05-03-457 A029-OK.PDF
Instruction Manual
P O R T A B L E
Air Conditioner
Model No.
Model No.
Sales: 800-934-9194
WA-1400E Model No. WA-1410E
WA-1400H Model No. WA-1410H
It is important that you read these
instructions before using your new
purchase and we strongly
recommend that you keep them in a
safe place for future reference.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for SPT WA-1400E
Summary of Contents for SPT WA-1400E
-
Page 1: Air Conditioner
05-03-457 A029-OK.PDF P O R T A B L E Instruction Manual Air Conditioner Model No. WA-1400E Model No. WA-1410E Model No. WA-1400H Model No. WA-1410H Sales: 800-934-9194 It is important that you read these instructions before using your new... -
Page 2: Table Of Contents
05-03-457 A029-OK.PDF TABLE OF CONTENTS THANK YOU ENERGY SAVING TIPS………..……………………………………………….. 2 SPECIFICATIONS..……………………………………………………………….3 BEFORE USE……….……………………………………………………………. 4 PARTS………..…………………………………………………………………….5 INSTALLATION.…………………………………………………………………...6 MOUNTING OF THE EXHAUST PIPE ………………………………………... 7 INSTALLATION OF THE CARBON FILTER…………………………………... 8 OPERATION ……………………………………………………………………… 9 NOTICE.…………………………………………………………………………..12 DRAINAGE………………………………………………………………………. 13 MAINTENANCE…………………………………………………………………. 15 TROUBLE SHOOTING…………………………………………………………. 16 DEFECTIVE NOTICE…………………………………………………………... -
Page 3: Thank You
05-03-457 A029-OK.PDF THANK YOU Thank you for choosing the portable air conditioner from SPT brand in indoor air treatment. We would like you to enjoy the many benefits this unit offers, so please take the time to read this manual carefully and take full advantage of the many advanced features that your SPT Conditioner offers you. -
Page 4: Specifications
500sq.ft. • The following may effect the unit in reaching your set tempearature: Outside Temperature, Room Size, Ceiling Height, Room Insulation, Number of people in the room, Direct Sunlight and Source of Heat. WA-1400E WA-1400H WA-1410E WA-1410H 14000 BTU/hr... -
Page 5: Before Use
05-03-457 A029-OK.PDF BEFORE USE Important! Transport the unit in an upright position only or leave in upright position for at least 2 hours before use. Keep at least 20 inches away from the wall. (Figure 1 & 4) Always place the unit on an even surface. Make sure the unit is connected to a correctly grounded power supply (refer to the rating label located at the back of the unit). -
Page 6: Parts
05-03-457 A029-OK.PDF PARTS Front 1. Control Panel 2. Air outlet 3. Carrying handle 4. Caster Accessories 10. Inward adaptor - for insertion over hose and connect to back of the air conditioner. 11. Round connector - for insertion over hose and into foam strip (or into hole in the wall/window). -
Page 7: Installation
05-03-457 A029-OK.PDF INSTALLATION EXHAUST PIPE INSTALLATION The unit is a portable air conditioner that may be moved from room to room. 1. Using the foam strips / Window installation Used to cover the window gap and can be cut to size if necessary. •... -
Page 8: Mounting Of The Exhaust Pipe
05-03-457 A029-OK.PDF • Use only the hose provided. Attach hose to back of unit by connecting the adaptor. • Avoid kinks and sharp bends in the exhaust hose as this will cause expelled moist air to build up and the unit will overheat and shut down. -
Page 9: Installing The Carbon Filter
05-03-457 A029-OK.PDF Installing the Carbon Filter 1. Remove the filter frame from the unit. 2. Unclip and remove one side of the frame. 3. Remove the active carbon filter from its plastic bag. 4. Insert the active carbon filter into the filter frame. -
Page 10: Operation
05-03-457 A029-OK.PDF OPERATION Control panel 1. Automatic mode indicator 2. Cooling mode indicator 3. Fan mode indicator 4. Heating mode indicator (for cool & heat models only). 5. Low ventilation indicator 6. Medium ventilation indicator 7. High ventilation indicator 8. Timer operation indicator 9. -
Page 11: Auto Mode
05-03-457 A029-OK.PDF Auto Mode When this mode is selected, the unit is preset to the following temperature settings and unit will only start to: Cool when room temperature is higher than 75°F Heat when room temperature is lower than 68°F (WA-1400H &WA-1410H models only) If room temperature is between 68°F and 75°F, unit will stay in Fan mode. -
Page 12: Sleep Function
05-03-457 A029-OK.PDF Setting ventilation speed Press SPEED button to choose the desired ventilation speed: High, Medium or Low. The indicator respective speed will light on at the same time. If the unit is in AUTO mode, it will choose the ventilation speed automatically according to the ambient temperature (the related indicators will light on), at this time, this button is invalid. -
Page 13: Regulating Air Flow Direction
05-03-457 A029-OK.PDF Regulating air flow direction FIG. 19 NOTICE ! The compressor will start approximately 3 minutes after the compressor is turned off (this will help prolong the life of the compressor). After switching the unit off, please wait at least 3 minutes before turning the unit back on. -
Page 14: Drainage
05-03-457 A029-OK.PDF DRAINAGE During the process of cooling or heating, some water will be extracted from the air. Most of this water is used to cool the cooling coils and make the unit run more efficiently. This is a feature not found in most other portable air conditioners. - Page 15 05-03-457 A029-OK.PDF NOTE The drain tube must be at or below the outlet level. Water Full (full water) indicator will not function in this mode of drainage. If you wish to extend the water tube, please connect with another tube (outside diameter 3/4").
-
Page 16: Maintenance
05-03-457 A029-OK.PDF .MAINTENANCE Always unplug the unit before cleaning and maintenance. Cleaning the Housing Use a soft, damp cloth to wipe the body clean. Never use strong chemicals, oil-based products, detergents, chemically treated cloths or other cleaning solutions. These could possibly damage the cabinet. Cleaning the Filter First remove the black active carbon filter from the frame, tap lightly to remove loose dust and dirt. -
Page 17: Trouble Shooting
05-03-457 A029-OK.PDF .TROUBLE SHOOTING The unit doesn’t run or only runs in fan mode The unit seems to do little The unit seems to do nothing The room is not cold enough Too noisy The compressor doesn’t run Never try to repair or dismantle the unit yourself Is the machine plugged in? Is the main power supply on? Is room temperature within working... -
Page 18: Defective Notice
05-03-457 A029-OK.PDF .DEFECTIVE NOTICE If this product is defective or not working properly Please DO NOT return to your retail store Please contact us directly with any Service or Technical Assistance Contact us toll free at: 1-800-330-0388 REPLACEMENT FILTERS: To purchase Replacement Filters for this unit, contact SPTUSA at 1-800-330-0388 and request model number WA-1400F. -
Page 19: Guarantee
05-03-457 A029-OK.PDF If this product is found to be faulty as a result of faulty materials or workmanship within one year from date of purchase, it will be repaired or replaced free of charge. This guarantee is subject to the following terms: Proof of purchase must be presented to SPT The warranty will be void if the product is modified, misused or repaired The guarantee after repair or replacement will not be extended beyond the... -
Page 20: Safety Power Supply Cord
05-03-457 A029-OK.PDF SAFETY POWER SUPPLY CORD: This Portable Air Conditioner is provided with a Leakage Current Detection and Interruption circuit (LCDI) built into the plug of the power supply cord. This device provides protection to reduce the risk of fire due to arcing faults in the power-supply cord.
