Robin America EX13 Parts Manual

Engine for coleman

Hide thumbs Also See for EX13:

Service manual (89 pages)

Parts manual (42 pages)

Table Of Contents

Quick Links

Download this manual See also: Service Manual, Parts Manual

PARTS

MANUAL

Models

EX130D52090

ENGINE

for

Coleman

PUB-EP

Rev. 11/06

Table of Contents

Need help?

Do you have a question about the EX13 and is the answer not in the manual?

Questions and answers

Summary of Contents for Robin America EX13

Page 1 PARTS MANUAL Models EX130D52090 ENGINE Coleman PUB-EP Rev. 11/06...
Page 2 940 Lively Blvd. • Wood Dale, IL 60191 • Phone: 630-350-8200 • Fax: 630-350-8212 e-mail: sales@robinamerica.com • www.robinamerica.com © Copyright 2006 Robin America, Inc. EX130D52090 - 2 - 11-06...
Page 3: How To Use This Manual
HOW TO USE THIS MANUAL Robin engines are identiﬁ ed by MODEL, SPECIFICATION, and CODE NUMBER. For each model there may be many different versions called speciﬁ cations. Each speciﬁ cation will be unique in some way. The difference may only be the paint color or it may have a different type of PTO or some other signiﬁ...
Page 4: Manual Layout
MANUAL LAYOUT 1. SECTION NAME Parts are broadly classiﬁ ed according to their functions. Refer to the Group Index (table of contents) for respective section name. 2. FIG. No. The FIG. number indexes the reference and part numbers to the illustration. Figure numbers that vary only in the tens place (i.e..: 700 and 710) are in a group of the same section 3.
Page 5 Group Name CRANKCASE GROUP ... 6 CRANKSHAFT GROUP ... 8 INTAKE and EXHAUST GROUP ... 10 GOVERNOR GROUP ... 18 COOLING and STARTING GROUP ... 22 FUEL, LUBRICANT GROUP ... 26 CARBURETOR GROUP ... 28 ELECTRIC DEVICE GROUP ... 32 ACCESSORY GROUP ...
Page 6: Crankcase Group
SECTION 1 CRANKCASE GROUP FIG. 100 EX130D52090 - 6 - 10-06...
Page 7 SECTION 1 CRANKCASE GROUP REF. PART NO. DESCRIPTION 276-10101-41 CRANK CASE CP 237-14202-03 VALVE GUIDE 277-16010-01 STEM SEAL 044-02502-10 OIL SEAL 060-02800-21 BALL BEARING 277-15011-03 PIPE KNOCK 010-50802-90 STUD 010-50603-51 STUD 044-00600-20 OIL SEAL 040-11400-30 PLUG 021-11400-20 GASKET 277-11002-21 MAIN BEARING COVER C 044-02502-10 OIL SEAL 060-02501-40...
Page 8: Crankshaft Group
SECTION 2 CRANKSHAFT GROUP FIG. 200 EX130D52090 - 8 - 10-06...
Page 9 SECTION 2 CRANKSHAFT GROUP REF. PART NO. DESCRIPTION 276-21201-21 CRANKSHAFT 018-01400-20 FLANGE NUT 032-30300-10 WOODRUFF KEY 276-22501-10 CONNECTING ROD AY 276-22502-00 CONNECTING ROD AY 277-23001-03 CONNECTING ROD BOLT 276-23301-13 PISTON PIN 276-23401-H3 PISTON 276-23403-H3 PISTON 276-23404-H3 PISTON 276-23501-17 PISTON RING SET 276-23502-17 PISTON RING SET 276-23503-17...
Page 10: Intake And Exhaust Group
SECTION 3 INTAKE and EXHAUST GROUP FIG. 301 241 231 EX130D52090 - 10 - 10-06...
Page 11 SECTION 3 INTAKE and EXHAUST GROUP REF. PART NO. DESCRIPTION 278-31601-31 CAMSHAFT 277-35101-03 PIN(CAM SHAFT) 024-00600-10 O RING 277-38601-03 PIN(SPRING) 277-36401-03 RELEASE LEVER 277-36501-03 CLIP 279-38701-13 RETURN SPRING 279-33601-03 VALVE SPRING 269-33701-03 SPRING RETAINER 276-33401-H3 INTAKE VALVE 276-33501-H3 EXHAUST VALVE 132-10KA0-31 COLLET-VALVE 276-35601-11...
