Page 1 SSH-C48Q Top-of-Rack Omni-Path Switch CLI User’s Guide Revison 1.0...
Page 2 This product, including software and documentation, is the property of Supermicro and/or its licensors, and is supplied only under a license. Any use or reproduction of this product is not allowed, except as expressly permitted by the terms of said license.
Page 3 Preface ® This manual is part of the documentation set for the Intel Omni-Path ® Fabric (Intel OP Fabric), which is an end-to-end solution consisting of adapters, edge switches, director switches and fabric management and development tools. ® The Intel OP Fabric delivers a platform for the next generation of High-Performance Computing (HPC) systems that is designed to cost-effectively meet the scale, density, and reliability requirements of...
Page 4: Intended Audience
SSH-C48Q Switch CLI User’s Guide Intended Audience ® ® The intended audience for the Intel Omni-Path (Intel document set is network administrators and other qualified personnel. Documentation Conventions This guide uses the following documentation conventions: • Note: provides additional information.
Page 5: Table Of Contents
Table of Contents Preface ..........iii Intended Audience ..........iv Documentation Conventions ........iv Introduction ...........1 CLI Overview ............1 Commands and Functional Groups ...... 3 Online Help ............5 Keyboard Shortcuts ..........6 Accessing the CLI ..........6 Standardized Warning Statements ..9 Warning Definition ............9 Installation Instructions ..........11 Circuit Breaker ............12...
Page 6 SSH-C48Q Switch CLI User’s Guide Backplane Voltage ............21 Comply with Local and National Electrical Codes ..22 Product Disposal ............23 Hot Swap Fan Warning ..........24 Power Cable and AC Adapter ........26 Groups and Commands ......29 General ............... 29 help ................29 list ................31 history .................32...
Page 7 Table of Contents user ................39 passwd .................40 userAdd ...............40 userRem ..............41 userListShow ..............42 sshKey .................42 loginMode ..............43 setldapSvrIpAddr ............44 setldapSvrPort .............44 idleTimeoutGet ............45 idleTimeoutSet ............45 sessionTimeoutDisable ..........46 sessionTimeoutEnable ..........46 loginMsgGet ...............47 loginMsgSet ..............47 loginNameGet .............48 loginNameSet ..............48 serialAuthGet ..............49 serialAuthSet ...............49 uiConfig ..............50 genPost ................52 exit ................53...
Page 8 SSH-C48Q Switch CLI User’s Guide hwCheck ..............54 hwMonitor ..............56 showNodeDesc ............60 setNodeDesc ...............60 setNodeDescFormat ............60 fruInfo .................61 chassisQuery ...............63 showInventory ............64 setBeacon ..............65 setSystemContact ............66 setSystemName ............66 setSystemLocation ............67 Network .............. 67 ifShow .................67 routeShow ..............68 ping ................69 ping6 ................71 showChassisIpAddr ............71...
Page 9 Table of Contents autoConfIPv6Disable ..........74 autoConfIPv6Disable ..........74 autoConfIPv6Show .............75 ndpShow ..............75 showDefaultRoute ............76 setDefaultRoute ............76 arpShow ..............77 hostShow ..............77 dhcpEnable ..............78 dhcpDisable ..............78 dhcpShow ..............78 dnsParamsShow ............79 dnsParamsSet ..............79 IpoStlConfigShow ............80 IpoStlConfigEnable ............81 IpoStlConfigDisable ...........81 IpoStlAddressShow ............81 IpoStlAddressSet ............82 IpoStlAddressSetIPv6 ..........82 IpoStlAddressShowIPv6 ..........83 Firmware .............
Page 10 SSH-C48Q Switch CLI User’s Guide fwUpdateChassis ............86 fwListFiles ..............87 fwShowUpdateParams ..........88 fwSetUpdateParams ............88 showCapability ............89 showLastScpRetCode ..........90 fwVersion ..............90 bootQuery ..............91 bootSelect ..............91 Fabric Management ..........93 pmResetCounters ............93 pmShowCounters ............93 pmShowRunningTotals ..........95 smAdaptiveRouting ............95 smControl ..............96 smConfig ..............96 smPKeys ..............97 smForceSweep ............98...
Page 11 Table of Contents smPmStart ..............102 smShowConfig ............103 smShowLids ..............104 smShowMcMember ..........105 smShowServices ............106 smShowInform ............106 smShowCounters ............107 smShowLidMap ............108 smShowTopology .............109 smShowVFInfo ............110 smLooptestStart ............110 smLooptestFastModeStart ........110 smLooptestStop ............111 smLooptestInjectPackets ..........112 smLooptestInjectAtNode ..........112 smLooptestInjectEachSweep ........113 smLooptestPathLength ..........113 smLooptestMinISLRedundancy .......114 smLooptestShowLoopPaths ........114 smLooptestShowSwitchLft ........115 smLooptestShowTopology ........116 smLooptestShowConfig ..........119...
Page 12 SSH-C48Q Switch CLI User’s Guide Log ..............120 logShow ..............120 logClear ..............121 logConfigure .............122 logResetToDefaults ..........123 logSyslogConfig ............124 logShowConfig ............127 logSyslogTest ............128 Interconnect Switch Management (ISM) ..129 ismPortStats ..............129 ismPortCounters ............131 ismLinearFwdb ............134 ismMultiFwdb ............134 ismSwitchInfoLid .............137 ismPortStatLid ............137 ismPortInfoLid ............137...
Page 13 Table of Contents ismModuleSetLWDS ..........152 ismIslSetLWDS ............154 ismPortSetFmEnabled ..........156 ismChassisSetFmEnabled .........157 ismPortSetCrcMode ..........158 ismChassisSetCrcMode ..........160 ismModuleSetCrcMode ..........162 ismIslSetCrcMode ............163 ismPortSetVCU ............164 ismChassisSetVCU ...........166 ismModuleSetVCU ...........166 ismIslSetVCU ............167 ismChassisSetMtu .............168 ismModuleSetMtu ............170 ismPortEnable ............172 ismChassisSetEnable ..........172 ismModuleSetEnable ..........173 ismPortDisable ............174 ismChassisSetSpeed ..........175 ismModuleSetSpeed ..........175 ismIslSetSpeed ............176 ismPortSetSpeed ............177...
Page 14 SSH-C48Q Switch CLI User’s Guide ismPortQsfpInfo ............179 ismChassisBounce ............182 ismModuleBounce ............182 ismIslBounce ............182 ismPortBounce ............183 ismRemoveStateDump ..........183 ismShowStateDump ..........184 ismTakeStateDump ...........184 ismShowArConfig ............185 ismShowArMoves ............185 Time Management ..........186 time ................186 timeZoneConf ............187 timeDSTConf ............188 timeNtpTimeout ............192 timeNtpRefreshTime ..........193 SNMP ............... 194 snmpCommunityConf ..........194...
Page 15 Table of Contents snmpNotify ...............199 snmpSystem ..............200 snmpUsrSec ..............201 CaptureInfo ............203 capture ...............203 showAllConfig ............203 captureFw ..............204 captureSm ..............204 captureIsm ..............204 captureChassis ............205 captureNetwork ............205 captureLog ..............205 captureMisc ...............206 captureSnmp .............206 captureShell ..............206...
Page 16 Notes...
Page 17: Introduction
Groups and Commands describes the CLI commands. CLI Overview This section details the usage of the Command Line Interface (CLI) feature for the Supermicro SSH-C48Q Switch family. The CLI allows you to perform remote configuration and management tasks that ®...
Page 18 SSH-C48Q Switch CLI User’s Guide Operator: • Read only access. Administrator: • Read and write access. • Reboot access. • Change operator and administrator passwords. • Disable user login and passwords, which allows all users adminis- trator-level access without the need for a user name or password.
Page 19: Commands And Functional Groups
Introduction Commands and Functional Groups The CLI commands are grouped into functional areas as shown in the following table. Type list -noprompt to display the list of command groups. Table 1: Command Groups Group Description General General General commands for user management and CLI configuration.
Page 20 SSH-C48Q Switch CLI User’s Guide Group Description SNMP Snmp Commands for configuring trap destinations and security parameters required to access the switch from an SNMP manager. CaptureInfo CaptureInfo Analysis and debugging commands for capturing switch-specific information. To list commands within a functional group, simply type the functional group name.
Page 21: Online Help
Introduction Online Help The online help for the CLI provides all necessary information to successfully execute each command. Access online help by typing help CommandName or CommandName help. For example, typing help list displays the following information for the list command: ->...
Page 22: Keyboard Shortcuts
SSH-C48Q Switch CLI User’s Guide Keyboard Shortcuts • The CLI keeps a history of recently executed commands. Use the UP ARROW and DOWN ARROW keys to access the history. • Edit the current command using the LEFT ARROW and RIGHT ARROW keys.
Page 23 Introduction 3) The system prompts for a password. The CLI has the following default passwords: Operator access: operpass Administrator access: adminpass Type the appropriate password and press ENTER. The system responds with: Welcome to the <SWITCH> CLI. Type 'list' for the list of commands.
Page 24 Notes...
Page 25: Standardized Warning Statements
The following statements are industry standard warnings, provided to warn the user of situations which have the potential for bodily injury. Should you have questions or experience difficulty, contact Supermicro's Technical Support department for assistance. Only certified technicians should attempt to install or configure components.
Page 26 SSH-C48Q Switch CLI User’s Guide 找到此设备的安全性警告说明的翻译文本。此警告符號代表危險。您正處於可能身體可能會受損傷的工作環境中。在您使用任何設備之前，請注意觸電的危險，並且要熟悉預防事故發生的標準工作程序。請依照每一注意事項後的號碼找到相關的翻譯說明內容。 Warnung WICHTIGE SICHERHEITSHINWEISE Dieses Warnsymbol bedeutet Gefahr. Sie befinden sich in einer Situation, die zu Verletzungen führen kann. Machen Sie sich vor der Arbeit mit Geräten mit den Gefahren elektrischer Schaltungen und den üblichen Verfahren zur Vorbeugung vor Unfällen vertraut.
Page 27: Installation Instructions
Standardized Warning Statements ‫זהרה‬ ‫א‬ ‫הצהרות‬ ‫תקנו ן ן‬ ‫חבלה‬ ‫זהרות על פי תקני התעשייה, על מנת להזהיר את המשתמש מפני‬ ‫א‬ ‫הצהרות הבאות הן‬ ‫קשר עם מחלקת תמיכה‬ ‫יש ליצור‬ ,‫תקלות בבעיה כלשהי‬ ‫י‬ ‫פיזית אפשרית. במידה ויש שאלות או ה‬ .‫רכיבים‬...
