R e l a t i v e H u m i d i t y C a l i b r a t i o n K i t

F o r c a l i b r a t i n g t h e f o l l o w i n g K e s t r e l M e t e r s

Kestrel 5 Series, 4 Series and Kestrel 3000-3500 Series

(Kestrel DROPs currently cannot be recalibrated)

Kestrelinstruments.com

800.784.4221

Need help?

Do you have a question about the 5 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Kestrel 5 Series

Page 1 F o r c a l i b r a t i n g t h e f o l l o w i n g K e s t r e l M e t e r s Kestrel 5 Series, 4 Series and Kestrel 3000-3500 Series (Kestrel DROPs currently cannot be recalibrated) Kestrelinstruments.com...
Page 2 ● ● ● ● ● ©2019 Nielsen Kellerman Co. Kestrel, the Kestrel bird, NK, Nielsen-Kellerman and the NK logo are registered trademarks of the Nielsen-Kellerman company. Please refer to Standard Practice for maintaining Constant Relative Humidity by Means of Aqueous Solutions ASTM Designation E104-85 (reapproved 1996) for additional information.
Page 3 The Kestrel should be recalibrated if the RH sensor has shown drift in its RH measurement. The Kestrel RH sensor is speci ed to develop less than 2% drift over 24 months. You may return your Kestrel to NK for Factory Recalibration of the relative humidity and related measurements.
Page 4 Please familiarize yourself with the new process. Note: Only place one Kestrel unit in each calibration jar at a time. Attempting to calibrate more than one unit in each jar at the same time will reduce RH calibration accuracy. If you are attempting to calibrate multiple units the process can be overlapped so that while the rst Kestrel unit is equilibrating in the second jar, the second Kestrel unit can begin equilibrating in the rst jar.
Page 5 Preparing the Calibration Salt Solutions » For your rst use only, you will need to add water to the provided salts to prepare the saturated salt solutions for the calibration chambers. » Note that it is important not to cross-contaminate either salt solution with the other salt. For this reason, every item is color-coded.
Page 6 12. Only calibrate one Kestrel unit in the jar at a time. Attempting to calibrate more than one unit at a time will reduce RH calibration accuracy.
Page 7 Setting up the Relative Humidity Recalibration Routine for Kestrel 5 Series units. 1. Check the battery status on the start-up screen. If the battery indicator does not show near full battery life remaining, replace the battery with a new Lithium AA battery.
Page 8 After the 24 hour Low Calibration period, remove the jar marked 32.8% (Low) and ensure the calibration timer has nished counting down. When the timer is complete the bottom line will say “Start High”. Remove the Kestrel from the jar marked 32.8% (Low) and wipe o any salt or water that may be on the unit.
Page 9 Setting up the Relative Humidity Recalibration Routine for Kestrel 3000-3500 Series units. Example Recalibration Schedule Day 1 Day 2 Day 3 8:30am 9:00am 9:00am 10:00am 10:00am 11:00am Start 1st jar Start 2nd jar Set up Begin Begin Complete calibration calibration...
Page 10 Place the Kestrel in the 1st jar with the impeller facing down. (For three button Kestrel 3000-3500 Series units, the 1st jar will be the 32.8% (Low) RH jar. For Two-Button 3000 units the 1st jar will be the 74.0% (High) jar.) Ensure the lanyard is hanging on the front side of the unit opposite from the RH sensor hole...
Page 11 C2. Return the Kestrel to the rst jar and after ensuring the lid is closed tightly, return the jars to the zipper case and if using, return the zipper case to the insulated cooler. Make a note of what time the calibration routine will end.
Page 12 10. Move the Kestrel to the 2nd salt jar and make sure that the jar lid is closed tightly. (For three button Kestrel 3000-3500 Series units, the 2nd jar will be the 74.0% (High) RH jar. For Two-Button 3000 units the 2nd jar will be the 32.8% (Low) jar.) Return the jars to the zipper pouch and if using, into the insulated...
Page 13 Setting up the Relative Humidity Recalibration Routine for Kestrel 4 Series units. Example Recalibration Schedule Day 1 Day 2 Day 3 8:30am 9:00am 9:00am 10:00am 10:00am 11:00am Start 1st jar Start 2nd jar Set up Begin Begin Complete calibration calibration...
Page 14 Return the Kestrel to the rst jar and after ensuring the lid is closed tightly, return the jars to the zipper case and if using, return the zipper case to the insulated cooler. Make a note of what time the calibration routine will end.
Page 15 11. Return the Kestrel to the second jar and after ensuring the lid is closed tightly, return the jars to the zipper case and if using, return the zipper case to the insulated cooler. Make a note of what time the calibration routine will end.
Page 16 Set your Kestrel to display Relative Humidity and go into the settings menu and turn o Auto Shutdown. Place your Kestrel in one of the two salt jars and let it sit for 24 hours inside the insulated zipper pouch.
Page 20 Kestrel® Weather and Environmental Meters are designed and manufactured in the USA NIELSEN-KELLERMAN 21 Creek Circle, Boothwyn, PA 19061 Phone: (610) 447-1555 Fax: (610) 447-1577 Web: Kestrelinstruments.com Email: info@NKhome.com Please register your Kestrel Meter at www.Kestrelinstruments.com 319024_3_19.03.05...
