-48V DC Power System
Quick Start Guide, QS582127000 (Issue AC, December 10, 2013)
Figure 37.
List AK: -48V Distribution Panel,
(4) TPL-B Fuse Positions (with Shunts) (without Return Busbar)
Spec. No: 582127000
Model No: 721
NPBB
-48VDC Load
Connections
LOAD CONNECTIONS
3/8-16 Studs on 1" Centers
(Customer must supply or order additional hardware)
Maximum Lug Width: 1.5 inches.
[52]
WARNING!
Observe proper
polarity when making
load connections.
Code: QS582127000
Issue AC, December 10, 2013
