NetSure
™
-48V DC Power System
Quick Start Guide, QS582127000 (Issue AC, December 10, 2013)
Figure 2.
Installing a Bullet Nose Type Circuit Breaker
Figure 3.
Installing a TPH Fuse
Spec. No: 582127000
Model No: 721
NPBB
Shorter Side
to the Top
Lettering on
handle must be
right side up.
Turn off
before installing.
Longer Side
to the Bottom
Insert these terminals
into corresponding sockets
on distribution panel.
[4]
Code: QS582127000
Issue AC, December 10, 2013
