Cluster Platform 4500/3
User's Guide
™
A product from the SunTone
Platforms portfolio
Sun Microsystems, Inc.
901 San Antonio Road
Palo Alto, CA 94303-4900 U.S.A.
650-960-1300
Part No. 816-0445-11
July 2001, Revision A
Send comments about this document to: docfeedback@sun.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 4500/3 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sun Microsystems 4500/3

Summary of Contents for Sun Microsystems 4500/3

  • Page 1 Cluster Platform 4500/3 User’s Guide ™ A product from the SunTone Platforms portfolio Sun Microsystems, Inc. 901 San Antonio Road Palo Alto, CA 94303-4900 U.S.A. 650-960-1300 Part No. 816-0445-11 July 2001, Revision A Send comments about this document to: docfeedback@sun.com...
  • Page 2 Sun, Sun Microsystems, le logo Sun, AnswerBook2, docs.sun.com, Solstice DiskSuite, OpenBoot, Sun Enterprise, BluePrints, JumpStart, Sun StorEdge, Netra, Solaris, et SunTone sont des marques de fabrique ou des marques déposées, ou marques de service, de Sun Microsystems, Inc. aux Etats-Unis et dans d’autres pays. Toutes les marques SPARC sont utilisées sous licence et sont des marques de fabrique ou des marques déposées de SPARC International, Inc.

  • Page 3: Table Of Contents

    Tools for Reading Online Documentation 1 Netscape Navigator Browser 2 AnswerBook2 Server 2 Adobe Acrobat Reader 2 The man Command 2 Solaris Documentation 3 The Cluster Platform 4500/3 System 5 Your Integrated System 6 Task Overview 6 Hardware Components 8...
  • Page 4 To Access the Terminal Concentrator from a Laptop 47 Console Output for the Automatic Software Install on the Cluster Nodes 51 Connections Within the Cluster Platform 4500/3 65 Troubleshooting the Cluster Platform 4500/3 Installation 69 Cluster Platform 4500/3 User’s Guide • July 2001...
  • Page 5 Figures Ethernet Address on the Disk Array Pull Tab 7 FIGURE 2-1 Cluster Platforms I/O Board Placement 10 FIGURE 2-2 Cluster Platform Interconnections and NAFO 12 FIGURE 2-3 Cluster Platform Rack Placement 14 FIGURE 2-4 Cluster Platform Internal Cabling 17 FIGURE 2-5 Cluster Control Panel Window 39 FIGURE 2-6...
  • Page 6 Cluster Platform 4500/3 User’s Guide • July 2001...
  • Page 7 Tables Ethernet IP Address Worksheet 8 TABLE 2-1 Cluster Platform Rack Components 15 TABLE 2-2 Power and Heat Requirements for Cluster Platforms 15 TABLE 2-3 Cluster Platform Cables 16 TABLE 2-4 Boot Disk to Server Connections 65 TABLE C-1 Disk Array to Hub Connections 66 TABLE C-2 FC-AL Hub to Server Connections 66 TABLE C-3...
  • Page 8 Cluster Platform 4500/3 User’s Guide • July 2001...

  • Page 9: Preface

    Preface Cluster Platform 4500/3 provides self-sustained building blocks integrated through Sun Cluster technology to support highly available applications. Related Documentation Application Title Installation Sun Enterprise 6500/5500/4500 Systems Installation Guide Sun StorEdge T3 Disk Tray Installation, Operation, and Service Manual Sun StorEdge Component Manager 2.1...

  • Page 10: Typographic Conventions

    Release Notes Typographic Conventions Typeface or Symbol AaBbCc123 AaBbCc123 AaBbCc123 Cluster Platform 4500/3 User’s Guide • July 2001 Title Sun StorEdge Component Manager 2.1 Release Notes Sun StorEdge Expansion Cabinet Installation and Service Manual Sun StorEdge Expansion Cabinet Installation and Service Manual...

