We congratulate you on your purchase of 3 in 1 Family Thermometer.
Our innovative thermometer enables very fast and reliable measure-
ments and with its predictive technology the thermometer offers a very
high clinical accuracy and has been designed to provide a maximum
of user-friendliness.
WARNING
WARNING
WARNING
• Cord poses a potential strangulation hazard to young
children. When not in use, store out of children's reach.
• Use of this thermometer is not intended as a substitute
for consultation with you physician.
• The thermometer is not waterproof! NEVER immerse
into liquids
CAUTION:
CAUTION:
CAUTION:
THIS PRODUCT IS NOT A TOY. ADULT SUPERVISION IS
REQUIRED. STORE AWAY FROM CHILD'S REACH.
Please read the following instructions
Keep this instruction manual
Requires 2 AAA batteries (included).
customerservice@summerinfant.com
INSTRUCTION MANUAL
3 IN 1 FAMILY
THERMOMETER
and warnings carefully.
for future reference.
For Technical Support
Call 1-800-268-6237
or E-Mail at
For use with children
from birth and up.
:
03180

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 3180 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Summer 3180

Summary of Contents for Summer 3180

  • Page 1 We congratulate you on your purchase of 3 in 1 Family Thermometer. Our innovative thermometer enables very fast and reliable measure- ments and with its predictive technology the thermometer offers a very high clinical accuracy and has been designed to provide a maximum of user-friendliness.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Your 3 in 1 Family Thermometer: operation and advantages Important safety instructions Features and Components Control displays and symbols Changing from Celsius to Fahrenheit and vice-versa Measuring the temperature How to recall 10 readings in memory mode Cleaning and storage Battery replacement Technical specifi...

  • Page 3: Operation And Advantages

    • Do not use the thermometer if there are signs of damage on the probe tips or the thermometer itself. If damaged, do not attempt to repair the thermometer! Please contact Summer Infant’s Consumer Relations Department. • This 3 in 1 Family Thermometer consists of high-quality precision parts.

  • Page 4: Features And Components

    FEATURES AND COMPONENTS Front View Front View Screen Power Memory Oral Oral Rectal Rectal Battery Cover Probe Tray Side View Probe Handle Main Unit...

  • Page 5: Control Displays And Symbols

    CONTROL DISPLAYS AND SYMBOLS LCD Display Display Meaning All segments displayed All segments displayed Recall of last reading Recall of last reading Probe detection Probe detection Ready-for-measurement Ready-for-measurement Completion of Completion of a measurement a measurement Completion of a Completion of a measurement by measurement by regular mode...

  • Page 6: Changing From Celsius To Fahrenheit And Vice-Versa

    CONTROL DISPLAYS AND SYMBOLS IMPORTANT: The thermometer is not waterproof. CHANGING FROM CELCIUS TO FARENHEIT AND VICE VERSA The 3 in 1 Family Thermometer can display temperature measurements in either Fahrenheit or Celsius. To switch the scale from °C to °F or vise versa, press the O/I button for more than 3 seconds, and the unit is changed from °C to °F, then the device enters to measuring mode automatically.
  • Page 7 MEASURING THE TEMPERATURE (CONT.) 1. Connect the right probe for the measuring site you would like to take the temperature of before turning on the device by connecting probe to probe handle. 2. Turn on the device and it automatically displays all segments, last reading and check circuit before it is ready for measurement 3.

  • Page 8: Battery Warning

    MEASURING THE TEMPERATURE (CONT.) 5. For rectum measurement When correctly used your thermometer is able to accurately measure the temperature in the Rectal in approximately 5 seconds. a. Move the two cheeks of the buttocks somewhat apart with one hand and carefully introduce the measuring tip not more than 1.5cm (less for babies and small children) in the rectum.

  • Page 9: How To Recall 10 Readings In Memory Mode

    HOW TO RECALL 10 READINGS IN MEMORY MODE The 3 in 1 Family Thermometer can recall the last 10 readings. To recall please follow the sequence. Operation Sequence Turn unit off and push Turn unit off and push memory key. The reading, memory key.

  • Page 10: Battery Replacement

    BATTERY REPLACEMENT The 3 in 1 Family Thermometer is supplied with two AAA batteries. Replace with new batteries when the low battery symbol appears on the LCD display. Remove the battery cover by depressing tab and opening. Remove old batteries and replace with new ones.
  • Page 11 TECHNICAL SPECIFICATIONS (CONT.) Features Beeper function Beeper function Memory function Memory function Auto Power-Off function Auto Power-Off function Out-of-range indication Out-of-range indication Low battery indication Low battery indication Operating temperature Operating temperature Storage temperature Storage temperature Self-test function Self-test function Reference to standards Reference to standards Please observe the applicable disposal regulations to dispose of the...

  • Page 12: Warranty

    All other damage claims excluded. A warranty claim must be submitted within the warranty period. We at Summer Infant stand behind all of our products. If you are not completely satisfi ed or have any questions, please contact our Customer Service Department at 1-800-268-6237 or e-mail us at customerservice@summerinfant.com.
