4358-3412E Summit
3/2/07
2:55 PM
Replacement Parts List
NOTE: If requested color is not available, similar color will be
substituted.
Part
Cost
Quantity Total Cost
Crotch Strap/Buckle $4.99 X______= $ ______________
Harness Strap . . . . .$2.00 X______= $ ______________
Seat Pad . . . . . . . .$39.99 X______= $ ______________
(Includes headrest, harness covers, and pillow)
Harness Retainer . . .$1.50 X______= $ ______________
Locking Clip . . . . . . .$2.50 X______= $ ______________
Top Anchorage
(Tether) Kit . . . . . . .$9.99 X______= $ ______________
Latch Kit . . . . . . . .$24.99 X______= $ ______________
Instructions . . . . . . .$0.00 X______= $ ______________
Merchandise Total
Shipping and handling:
Up to $25.00 . . . . . . . . . .$5.95
$25.01 to $50.00 . . . . . . .$6.95
$50.01 to $75.00 . . . . . . .$8.95
$75.01 to $100.00 . . . . . .$9.95
Sales Tax
(Indiana, California, Arkansas, and Massachusetts residents add applicable
sales tax.)
Grand Total
No shipping and handling on instructions for quantities under 6. Add $.50 for
each instruction over 6, then add applicable shipping and handling.
Fill Out For Credit Card
Visa
Card Exp. Date: ______________________________
Cardholder's Name: __________________________
Card Number: ______________________________
Signature: __________________________________
46
Page 1
$______________
$ ______________
$100.01 to $150.00 . . . . .$10.95
$150.01 to $200.00 . . . . .$11.95
$200.01 and up . . . . . . . .$13.95
Outside Continental USA $10.00
$ ____________
$ ______________
Mastercard
S S u u m m m m i i t t
D D e e l l u u x x e e H H i i g g h h b b a a c c k k B B o o o o s s t t e e r r
I I n n s s t t r r u u c c t t i i o o n n M M a a n n u u a a l l
www.djgusa.com
This child
restraint is
designed for
use by children
whose:
Weight:
22-100 pounds
(10.1-45.4 kg)
Height:
34-52 inches
(85.1-132.1 cm)
Forward-Facing
Use Only
Read all instructions
BEFORE USING
this child restraint.
KEEP INSTRUCTIONS FOR FUTURE USE.
IMPORTANT!
Failure to follow the warnings on the labels
and in the instruction manual can result in
the death or serious injury of your child.
Para recibir las instrucciones en español, llame al
1-800-544-1108 o solicitarse por escrito al dirección por arriba.
Eng. 4358-3412E
Advertisement
Table of Contents
Summary of Contents for Summit ENG. 4358-3412E
- Page 1 Card Number: ______________________________ Signature: __________________________________ Eng. 4358-3412E S S u u m m m m i i t t D D e e l l u u x x e e H H i i g g h h b b a a c c k k B B o o o o s s t t e e r r I I n n s s t t r r u u c c t t i i o o n n M M a a n n u u a a l l www.djgusa.com...
-
Page 2: Table Of Contents
4358-3412E Summit 3/2/07 2:55 PM Page 3 Before You Begin... Thank you for choosing this car seat, referred to throughout this manual as a child restraint.The DJG family is committed to creating a child restraint with the most comfort and convenience available today. -
Page 3: Warnings
4358-3412E Summit 3/2/07 2:55 PM Page 5 WARNING Failure to follow these warnings can result in the serious injury or death of your child. To help you recognize those instructions which are most critical for your child’s safety, we use this symbol... -
Page 4: General And Warm Weather Use
4358-3412E Summit 3/2/07 2:55 PM Page 7 WARNING Secure the top anchorage strap (tether) provided with this child restraint as specified in both the vehicle and this instruction manual. Do not remove any of the warning labels or other labels on the child restraint. -
Page 5: Understanding Your Vehicle
4358-3412E Summit 3/2/07 2:55 PM Page 9 Understanding Your Vehicle Your vehicle’s features may be considerably different than those pictured here. Consult your vehicle owner’s manual to help identify your vehicle’s specific features. A.Anchor Bracket For Top Anchorage Strap (Forward-Facing Only) -
Page 6: Child Restraint Parts
4358-3412E Summit 3/2/07 2:55 PM Page 11 Child Restraint Parts Pillow Harness Retainer (on select models) Harness Straps Adjustable Buckle Plate Headrest Buckle Shoulder Belt Positioning Guide Armrests Harness Covers Harness Release (on select models) Lever Front Back Harness Adjustment Strap... -
Page 7: Preparing Child Restraint To Fit Your Child
4358-3412E Summit 3/2/07 2:55 PM Page 13 Choosing Restraint and Position Your child’s height, weight and age determine how your child restraint should be placed in the vehicle and which restraint should be used. 22-40 lbs (10.1-18 kg) 34-43 in. (85.1-110 cm) - Page 8 4358-3412E Summit 3/2/07 2:55 PM Page 15 Place the child’s bottom and back flat against the child restraint.This will increase comfort and allow the harness to properly tighten. Adjust Buckle: Determine which of the three available buckle slots is both comfortable and snug.