  • Page 11: Shell Prompts

    A complete set of Solaris documentation and many other titles are located at: http://docs.sun.com Ordering Sun Documentation Fatbrain.com, an Internet professional bookstore, stocks select product documentation from Sun Microsystems, Inc. For a list of documents and how to order them, visit the Sun Documentation Center on Fatbrain.com at: http://www.fatbrain.com/documentation/sun...

  • Page 12: Sun Welcomes Your Comments

    Sun is interested in improving its documentation and welcomes your comments and suggestions. You can email your comments to Sun at: docfeedback@sun.com Please include the part number (816-0445-10) of your document in the subject line of your email. Cluster Platform 4500/3 User’s Guide • July 2001...

  • Page 13: Introduction

    C H A P T E R Introduction This manual describes how to customize your Cluster Platform 4500/3 system. It is intended for the Solaris System Administrator who is familiar with the Solaris™ operating environment, Solstice DiskSuite™ software, and Sun Cluster software. For specific information about configuring disksets, disk volumes, file systems, and data services, refer to the Sun Cluster 3.0 documentation.

  • Page 14: Netscape Navigator Browser

    The man command displays documentation about individual commands and files in the Solaris operating environment and other software products in the Cluster Platform 4500/3. If the directory that contains man page files for a product is not automatically accessed by the man command, you can add that location to the MANPATH environmental variable included in the .profile file (when using...

  • Page 15: Solaris Documentation

    Solaris Documentation AnswerBook™ documentation about the Solaris 8 10/00 Operating Environment is included on the Solaris™ 8 Documentation CD. The following document collections are included: The /opt/answerbooks/english/solaris_8 directory contains the following document collections: SUNWaadm—Solaris 8 System Administrator Collection SUNWabsdk—Solaris 8 Software Developer Collection SUNWabe—Solaris 8 User Collection SUNWaman—Solaris 8 Reference Manual Collection SUNWdtad—Solaris 8 Common Desktop Environment Developer Collection...
  • Page 16 Cluster Platform 4500/3 User’s Guide • July 2001...

  • Page 17: The Cluster Platform 4500/3 System

    C H A P T E R The Cluster Platform 4500/3 System The Cluster Platform 4500/3 system provides self-sustained platforms, integrated through the Sun Cluster technology, to support highly available applications. This two-node cluster system with shared, mirrored FC-AL storage can be used to ®...

  • Page 18: Your Integrated System

    Task Overview To integrate your Cluster Platform 4500/3 into a production environment, you must: 1. Provide a name, IP address, and root password for the management server. 2. Provide a name and IP address for the terminal concentrator.

  • Page 19: Figure 2-1 Ethernet Address On The Disk Array Pull Tab

    Ethernet address. (See Figure 2-4 for the placement of each cluster node.) shows the location of the Ethernet address for the disk array. TABLE 2-1 Ethernet Address on the Disk Array Pull Tab FIGURE 2-1 Chapter 2 The Cluster Platform 4500/3 System...

  • Page 20: Hardware Components

    Sun StorEdge T3 array No. 2 (node 2) Hardware Components Your Cluster Platform 4500/3 shipment includes the following hardware components (see Consolidation rack: One Sun StorEdge Expansion Cabinet which includes power sequencers, front and rear door options, and a fan assembly Management server: One Sun Netra T1 AC200 system configured with one 500 MHz UltraSPARC II CPU, 512 Mbytes of memory and two 18.2-Gbyte boot disks...

  • Page 21: Connectivity

    Storage access: Access to disk arrays is achieved through proper configuration of the FC-AL from each node. Administration networks: Sun StorEdge™ Component Manager 2.1, included with your Cluster Platform 4500/3, is used to administer the disk arrays. Network Administration The administration network provides access to the Ethernet hub.

  • Page 22: Software Components

    Cluster Platforms I/O Board Placement FIGURE 2-2 Software Components The Cluster Platform 4500/3 software packages include the following: Solaris 8 10/00 operating environment Sun Cluster 3.0 software with patches, and Sun Cluster 3.0 installation CDs Solstice DiskSuite 4.2.1 ® UNIX File System (UFS) Sun StorEdge Component Manager 2.1...
  • Page 23 Note – See “Ethernet IP Address Worksheet” on page 8 to specify the appropriate information for your network environment. Chapter 2 The Cluster Platform 4500/3 System...