Page 28: Circuit Breaker
SSH-C48Q Switch CLI User’s Guide 設置手順書システムを電源に接続する前に、設置手順書をお読み下さい。警告将此系统连接电源前 , 请先阅读安装说明。警告將系統與電源連接前，請先閱讀安裝說明。 Warnung Vor dem Anschließen des Systems an die Stromquelle die Installationsanweisungen lesen. ¡Advertencia! Lea las instrucciones de instalación antes de conectar el sistema a la red de alimentación.
Page 29 Standardized Warning Statements この製品は、短絡（過電流）保護装置がある建物での設置を前提としています。保護装置の定格が 250 V、20 A を超えないことを確認下さい。警告此产品的短路 ( 过载电流 ) 保护由建筑物的供电系统提供 , 确保短路保护设备的额定电流不大于 250V,20A。警告此產品的短路 ( 過載電流 ) 保護由建築物的供電系統提供 , 確保短路保護設備的額定電流不大於 250V,20A。 Warnung Dieses Produkt ist darauf angewiesen, dass im Gebäude ein Kurzschluss- bzw. Überstromschutz installiert ist. Stellen Sie sicher, dass der Nennwert der Schutzvorrichtung nicht mehr als: 250 V, 20 A beträgt.
Page 30: Power Disconnection Warning
SSH-C48Q Switch CLI User’s Guide Waarschuwing Dit product is afhankelijk van de kortsluitbeveiliging (overspanning) van uw electrische installatie. Controleer of het beveiligde aparaat niet groter gedimensioneerd is dan 220V, 20A. Power Disconnection Warning Warning! The system must be disconnected from all sources of power...
Page 31 Standardized Warning Statements Attention Le système doit être débranché de toutes les sources de puissance ainsi que de son cordon d'alimentation secteur avant d'accéder à l'intérieur du chassis pour installer ou enlever des composants de systéme. ‫אזהרה מפני ניתוק חשמל י י‬ !‫אזהרה‬...
Page 32: Equipment Installation
SSH-C48Q Switch CLI User’s Guide Equipment Installation Warning! Only trained and qualified personnel should be allowed to install, replace, or service this equipment. 機器の設置トレーニングを受け認定された人だけがこの装置の設置、交換、またはサービスを許可されています。警告只有经过培训且具有资格的人员才能进行此设备的安装、更换和维修。警告只有經過受訓且具資格人員才可安裝、更換與維修此設備。 Warnung Das Installieren, Ersetzen oder Bedienen dieser Ausrüstung sollte nur geschultem, qualifiziertem Personal gestattet werden.
Page 33: Restricted Area
Standardized Warning Statements Restricted Area Warning! This unit is intended for installation in restricted access areas. A restricted access area can be accessed only through the use of a special tool, lock and key, or other means of security. (This warning does not apply to workstations).
Page 34: Battery Handling
SSH-C48Q Switch CLI User’s Guide ‫אזור עם גישה מוגבל ת ת‬ !‫אזהרה‬ ‫יש להתקין את היחידה באזורים שיש בהם הגבלת גישה. הגישה ניתנת בעזרת‬ .('‫כלי אבטחה בלבד )מפתח, מנעול וכד‬ ‫ﻣﺤﻈﻮرة‬ ‫ﻣﻨﺎطﻖ‬ ‫ﻟﺘﺮﻛﯿﺒﮭﺎ ﻓﻲ‬ ‫ھﺬه اﻟﻮﺣﺪة‬ ‫ﺗﺨﺼﯿﺺ‬ ‫ﺗﻢ‬ ،‫أداة ﺧﺎﺻﺔ‬...
Page 35 Standardized Warning Statements 電池更換不當會有爆炸危險。請使用製造商建議之相同或功能相當的電池更換原有電池。請按照製造商的說明指示處理廢棄舊電池。 Warnung Bei Einsetzen einer falschen Batterie besteht Explosionsgefahr. Ersetzen Sie die Batterie nur durch den gleichen oder vom Hersteller empfohlenen Batterietyp. Entsorgen Sie die benutzten Batterien nach den Anweisungen des Herstellers. Attention Danger d'explosion si la pile n'est pas remplacée correctement. Ne la remplacer que par une pile de type semblable ou équivalent, recommandée par le fabricant.
Page 36: Redundant Power Supplies
SSH-C48Q Switch CLI User’s Guide Redundant Power Supplies Warning! This unit might have more than one power supply connection. All connections must be removed to de-energize the unit. 冗長電源装置このユニットは複数の電源装置が接続されている場合があります。ユニットの電源を切るためには、すべての接続を取り外さなければなりません。警告此部件连接的电源可能不止一个，必须将所有电源断开才能停止给该部件供电。警告此裝置連接的電源可能不只一個，必須切斷所有電源才能停止對該裝置的供電。 Warnung Dieses Gerät kann mehr als eine Stromzufuhr haben. Um sicherzustellen, dass der Einheit kein trom zugeführt wird, müssen...
Page 37: Backplane Voltage
Standardized Warning Statements 이 장치에는 한 개 이상의 전원 공급 단자가 연결되어 있을 수 있습니다 . 이 장치에 전 원을 차단하기 위해서는 모든 연결 단자를 제거해야만 합니다 . Waarschuwing Deze eenheid kan meer dan één stroomtoevoeraansluiting bevatten. Alle aansluitingen dienen verwijderd te worden om het apparaat stroomloos te maken Backplane Voltage Warning!
Page 38: Comply With Local And National Electrical Codes
SSH-C48Q Switch CLI User’s Guide ‫מתח בפנל האחור י י‬ !‫הרה‬ ‫אז‬ ‫קיימת סכנת מתח בפנל האחורי בזמן תפעול המערכת. יש להיזהר במהלך‬ .‫העבודה‬ ‫اﻟﻠﻮﺣﺔ‬ ‫أواﻟﻄﺎﻗﺔ اﻟﻤﻮﺟﻮدة ﻋﻠﻰ‬ ‫اﻟﺘﯿﺎر اﻟﻜﮭﺮﺑﺎﺋﻲ‬ ‫ﻣﻦ‬ ‫ﺧﻄﺮ‬ ‫ھﻨﺎك‬ ‫ھﺬا اﻟﺠﮭﺎز‬ ‫ﺧﺪﻣﺔ‬ ‫ﻛﻦ ﺣﺬرا ﻋﻨﺪ‬ ‫ﯾﻌﻤﻞ‬...
Page 39: Product Disposal
Standardized Warning Statements ¡Advertencia! La instalacion del equipo debe cumplir con las normas de electricidad locales y nacionales. Attention L'équipement doit être installé conformément aux normes électriques nationales et locales. ‫תיאום חוקי החשמל הארצי‬ !‫אזהרה‬ ‫הציוד חייבת להיות תואמת לחוקי החשמל המקומיים והארציים‬ ‫התקנת‬...
Page 40: Hot Swap Fan Warning
SSH-C48Q Switch CLI User’s Guide Warnung Die Entsorgung dieses Produkts sollte gemäß allen Bestimmungen und Gesetzen des Landes erfolgen. ¡Advertencia! Al deshacerse por completo de este producto debe seguir todas las leyes y reglamentos nacionales. Attention La mise au rebut ou le recyclage de ce produit sont généralement soumis à...
Page 41 Standardized Warning Statements 警告当您从机架移除风扇装置，风扇可能仍在转动。小心不要将手指、螺丝起子和其他物品太靠近风扇警告當您從機架移除風扇裝置，風扇可能仍在轉動。小心不要將手指、螺絲起子和其他物品太靠近風扇。 Warnung Die Lüfter drehen sich u. U. noch, wenn die Lüfterbaugruppe aus dem Chassis genommen wird. Halten Sie Finger, Schraubendreher und andere Gegenstände von den Öffnungen des Lüftergehäuses entfernt. ¡Advertencia! Los ventiladores podran dar vuelta cuando usted quite ell montaje del ventilador del chasis.
Page 42: Power Cable And Ac Adapter
Electrical Appliance and Material Safety Law prohibits the use of UL or CSA -certified cables (that have UL/CSA shown on the code) for any other electrical devices than products designated by Supermicro only. 電源コードと AC アダプター...
Page 43 Elektrische Geräte und Material Safety Law verbietet die Verwendung von UL-oder CSA-zertifizierte Kabel, UL oder CSA auf der Code für alle anderen elektrischen Geräte als Produkte von Supermicro nur bezeichnet gezeigt haben. ¡Advertencia! Al instalar el producto, utilice los cables de conexión previstos o designados, los cables y adaptadores de CA.
Page 44 SSH-C48Q Switch CLI User’s Guide ‫اﻟﻜﺎﺑﻼت اﻟﻜﮭﺮﺑﺎﺋﯿﺔ‬ ‫ﻛﺎﺑﻼت اﻟﺘﻮﺻﯿﻞ،و‬ ‫اﻟﺠﮭﺎز ﯾﺠﺐ اﺳﺘﺨﺪام‬ ‫ﻋﻨﺪ ﺗﺮﻛﯿﺐ‬ ‫اﻟﺘﯿﺎر اﻟﻤﺘﺮدد‬ ‫وﻣﺤﻮﻻت‬ ‫أو ﺣﺮﯾﻖ‬ ‫ﺣﺪوث ﻋﻄﻞ‬ ‫ﻓﻲ‬ ‫ﯾﺘﺴﺒﺐ‬ ‫أﺧﺮى‬ ‫وﻣﺤﻮﻻت‬ ‫ﻛﺎﺑﻼت‬ ‫اﺳﺘﺨﺪام أي‬ ‫أن‬ . ‫اﻟﺘﻲ‬ ‫ﻣﻊ اﻟﻤﻨﺘﺞ‬ ‫ﺗﻢ ﺗﻮﻓﯿﺮھﺎ ﻟﻚ‬ UL ‫ أو‬CSA ‫اﻟﻜﺎﺑﻼت‬...
Page 45: Groups And Commands
Groups and Commands This section lists all CLI functional groups along with the commands for each group. The commands for all supported switches are listed. Any commands that are different for a particular switch are noted. For more specific information for each functional group, execute the command: help GroupName For more specific command information, execute the command:...
