- Page 1 Instruction anual STUV SWINGLOX...
- Page 2 This product has been developed and produced carefully in Germany. It offers comfortable securing and operating of your safe. This SWINGLOX User Manual has been written in particular to guide you step by step through the functions and operating options of your locking system.
- Page 3 Opening, Battery Warning Flash 5 1 Master, up to 8 Users, Opening Delay, Fast Opening Code Changing a Code (Master Code and User Code) (Special Function 0) • Create User (Special Function 1) • User On / Off (Special Function 2) •...
- Page 4 Battery installation / Battery change To remove the keypad housing, turn the housing to the left to the mark on the top of the case. ATTENTION: during assembly / disassembly of the keyboard housingmake sure thereis a exact match between the marking of the housing andthe indicator marks 1 or 2. Lift off the keypad housing, paying attention to the connection cable.
- Page 5 Opening Upon leaving the factory, the lock’s master code is configured as 1 - 2 - 3 - 4 - 5 - 6. For security reasons, change the factory configured master code immediately (see special function 0)! Note: • Entry is cancelled after 5 seconds have passed without a key being used Enter code 1 2 3 4 5 6 A er the signal for correct input, turn...
- Page 6 Misentry Penalty After 4 invalid codes the entry is blocked for about 5 minutes. During this period the lock signals every 10 seconds. After this time penalty, the entry of every second invalid code initiates a new 5 minutes delay period.
- Page 7 Special Function 1: Create User The only active user by factory settings is the user with the master code. Further users will have to be created before they can operate the lock. It is recommended that the Master inform users that, even after entering valid user codes, he can open the safe with his Master Code at any time.
- Page 8 Special Function 2: Turning Users on/off (Flash 5) All users are turned on or off. Note: Can only be executed with the master code. • The lock can only be opened with the master code when users are turned off. •...
- Page 9 Special Function 7: User Info This function provides you with an overview of the number of user slots that are free / being used. Note: • Can only be executed with the master code. Start special func-on 7 constantly Enter master code 1 2 3 4 5 (example) constantly...
- Page 10 Note: Can only be executed with the master code. • A shorter opening delay time has to be entered during the opening window (after the opening delay has • passed). If the function is called up prior to or during the opening delay time, the opening delay time can only •...
- Page 11 Opening with Opening Delay activated Note: Entering an invalid code during the opening delay time will cancel the entire process • Entry of two valid codes within the opening window with Flash 4 only (see Opening after Dual Mode • Operation).
- Page 12 Security Information: Any records of the used code shall be stowed in a way that they are not accessible to third parties. • When entering the code, make sure that the input cannot be observed by bystanders. • Removing the keypad The cable duct for the lock and the battery are located behind the keypad housing.
- Page 13 Mounting the keypad Place the keypad housing on the base plate and turn the unit back into the initial position to the right. Battery Warning First step: If the battery reaches a critically low level of charge, there will be an early warning of several signal tones after successful code entering.