  • Page 24: Figure 2-3 Cluster Platform Interconnections And Nafo

    Cluster node 1 8:0:20:d1:e6:f6 129.153.47.81 Cluster Platform Interconnections and NAFO FIGURE 2-3 Cluster Platform 4500/3 User’s Guide • July 2001 Production Network T3 No. 1 data eri0 sc3sconf1-T3 1 10BT FC-AL hub 0 0 1 2 3 4 5 6...

  • Page 25: Cluster Platform Component Location

    Cluster Platform Component Location shows how the Cluster Platform 4500/3 is arranged in the expansion FIGURE 2-4 cabinet. lists the rack components and the quantities required. FIGURE 2-2 Note – The rack arrangement complies with weight distribution, cooling, EMI, and power requirements.

  • Page 26: Figure 2-4 Cluster Platform Rack Placement

    System No. 2 (cluster node 2) System No. 1 (cluster node 1) Air baffle Disk array No. 2 (mirror) Disk array No. 1 (data) Terminal concentrator (not shown) Cluster Platform Rack Placement FIGURE 2-4 Cluster Platform 4500/3 User’s Guide • July 2001...

  • Page 27: Power And Heating Requirements

    If the cabinet is installed on a raised floor, cool conditioned air should be directed to the bottom of each rack through perforated panels. The 72-inch cabinet in the Cluster Platform 4500/3 consumes power and dissipates heat, as shown in...

  • Page 28: Cabling The System

    Cabling the System The Cluster Platform 4500/3 is shipped with the servers, hubs, and each of the arrays already connected in the cabinet. You should not need to cable the system. Refer to FIGURE 2-4 This section describes how the Cluster Platform 4500/3 components are cabled when shipped from the factory.

  • Page 29: Figure 2-5 Cluster Platform Internal Cabling

    SCSI cable DB-25/RF-45 serial cable Null Ethernet cable F100 cable Serial cable RF-45 Ethernet cable Cluster Platform Internal Cabling FIGURE 2-5 Chapter 2 The Cluster Platform 4500/3 System...