Page 46 SSH-C48Q Switch CLI User’s Guide -> help list NAME list SYNOPSIS list [group] [-noprompt] DESCRIPTION List available commands. OPTIONS group - List the commands in that particular group -noprompt - Just list the command groups. The following General Help text is returned when help help is entered: ->...
Page 47: List
Groups and Commands The help descriptions use the following conventions. Formatting differences between the help output and this document are also noted. • Square brackets [ ] indicate optional parameters. For example, [-noprompt] • Angle brackets < > indicate user-selectable input. For example, <command>.
Page 48: History
SSH-C48Q Switch CLI User’s Guide ->list -noprompt List of Valid Groups: General General commands for user management and CLI configuration. Chassis Chassis management commands. (FRU info, fan / power supply state, etc). Network Ethernet interface management commands. Firmware Used to display or modify firmware revision levels.
Page 49: Reboot
Reboots the device. reboot [now] [-m] [slot slot] [-s] [-n] [all] Does not prompt before rebooting. Reboots Master (local) Supermicro SSH-C48Q Switch Family (non-disruptive). slot slot Resets specific device where slot = slotNumber (disruptive). Reboots Slave (remote) Supermicro SSH-C48Q Switch Family.
Page 50: Killclisession
SSH-C48Q Switch CLI User’s Guide Use the argument all to perform disruptive reboot of all present Management Modules and cards. You can reboot the local (Master) Management Module or the remote (Slave) Management Module with one or multiple arguments. Non-disruptive reboots do not interfere with switch traffic if ASIC firmware is not changing.
Page 51: Broadcast
Groups and Commands type ip address ------------------------------------------------ -------------------------- admin admin 0 02:25:26 10/14/2015 02:25:26 10/14/2015 serial admin admin 1 09:23:16 10/16/2015 09:59:01 10/16/2015 ssh ::ffff:10.127.236.39 Displays a list of currently active CLI sessions. Note that a session can be active, but no user information is available.
Page 52: Swapbsdel
SSH-C48Q Switch CLI User’s Guide swapBsDel Toggles the key bindings for the backspace and delete characters. swapBsDel None. -> swapBsDel Terminals may bind the backspace and delete key bindings differently. This command swaps two commonly used bindings, which allow you to use the backspace and delete keys properly without having to adjust your terminal settings.
Page 53: Gettermwidth
Groups and Commands getTermWidth Displays the terminal width for text formatting purposes. getTermWidth None. -> getTermWidth Current terminal width: 80 characters. Displays the terminal width used for text formatting purposes. Note that not all commands adhere to this setting. prompt Modifies the CLI prompt (global for all active CLI sessions).
Page 54: Case
SSH-C48Q Switch CLI User’s Guide case Displays or modifies the case sensitivity of the command interpreter for the CLI session. case [{off | on}] off | on Turns case sensitivity off or on. -> case off Case sensitivity is now off If no value is entered, the current setting is displayed.
Page 55: Echo
Groups and Commands echo Echoes the input parameters back to the output. echo [text1 text2] text1 text2 Text to be echoed. If there are multiple arguments, they must be separated by spaces. -> echo text1 text2 text1 text2 logout Terminates the current CLI session. logout None.
Page 56: Passwd
SSH-C48Q Switch CLI User’s Guide passwd Modifies a user account password. passwd [username] [-r] username User account name associated with the password change. Resets user account password. This option is only allowed from serial connection. -> passwd operator1 Changing password for user: operator1...
Page 57: Userrem
Groups and Commands admin Administrator operator Operator support Support personnel username New user account name. Must be between 4 and 32 characters. password Optional password. If not supplied, the default password for that role is used. -> userAdd admin Bob User added: Bob Password is set to the default password for this role: admin...
Page 58: Userlistshow
SSH-C48Q Switch CLI User’s Guide userListShow Displays all user accounts for this device. userListShow None. -> userlistshow username role operator operator admin admin ivtester support sshKey Displays or modifies the configured set of SSH keys. sshKey [{show | add "key" | rem <index> | rem...
Page 59: Loginmode
Groups and Commands : Users with administrative privileges may use the -u option NOTE to manage keys for other users. When valid key is present, user can log in without a password. -> sshKey show Index ----------------------------------- "ssh-rsa AAAAB3NzaC1yc2EAAAABIwAAAQEArNiSexu30rZjs1HAXbDB wTgJgcxLF..." loginMode Displays or changes how users are authenticated when connecting to the GUI or CLI.
Page 60: Setldapsvripaddr
SSH-C48Q Switch CLI User’s Guide If no value is entered, the current setting is displayed. When user names are disabled, all users are logged on as the administrative user. There is no way to change this behavior. setldapSvrIpAddr Displays or modifies the LDAP server IP address.
Page 61: Idletimeoutget
Groups and Commands idleTimeoutGet Displays the idle timeouts for the CLI and GUI interfaces to the system. If set to zero, the timeout for that interface is disabled. idleTimeoutGet [{--all | --cli | --gui}] --all Display all timeouts. If no option is entered, this is the default behavior.
Page 62: Sessiontimeoutdisable
SSH-C48Q Switch CLI User’s Guide --gui Sets the idle timeout for the GUI. timeout Value for idle timeout (in seconds). If set to 0, the timeout is disabled. -> idleTimeoutSet --all 700 CLI timeout is 700 seconds. GUI timeout is 700 seconds.
Page 63: Loginmsgget
Groups and Commands loginMsgGet Displays the CLI login message. loginMsgGet None. -> loginMsgGet Welcome message: Be certain to logout when you are finished using the CLI. You can customize the login message using loginMsgSet. loginMsgSet Sets the welcome message displayed when logging onto the CLI.
Page 64: Loginnameget
SSH-C48Q Switch CLI User’s Guide loginNameGet Displays the text string that is shown prior to logging in via Telnet. loginNameGet None. -> loginNameGet login-name: Switch1 The login name is an arbitrary string displayed prior to a user attempting a login to a new CLI session.
Page 65: Serialauthget
Groups and Commands serialAuthGet Displays the mode setting for serial console authentication. If enabled, user login and authentication are required on the serial console of the system. serialAuthGet None. -> serialAuthGet Serial authentication is currently disabled. serialAuthSet Modifies the serial console authentication mode setting.
Page 66: Uiconfig
SSH-C48Q Switch CLI User’s Guide uiConfig Displays or modifies the user interface access methods. uiConfig [-telnet {0|1}] [-https {0|1}] [-http {0|1}] [-sftp {0|1}] [-snmp {0|1}] [-ssh {0|1}] -telnet Disables or enables access to the device via Telnet. 0 = Disable access.
Page 67 Groups and Commands 0 = Disable access. 1 = Enable access. -ssh Disables or enables SSH access. 0 = Disable access. 1 = Enable access. -> uiconfig -telnet 0 Successfully modified configuration. Option Value ----------------------- -telnet -http -https -sftp -snmp -ssh There are several access methods for this device.
Page 68: Genpost
SSH-C48Q Switch CLI User’s Guide Any access method supported by the device but not listed here, cannot be configured and is always enabled. genPost Displays General POST results and runs tests. genPost [{all | test}] Runs all tests. test Runs specific test number.
Page 69: Exit
Groups and Commands Running: all POST PROTO Parameters P1:1 P2:2 P3:3 ID Gen POST Name Result DEM PWR Result-Ext ------------------------------------------------ --------------------------- * POST TEST CPU NO-RUN * POST TEST MEM DRAM NO-RUN * POST TEST BOOTROM IMG CHKSUM NO-RUN * POST TEST RUN-TIME IMG CHKSUM NO-RUN * POST TEST JMP RAM NO-RUN...
Page 70: Chassis
SSH-C48Q Switch CLI User’s Guide Chassis Commands in this category are used for chassis management, such as FRU info, fan/power supply state, and others. hwCheck Displays the hardware status for chassis, modules, fans, and power supplies. hwCheck [{-verbose | {0 | 1}}] Returns GOOD or provides detailed status/warning/error information.
Page 71 Groups and Commands status=Engaged errors=0 warnings=0 fanErrors=0. Power Supply 2 health: status=Engaged errors=0 warnings=0 fanErrors=0. Supermicro SSH-C48Q Switch health: LTC4260 Voltage Min Val. Max Val. Status 12.995 10.800 14.300 Voltage is OK LTC2974 Voltage Min Val. Max Val. Status 1.800 1.614...
Page 72: Hwmonitor
SSH-C48Q Switch CLI User’s Guide LTC3880 Voltage Min Val. Max Val. Status 3.334 3.161 3.508 Voltage is OK Temperature Warning Critical Actual ASIC_EXT 105C ASIC_INT 104C QSFP_MAX 100C CPU_CORE 100C Temperature Errors Temperature Warnings Temperature I/O Errors Good Temperatures Voltage Warnings...
Page 73 The CLI displays different output depending on ® the Intel Omni-Path switch type. The display refreshes automatically. Example for Supermicro SSH-C48Q Switch Family -> hwmonitor System monitor, Uptime: 4 days 0 hours 21 minutes 1 seconds Power Supply 1: online...
Page 74 SSH-C48Q Switch CLI User’s Guide Cable13[Active] Cable14[ Down ] Cable15[ Down ] Cable16[ Down ] Cable17[ Down ] Cable18[ Down ] Cable19[ Down ] Cable20[ Down ] Cable21[ Down ] Cable22[ Down ] Cable23[ Down ] Cable24[Active] Cable25[ Down ]...
Page 75 Groups and Commands • ! = Device is inserted and powered off. • A = Device is required in the configuration, but is not inserted. • = Device is not required in the configuration, and is not inserted. (Column is empty.) TMP (Temperature) headings have two columns: •...
Page 76: Shownodedesc
SSH-C48Q Switch CLI User’s Guide showNodeDesc Displays the node subnet management agent (SMA) description (or the default). showNodeDesc [-d] Shows the default node name for this unit. -> showNodeDesc Node (SMA) Description is = OmniPth000000f600000000 If no value is entered, the current node description is displayed.
Page 77: Fruinfo
Groups and Commands format Description format type. If no value is entered, the current setting is displayed. Options include: Verbose format. Brief format (consistent with the CLI/GUI Port Stat port naming). -> setNodeDescFormat Format = 0 fruInfo Displays field replaceable unit (FRU) information.