-
Page 9: Reclining The Child Restraint
4358-3412E Summit 3/2/07 2:55 PM Page 17 Reclining the Child Restraint This child restraint has 3 positions: Upright, Semi- reclined, and fully reclined. Forward-Facing - Reclined, semi-reclined or upright. Belt-Positioning Booster - Must be fully- upright. To fully recline, pull out on handle and push top of child restraint back. -
Page 10: Removing Your Child From The Child Restraint
4358-3412E Summit 3/2/07 2:55 PM Page 19 Pull on harness adjustment strap to tighten harness snugly. NOTE: A snug strap should not allow any slack. It lies in a relatively straight line without sagging. It does not press on the child’s flesh or push the child’s body into an... -
Page 11: Locking Clip
4358-3412E Summit 3/2/07 2:55 PM Page 21 Choosing LATCH or Vehicle Belts The LATCH System LATCH means Lower Anchor bars Anchors and Tethers for CHildren. Not all vehicles manufactured before September 2002 were equipped with LATCH. The LATCH system allows... -
Page 12: Locking Clip
4358-3412E Summit 3/2/07 2:55 PM Page 23 Manual Belts Manual lap belts are common in the center rear seat and can allow the child restraint to loosen when it is tilted or jarred. After tightening the lap belt securely, tilt and push the child restraint forward and to both sides. -
Page 13: Forward-Facing Use
4358-3412E Summit 3/2/07 2:55 PM Page 25 Position locking clip about 1 in. (2.5 cm) from vehicle belt’s buckle plate. Rebuckle belt. Lap belt portion should now be tight. If not, remove locking clip and repeat all steps. Forward-Facing Use... -
Page 14: Forward-Facing Installation
4358-3412E Summit 3/2/07 2:55 PM Page 27 Forward-Facing Installation After deciding whether to use your Vehicle Belts or LATCH, be sure to read the warnings below as they pertain to both systems. When LATCH is not being used, fasten belt hooks together behind the child restraint as shown. -
Page 15: Latch
4358-3412E Summit 3/2/07 2:55 PM Page 29 With weakest hand at belt path, tilt and push the child restraint forward and back, and from side to side. If the seat belts do not loosen, your child restraint should be secure. - Page 16 4358-3412E Summit 3/2/07 2:55 PM Page 31 Fasten one LATCH belt hook to the anchor in the vehicle seat located in the vehicle seat bight. Repeat for other side of child restraint. See your vehicle owner’s manual for locations and more information.
-
Page 17: Adjusting The Top Anchorage (Tether) Strap
4358-3412E Summit 3/2/07 2:55 PM Page 33 Adjusting the Top Anchorage Strap The top anchorage strap is used for the forward-facing position only. Most vehicles made after 9/1/99 already have the anchor hardware for a top anchorage strap. Refer to your owner’s manual or call your dealer. -
Page 18: Belt-Positioning Booster Use
4358-3412E Summit 3/2/07 2:55 PM Page 35 Style 3 - To Attach Top Anchorage Strap: Put knee in child restraint and push down; attach hook to anchor in vehicle. To Adjust Top Pull loose Anchorage Strap: end to To tighten; pull on free end tighten of top anchorage strap. -
Page 19: Removal Of Harness
4358-3412E Summit 3/2/07 2:55 PM Page 37 Removal of Harness Harness must be removed for use as a Belt-Positioning Booster. From the back of the seat, unfasten harness from splitter plate. Pull harness through the slots from the front. Unthread harness from the harness retainer. -
Page 20: Belt-Positioning Booster Installation
4358-3412E Summit 3/2/07 2:55 PM Page 39 Belt-Positioning Booster Installation Child restraint must be in the full upright position. Pull out on recline handle and pull child restraint all the way up. Place booster seat against the back of the vehicle seat.Tuck the top... -
Page 21: Reinstall Harness
4358-3412E Summit 3/2/07 2:55 PM Page 41 Reinstall Harness Reinstall Harness: Fit the buckle strap down through the slot in the seat. Make sure buckle faces out. With seat reclined all the way back, reach under seat between base and shell and pull buckle clip through pad and shell. -
Page 22: Removing Seat Pad For Cleaning
4358-3412E Summit 3/2/07 2:55 PM Page 43 Removing Seat Pad for Cleaning WARNING Do not use this child restraint without the seat pad. Failure to do this can result in serious injury. From back of shell, release the elastic straps shown in red. -
Page 23: Troubleshooting
4358-3412E Summit 3/2/07 2:55 PM Page 45 From the back, use a screwdriver to press in on lip of upper harness guides and pop guides through the front. Pull cover off headrest. Hand wash with warm sudsy water, rinse clean and air dry. -
Page 24: Warranty
4358-3412E Summit 3/2/07 2:55 PM Page 47 Warranty Dorel Juvenile Group, Inc. (DJG) warrants this product to the original retail purchaser as follows: This product is warranted against defective materials or workmanship for one year from the date of original purchase.
