- Page 1 GB/UK LAVASTONE GRILL SERIES 70 2856211 2856311 INSTALLATION, USE AND MAINTENANCE...
- Page 2 2856201 2856301 (G= gas\gaz) Fig. – Abb. 1: Dimensioni \ Dimensions \ Floor space dimensions \ Raumbedarfsmasse \ Espacio máximo necesario Fig. – Abb. 2: targhetta caratteristiche \ Plaques des caractéristiques \ data plate\ typenschild Pag. 1/56...
- Page 3 Fig. – Abb. 3: Installazione \ Lieu d'installation \ Place \ Installationsort Figg. – Abb. 4, 5, 6: Scarico fumi \ Évacuation des fumées \ Fumes evacuation \ Rauchabzug Fig. – Abb. 7: Simbolo equipotenziale \ Symbole equipotenziel \ Equipotenziale label \ quipotenzial Symbol Fig.
- Page 4 Figg.. – Abb. 9 : Sostituzione ugello bruciatore \ Changement du gicleur du brûleur \ Substituting burner nozzle Austausch Hauptbrennerdüse Fig. – Abb. 10 : Regolazione dell’aria primaria bruciatore \ Réglage de l'air primaire du brûleur \ Regulating primary burner Primärluftregelung des Hauptbrenners Figg.
- Page 5 Fig. – Abb. 13 : Istruzioni uso \ Instructions d’utilisation \ Instruction for use) \ Bedienungsanleitungen Fig. – Abb.14 : Istruzioni uso \ Instructions d’utilisation \ Instruction for use) \ Bedienungsanleitungen Pag. 4/56...
- Page 7 (Table 3) BURNER FEATURES (CY, MT - CAT. I 3B/P Normal Reduced Diam. Main By-pass Pilot Injectors Gas Type Capacity Capacity Injector Diameter Regulation [N°] “x” [mm] [kW] [kW] [1/100 mm] [1/100 mm] LAVASTONE GRILL ½ UNIT BURNER Liquid Gas LPG 9,00 3,50 AL150...
- Page 8 (Table 7) BURNER FEATURES (SE, DK, FI - CAT. II 2H3B/P , III 1ab2H3B/P 1a2H3B/P Normal Reduced Diam. Main By-pass Pilot Injectors Gas Type Capacity Capacity Injector Diameter Regulation [N°] “x” [mm] [kW] [kW] [1/100 mm] [1/100 mm] LAVASTONE GRILL ½ UNIT BURNER Liquid Gas LPG 9,00 3,50...
- Page 9 (Table 10) BURNER FEATURES (HU - CAT. II 2HS3B/P Normal Reduced Diam. Main By-pass Pilot Injectors Gas Type Capacity Capacity Injector Diameter Regulation [N°] “x” [mm] [kW] [kW] [1/100 mm] [1/100 mm] LAVASTONE GRILL ½ UNIT BURNER Liquid Gas LPG 9,00 3,50 AL150...
-
Page 10: Technical Features
installation of non-original spare parts, not observing local norms, incorrect use or not observing the instructions in this booklet For the installer The functioning of the appliance must be explained and shown to the user. After having ensured that everything is clear, the instruction booklet must be handed over. ... - Page 11 Neutral cabinet In the standing versions without oven, door are available for closing the opening and making a neutral cabinet. There are also racks available for inserting GASTRONORM wash bowls. PROVISIONS FOR INSTALLATION Place (fig. 3 – pag.2) It is advisable to install the appliance in a well ventilated room or under an extractor hood. The appliance may be installed as a single unit or together with others.
-
Page 12: Installation
installed). Type “B11” gas appliance These appliances must be connected in one of the following ways: Natural evacuation (fig.4 – pag.2). Connection to reliable chimney with natural pull, interposing a pull device, letting out the products of combustion directly outside. ... - Page 13 Electric connection The appliance must be connected to the EQUIPOTENZIALE system. The connector is situated near the end of the electric cable and is identified by a label with the symbol shown on figure 7 (pag.2). Checking gas tightness and pressure (fig.8 – pag.2). Before proceeding to check the pressure, it is necessary to check the tightness of the gas installation up to the nozzle with a leak-finder spray to ensure that no damage has been done to the appliance during transportation.
- Page 14 Checking pilot burner Check the flame of the pilot burner, which must be neither too short nor too high but must lap the thermocouple and have a sharp form; otherwise, it is necessary to check the size of the nozzle depending on the pilot version, as specified in the following paragraphs.
-
Page 15: Instructions For Use
the meter, turning it clockwise to reduce the flow and anti-clockwise to increase it. After regulating, fix the position of the by-pass with a drop of red paint, suitable for this use Substituting the pilot burner nozzle (fig. 12 – pag.3) To substitute the nozzle of the pilot burner, it is necessary to remove the handles of the container of the lava stone , unscrewing with a setscrew wrench the socket head screws that fix it (for the models where it is foreseen).It is necessary to remove the knob and the control panel as in figure 11. -
Page 16: Care And Maintenance Of The Appliance
Some problems and their possible solutions Problem Possible solution Check that gas inlet pressure is the same as that shown in table TYPES OF GAS Check that the nozzle of the burner is not blocked The burner does not light on Check that the igniter plug is well fixed and connected Check that the igniter plug is intact Check that the igniter cable is intact... - Page 17 Maintenance ATTENTION! Before doing any kind of maintenance or repairs, make sure that the gas cutoff valve is closed. The following maintenance operations must be carried out at least once a year by specialized personnel. It is advisable to have a maintenance contract. ...
