West Taft Avenue • Orange, CA 9865 Located Inside (see Figure 8)

This manual is also suitable for:

Ssbv-4035cneSsbv-3530cnmSsbv-4035cnm