  • Page 30: Customizing The Cluster Platform 4500/3

    Customizing the Cluster Platform 4500/3 When the Cluster Platform 4500/3 is shipped from the factory, the Netra 200 AC is preloaded with all of the necessary software to install the cluster nodes with the Solaris operating environment and Sun Cluster 3.0 software.
  • Page 31 From a terminal window on the Sun workstation, enter the following command: # /usr/bin/tip hardwire Note – If the port is busy, refer to “Troubleshooting the Cluster Platform 4500/3 Installation” on page 69 in Appendix D. 3. Configure the terminal concentrator device: Power on the terminal concentrator.
  • Page 32 5. Copy the Ethernet address entered above for the terminal concentrator, and add it to “Ethernet IP Address Worksheet” on page 8 for later reference when configuring the cluster. Cluster Platform 4500/3 User’s Guide • July 2001 command to verify the network configuration: addr...
  • Page 33 64 bytes from scotch (148.212.87.62): icmp_seq=2. time=0. ms 64 bytes from scotch (148.212.87.62): icmp_seq=3. time=0. ms Note – The Sun workstation must be connected to the same subnet to which the terminal concentrator was configured. (tilde and period). Power-cycle the Chapter 2 The Cluster Platform 4500/3 System...
  • Page 34 Note – Change the default terminal concentrator password to avoid unnecessary security exposure. The terminal concentrator password matches the IP address of the terminal concentrator. Cluster Platform 4500/3 User’s Guide • July 2001 Copyright 1991 Xylogics, Inc.
  • Page 35 Note – Make sure all network interfaces for node 1 and node 2 are attached to the production network. (See Figure 2-3 on page 12 for connection details.) Ctrl-X: exit Ctrl-F: page down usr/sbin/ping -I 5 148.212.87.62 Chapter 2 The Cluster Platform 4500/3 System Ctrl-B:...
  • Page 36 Boot device: /pci@1f,0/pci@1/scsi@8/disk@0,0 SunOS Release 5.8 Version Generic_108528-06 64-bit Copyright 1983-2000 Sun Microsystems, Inc. Hostname: unknown metainit: unknown: there are no existing databases Configuring /dev and /devices Cluster Platform 4500/3 User’s Guide • July 2001 <ctrl]> File and args: All rights reserved.
  • Page 37 0. English (C - 7-bit ASCII) 1. Canada-English (ISO8859-1) 2. Thai 3. U.S.A. (en_US.ISO8859-1) 4. U.S.A. (en_US.ISO8859-15) 5. Go Back to Previous Screen Please make a choice (0 - 5), or press h or ? for help: 0 Chapter 2 The Cluster Platform 4500/3 System...
  • Page 38 Specify No if the system is connected to a network/communication card that is not supported on the Solaris CD, and follow the instructions listed under Help. Networked --------- [X] Yes [ ] No <esc>2 Cluster Platform 4500/3 User’s Guide • July 2001...
  • Page 39 > To make a selection, use the arrow keys to highlight the option press Return to mark it [X]. Primary network interface ------------------------- [X] eri0 [ ] eri1 <esc>2 Choose Yes if DHCP Chapter 2 The Cluster Platform 4500/3 System...
  • Page 40 It must be unique and follow your site’s address conventions, or a system/network failure could result. IP addresses contain four sets of numbers separated by periods (for example 129.200.9.1). IP address: 192.212.87.38 <esc>2 Cluster Platform 4500/3 User’s Guide • July 2001...
  • Page 41 > Confirm the following information. to change any information, press F4. Primary network interface: eri0 IP address: 192.212.87.38 Enable IPv6: No <esc>2 If it is correct, press F2; Networked: Yes Use DHCP: No Host name: sc3sconf1-ms Chapter 2 The Cluster Platform 4500/3 System...
  • Page 42 <esc>2 23. Select and confirm a naming service. Consult your network administrator to specify a naming service. No naming services are selected for the following example. Cluster Platform 4500/3 User’s Guide • July 2001 If it is correct, press F2;...
  • Page 43 > To make a selection, use the arrow keys to highlight the option and press Return to mark it [X]. System part of a subnet ----------------------- [X] Yes [ ] No <esc>2 If it is correct, press F2; Chapter 2 The Cluster Platform 4500/3 System Select...
  • Page 44 (for example 255.255.255.0). Netmask: 192.255.255.0 <esc>2 Cluster Platform 4500/3 User’s Guide • July 2001 A netmask must contain four...
  • Page 45 [ ] Eastern [ ] Central [ ] Mountain [X] Pacific [ ] East-Indiana [ ] Arizona [ ] Michigan [ ] Samoa [ ] Alaska [ ] Aleutian [ ] Hawaii <esc>2 Chapter 2 The Cluster Platform 4500/3 System...
  • Page 46 After the system reboots, the cluster environment customization starts. After the system customization is completed, the management server installs the Solstice DiskSuite software and configures itself as an installation server for the cluster nodes. Cluster Platform 4500/3 User’s Guide • July 2001 (4 digits) : 2000 (1-12) : 12...
  • Page 47 Enter the First T3’s IP Address... 192.145.23.93 Enter the First T3’s Ethernet Address... 00:12:e2:00:4c:4b Enter the Second T3’s Name... t3-mirror Enter the Second T3’s IP Address... 192.145.23.94 Enter the Second T3’s Ethernet Address... 00:10:f2:00:3e:4f Chapter 2 The Cluster Platform 4500/3 System...
  • Page 48 13) Second T3’s IP Address... 192.145.23.94 13) Second T3’s Ethernet Address... 00:10:f2:00:3e:4f 99) quit update mode... Are all variables correctly set y/n? y Cluster Platform 4500/3 User’s Guide • July 2001 Variable Setting if all of the variables are correct.
  • Page 49 Note – The error messages are expected as part of the standard configuration customization process. Do not attempt to reconfigure the devices. The error messages will not return after reboot. File and args: All rights reserved. Please wait. Chapter 2 The Cluster Platform 4500/3 System...

