Summer 7260 Installation Manual

W OO D GATE EX TEN SION FRAME

Contents:

One Extension Frame
Step 1: To use with extension frame assemble as shown in Figure A.
Step 2: Screw the tension knobs down the tension bolts until they
contact the pads. Insert 4 tension bolts into holes on outside and slide
inward towards frame as far as possible.
Note: Do not use more than 3 total
extensions per gate. Do not use
more than 2 extensions per side.
Two Extension Pins
Long end of
Extension Pin
Gate
Frame
Figure A
Extension
Frame
Tension
Bolt
Pad
Tension
Knob