Page 12 SECTION 3 INTAKE and EXHAUST GROUP FIG. 317 EX130D52090 - 12 - 10-06...
Page 13 SECTION 3 INTAKE and EXHAUST GROUP REF. PART NO. DESCRIPTION 277-32622-20 AIR CLEANER AY -200 277-32632-08 BASE CP -220 277-32604-08 GASKET -250 277-32643-18 COVER CP -260 073-20044-30 LABEL(CHOKE) -520 277-32661-17 ELEMENT CP EX130D52090 QTY. REMARKS GENERATOR 14X28 ILLUST GENERATOR - 13 - FROM-TO FIG.
Page 14: Governor Group
SECTION 4 GOVERNOR GROUP FIG. 400 EX130D52090 - 14 - 10-06...
Page 15 SECTION 4 GOVERNOR GROUP REF. PART NO. DESCRIPTION 277-42301-23 GOVERNOR LEVER 277-42201-33 GOVERNOR SHAFT 279-42701-11 GOVERNOR ROD CP 277-42801-23 ROD SPRING 003-13050-00 CLIP 013-00602-40 BOLT and WASHER AY 018-60600-20 277-42510-13 GOVERNOR SPRING 277-46501-11 SPEED CONTROL CP 004-31064-00 SCREW 002-17060-00 011-00600-20 FLANGE BOLT EX130D52090 QTY.
Page 16: Cooling And Starting Group
SECTION 5 COOLING and STARTING GROUP FIG. 500 EX130D52090 - 16 - 10-06...
Page 17 SECTION 5 COOLING and STARTING GROUP REF. PART NO. DESCRIPTION 276-51202-01 BLOWER HOUSING 073-20054-70 LABEL(TRADE MARK) 011-00600-30 FLANGE BOLT 277-52711-21 BAFFLE 1, caseCP 277-52702-03 BAFFLE 2, head 277-55001-21 DUCT (CASE) CP 001-04061-60 FLANGE BOLT 011-00600-20 FLANGE BOLT 011-00600-20 FLANGE BOLT 013-00602-80 BOLT AND WASHER AY EX130D52090...
Page 18 SECTION 5 COOLING and STARTING GROUP FIG. 510 EX130D52090 - 18 - 10-06...
Page 19 SECTION 5 COOLING and STARTING GROUP REF. PART NO. DESCRIPTION 276-50301-00 RECOIL STARTER AY 226-50716-08 SPIRAL SPRING 277-50121-08 REEL 277-50110-08 STARTER ROPE 281-50300-08 STARTER KNOB 281-50325-08 RATCHET 281-50330-08 FRICTION SPRING 281-50340-08 FRICTION PLATE - 11 276-50145-08 STARTER PULLEY - 49 281-50351-08 CENTER SCREW EX130D52090...
Page 20 SECTION 6 FUEL, LUBRICATION GROUP FIG. 600 EX130D52090 - 20 - 10-06...
Page 21 SECTION 6 FUEL, LUBRICATION GROUP REF. PART NO. DESCRIPTION 276-62304-40 CARBURETOR 106-62538-08 THROTTLE VALVE 209-62351-08 SCREW 277-62527-08 CHOKE VALVE 246-62420-08 PILOT JET 277-62560-08 CHOKE LEVER 276-62530-18 THROTTLE SHAFT A 227-62451-08 BOLT 277-62500-08 NEEDLE 277-62515-08 277-62506-08 FLOAT, body 214-62450-08 PACKING 214-62540-08 CHAMBER PACKING 226-62506-08 FLOAT...
Page 22: Electric Device Group
SECTION 7 ELECTRIC DEVICE GROUP FIG. 700 EX130D52090 - 22 - 10-06...
Page 23 SECTION 7 ELECTRIC DEVICE GROUP REF. PART NO. DESCRIPTION 276-79230-21 FLYWHEEL 277-79431-01 IGNITION COIL CP 001-14062-50 BOLT AND WASHER AY 277-73101-H1 WIRE 1 CP 065-01401-50 SPARK PLUG 065-50002-70 SPARK PLUG CAP EX130D52090 QTY. REMARKS MARK BM3790 L=360 BLACK NGK BR6HS - 23 - FROM-TO FIG.
Page 24: Accessory Group
SECTION 9 ACCESSORY GROUP FIG. 900 EX130D52090 - 24 - 10-06...
Page 25 SECTION 9 ACCESSORY GROUP REF. PART NO. DESCRIPTION QTY. REMARKS FROM-TO FIG. 277-90301-H0 ACCESSORY TOOL KIT EX130D52090 - 25 - 10-06...
Page 26 PRINTED IN THE USA...
