Thor Gas Hot Plate
Installation and Operation Instructions
Model: GE756-P, GE756-N, GE757-P, GE757-N
Please complete this information and retain this manual for the life of the equipment. For Warranty
Service and/or parts, this information is required.
Model Number
WARNING: For your safety, do not store or use gasoline or other flammable vapors or
liquids in the vicinity of this or any other appliances. Keep the area free and clear of
combustible.
WARNING ： Improper installation, adjustment, alteration, service or maintenance can
cause property damage, injury, or death. Read the installation operating and maintenance
instructions thoroughly before installing, or servicing this equipment.
WARNING：Instructions must be posted in a prominent location. All safety precautions
must be taken in the event the user smells gas. Safety information can be obtained from
your local gas supplier.
IMPORTANT FOR FUTURE REFERENCE
Serial Number
15 Badgally Road, Campbelltown
NSW 2560
Date Purchased
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for THOR GE757-P
Summary of Contents for THOR GE757-P
- Page 1 Thor Gas Hot Plate Installation and Operation Instructions Model: GE756-P, GE756-N, GE757-P, GE757-N IMPORTANT FOR FUTURE REFERENCE Please complete this information and retain this manual for the life of the equipment. For Warranty Service and/or parts, this information is required.
-
Page 2: Table Of Contents
Contents Introduction ....................1 Specifications ....................2 General Pack Contents Gas Supply Requirements Dimensions ....................3 Installation ....................5 Installation Requirements Unpacking Location Clearances Assembly Gas Connection Operation ......................7 Operation Guide Description of Controls Open Burners Cleaning and Maintenance ................10 General After Each Use Daily Cleaning Weekly Cleaning Periodic Maintenance... -
Page 3: Introduction
Introduction We are confident that you will be delighted with your Thor Gas Hot Plate, and it will become a most valued appliance for you. To ensure you receive the utmost benefit from your new Gas Hot Plate, there are two important things you can do. -
Page 4: Specifications
SPECIFICATION General Commercial heavy duty hot plate with cast iron trivets and burners, and fitted with full pilot and flame failure protection. Pack Contents The following is included: Thor Gas Hot Plate Feet Instruction Manual Gas Supply Requirements... -
Page 5: Dimensions
Dimensions GE756-P / GE756-N GE757-P / GE757-N... -
Page 6: Installation Requirements
Installation Installation Requirements NOTE: • It is most important that this appliance is installed correctly and that operation is correct before use. Installation shall comply with local gas, health and safety requirements. • This appliance shall be installed with sufficient ventilation to prevent the occurrence of unacceptable concentrations of substances harmful to health. -
Page 7: Installation
Installation Clearances NOTE: Only non-combustible materials can be used in close proximity to this appliance. Combustible Surface Non Combustible Surface Left / Right Hand Side 250mm Rear 250mm Assembly NOTE: • This appliance is assembled before delivery except feet. • This appliance is fitted with adjustable feet to enable the appliance to be positioned securely and level. This should be carried out on completion of the gas connection. - Page 8 Installation Check that the gas operating pressure. NOTE: The operating pressure to be measured at the manifold test point and with 2 burners operating at the ‘High Flame’ setting. Turn off the mains gas supply and bleed the gas out of the appliance gas lines. Turn on the gas supply and the appliance.
-
Page 9: Operation
Operation Operation Guide CA UTION: • This appliance is for professional use and is only to be used by qualified persons. • Only authorized service persons are to carry out installation, servicing or gas conversion operation operations. • Components having adjustments protected by the manufacturer should not be adjusted by the user/operator. -
Page 10: Open Burners
Operation 1. Lighting the Main Burners The hot plates are fitted with individual standing pilots for each open burner which allows the main burners to be turned ON- OFF without the need to manually re-light the burner each time that it is turned ON, as the burner will be automatically lit itself by the pilot burner. - Page 11 Operation Main burner air supply: 1. For efficient burner operation, a proper balance of gas volume and primary air supply must be maintained which will result in complete combustion. Insufficient air supply results in a yellow streaming flame. Primary air supply is controlled by an air shutter on the front of the burner. 2.
-
Page 12: Cleaning And Maintenance
Cleaning and Maintenance CA UTION: Always turn off the gas supply before cleaning. This appliance is not water proof. Do not use water jet spray to clean this appliance. GENERAL Clean the Gas Hot Plate regularly. A clean Gas Hot Plate looks better, will last longer and will perform better. - Page 13 Cleaning and Maintenance Trivets and Burners Pic1 a. Remove the trivets from the top of the appliance (Refer to pic1). b. Remove the burner from the top of the bracket of appliance (Refer to Pic2). c. The trivets and burners should be cleaned with a mild detergent and hot water solution using a soft bristled brush.
-
Page 14: Trouble Shooting
Trouble Shooting This section provides an easy reference guide to the more common problems that may occur during the operation of your equipment. The fault finding guide in this section is intended to help you correct, or at least accurately diagnose problems with your equipment. Although this section covers the most common problems reported, you may encounter a problem not covered in this section. -
Page 15: Replacement Parts List
Replacement Parts List IMPORTANT: Only genuine authorized replacement parts should be used for the servicing and repair of this appliance. The instructions supplied with the parts should be followed when replacing components. For further information and servicing instructions, contact your nearest authorized service branch. When ordering replacement parts, please quote the part number and the description listing below. -
Page 16: Explosion Drawing
Explosion Drawing GE756-P / GE756-N... -
Page 17: Spare Parts List
Spare Parts List DESCRIPTION MODEL CODE GE756-P Dial 06.05.1471455 GE756-N GE756-P Safety Valve 01.20.1068524 GE756-N GE756-P L Connector For Orifice 01.18.1067404 GE756-N GE756-P Main Pipe Assy.- Front 01.24.1070902 GE756-N GE756-P 01.20.1068652 Orifice GE756-N 01.20.1068637 GE756-P Air Shutter 01.02.1005356 GE756-N GE756-P Burner 01.03.1015066 GE756-N... - Page 18 Explosion Drawing GE757-P / GE757-N...
- Page 19 Spare Parts List DESCRIPTION MODEL CODE GE757-P Dial 06.05.1471455 GE757-N GE757-P Safety Valve 01.20.1068524 GE757-N GE757-P L Connector For Orifice 01.18.1067404 GE757-N GE757-P Main Pipe Assy.- Front 01.24.1070902 GE757-N GE757-P 01.20.1068652 Orifice GE757-N 01.20.1068637 GE757-P Air Shutter 01.02.1005356 GE757-N GE757-P Burner 01.03.1015066...
- Page 20 Please keep this manual in a safe place for future use! 15 Badgally Road, Campbelltown NSW 2560 V1.Rev0.05-15...
