Summit 42369 Installation Manual

BUILT-IN LP GAS GRILL INSTALLATION GUIDE
LOCATING YOUR GRILL
When determining a suitable location for your Summit
keeping any gas supply lines as short as possible. Never locate the Summit
enclosed area. Locate the grill and structure so there is enough room to safely evacuate the area in case of a fi re.
CLEARANCE FROM SURFACES OR STRUCTURES
WARNING: Clearance from any surface or structure is
24 inches (609.6 mm) from the back and sides of the grill.
Refer to "Typical Gas Supply Installation" before starting
installation.
WARNING: The structure, "island", countertops, and
adjacent work areas for the built-in grill installation must be
built from noncombustible materials only.
NOTE: If you have questions on what materials are considered noncombustible,
contact your local building materials supplier or fi re department.
BUILT-IN STRUCTURE CUTOUT DIMENSIONS
ALL DIMENSIONS ARE TO FINISHED SURFACES.
3
2
1
SUMMIT
PLATINUM D4 , D6
®
gas grill installation, give attention to concerns such as exposure to wind, proximity to traffi c paths, and
®
42369
®
gas grill in a garage, breezeway, shed, under an unprotected overhang, or other
Note: For a countertop treatment: Recommended 3/4 inch
(19.1 cm) overhang. Notch front edge for frame to fully
slide in.
WARNING: All countertop fi nished surfaces must be
constructed of a noncombustible material.
Built-In Cutout Dimensions
D4
1 /
1 30
1 /
2 34
3 21˝
THIS GAS APPLIANCE IS DESIGNED
FOR OUTDOOR USE ONLY.
24 inches (61 cm) Any Surface
27 inches (685.8 mm) min. for
lid clearance
Grill Frame
D6
1 /
˝ 38 ˝
4 4
1 /
˝ 34 ˝
4 4
21˝
Tolerances
1 / 1 /
+ " - ˝
4 4
1 / 1 /
+ " - ˝
4 4
1 / 1 /
+ " - ˝
4 4
42369 US 11/22/05
LP