Page 78 SSH-C48Q Switch CLI User’s Guide SlotNumbers: (pairs:ext0|Slt1) CmeAccess: (bits:ext0|Slt1|Cme) SlotNumber: 0 <-Record accessed via this slot CmeAccessBits: 2 (Access slot relative) ProxyAccess: (Access slot relative) LockDrivesCTR: 0 (Clear to Remove interlock) MechLock: NodeCount: xInfo_AssetTagInfo: RecType: LastRec: LenMult: ReadOnly: RecordFormat: RecLen:...
Page 79: Chassisquery
Groups and Commands 100SWE48QF2 VersionEncLen:c3 Version: MfgEncLen: Manufacturer: Intel Corporation ProdNmEncLen: df ProductName: OP Edge 48p Q7 forward 2PSU MfgIdEndLen: MfgId: 001175 MfgTime: 15/03/26 10:00 OemEncLen: 40 OemData: chassisQuery Displays information about the line cards in a chassis. chassisQuery [-master] [-slave] [slot] [-showType] [-type cardtype] [-ignoreInvalidType] -master...
Page 80: Showinventory
___________________________________ Power Supply 1 ----------------------------------- Manufacturer Id - 001175 Manufacturer Name - Intel Corporation Part Number - N/A Product Name - Supermicro SSH-C48Q Switch Series Power Supply ___________________________________ Power Supply 2 ----------------------------------- Manufacturer Id - 001175 Manufacturer Name - Intel Corporation...
Page 81: Setbeacon
Version - 004 Total devices found: 4 setBeacon Modifies or displays the chassis beacon LED setting. : This command is only available on Supermicro SSH-C48Q NOTE Switch Family. setBeacon [{0 | 1}] If no value is entered, the current setting is displayed.
Page 82: Setsystemcontact
SSH-C48Q Switch CLI User’s Guide Enable beacon. -> setBeacon 0 setSystemContact Sets or displays the chassis system contact information. setSystemContact [contact] contact System contact string; must be enclosed in double quotes. Maximum length is 255 characters. If no value is entered, the current setting is displayed.
Page 83: Setsystemlocation
Groups and Commands setSystemLocation Sets or displays the chassis system location. setSystemLocation [location] location System location string; must be enclosed in double quotes. Maximum length is 255 characters. If no value is entered, the current setting is displayed. -> setSystemLocation System Location : {no value} Network...
Page 84: Routeshow
SSH-C48Q Switch CLI User’s Guide inet6 unicast fe80::1%lo0 prefixlen 64 automatic inet6 unicast ::1 prefixlen 128 UP RUNNING LOOPBACK MULTICAST NOARP ALLMULTI MTU:1500 metric:1 VR:0 ifindex:1 RX packets:41 mcast:3 errors:0 dropped:0 TX packets:41 mcast:3 errors:0 collisions:0 unsupported proto:0 RX bytes:1903...
Page 85: Ping
Groups and Commands INET route table - vr: 0, table: 254 Destination Gateway Flags Metric 0.0.0.0/0 10.228.208.1 10.228.208.0/22 WRS-Template WRS-Template WRS-Template localhost localhost INET6 route table - vr: 0, table: 254 Destination Gateway Flags Metric localhost6 localhost6 2002:ae4::/32 2002:ae4:d15f::ae4:d15f 2002:ae4:d15f::ae4:d15f 2002:ae4:d15f::ae4:d15f fe80::%lo0/64 fe80::1%lo0...
Page 86 SSH-C48Q Switch CLI User’s Guide ping {hostname | ipAddress} [packetCount] hostname The network hostname to ping. Hostname is limited to 64 charac- ters. ipAddress The IP address to ping. packetCount The number of packets with which to ping the host (default is 5).
Page 87: Ping6
Groups and Commands ping6 Sends ping packets to a specified IPv6 address. ping6 [-n] [-c packetCount] [-I interface] ipv6Address Numeric output only. -c packetCount The number of packets with which to ping the host (default is 5). -I interface The local interface name to use (useful for link local ping). ipv6Address The network host to ping (scoped address accepted).
Page 88: Setchassisipaddr
SSH-C48Q Switch CLI User’s Guide setChassisIpAddr Modifies the chassis IP address and network mask. : If you are not using the console port, changing the chassis NOTE IP address drops the connection to the CLI, which may cause the device to become unreachable.
Page 89: Delchassisipv6Addr
Groups and Commands delChassisIpv6Addr Deletes the user-configured chassis IPv6 address. delChassisIpv6Addr None. -> delChassisIpv6Addr Deleting the chassis IPv6 address may drop the connection to the CLI if not using the console port, and may cause the device to become unreachable. This command does not affect link-local or autoconfigured addresses.
Page 90: Autoconfipv6Enable
SSH-C48Q Switch CLI User’s Guide autoConfIPv6Enable Enables IPv6 address autoconfiguration. autoConfIPv6Enable None. -> autoConfIPv6Enable This command allows prefix learning from attached routers. It does not affect link-local or manually configured addresses. autoConfIPv6Disable Disables IPv6 address autoconfiguration. autoConfIPv6Disable None. -> autoConfIPv6Disable This command prevents prefix learning from attached routers.
Page 91: Autoconfipv6Show
Groups and Commands autoConfIPv6Show Displays IPv6 address autoconfiguration setting(s). autoConfIPv6Show None. -> autoConfIPv6Show OOB IPv6 Autoconfig is enabled ndpShow Displays the IPv6 neighbors table. ndpShow None. -> ndpShow Neighbor Linklayer Address Netif Expire 2002:ae4:: 00:00:95:12:d3:1d gei0 perm 2002:ae4:d15f::ae4:d15f 00:00:95:12:d3:1d gei0 perm ff02::2 33:33:00:00:00:02...
Page 92: Showdefaultroute
SSH-C48Q Switch CLI User’s Guide fe80:: 00:00:95:12:d3:1d gei0 perm ipnet_cmd_ndp failed ret:0 showDefaultRoute Displays the default gateway IP address. showDefaultRoute None. -> showDefaultRoute Gateway IP Address: 172.26.0.254 This is the IP address for the default gateway to route packets from the OOB (out of band) management port to an external network.
Page 93: Arpshow
Groups and Commands arpShow Displays the link level address resolution protocol (ARP) table. arpShow None. -> arpShow 10.228.209.95 at 00:00:95:12:d3:1d permanent published on gei0 10.228.211.255 at ff:ff:ff:ff:ff:ff on gei0 10.228.208.1 at 00:00:5e:00:01:50 on gei0 hostShow Displays the host name table. hostShow None.
Page 94: Dhcpenable
SSH-C48Q Switch CLI User’s Guide dhcpEnable Enables DHCP on the Ethernet interface. dhcpEnable None. -> dhcpEnable DHCP is enabled Enables the DHCP client subsystem, requests a DHCP lease, and then configures the interface with the lease data from the server.
Page 95: Dnsparamsshow
Groups and Commands Enables verbose display. -> dhcpShow Client state = BOUND Assigned IP address: 172.26.3.35 Client subnet mask: 255.255.240.0 DHCP server: 172.26.1.20 Default IP router: 172.26.0.1 Client lease duration: 518400 secs (421299 remaining) dnsParamsShow Displays the stored domain name system (DNS) parameters.
Page 96: Ipostlconfigshow
SSH-C48Q Switch CLI User’s Guide -d domain name The local domain name where this switch is installed (limit 32 char- acters). 0 = Disable the DNS resolver. 1 = Enable the DNS resolver. -> dnsParamsSet -e 0 -> dnsParamsShow DNS Resolver : Disabled DNS Server Address : xxx.xxx.xxx.xxx...
Page 97: Ipostlconfigenable
Groups and Commands IpoStlConfigEnable Enables the IPoStl feature. : In this release, the term IpoIb is partially replaced by a NOTE temporary term IpoStl. Command names have been updated, however, the returned text may display IpoIb. This will be updated in a future release. IpoStlConfigEnable None.
Page 98: Ipostladdressset
SSH-C48Q Switch CLI User’s Guide None. -> IpoStlAddressShow IP Address & Netmask are not configured for IpoIb interface IPoSTL must be enabled to display these fields. IpoStlAddressSet Changes the IPoSTL IP address and network mask settings. : In this release, the term IpoIb is partially replaced by a NOTE temporary term IpoStl.
Page 99: Ipostladdressshowipv6
Groups and Commands The option ipv6Address/netMaskLen is made up of two major components, separated by a /. ipv6Address Notation format is: a:b:c:d:e:f:g:h, where embedded 0s can be shortened (for example, a:b::g:h). netMaskLen Value between 0 and 128 inclusive. -> IpoStlAddressSetIPv6 ipv6Address/netMaskLen IpoStlAddressShowIPv6 Displays the IPoStl IPv6 address and associated netmask settings.
Page 100: Firmware
Commands in this category are used to manage firmware, such as display firmware revision, update firmware, and other tasks. fwUpdate Updates the firmware. : This command is only available on ISupermicro SSH-C48Q NOTE Switch Family. fwUpdate [hostip username password directory filename] Firmware update uses FTP to retrieve the firmware file, then writes the file to flash.
Page 101: Fwupdateslot
Some modes may not be available in all configurations. fwUpdateSlot Updates the firmware on a specific card. : This command is only available on Supermicro SSH-C48Q NOTE Switch Family. fwUpdateSlot slot [hostip username password directory filename] Firmware update uses FTP to retrieve the firmware file, then writes the file to flash.
Page 102: Fwupdatechassis
Ftp password:[ftp] xxxxx File Directory:[PATH TO FIRMWARE FILE] File name:[xxxx.pkg] fwUpdateChassis Updates the firmware for all cards in a chassis or management card only. : This command is only available on ISupermicro SSH-C48Q NOTE Switch Family. fwUpdateChassis moduletype [-noprompt] [reboot]...
Page 103: Fwlistfiles
Groups and Commands Firmware update retrieves the firmware file from an FTP server, saves the file locally, then writes the file to flash. Using the all option updates all cards in the chassis. This assumes that all firmware files are in the same directory of the FTP server.
Page 104: Fwshowupdateparams
SSH-C48Q Switch CLI User’s Guide drwxrwxrwx 1024 Oct 14 02:24 operator/ drwxrwxrwx 1024 Oct 14 02:24 admin/ drwxrwxrwx 1024 Oct 14 02:24 ivtester/ The firmware directory temporarily stores firmware files before they are written to flash. fwShowUpdateParams Displays the default update firmware settings.