  • Page 50: Starting The Cluster Console

    Last login: Thu Jan 4 15:51:14 sc3sconf1-ms login: ROOT LOGIN /dev/console Sun Microsystems Inc. Check the “Cluster Platform 4500/3 User’s Guide” (referred to in the software as "Sun Cluster Standard Configuration User’s Guide, Sun Enterprise E4500 Server and StorEdge T3 Array") for instructions on how to set up the terminal concentrator.

  • Page 51: Figure 2-6 Cluster Control Panel Window

    PROM (OBP) prompt, position the cursor in the Cluster Console window, and enter the <ctrl> character sequence. This character forces access to the telnet prompt. Enter the command, as follows: Stop-A telnet> send brk ok> FIGURE 2-8 Chapter 2 The Cluster Platform 4500/3 System shows...

  • Page 52: Figure 2-7 Cluster Nodes Console Windows

    ). To ungroup the Cluster Console window from the FIGURE 2-7 cluster node console windows, select Options from the Hosts menu ( ) and FIGURE 2-8 deselect the Group Term Windows checkbox. Cluster Platform 4500/3 User’s Guide • July 2001...

  • Page 53: Installing The Software Stack On Both Cluster Nodes

    2. Log into each cluster node as a superuser (password is abc) and change the default password to a secure password choice: # passwd passwd: Changing password for root New password: secure-password-choice Re-enter new password: secure-password-choice Chapter 2 The Cluster Platform 4500/3 System...

  • Page 54: Cluster Platform 4500/3 Recovery

    Cluster Platform 4500/3 Recovery The recovery CDs enable you to replace the factory-installed Cluster Platform 4500/3 software environment on the management server in the event of a system disk failure. Caution – Initiate a recovery only at the direction of technical support.

  • Page 55: Recovery Cd-Roms

    Contains a bootable copy of the Solaris 8 10/00 Operating Environment, configured to execute recovery software CD1: Cluster Platform 4500/3 Recovery Operating System CD 2 Installs software for the Solaris operating environment, Solstice DiskSuite, Sun Cluster 3.0, and recommended patches.
  • Page 56 Note – Messages which display when a suitable disk slice is found may vary, depending upon the state of your disks. Disregard any messages and select any suitable disk slice; the mini-root is only used during system boot. Cluster Platform 4500/3 User’s Guide • July 2001 command, as Stop-A...
  • Page 57 5. Select a CD-ROM drive from the menu. Once the Cluster Platform 4500/3 recovery utility has placed a copy of the Solaris operating environment onto a suitable disk slice, the system reboots. You are prompted to specify the CD-ROM drive. Completing this process takes approximately 15 minutes.

  • Page 58: Completing The Recovery Process

    Once the management server recovery software is loaded, you must configure the system to match your environment. Refer to “Customizing the Cluster Platform 4500/3” on page 18 to customize your cluster environment. If the recovery process involves the replacement of cluster nodes, refer to “Ethernet IP Address Worksheet”...

  • Page 59: Laptop Settings To Access Monitor Mode

    A P P E N D I X Laptop Settings to Access Monitor Mode This appendix provides the settings you must use to access monitor mode using a laptop computer. These are different from those used by a Sun workstation. To Access the Terminal Concentrator from a Laptop 1.
  • Page 60 7. Click OK to open the StandardConfig—HyperTerminal application window and to support monitor mode. 8. In the StandardConfig—HyperTerminal window, select File the StandardConfig Properties window. Cluster Platform 4500/3 User’s Guide • July 2001 Customer-supplied DB-9/DB-25 female/female adapter DB-25/RJ-45 (Part No. 5121A)
  • Page 61 9. In the StandardConfig Properties window, click the Settings option, and select VT100 for the Emulation option. At this point, the HyperTerminal window provides monitor mode access to the terminal concentrator. Note – To set up the terminal concentrator, see “Customizing the Terminal Concentrator”...
  • Page 62 Cluster Platform 4500/3 User’s Guide • July 2001...

