SunBriteTV 2310HD Specification Sheet

Model 2310HD
LCD Screen 23-inch diagonal TFT Active Matrix
Resolution 1366 x 768 WXGA
Aspect Ratio 16:9
Active Area 508.1 x 285.7 mm
Contrast Ratio 700:1
Response Time 8 milliseconds
Viewing Angle 160 by 140
o
Input Connectors:
Antenna/CATV (NTSC, ATSC, QAM)
RF
HDMI
HDMI Input x1
Video Composite
S-Video x1 and Composite Video x1
L/R Audio Inputs x2
Video Component
YCbCr/YPbPr x1 (supports HDTV inputs at 480i, 480P, 567i,
576P, 720P and 1080i) and audio L/R channels x1
PC
15-pin D-sub VGA
Full-featured command set with discrete on/off, input
RS232 Serial
select and volume control
Input Power 100-240 VAC, 50-60 Hz 2.2A Max
Audio 10-watt x 2 channels, water-resistant speakers
L/R Audio output connector inside rear cover
Operating Temp. o
-24 to 122
Non-op. Temp. o
-24 to 140
(Off-mode with
power applied)
Accessories Included Water-resistant remote control with lithium battery
Removable table top stand
TV Dimensions 23.51 in. W x 16.27 in. H x 4.90 in. D
Weight 22 lbs., 25 lbs. with table top stand
Shipping Dimen- 30.31 in. W x 19.49 in. H x 8.86 in. D
sions
Shipping Weight 28 lbs.
Warranty One-year, in-factory, parts and labor
*Temperature range is for operation in shaded location.
o
o o o
F. (-31 to 50 C.) *
o o o
F. (-31 to 60 C.)
All Weather Outdoor LCD Television
Model 2310HD
Super Bright 23" LCD Screen, HD Ready
All-weather enclosure protects internal components
from rain, dirt, insects and scratches
Dual-fan airflow system keeps unit cool and dry in
temperatures up to 122 degrees F.
Internal thermostatically-controlled heater protects TV
in temperatures as low as -24 degrees F.
Innovative watertight cable entry system with pass-
through design keeps cables dry and allows for easy
hook-ups
Optional wall mounts and deck planter poles are
weatherized and include stainless steel hardware
SunBriteTV Model 2310HD
(All dimensions are in inches)
TV Dimensions are:
23.51 in. W x 16.27 in. H x 4.90 in. D
Height dimension with table top stand is 17.14 in.
TV with optional wall mount measures 7.60 in. when folded flush against the wall.
Optional Accessories
SB-CM20 Ceiling mount with tilt and swivel includes adjustable extension column that
provides 5" to 11" above unit to ceiling. Also includes 4" x 4" designer ceiling
plate. Meets VESA standards.
SB-WM23 Articulating wall mount with tilt, swivel, pan and extends up to 9" from wall.
Meets VESA standards.
SB-DP20X Deck/Planter pole (requires purchase of wall mount). Special order item.
SB-FMT23 RadioFM TM, transmits audio from TV to FM radio
SB-DC23 Outdoor TV dust cover
Specifications may be subject to change.
866.357.8688
www.sunbritetv.com
5069 Maureen Lane, Unit A
Patent pending. All rights reserved. (C) 2008 SunbriteTV LLC
Moorpark, CA 93021

