- Page 1 Guardian Easytrack System ® 3-Post Assembly Model 93000 Installation & Instruction Manual...
-
Page 2: Table Of Contents
Thank you for choosing a Guardian Easytrack System. We want to hear your questions or comments about this manual, the safety and reliability of your Easytrack System and the service you receive from your Sunrise Medical Supplier. Please feel free to write or call us at the address and telephone number below:... -
Page 3: Important Safeguards
• Easytrack can not be used with any type of suspended ceiling, including suspended drywall, acoustic tile, etc. • Installation on a plaster ceiling may cause cracking. Sunrise Medical cannot be held responsible for damage. • Do not install on a ceiling with water damage. -
Page 4: Requirements
REQUIREMENTS Failure to meet requirements listed below could result in serious bodily harm. Ceiling Requirements • Install to a rigid ceiling (must have a framework above it). • Must have a maximum of 24" (610mm) between the trusses in the ceiling. •... -
Page 5: Before You Begin
B e f o r e Y o u B e g i n BEFORE YOU BEGIN Read "Requirements" and “Important Safeguards” before attempting to assemble the Easytrack System. 1. Survey the room where you plan to install the Easytrack System. Make sure the room meets all the specifi- cations outlined in "Requirements". -
Page 6: Kit Contents & Part Numbers
EASYTRACK 3-POST SYSTEM KIT CONTENTS & PART NUMBERS (Figure 6) Description Part # 1 Pivoting extendable rail w/standard trolley 900-0850 2 Extendable rail w/swivel trolley 900-0800 3 Pivot post 4 Post top for pivot post N/A 5 Standard post 900-0500 6 Blue locking handle 7 Round blue cap 900-0720... -
Page 7: Assembly Of 3-Post System
A s s e m b l y o f 3 - P o s t S y s t e m 5. Take the pivot post out of the box and the post top for pivot post. Insert the post top into the post until it snaps into place (Figure 9). - Page 8 12. Once the bubble is in the center of the clip-on level, continue to tight- en ONLY until the red zone at the top of the post is no longer visible (Figures 16-A & B). Red zone must not be visible for the post to be safely secured.
- Page 9 A s s e m b l y o f 3 - P o s t S y s t e m b. Find the end stopper from inside the top of the rail. The top por- tion is the section without the small trolley in it (Figure 20).
-
Page 10: Disassembly Of 3-Post Sytem
BEFORE USING THE EASYTRACK SYSTEM GO THROUGH THE FOLLOWING CHECKLIST: Make sure the red zone on top of all posts are not visible. Make sure the posts are straight. (Did you use the clip-on level?) Make sure the rail is locked into place (see step 15) and that it looks level. Make sure the stopper is snug (see step 22b). -
Page 11: Maintenance
S p e c i f i c a t i o n s / M a i n t e n a n c e NOTE– Metal pins cannot be pressed in when there is downward pressure on them. Pressure must be released to press in pins. - Page 12 Upon receipt of your Easytrack System: 1. Make sure you received all components listed in Figure 6. 2. Inspect all parts for possible damage in transit. 3. Ensure all components are in working order. 4. Arrange for repair/replacement of any faulty parts. 5.
-
Page 13: Troubleshooting
T r o u b l e s h o o t i n g TROUBLESHOOTING PROBLEM 1. Trolley moves substantially on its own when the Easytrack System is fully assembled. 2. Extended rail comes completely apart during assembly. 3. Not able to push pin to assemble/disassem- ble post. -
Page 14: Easytrack Products & Accessories
EASYTRACK PRODUCTS & ACCESSORIES Easytrack 2-Post System... Easytrack 4-Post System... Easytrack 2-Post with Tub Bracket ... Easytrack 3-Post with Tub Bracket ... Easytrack Portable Carry Bag... 3-Post System E a s y t r a c k P r o d u c t s & A c c e s s o r i e s 92000 94000 92001... -
Page 15: Warranty
This warranty is extended only to the original purchaser/user of Sunrise products. Sunrise Medical Inc. warrants its products to be free from defects in material under normal use and service and will, within the periods stated below, from the date of purchase. If within such warranty period any such product shall be proven to be defective, such product shall be repaired or replaced at Sunrise Medical's option. -
Page 16: East Dry Creek Parkway Longmont, Colorado
Distributed by: Sunrise Medical 7477 East Dry Creek Parkway Longmont, Colorado 80503 (800) 333-4000 In Canada (800) 263-3390 Printed in Canada © 2001 Sunrise Medical 10.01 900-0610 Rev. A...