  • Page 63: Console Output For The Automatic Software Install On The Cluster Nodes

    Can’t open input device. Keyboard not present. 8-slot Sun Enterprise E4500/E5500, No Keyboard OpenBoot 3.2.28, 8192 MB memory installed, Serial #15070773. Copyright 2000 Sun Microsystems, Inc. Ethernet address 8:0:20:e5:f6:35, Host ID: 80e5f635. Rebooting with command: boot net - install Boot device: /sbus@3,0/SUNW,hme@3,8c00000 install SunOS Release 5.8 Version Generic_108528-03 64-bit...
  • Page 64 Searching for JumpStart directory... Using rules.ok from 192.153.47.38:/SOFTWARE/Solaris8_10-00. Checking rules.ok file... Using profile: Profiles/sc3sconf1-n0.profile Using finish script: Drivers/sc3sconf1-n0.driver Executing JumpStart preinstall phase... Searching for SolStart directory... Checking rules.ok file... Using begin script: install_begin Cluster Platform 4500/3 User’s Guide • July 2001...
  • Page 65 Solaris Software, Solstice DiskSuite, and Patches CODE EXAMPLE B-1 Using finish script: patch_finish Executing SolStart preinstall phase... Executing begin script "install_begin"... Begin script install_begin execution completed. Processing default locales Processing profile - Selecting cluster (SUNWCXall) - Deselecting package (SUNWpmowm) - Deselecting package (SUNWpmowu) - Deselecting package (SUNWpmr) - Deselecting package (SUNWpmu) - Deselecting package (SUNWpmux)
  • Page 66 - Installing boot blocks (c0t2d0s3) Installation log location - /a/var/sadm/system/logs/install_log (before reboot) - /var/sadm/system/logs/install_log (after reboot) Installation complete Executing SolStart postinstall phase... Executing finish script "patch_finish"... Cluster Platform 4500/3 User’s Guide • July 2001 Solaris Software, Solstice DiskSuite, and Patches...
  • Page 67 Solaris Software, Solstice DiskSuite, and Patches CODE EXAMPLE B-1 Finish script patch_finish execution completed. Executing JumpStart postinstall phase... Executing finish script "Drivers/sc3sconf1-n0.driver"... ROOT_DIR is set to /a. FINISH_DIR is set to /tmp/install_config/Finish. FILES_DIR is set to /tmp/install_config/Files. Management Server "MStest01" (192.153.47.38) at 8:0:20:c2:1b:3c Variable Settings (Final) -------------------------------------------...
  • Page 68 WARNING: Failed to register application "DiskSuite Tool" with solstice launcher. Installation of <SUNWmdg> was successful. =========================== Installing Package: SUNWmdja =========================== Processing package instance <SUNWmdja> from </a/tmp/jumpstart-packages> Solstice DiskSuite Japanese localization (sparc) 4.2.1,REV=1999.12.09.15.37 Cluster Platform 4500/3 User’s Guide • July 2001...
  • Page 69 Solaris Software, Solstice DiskSuite, and Patches CODE EXAMPLE B-1 Copyright 2000 Sun Microsystems, Inc. All rights reserved. ## Executing checkinstall script. Using </a> as the package base directory. ## Processing package information. ## Processing system information. 8 package pathnames are already properly installed.
  • Page 70 Setting default IPv4 interface for multicast: add net 224.0/4: gateway sc3sconf1-n1 syslog service starting. Print services started. Feb 27 12:02:23 sc3sconf1-n0 sendmail[596]: My unqualified host name (sc3sconf1-n1) unknown; sleeping for retry volume management starting. =========================== Setting up Meta DB’s =========================== Cluster Platform 4500/3 User’s Guide • July 2001...
  • Page 71 Solstice DiskSuite Configuration CODE EXAMPLE B-2 ============================================================ PLEASE WAIT: Setting up system for root and swap mirroring. System will reboot after setup! ============================================================ hsp001: Hotspare pool is setup hsp002: Hotspare pool is setup d2: Concat/Stripe is setup d3: Concat/Stripe is setup d6: Concat/Stripe is setup d7: Concat/Stripe is setup d11: Concat/Stripe is setup...
  • Page 72 Patch number 110648-02 has been successfully installed. See /var/sadm/patch/110648-02/log for details Patch packages installed: SUNWscdev SUNWscr SUNWscu Updating the /etc/inet/ntp.conf file... ============================================================ System will reboot now! ============================================================ syncing file systems... done Cluster Platform 4500/3 User’s Guide • July 2001 Solstice DiskSuite Configuration...
  • Page 73 Can’t open input device. Keyboard not present. 8-slot Sun Enterprise E4500/E5500, No Keyboard OpenBoot 3.2.28, 8192 MB memory installed, Serial #15070773. Copyright 2000 Sun Microsystems, Inc. Metadevice Mirror Attachment and Cluster Node Booting CODE EXAMPLE B-3 removing /etc/rc2.d/S94n0-sds-mirror script... Apr 20 14:30:50 node1 reboot: rebooted by root Apr 20 14:30:50 node1 syslogd: going down on signal 15 syncing file systems...
  • Page 74 Apr 20 14:36:56 sc3sconf1-n1 cl_runtime: NOTICE: clcomm: Adapter qfe0 constructed Apr 20 14:36:56 sc3sconf1-n1 cl_runtime: NOTICE: clcomm: Path sc3sconf1-n10:qfe0 - tn1:qfe0 being constructed Apr 20 14:36:57 sc3sconf1-n1 cl_runtime: NOTICE: clcomm: Adapter qfe4 Cluster Platform 4500/3 User’s Guide • July 2001...
  • Page 75 Metadevice Mirror Attachment and Cluster Node Booting CODE EXAMPLE B-3 constructed Apr 20 14:36:57 sc3sconf1-n1 cl_runtime: NOTICE: clcomm: Path sc3sconf1-n1:qfe4 - tn1:qfe4 being constructed Apr 20 14:37:38 sc3sconf1-n1 qfe: SUNW,qfe0: 100 Mbps full duplex link up - internal transceiver Apr 20 14:37:38 sc3sconf1-n1 qfe: SUNW,qfe4: 100 Mbps full duplex link up - internal transceiver...
  • Page 76 Cluster Platform 4500/3 User’s Guide • July 2001...

