Microwave Oven
INSTRUCTION MANUAL
MODEL: SMW730
Read these instructions carefully before using your
microwave oven.Keep these instructions in a safe place for
future reference. If you follow the instructions, your oven will
provide you with many years of good service.
SAVE THESE INSTRUCTIONS CAREFULLY
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Sunbeam SMW730
Summary of Contents for Sunbeam SMW730
-
Page 1: Microwave Oven
Microwave Oven INSTRUCTION MANUAL MODEL: SMW730 Read these instructions carefully before using your microwave oven.Keep these instructions in a safe place for future reference. If you follow the instructions, your oven will provide you with many years of good service. -
Page 2: Table Of Contents
TABLE OF CONTENTS SAFETY Proper and Safe Use of Your Oven------------------------------ 3 Important Safety Instructions-------------------------------------- 4 Grounding Installation ---------------------------------------------- 5 Utensils SETTING UP YOUR OVEN Names of Oven Parts and Accessories----------------------- 7 Turntable Installation---------------------------------------------- 8 Installation----------------------------------------------------------- 8 OPERATION Control Panel and Features------------------------------------ 9 Operation Instructions-------------------------------------------- 10 MAINTENANCE Troubleshooting ------------------------------------------------------ 17... -
Page 3: Microwave Energy
Power Source: Power Consumption: Maximum Output: Oven Capacity: Turntable Diameter: External Dimensions (LxWxH): Net weight: MICROWAVE ENERGY SMW730 120V ~ 60Hz 1200 W 800 W 0.7 Cu.ft. 245 mm 461 mm X 365 mm X 280 mm Approx. 12.5 Kg... -
Page 4: Safety
1. The oven must be on a leveled surface. 2. The turntable and turntable roller rest must be in the oven during cooking. Place the cookware gently on the turntable and handle it carefully to avoid possible breakage. 3. Incorrect use of browning dish may cause the turntable to break. 4. -
Page 5: Important Safety Instructions
Important Safety Instructions W A R N I N G — persons, or exposure to excessive microwave oven energy when using your appliance, follow basic precautions, including the following: 1. Read all instructions before using the appliance. 2. Read and follow the specific:" PRECAU- TIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY". -
Page 6: To Reduce The Risk Of Injury To Persons: Grounding Installation
18. Liquids, such as water, coffee, or tea are able to be overheated beyond the boiling point without appearing to be boiling. Visible bubbling or boiling when the container is removed from the microwave oven is not always present. This could result in very hot liquids suddenly boiling over when the container is disturbed or a spoon or other utensil is inserted into the liquid. -
Page 7: Utensils
CAUTION Personal Injury Hazard Tightly-closed utensils could explode. Closed containers are opened and plastic pouches pierced before cooking. See below and the next page for further instructions “ Materials you can use in microwave oven or materials to be avoided in microwave oven.” There may be certain non-metallic utensils that are not safe to use for microwaving. -
Page 8: Materials To Be Avoided In Microwave Oven
Materials to be avoided in microwave oven Utensils Remarks Aluminum tray May cause arcing. Transfer food into microwave-safe dish. Food carton with May cause arcing. Transfer food into microwave-safe dish. metal handle Metal or metal- Metal shields the food from microwave energy. Metal trim may cause trimmed utensils arcing. -
Page 9: Turntable Installation
TURNTABLE INSTALLATION Hub(underside) Glass tray Turntable shaft Turntable ring assembly Installation Remove all packing material and accessories. Examine the oven for any damage such as dents or broken door. Do not install if oven is damaged. Installation Select a level surface that provide enough open space for the intake and/or outlet vents. -
Page 10: Control Panel And Features
Control Panel and Features Display Window OPERATION (1). (2). (3). (4). (5). (6). (7). (8). (9). (10) (10). Control Panel 1 POPCORN 2 BABY MILK 3 POTATO 4 DINNER PLATE 5 POWER 6 AM/PM 7 DEFROST W.T. 8 TIME DEFROST 9 CLOCK:setting time 10 STOP: 11 PIZZA... -
Page 11: Operation Instructions
Operation Instructions 1. Power Level Ten power levels are available, life cycle T=22 seeds Level Power 100% Remarks: When a power level between 10-8 is chosen, the high level indicator lights up and will flash when in operation. When a power level between 7- 1 is chosen, the low level indicator lights up and will flash when in operation. - Page 12 (4) Press numerical pads to input the second cooking time, the maximum cooking time is 99 minutes and 99 seconds. (5) Press " START " to start cooking, the remaining cooking time will be displayed; ":","MICRO", "POWER" indicators will be flashing. (6) One "beep"...
- Page 13 . POPCORN Do not use this instant key if your popcorn bag size is less than 1.75 Oz (about 50 gram). Press "POPCORN" twice , "MICRO" appears in the display. Times ( Press " Popcorn ") Once Twice ** The cooking time for popcorn is for reference only . The setting can be adjusted according to various weights and types to meet individual taste needs.After cooking time is set.
-
Page 14: Dinner Plate
. BEVERAGE a) Press "BEVERAGE " repeatedly until the number you wish appears in the display, "MICRO" " AUTO COOK " • "ML" lights. • You can reheat 1~3 cups of beverage each time (approximate 250 gram). For example, press "Beverage" twice, "... -
Page 15: Fresh Vegetable
FRESH VEGETABLE a) Press "FRESH VEGETABLE" repeatedly until the number you wish appears in the display, "MICRO" "1" SET: 6.0 oz food (approximate 170 gram) "2" SET: 12.0 oz food (approximate 340 gram) "3" SET: 18.0 oz food (approximate 510 gram) For example, press "FRESH VEGETABLE"... - Page 16 process of pre-setting, memory cooking programs is set at the same time, only cooking programs can be recorded and the pre-set time will not be recorded. 17. Pre-set Function (1) Set a certain cooking procedure(one block or two),the setting method and display is same as relevant cooking procedure.(Defrosting is beyond pre-set cooking).
- Page 17 20. Cooking End Reminding Function When cook ends, there will be 5 "beep" to remind the completion. 21. Other Specifications (1) In waiting state , LED will display clock and ":" will not flash. (2) In function setting state, LED will display the related setting. (3) In operation and suspending state, LED will display the residual cooking time.
-
Page 18: Troubleshooting
Trouble shooting Microwave oven interfering TV reception Dim oven light Steam accumulating on door, hot air out of vents Oven started accidentally with no food in . Radio and TV reception may be interfered when microwave oven is in operation. It is similar to the interference of small electrical appliances , like mixer , vacuum cleaner,and electric fan. -
Page 19: Cleaning
© 2005 Sunbeam Products, Inc. All rights reserved. Sunbeam® is a registered trademark of Sunbeam Products, Inc. used under license. Manufactured for Curtis International Ltd. 315 Attwell Drive, Etobicoke, Ontario M9W 5C1, Canada For service call: 1-800-968-9853...