Page 105: Showcapability
Groups and Commands : The cardtype parameter is only required when specifying NOTE the filename. -h hostname The host name or IP address of the FTP server. Maximum = 64 char- acters. -u username The user name to access the FTP server. -p password The password to access the FTP server.
Page 106: Showlastscpretcode
SSH-C48Q Switch CLI User’s Guide showLastScpRetCode Displays the return code from the last SCP firmware or XML configuration push operation to the unit. showLastScpRetCode [slot] [-all] slot The slot number in the chassis. -all All slots in the chassis. -> showLastScpRetCode 101...
Page 107: Bootquery
Groups and Commands bootQuery Displays boot image version information. bootQuery slot [-active] [-alternate] [-all] slot Slot number. -active Displays the version of the active firmware image. -alternate Displays the version of the alternate firmware image. -all Displays the versions for the primary and alternate firmware images. ->...
Page 108 SSH-C48Q Switch CLI User’s Guide -i index The index of the boot image to be used next. -alternate Chooses the alternate image to be used next. -version version Chooses a specific version to be the image to be used next.
Page 109: Fabric Management
Groups and Commands Fabric Management Commands in this category are used for Subnet Manager (SM), Subnet Administration (SA), Performance Manager (PM), and Fabric Executive (FE) configuration and operation. pmResetCounters Resets various statistics and counters maintained by the performance manager (PM). pmResetCounters None.
Page 110 SSH-C48Q Switch CLI User’s Guide 7307203 PMA Query Retransmits: 7418 PMA Query Retransmits Exhausted: PM TX GET(ClassPortInfo): PM TX GET(PortSamplesControl): PM TX GET(PortSamplesResult): PM TX GET(PortCounters): 5507335 PM TX SET(PortCounters): 1119563 PM TX GET(PortCountersExtended): 352409 PM TX GET(VendorPortCounters): PM TX SET(VendorPortCounters):...
Page 111: Pmshowrunningtotals
Groups and Commands PA RX GET(GrpInfo): ......pmShowRunningTotals Displays the running total counters for all ports in the fabric maintained by the performance manager (PM). pmShowRunningTotals None. smAdaptiveRouting Displays or dynamically sets SM Adaptive Routing when the feature is configured.
Page 112: Smcontrol
SSH-C48Q Switch CLI User’s Guide smControl Starts and stops the embedded FM. smControl [start | stop | restart | status] start Starts the embedded FM. stop Stops the embedded FM. restart Restarts the embedded FM. (Starts it if it's not already running.) status Prints out the embedded FM status.
Page 113: Smpkeys
Groups and Commands Does not start the subnet manager at chassis boot. startOnSlaveCmu Starts the subnet manager at chassis boot. Starts the subnet manager on the slave CMU. Does not start the subnet manager on the slave CMU. Option 1 ->...
Page 114: Smforcesweep
SSH-C48Q Switch CLI User’s Guide None. -> smPKeys Virtual Fabric: Default PKey: 0xffff Virtual Fabric: Networking PKey: 0x1234 smForceSweep Forces a fabric sweep by the embedded subnet manager. smForceSweep None. -> smForceSweep This command has no output message. To see the resulting sweep information, the “Info”...
Page 115: Smloglevel
Groups and Commands Restore normal SM priority. Restore normal priorities for the SM and PM. -> smRestorePriority This command restores the normal priorities of various subnet managers after they have elevated their priority as a result of a failover. Issuing this command allows the "unsticking"...
Page 116: Smlogmode
SSH-C48Q Switch CLI User’s Guide INFO+ VERBOSE+ DEBUG2+ DEBUG4+ TRACE+ -> smLogLevel Log Level:2 The subnet manager must be running to use this command. Changes made with this command affect only the currently running SM in a fabric with multiple SMs running. Changes are forgotten if the SM is restarted or the chassis is rebooted.
Page 117: Smlogmask
Groups and Commands Logging is quieted by downgrading the majority of fatal, error, warn, and info log messages. (INFO) and only outputting user actionable events when LogLevel is 1 or 2. -> smLogMode Log Mode:0 The subnet manager must be running to use this command.
Page 118: Smpmstart
SSH-C48Q Switch CLI User’s Guide mask Bit mask for logging to enable. -> smLogMask SA SA Log Mask: 0x1ff The subnet manager must be running to use this command. Changes made with this command affect only the currently running SM in a fabric with multiple SMs running.
Page 119: Smshowconfig
Groups and Commands PM is disabled FE is enabled The configuration can only be changed from the master Chassis Management Card. smShowConfig Displays the XML configuration file. smShowConfig [-infoOnly | -contentOnly] [-noprompt] -infoOnly Displays the timestamp for the XML configuration file. -contentOnly Displays the contents of the XML configuration file.
Page 120: Smshowlids
SSH-C48Q Switch CLI User’s Guide    <Applications> Continue? [Y] With no arguments, the XML configuration file timestamp and contents are displayed, one screen at a time.
Page 121: Smshowmcmember
Groups and Commands • opasaquery • opareport smShowMcMember Displays multicast member information in the embedded subnet manager. smShowMcMember [-h] Display the host name as part of the output. -> smShowMcMember Multicast Groups: join state key: F=Full N=Non S=SendOnly Member 0xff12601bffff0000:00000001ffffd5bb (c001) qKey = 0x00000000 pKey = 0xFFFF mtu = 4 rate life = 19...
Page 122: Smshowservices
SSH-C48Q Switch CLI User’s Guide Similar information can also be obtained using the FastFabric command on the management node: • opashowmc smShowServices Displays subnet administration service records of the subnet manager. smShowServices None. The components (fields) of each service record are displayed.
Page 123: Smshowcounters
Groups and Commands command is not available unless the subnet manager is in the Master mode. Similar information can also be obtained using the FastFabric command on the management node: • opasaquery -o inform smShowCounters Displays various statistics and counters maintained by the subnet manager.
Page 124: Smshowlidmap
SSH-C48Q Switch CLI User’s Guide SM TX SET(Notice): SM RX TRAP(Notice): SM TX TRAPREPRESS(Notice): SM TX GET(NodeDescription): SM TX GET(NodeInfo): SM TX GET(SwitchInfo): This command is not available unless the subnet manager is in Master mode. smShowLidMap Displays the LID-to-port GUID map for the subnet manager.
Page 125: Smshowtopology
Groups and Commands 341, Intel 12300 GUID=0x00066a00da000100 172.26.2.2 Spine 1, Ch Lid 0x0006: guid = 0x00066a00a0000248, pass = 229 Lid 0x0007: guid = 0x00066a01a0007116, pass = 341, st149 Lid 0x0008: guid = 0x0000000000000000, pass = 0 Lid 0x0028: guid = 0x0000000000000000, pass = 0 Lid 0x002a: guid = 0x0000000000000000, pass = 0 Use this command to display the LID-to-port GUID map of the subnet manager.
Page 126: Smshowvfinfo
SSH-C48Q Switch CLI User’s Guide smShowVFInfo Displays Virtual Fabric (VF) information. : The subnet manager must be running to use this command. NOTE smShowVFInfo None. smLooptestStart Starts the SM Loop Test in normal mode with the specified number of 256 byte packets. If the SM has not been previously started, this command starts the SM.
Page 127: Smloopteststop
Groups and Commands packets The number of 256 byte packets used when starting the SM Loop Test in Fast Mode. Valid values = 0 - 10. Default = 5. If the number of packets is 0, then no packets are injected. smLooptestStop Stops the SM Loop Test.
Page 128: Smlooptestinjectpackets
SSH-C48Q Switch CLI User’s Guide ....done The SM Loop Test is being stopped Use this command to stop the SM Loop Test. Returns switch LFTs back to normal. : This command will stop SM if it was started by either the...
Page 129: Smlooptestinjecteachsweep
Groups and Commands node index The node index of the switch to inject packets. -> smLooptestInjectAtNode 3 Sending 2 packets to node index 3 Packets have been injected into the SM Loop Test for node 3 -> topology_loopTest: DONE smLooptestInjectEachSweep Enables/disables packet injected on each sweep for the SM Loop Test.
Page 130: Smlooptestminislredundancy
SSH-C48Q Switch CLI User’s Guide length The loop path length for the SM Loop Test. Valid values are 2, 3 (default), and 4. -> smLooptestPathLength 3 The SM Loop Test path length has been set to 3 -> topology_loopTest: DONE...
Page 131: Smlooptestshowswitchlft
Groups and Commands -> smLooptestShowLoopPaths Node Idx: 0, Guid: 0x00066a00e3002711 Desc Intel 12200 GUID=0x00066a00e3002711 ------------------------------------------------ -------------------------- Node Node Node Path NODE GUID #Ports PATH[n:p->n:p] ---- ------ ------------------ ------ ------ --------------- 0 0x0001 0x00066a00e3002711 0x0040 0:9->0:33 0 0x0001 0x00066a00e3002711 0x0042 0:33->0:9 ------------------------------------------------ -------------------------- There are 2 total loop paths of <=4 links in...
Page 132: Smlooptestshowtopology
SSH-C48Q Switch CLI User’s Guide 0x0001 0000 0x0005 0031 0x0009 0017 0x0010 0011 0x0016 0021 0x001d 0022 0x0021 0025 0x0040 0009 0x0041 0033 0x0042 0033 0x0043 0009 smLooptestShowTopology Displays the topology for the SM Loop Test. smLooptestShowTopology None. -> smLooptestShowTopology...
Page 133 Groups and Commands 11 0000000000000000 2.5-10 10.0 00000000 17 0000000000000000 2.5-10 10.0 00000000 21 0000000000000000 2.5-10 10.0 00000000 22 0000000000000000 2.5-10 10.0 00000000 25 0000000000000000 2.5-10 10.0 00000000 31 0000000000000000 2.5-10 10.0 00000000 33 0000000000000000 2.5-10 10.0 00000000 ------------------------------------------------ ---------------------------------- st164 HFI-1 ------------------------------------------------ ----------------------------------...