  • Page 77: Connections Within The Cluster Platform 4500/3

    Platform 4500/3 This appendix describes the preinstalled arrangement of some cables within the Cluster Platform 4500/3. This information is provided to assist in restoring the hardware to its original configuration after service. Cables that connect the servers to their storage components are run between the I/O system boards on the Sun Enterprise 4500 system cluster nodes to the FC-AL hubs or disk arrays.

  • Page 78: Table C-2 Disk Array To Hub Connections

    No. 2 Management Server Connections TABLE C-4 From Device Management server Management server Cluster Platform 4500/3 User’s Guide • July 2001 From Location To Device F100 No. 1 FC-AL hub No. 1 F100 No. 2 FC-AL hub No. 2 10BASE-T...
  • Page 79 To Device To Location hme0 Production Network hme1 NAFO Failover hme0 Production Network hme1 NAFO Failover Connections Within the Cluster Platform 4500/3 Cable Length/Type Serial cable RJ-45/DB-25 serial RJ-45/DB-25 serial Cable Length/Type Null Ethernet Null Ethernet Null Ethernet Null Ethernet...

  • Page 80: Table C-8 Ethernet Hub Connections

    Ethernet Hub Connections TABLE C-8 From Device Ethernet hub Ethernet hub Ethernet hub Ethernet hub Cluster Platform 4500/3 User’s Guide • July 2001 From Location To Device Port No. 0 Disk array No. 1 (node 1) Port No. 1 Disk array No. 2 (node 2) Port No.

  • Page 81: Troubleshooting The Cluster Platform 4500/3 Installation

    A P P E N D I X Troubleshooting the Cluster Platform 4500/3 Installation This appendix provides steps for troubleshooting the Cluster Platform 4500/3 installation. Configuring the Terminal Concentrator To connect to an alternate port for communication with the terminal concentrator,...
  • Page 82 Cluster Platform 4500/3 User’s Guide • July 2001...
