INSTALLATION AND SERVICE MANUAL
Please fill in for future reference:
MODEL: ___________________________
SERIAL NUMBER: ____________________
DATE PURCHASED: ___________________
EUROXXXXXX-SW
S/N: XXXX-XXXXXX
WARNING: PLEASE READ COMPLETELY BEFORE YOU INSTALL OR OPERATE YOUR NEW PUMP!
This is an external "out-of-pond" pump. It is NOT submersible. Protect from rainfall and frost.
Do NOT allow this pump to become submerged. Never run dry. Max. case pressure.- 25 PSI.
Model
INLET
OUTLET
MAX FLOW (gph)
MAX FLOW (litres per hour)
MAX HEAD (metres)
8000 / 10,000 / 12,000
®
SEQUENCE 8000
2"
1.5"
1760
8000
2.4m
Sustainable, Efficient.
SEQUENCE 10,000
2"
1.5"
2200
10,000
2.4m
SEQUENCE 12,000
2"
1.5"
2640
12,000
2.5m
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Evolution Aqua Sequence 800
Summary of Contents for Evolution Aqua Sequence 800
- Page 1 8000 / 10,000 / 12,000 ® INSTALLATION AND SERVICE MANUAL Please fill in for future reference: MODEL: ___________________________ SERIAL NUMBER: ____________________ DATE PURCHASED: ___________________ EUROXXXXXX-SW S/N: XXXX-XXXXXX WARNING: PLEASE READ COMPLETELY BEFORE YOU INSTALL OR OPERATE YOUR NEW PUMP! This is an external “out-of-pond” pump. It is NOT submersible. Protect from rainfall and frost. Do NOT allow this pump to become submerged.
- Page 2 Its leading edge design provides you with high output at a minimal operating cost. It is carefully constructed to give you long term, reliable service. To insure proper performance, we urge you to carefully follow the instructions in this manual. If you have any questions, please call your Evolution Aqua Dealer for assistance. INSTALLATION Please read carefully! When properly installed, the Sequence®...
- Page 3 Install the drain plug and O-ring, into the volute drain hole. Before operating the Sequence® pumps, allow a proper cure time for the sealant used in step 2. BRACKET DESCRIPTION EVOLUTION AQUA PART NUMBER: M BOLT 1000.111 DRAIN PLUG + O-RING...
- Page 4 8000 / 10,000 / 12,000 ® MAINTENANCE Lubrication *The pump must be drained before servicing or if stored below freezing temperatures. Periodic replacement of seals may be Motor - Permanently Lubricated ball bearings - no service required. required due to normal carbon wear. Rotary Seal - Requires no lubrication after assembly.
- Page 5 Evolution Aqua will examine the pump, and if the fault is covered by the warranty, will repair and return to the customer at the earliest opportunity. The cost of returning the pump to the customer will be met by Evolution Aqua.
- Page 6 8000 / 10,000 / 12,000 ® EVOLUTION AQUA LTD. Evolution House, Kellet Close, Wigan WN5 0LP tel: +44 (0)1942 216554 • fax: +44 (0)1942 216562 The difference is clear at www.evolutionaqua.com Sustainable, Efficient.