Page 134 SSH-C48Q Switch CLI User’s Guide path=17 Port ---- GUID ---- (S) _VL_ __MTU__ __WIDTH__ ___SPEED____ CAP_MASK 1 00117500007eaa56 LID=0009 LMC=0000 1X/4X 2.5-10 10.0 07610868 17 17 ------------------------------------------------ ---------------------------------- st166 HFI-1 ------------------------------------------------ ---------------------------------- Node[ 3] => 00117500007ec376 ports=1, path=21 Port ---- GUID ---- (S)
Page 135: Smlooptestshowconfig
Groups and Commands Port ---- GUID ---- (S) _VL_ __MTU__ __WIDTH__ ___SPEED____ CAP_MASK 1 0002c90300033695 LID=0021 LMC=0000 1X/4X 2.5-10 10.0 02510868 25 25 ------------------------------------------------ ---------------------------------- st9 HFI-1 ------------------------------------------------ ---------------------------------- Node[ 6] => 00117500007eaa1c ports=1, path=31 Port ---- GUID ---- (S) _VL_ __MTU__ __WIDTH__...
Page 136: Log
SSH-C48Q Switch CLI User’s Guide Commands in this category are used for log file display and configuration. logShow Displays the log file that is contained in RAM. logShow None. -> logShow N|2015/10/14 02:20:14.820U: Thread "csmLogThread" (0x42358c0) MSG:NOTICE|CHASSIS:hds1swb6231|COND:#18 FRU state changed from offline to...
Page 137: Logclear
(0x6f7dce8) PrrVpd: Enhanced port 0 communication enabled N|2015/10/14 02:25:16.820U: Thread "csmLogThread" (0x42358c0) MSG:NOTICE|CHASSIS:hds1swb6231|COND:#18 FRU state changed from offline to online|FRU:Supermicro SSH-C48Q Switch Series|PN:H50565-004 logClear Deletes all entries in the log file. logClear [-noprompt] -noprompt Delete all log messages without prompting.
Page 138: Logconfigure
SSH-C48Q Switch CLI User’s Guide logConfigure Configures the log settings. logConfigure None. This is an interactive command. See Notes section for configuration selections. -> logConfigure Type Q or X to exit. Please enter the number corresponding to what you want to configure.
Page 139: Logresettodefaults
Groups and Commands Level: Debug4 [0] Level: Debug5 [0] Log device configuration changed This is an interactive command to configure active log settings, options include: 2 Preset Enable or disable each log level that may be generated on the system. The log presets act as a general filter. For example, if the Info logging level is disabled in the presets, no Info messages will be shown on any output device, regardless of the Info log setting for a device.
Page 140: Logsyslogconfig
SSH-C48Q Switch CLI User’s Guide -noprompt Restore the defaults without prompting. -> logResetToDefaults Log configuration has been reset logSyslogConfig Configures the syslog host IP address and port. logSyslogConfig [-h hostname or ip_address] [-p port] [-f facility] [-m mode] -h hostname or ip_address Sets the syslog server hostname or IP address in dotted decimal format (xxx.xxx.xxx.xxx).
Page 141 Groups and Commands daemon auth syslog news uucp cron authpriv audit alert...
Page 142 SSH-C48Q Switch CLI User’s Guide clock local0 local1 local2 local3 local4 local5 local6 local7 -m mode Whether syslog is to be put into a special OEM mode. Values are 0 or 1. -> logSyslogConfig -h 172.26.0.202 Successfully configured the syslog host Additional configuration may be necessary to fully configure the log system.
Page 143: Logshowconfig
Displays the current log configuration settings. logShowConfig None. -> logshowconfig Log Configuration for: Supermicro SSH-C48Q Switch Series ------------------------------ Configurable devices index : name : |D|F|E|A|W|P|C|I|P|N|1|2|3|4|5| ------------------------------------------------ ----...
Page 144: Logsyslogtest
SSH-C48Q Switch CLI User’s Guide : Debug1 : Disabled : Debug2 : Disabled : Debug3 : Disabled : Debug4 : Disabled : Debug5 : Disabled logSyslogTest Tests the Syslog configuration. logSyslogTest severityType severityType Options include: -e Send Error severity CSM test message to Syslog.
Page 145: Interconnect Switch Management (Ism)
Groups and Commands Interconnect Switch Management (ISM) Commands in this category are used for port configuration and statistics. ismPortStats Displays link error information associated with each switch port. ismPortStats does not return meaningful information until three things have occurred: 1) The SM has configured a LID for the switches in the chassis. 2) The chassis software has discovered that the switches have been assigned a LID and has polled for port statistic informa- tion.
Page 146 SSH-C48Q Switch CLI User’s Guide -> ismPortStats Name Cable01 Cable02 Cable03 PhysState PortState LinkWidth LinkSpeed 25Gbps 25Gbps 25Gbps LinkDowned InPKeyViol OutPKeyViol Continue? [Y] y Name Cable04 Cable05 Cable06 PhysState PortState LinkWidth LinkSpeed 25Gbps 25Gbps 25Gbps LinkDowned InPKeyViol OutPKeyViol Continue? [Y] n...
Page 147: Ismportcounters
Groups and Commands ismPortCounters Displays a table comparision of transmit, receive, and error counters corresponding to each port of the switch. Optionally displays link error statistics associated with each port of the switch. : This command is best displayed with a terminal width of at NOTE least 120 columns.
Page 148 SSH-C48Q Switch CLI User’s Guide | Packets Words | Errors | Speed Width Potential Cable01 3951205094 2800544271045 | 4154378847 3019711679236 | 25Gbps 100% Cable02 8993888342 5766797571908 | 9315042983 5518255518847 | 25Gbps 100% Cable03 6868061425 4318743689062 | 8561944708 5264142620113 | 25Gbps...
Page 149 Groups and Commands Cable16 0 | 0.0Gbps 0X Cable17 0 | 0.0Gbps 0X Cable18 0 | 0.0Gbps 0X Cable19 0 | 0.0Gbps 0X Cable20 0 | 0.0Gbps 0X Cable21 0 | 0.0Gbps 0X Cable22 0 | 0.0Gbps 0X Continue? [Y] n The system prompts to continue the output after each group of ports are displayed.
Page 150: Ismlinearfwdb
SSH-C48Q Switch CLI User’s Guide ismLinearFwdb Displays the entries in the linear forwarding table. LIDs and a corresponding port are shown. A packet addressed to a LID is forwarded to the corresponding port listed in the displayed table. ismLinearFwdb [switch] switch Switch number.
Page 151 Groups and Commands c001 0 (EnhPrt0) 1 (Cable01) 2 (Cable02) 3 (Cable03) 4 (Cable04) 5 (Cable05) 6 (Cable06) 7 (Cable07) 8 (Cable08) 9 (Cable09) 10 (Cable10) 11 (Cable11) 12 (Cable12) 13 (Cable13) 14 (Cable14) 15 (Cable15) 16 (Cable16) 17 (Cable17) 18 (Cable18) 19 (Cable19) 20 (Cable20) 21 (Cable21) 22 (Cable22) 23 (Cable23) 24 (Cable24) 25 (Cable25) 26 (Cable26) 27 (Cable27) 28...
Page 152 SSH-C48Q Switch CLI User’s Guide 25 (Cable25) 26 (Cable26) 27 (Cable27) 28 (Cable28) 29 (Cable29) 30 (Cable30) 31 (Cable31) 32 (Cable32) 33 (Cable33) 34 (Cable34) 35 (Cable35) 36 (Cable36) c021 0 (EnhPrt0) 1 (Cable01) 2 (Cable02) 3 (Cable03) 4 (Cable04) 5 (Cable05) 6 (Cable06)
Page 153: Ismswitchinfolid
Groups and Commands ismSwitchInfoLid Displays SMA switch information for a specific switch chip. ismSwitchInfoLid switch switch Switch index (number of a Leaf or Spine switch or of the local switch). ismPortStatLid Displays port statistics for a specific LID. ismPortStatLid lid port IBTA local identifier (LID of the Leaf or Spine switch or the local switch).
Page 154: Ismnodeinfolid
SSH-C48Q Switch CLI User’s Guide Port number (defaults to 0). ismNodeInfoLid Displays SMA node information for a specific LID. ismNodeInfoLid lid IBTA local identifier (LID of the Leaf or Spine switch or the local switch). ismPortSetWidth Displays or modifies the LinkWidth.Supported setting for a port.
Page 155 Groups and Commands The option portName is case-sensitive. If portName contains spaces, it must be bounded by quotation marks. For example, ismPortSetWidth "Cable 1", 1. linkWidth Options include: 2X_1X 3X_1X 3X_2X 3X_2X_1X 4X_1X...
Page 156 SSH-C48Q Switch CLI User’s Guide 4X_2X 4X_2X_1X 4X_3X 4X_3X_1X 4X_3X_2X 4X_3X_2X_1X -bounce Brings the active links down and back up if a new value is set. Calling this function with the -bounce option disruptively brings active links down and back up so the links use the new setting imme- diately.
Page 157: Ismchassissetwidth
Groups and Commands ismChassisSetWidth Displays or modifies the LinkWidth.Supported setting for all chassis ports. LinkWidth.Supported should be a subset of LinkWidthDowngrade.Supported for proper port operation. ismChassisSetWidth [linkWidth] [-bounce] [-verbose] linkWidth Options include: 2X_1X 3X_1X 3X_2X 3X_2X_1X...
Page 158 SSH-C48Q Switch CLI User’s Guide 4X_1X 4X_2X 4X_2X_1X 4X_3X 4X_3X_1X 4X_3X_2X 4X_3X_2X_1X -bounce Brings the active links down and back up if a new value is set. Calling this function with the -bounce option disruptively brings active links down and back up so the links use the new setting imme- diately.
Page 159: Ismmodulesetwidth
Groups and Commands Cable03 link width supported: 2X If no parameter is entered, the current settings are displayed. ismModuleSetWidth Displays or modifies the LinkWidth.Supported setting for each of the module ports. LinkWidth.Supported should be a subset of LinkWidthDowngrade.Supported for proper port operation.
Page 160 SSH-C48Q Switch CLI User’s Guide 3X_2X 3X_2X_1X 4X_1X 4X_2X 4X_2X_1X 4X_3X 4X_3X_1X 4X_3X_2X 4X_3X_2X_1X -bounce Brings the active links down and back up if a new value is set.
Page 161: Ismislsetwidth
Displays or modifies the LinkWidth.Supported setting for each of the inter-switch-link (ISL) ports. LinkWidth.Supported should be a subset of LinkWidthDowngrade.Supported for proper port operation. : This command is only available on Supermicro SSH-C48Q NOTE Switch Family. ismIslSetWidth [linkWidth] [-bounce] [-verbose] linkWidth...
Page 162 SSH-C48Q Switch CLI User’s Guide 3X_2X 3X_2X_1X 4X_1X 4X_2X 4X_2X_1X 4X_3X 4X_3X_1X 4X_3X_2X 4X_3X_2X_1X -bounce Brings the active links down and back up if a new value is set.
Page 163: Ismportsetlwds
Groups and Commands Calling this function with the -bounce option disruptively brings active links down and back up so the links use the new setting imme- diately. Otherwise, the new setting is used the next time links retrain. -verbose Verbose output mode. If no parameter is entered, the current settings are displayed.
Page 164 SSH-C48Q Switch CLI User’s Guide If portName contains spaces, it must be bounded by quotation marks. For example, ismPortSetWidth "Cable 1", 1. LinkWidthDownGradeSupported Options include: 2X_1X 3X_1X 3X_2X 3X_2X_1X 4X_1X 4X_2X...
Page 165: Ismchassissetlwds
Groups and Commands 4X_2X_1X 4X_3X 4X_3X_1X 4X_3X_2X 4X_3X_2X_1X -bounce Brings the active links down and back up if a new value is set. Calling this function with the -bounce option disruptively brings active links down and back up so the links use the new setting imme- diately.
Page 166 SSH-C48Q Switch CLI User’s Guide chassis ports. This setting becomes effective on the next port bounce. ismChassisSetLWDS [LinkWidthDownGradeSupported] [-bounce] [-verbose] LinkWidthDownGradeSupported Options include: 2X_1X 3X_1X 3X_2X 3X_2X_1X 4X_1X...
Page 167 Groups and Commands 4X_2X 4X_2X_1X 4X_3X 4X_3X_1X 4X_3X_2X 4X_3X_2X_1X -bounce Brings the active links down and back up if a new value is set. Calling this function with the -bounce option disruptively brings active links down and back up so the links use the new setting imme- diately.
Page 168: Ismmodulesetlwds
SSH-C48Q Switch CLI User’s Guide ismModuleSetLWDS Displays or modifies the LinkWidthDowngrade.Supported (LWDS) setting for each of the module ports. This setting becomes effective on the next port bounce. ® : This command is only available on Intel Omni-Path Host NOTE Fabric Interface.
Page 169 Groups and Commands 4X_1X 4X_2X 4X_2X_1X 4X_3X 4X_3X_1X 4X_3X_2X 4X_3X_2X_1X -bounce Brings the active links down and back up if a new value is set. Calling this function with the -bounce option disruptively brings active links down and back up so the links use the new setting imme- diately.
Page 170: Ismislsetlwds
Displays or modifies the LinkWidthDowngrade.Supported (LWDS) setting for each of the inter-switch-link (ISL) ports. This setting becomes effective on the next port bounce. : This command is only available on Supermicro SSH-C48Q NOTE Switch Family. ismIslSetLWDS [LinkWidthDownGradeSupported] [-bounce] [-verbose] LinkWidthDownGradeSupported...
Page 171 Groups and Commands 3X_2X 3X_2X_1X 4X_1X 4X_2X 4X_2X_1X 4X_3X 4X_3X_1X 4X_3X_2X 4X_3X_2X_1X -bounce Brings the active links down and back up if a new value is set. Calling this function with the -bounce option disruptively brings active links down and back up so the links use the new setting imme- diately.
Page 172: Ismportsetfmenabled
SSH-C48Q Switch CLI User’s Guide -verbose Verbose output mode. If no parameter is entered, the current settings are displayed. ismPortSetFmEnabled Displays or modifies the FM ENABLED setting for a port. ismPortSetFmEnabled portName [fmEnabled] [-bounce] [-verbose] portName Valid entries for portName depend on the chassis type. Use the command ismPortStats to see the current portName definitions.
Page 173: Ismchassissetfmenabled
Groups and Commands Disabled. Enabled. -bounce Brings the active links down and back up if a new value is set. Calling this function with the -bounce option disruptively brings active links down and back up so the links use the new setting imme- diately.
Page 174: Ismportsetcrcmode
SSH-C48Q Switch CLI User’s Guide -bounce Brings the active links down and back up if a new value is set. Calling this function with the -bounce option disruptively brings active links down and back up so the links use the new setting imme- diately.
Page 175 Groups and Commands On director class systems, an example interswitch link name is: S105AP18L104AP36, that is, Spine 105 chip A port 18. crcMode Options include: 14b_or_16b 48b_or_16b 48b_or_14b_or_16b per_lane_or_16b per_lane_or_14b_or_16b per_lane_or_48b_or_16b per_lane_or_48b_or_14b_or_16b -bounce Brings the active links down and back up if a new value is set.
Page 176: Ismchassissetcrcmode
SSH-C48Q Switch CLI User’s Guide Calling this function with the -bounce option disruptively brings active links down and back up so the links use the new setting imme- diately. Otherwise, the new setting is used the next time links retrain.
Page 177 Groups and Commands per_lane_or_16b per_lane_or_14b_or_16b per_lane_or_48b_or_16b per_lane_or_48b_or_14b_or_16b -bounce Brings the active links down and back up if a new value is set. Calling this function with the -bounce option disruptively brings active links down and back up so the links use the new setting imme- diately.
Page 178: Ismmodulesetcrcmode
SSH-C48Q Switch CLI User’s Guide ismModuleSetCrcMode Displays or modifies the cyclic redundancy check (CRC) mode setting for all module ports. ® : This command is only available on Intel Omni-Path Host NOTE Fabric Interface. ismModuleSetCrcMode [crcMode] [-bounce] crcMode Options include:...
Page 179: Ismislsetcrcmode
If no parameter is entered, the current settings are displayed. ismIslSetCrcMode Displays or modifies the cyclic redundancy check (CRC) mode setting for all inter-switch-link ports. : This command is only available on Supermicro SSH-C48Q NOTE Switch Family. ismIslSetCrcMode [crcMode] [-bounce] [-verbose] crcMode Options include:...
Page 180: Ismportsetvcu
SSH-C48Q Switch CLI User’s Guide 48b_or_14b_or_16b per_lane_or_16b per_lane_or_14b_or_16b per_lane_or_48b_or_16b per_lane_or_48b_or_14b_or_16b -bounce Brings the active links down and back up if a new value is set. Calling this function with the -bounce option disruptively brings active links down and back up so the links use the new setting imme- diately.
Page 181 Groups and Commands portName Valid entries for portName depend on the chassis type. Use the command ismPortStats to see the current portName definitions. On edge systems, an example cable portName is: Cable01, that is, Cable Port 1. On director class systems, an example cable portName is: L101P01, that is, Leaf 101 Port 1.
Page 182: Ismchassissetvcu
SSH-C48Q Switch CLI User’s Guide ismChassisSetVCU Displays or modifies the VCU (Virtual lane Credit Units) setting for all chassis ports. ismChassisSetVCU [vcu] [-bounce] [-verbose] Valid options range from 0 to 7 inclusive. Default = 0. -bounce Brings the active links down and back up if a new value is set.
Page 183: Ismislsetvcu
Displays or modifies the VCU (Virtual lane Credit Units) setting for all inter-switch-link ports. : This command is only available on Supermicro SSH-C48Q NOTE Switch Family. ismIslSetVCU [vcu] [-bounce] [-verbose] Valid options range from 0 to 7 inclusive. Default = 0.
Page 184: Ismchassissetmtu
SSH-C48Q Switch CLI User’s Guide -verbose Verbose output mode. If no parameter is entered, the current settings are displayed. ismChassisSetMtu Displays, sets, and unsets the chassis maximum packet MTU Capability and VL Capability for all ports. ismChassisSetMtu [mtuCap [vlCap]] [-bounce]...
Page 185 Groups and Commands VL0-VL1 VL0-VL2 VL0-VL3 VL0-VL4 VL0-VL5 VL0-VL6 VL0-VL7 -bounce Brings the active links down and back up if a new value is set. Calling this function with the -bounce option disruptively brings active links down and back up so the links use the new setting imme- diately.
Page 186: Ismmodulesetmtu
SSH-C48Q Switch CLI User’s Guide ismModuleSetMtu Displays, sets, and unsets the chassis maximum packet MTU Capability and VL Capability for all module ports. ® : This command is only available on Intel Omni-Path Host NOTE Fabric Interface. ismModuleSetMtu [mtuCap [vlCap]] [-bounce]...
Page 187 Groups and Commands VL0-VL2 VL0-VL3 VL0-VL4 VL0-VL5 VL0-VL6 VL0-VL7 -bounce Brings the active links down and back up if a new value is set. Calling this function with the -bounce option disruptively brings active links down and back up so the links use the new setting imme- diately.
Page 188: Ismportenable
SSH-C48Q Switch CLI User’s Guide ismPortEnable Enables a port. ismPortEnable portName [-verbose] portName Valid entries for portName depend on the chassis type. Use the command ismPortStats to see the current portName definitions. On edge systems, an example cable portName is: Cable01, that is, Cable Port 1.
Page 189: Ismmodulesetenable
Groups and Commands enable Options include: Disable Enable -> ismChassisSetEnable Cable01 is ENABLED Cable02 is ENABLED Cable03 is ENABLED If no value is entered, the current setting is displayed. When disabling ports, only cable ports are disabled. ismModuleSetEnable Displays or modifies the port enable setting for each port in the module.
Page 190: Ismportdisable
SSH-C48Q Switch CLI User’s Guide Enable If no value is entered, the current setting is displayed. ismPortDisable Disables a port. ismPortDisable portName [-verbose] portName Valid entries for portName depend on the chassis type. Use the command ismPortStats to see the current portName definitions.
Page 191: Ismchassissetspeed
Groups and Commands ismChassisSetSpeed Displays or modifies the LinkSpeed.Supported setting for all ports in the chassis. ismChassisSetSpeed [linkSpeed] [-bounce] linkSpeed Options include: 25 Gbps -bounce Brings the active links down and back up if a new value is set. Calling this function with the -bounce option disruptively brings active links down and back up so the links use the new setting imme- diately.
Page 192: Ismislsetspeed
Calling this function without an option displays the current settings. ismIslSetSpeed Displays or modifies the LinkSpeed.Supported setting for all inter-switch ports in the chassis. : This command is only available on Supermicro SSH-C48Q NOTE Switch Family. ismIslSetSpeed [linkSpeed] [-bounce] linkSpeed Options include:...
Page 193: Ismportsetspeed
Groups and Commands -bounce Brings the active links down and back up if a new value is set. Calling this function with the -bounce option disruptively brings active links down and back up so the links use the new setting imme- diately.
Page 194: Ismportsetbeacon
SSH-C48Q Switch CLI User’s Guide linkSpeed Options include: 25 Gbps -bounce Brings the active links down and back up if a new value is set. Calling this function with the -bounce option disruptively brings active links down and back up so the links use the new setting imme- diately.
Page 195: Ismportqsfpinfo
Groups and Commands S105AP18L104AP36, that is, Spine 105 chip A port 18. The option portName is case-sensitive. If portName contains spaces, it must be bounded by quotation marks. For example, ismPortSetWidth "Cable 1", 1. {0 | 1} If no value is entered, the current setting is displayed. Options include: -verbose Verbose output mode.
Page 196 Displays info for all installed QSFPs on the specified leaf. LxxxPyy Displays info for QSFP installed on the specified leaf and port. Cableyy Displays info for QSFP installed on the specified port. : This option is only available on Supermicro SSH-C48Q NOTE Switch Family models. -verbose Verbose output mode.
Page 197 Groups and Commands Vendor S/N : CN1449FA102L0027 Power Class 1.5W max Date Code : 12-04-2014 Code Xmitter Tech : Copper Cable unequalized Cable Length : 1 meter Attenuation : 0dB @ 2.5GHz 5dB @ 5.0GHz Cable End : Not Indicated ->...
Page 198: Ismchassisbounce
: This command is only available on Intel Omni-Path Host NOTE Fabric Interface. ismModuleBounce [-verbose] -verbose Verbose output mode. ismIslBounce Bounces all enabled inter-switch-link ports in the chassis. : This command is only available on Supermicro SSH-C48Q NOTE Switch Family. ismIslBounce [-verbose] -verbose Verbose output mode.
Page 199: Ismportbounce
Groups and Commands ismPortBounce Bounces enabled ports. ismPortBounce portName [-verbose] portName Valid entries for portName depend on the chassis type. Use the command ismPortStats to see the current portName definitions. On edge systems, an example cable portName is: Cable01, that is, Cable Port 1. On director class systems, an example cable portName is: L101P01, that is, Leaf 101 Port 1.
Page 200: Ismshowstatedump
/firmware/prr*.gz. Copy these files using sftp run from an external host. After the files have been copied externally, Supermicro recommends you enter reboot now all to resume normal operation. You must do the file copy before the reboot, because the state dump files in the local RAM file system are not persistent across the reboot.
Page 201: Ismshowarconfig
Groups and Commands ismShowArConfig Displays adaptive routing info for a specific switch chip or entire chassis. ismShowArConfig [switch] switch Switch index. -> ismShowArConfig Switch Name | Ena | Pau | LRO | Algo Freq | Thresh | Events -------------------- | --- | --- | --- | ------ | ---- | ------ | ---------- Switch 1 ismShowArMoves...
Page 202: Time Management
SSH-C48Q Switch CLI User’s Guide Time Management Commands in this category are used for retrieving and setting the current system time, setting the time zone, and setting daylight saving time parameters. time Configures the time on the device. time [-S ipaddr] [-T hhmmss[mmddyyyy]] -S ipaddr Sets the NTP Server IP address.
Page 203: Timezoneconf
Groups and Commands If no value is entered, the current system time is displayed. timeZoneConf Displays or configures the time zone setting. timeZoneConf [offset] offset The time offset in relation to Greenwich Mean Time (GMT). The offset parameter specifies a time zone the system should use when setting the time.
Page 204: Timedstconf
SSH-C48Q Switch CLI User’s Guide timeDSTConf Configures and displays the Daylight Saving Time settings. timeDSTConf [sw sd sm ew ed em] Start which, valid options include: Start day, valid options include: Sunday Monday...
Page 205 Groups and Commands Tuesday Wednesday Thursday Friday Saturday Start month, valid options include: March April June July...
Page 206 SSH-C48Q Switch CLI User’s Guide August September October November End which, valid options include: End day, valid options include: Sunday...
Page 207 Groups and Commands Monday Tuesday Wednesday Thursday Friday Saturday End month, valid options include: March April June...
Page 208: Timentptimeout
SSH-C48Q Switch CLI User’s Guide July August September October November -> timeDSTConf 2 1 3 1 1 11 Timezone offset successfully configured Current DST = Start: 2'nd Sunday of March End: 1'st Sunday of November timeNtpTimeout Displays or sets the number of seconds to wait for a NTP response.
Page 209: Timentprefreshtime
Groups and Commands NTP timeout is the amount of time (in seconds) for the system to wait for a response from the NTP server. This setting can be configured using the same command with the new timeout value (in whole seconds) as the only argument.
Page 210: Snmp
SSH-C48Q Switch CLI User’s Guide SNMP Commands in this category are used for configuring trap destinations and SNMP security parameters. snmpCommunityConf Configures and displays the SNMP community strings. snmpCommunityConf [-r readonly_comm_str] [-w read_write_comm_str] -r readonly_comm_str A read-only community string. -w read_write_comm_str A read/write community string.
Page 211 Groups and Commands timeout] [-r retry_count] [-l tag_list] [-v parameters] [-s storage_type] [-i status] show Displays the contents of the snmpTargetAddrTable. Adds a row to the snmpTargetAddrTable. edit Modifies an existing row in the snmpTargetAddrTable. delete Removes an existing row of the snmpTargetAddrTable. -n name Name.
Page 212 SSH-C48Q Switch CLI User’s Guide Tag list. Indicates the traps and information that is sent. -v parameters Parameters. This maps to an entry in the snmpTargetAddrTable. -s storage_type Storage type. Determines whether the entry is saved in flash memory. Options include: volatile or nonVolatile (string).
Page 213: Snmptargetparams
Groups and Commands If no value is entered, the current settings are displayed. The output is in the form: mib : mib_object : table_index : value For more details on the snmpTargetAddrTable, see SNMP-TARGET-MIB, RFC 2573. snmpTargetParams Displays the snmpTargetParamsTable entries. snmpTargetParams [show] show Displays the contents of the snmpTargetParamsTable.
Page 214: Snmpnotifyprofile
SSH-C48Q Switch CLI User’s Guide snmpNotifyProfile Displays the snmpNotifyFilterProfileTable entries. snmpNotifyProfile [show] show Displays the contents of the snmpNotifyFilterProfileTable. -> snmpNotifyProfile rfc2573n:snmpNotifyFilterProfileName: v1 params : v1 params rfc2573n:snmpNotifyFilterProfileName: v2 params : v2 params rfc2573n:snmpNotifyFilterProfileName: v3 params : v3 params rfc2573n:snmpNotifyFilterProfileStorType: v1...
Page 215: Snmpnotifyfilter
Groups and Commands snmpNotifyFilter Displays the snmpNotifyFilterTable entries. snmpNotifyFilter [show] show Displays the contents of the snmpNotifyFilterTable. -> snmpNotifyFilter rfc2573n:snmpNotifyFilterMask: v1 params : 0 rfc2573n:snmpNotifyFilterMask: v2 params : 0 rfc2573n:snmpNotifyFilterMask: v3 params : 0 rfc2573n:snmpNotifyFilterType: v1 params : 1 rfc2573n:snmpNotifyFilterType: v2 params : 1 rfc2573n:snmpNotifyFilterType: v3 params : 1...
Page 216: Snmpsystem
SSH-C48Q Switch CLI User’s Guide rfc2573n:snmpNotifyTag: tms : tmscom rfc2573n:snmpNotifyType: switch : 1 If no value is entered, the current settings are displayed. The output is in the form: mib : mib_object : table_index : value For more details on the snmpNotifyTable, see SNMP-NOTIFICATION-MIB, RFC-2573.
Page 217: Snmpusrsec
Groups and Commands -> snmpSystem show rfc1907:sysDescr: þ : 20.28.4D.61.73.74.65.72.29 rfc1907:sysObjectID: : 1.3.6.1.4.1.10222.7.1.2 rfc1907:sysUpTime: : 1 Day(s), 23 Hour(s), 34 Minute(s), 47 Second(s) rfc1907:sysContact: þ : {no value} rfc1907:sysName: þ : Intel 12800-040-254 rfc1907:sysLocation: þ : Main Chassis Unit, Slot rfc1907:sysServices: : 79 If no value is entered, the current setting is...
Page 218 SSH-C48Q Switch CLI User’s Guide -a algo Authentication algorithm and key. Options include: MD5 key MD5 authentication algorithm is used. SHA key SHA authentication algorithm is used. NONE No authentication algorithm is used. -> snmpUsrSec User : initialmd5 Auth : MD5...
Page 219: Captureinfo
Groups and Commands CaptureInfo Commands in this category are used by support personnel for analysis and debugging. capture Displays information for this device. capture None. The output of this command is intended for support personnel to capture switch configuration, logs, and other pertinent data.
Page 220: Capturefw
SSH-C48Q Switch CLI User’s Guide captureFw Displays firmware information for this device. captureFw None. The output of this command is intended for support personnel to capture switch configuration, logs, and other pertinent data. captureSm Displays Subnet Management information for this device.
Page 221: Capturechassis
Groups and Commands captureChassis Displays chassis information for this device. captureChassis None. The output of this command is intended for support personnel to capture switch configuration, logs, and other pertinent data. captureNetwork Displays network information for this device. captureNetwork None. The output of this command is intended for support personnel to capture switch configuration, logs, and other pertinent data.
Page 222: Capturemisc
SSH-C48Q Switch CLI User’s Guide captureMisc Displays miscellaneous information for this device. captureMisc None. The output of this command is intended for support personnel to capture switch configuration, logs, and other pertinent data. captureSnmp Displays SNMP information for this device.
Page 223 Disclaimer The products sold by Supermicro are not intended for and will not be used in life support systems, medical equipment, nuclear facilities or systems, aircraft, aircraft devices, aircraft/emergency communication devices or other critical systems whose failure to perform be reasonably expected to result in significant injury or loss of life or catastrophic property damage.
